Vokera Pinnacle User manual

Users

Instructions

THESE INSTRUCTIONS

TO BE RETAINED

BY USER

Dear Customer

Your Vokera Pinnacle boiler has been designed to meet and exceed the very latest standards in gas central heating

technology, and if cared for, will give years of reliable use and efficiency. Please therefore take some time to read

these instructions carefully.

Do’s and don’t’s

●Do ensure that the system pressure is periodically checked

●Do ensure that you know how to isolate the appliance in an emergency

●Do ensure that you are familiar with the appliance controls

●Do ensure that your installer has completed the appliance log book

●Do not attempt to remove the appliance casing or gain internal access

●Do not hang clothes etc. over the appliance

●Do not forget to have the appliance serviced annually.

Contents

Introduction Page

Dear customer 2

Do’s and don’t’s 2

Things you should know Page

1.1 Gas appliances 3

1.2 Electrical supply 3

1.3 Guarantee registration card 3

1.4 Benchmark log book 3

1.5 How does it work? 3

1.6 Dimensions 3

1.7 Clearances required 3

1.8 Frost protection system 3

Getting started Page

2.1 Before switching on 3

2.2 Appliance controls 3

2.3 Lighting the boiler 4

2.4 Adjusting the operating temperature 4

2.5 Digital display 4

2.6 Fault code table 5

How to... Page

3.1 Top-up the system pressure 6

3.2 Reset the appliance 6

3.3 Shut down the system for short periods 6

3.4 Shut down the system for long periods 6

3.5 Care for the appliance 6

What if... Page

4.1 I suspect a gas leak 6

4.2 I frequently have to top-up the system 6

4.3 The status led is red 6

4.4 The appliance is due its annual service 6

4.5 I need to call an engineer 6

Setting the Vokera Page

5.1 Mechanical clock 7

5.2 Digital clock 7

INTRODUCTION

Fig. 1

1= step button

2= increase button

3= mode button

4= digital display

5= status LED

6= reset button

7= decrease button

8= heating selector

9= clock aperture

10= pressure gauge

THINGS YOU SHOULD KNOW

1.1 GAS APPLIANCE

GasSafety(InstallationsandUse)Regulations.

Intheinterestsofyoursafetyandthatofothersit

is a legal requirement that all gas appliances are

installedandcorrectlymaintainedbyacompetent

person and in accordance with the latest

regulations.

1.2 ELECTRICAL SUPPLY

Please ensure that this appliance has been

properly connected to the electrical supply by

means of a double pole isolator or un-switched

socket, and that the correct size of fuse (3 amp)

has been fitted.

Warning: this appliance must be earthed!

1.3 GUARANTEE REGISTRATION CARD

Please take the time to fill out your guarantee

registration card. The completed warranty card

should be posted within 30 days of installation.

1.4

BENCHMARK

LOG BOOK

The

Benchmark

Log Book is supplied with your

boiler. This important document must be

completedduringtheinstallation/commissioning

of your boiler. All CORGI Registered Installers

carry a CORGI ID card and have a registration

number. Both should be recorded in your

Benchmark

Log Book. You can check your

installer by calling CORGI direct 01256 372300.

Failuretoinstallandcommissiontheappliancein

accordance with the manufacturers instructions

mayinvalidate the warranty. This does not affect

your statutory rights.

1.5 HOW DOES IT WORK?

Your Pinnacle boiler is a high efficiency central

heating boiler, which supplies heated water to

your radiators and hot water cylinder.

Thecentralheatingandhotwateriscontrolledvia

a programmer and any thermostats that your

installer may have fitted. The Pinnacle boiler

1.8 FROST PROTECTION SYSTEM

The Pinnacle is equipped with a built-in frost

protectionsystem,thisenablestheboilertoover-

ride the time controls – if switched off – and

operate the burner and/or pump, should the

temperature drop below 7 °C.

Please note that the frost protection system is

designed to protect the appliance only, should

frostprotectionberequiredforthecentralheating

system, additional controls may be required.

NOTE

The frost protection system is reliant on the

appliance having a permanent electrical supply,

and being in a non-fault condition.

GETTING STARTED

2.1 BEFORE SWITCHING ON

Before switching the appliance on please

familiarise yourself with:

●how to isolate the appliance from the gas,

water, and electricity supplies;

●how to check and top-up – if necessary – the

system water pressure;

●the time clock or programmer;

●any external thermostats and their functions;

●the appliance controls.

2.2 APPLIANCE CONTROLS (fig. 1)

Theappliancecontrolsareconcealedbehindthe

frontcover.Togainaccess tothecontrols simply

pressthecoverinwardstoreleasethecatch.The

appliance is equipped with a simple keypad that

can be used to alter the following function:

●theoutletflowtemperaturetothecentralheating

system and hot water cylinder;

The pressure gauge shows the current pressure

of the system, the gauge should be set between

1 and 1.5 bar. When the appliance is operating

the gauge may rise or fall slightly, this is quite

normal. The minimum permissible level for the

safeandefficientoperationoftheapplianceis0.5

bar. Should the pressure fall below 0.5 bar, the

boiler may lockout.

Depending on the type of controls specified by

your installer you may have an integral Vokera

timeclockfittedtotheappliance,ifso,instructions

can be found on page 8-9. If an external time

clockorprogrammerhasbeenfitted,pleaserefer

to the instructions supplied with such.

lights electronically and does not have a pilot

light. In the unlikely event of a fault developing

with your boiler, the supply of gas to the burner

will be terminated automatically.

1.6 DIMENSIONS

HEIGHT

WIDTH

DEPTH

820 mm

450 mm

355 mm

1.7 CLEARANCES REQUIRED

ABOVE

BELOW

SIDES

FRONT

150 mm

120 mm

12 mm

600 mm

2.3 LIGHTING THE BOILER

Ensurethegasandelectricalsupplyto the boiler

are turned on. The boiler will now go through a

self-test and purge sequence indicated by the

letter ‘A’ shown on the left side of the digital

display.

2.3.1 ON/OFF MODES

The heating mode can be switched ON or OFF

at the boiler irrespective of the current

programmer setting. This is indicated by the

status LED (fig. 1).

IfthestatusLEDispermanentlyilluminatedgreen,

this indicates that the heating mode is enabled

and is controlled via the programmer and any

external controls such as a room thermostat or

cylinder thermostat.

If the status LED is flashing green, the boiler will

not respond to any heat requests from the

programmer or room thermostat etc. (only frost

protection is active).

To switch the heating mode ON or OFF, press

andholdthe button(fig.2)whilstlooking at

the digital display:

●

c OF

indicates the heating mode is switched

OFF

●

c55

(oranyothernumber,indicatingthecentral

heating operating temperature), indicates the

heating mode is switched ON.

2.3.2 HEATING REQUEST

When there is a demand for heating via the

programmer,theboilerwillgothroughanignition

sequence, whereby the burner will light. When

the appliance reaches the set temperature, the

burner will go off for minimum period of

approximately 90 seconds. When the

programmer/time clock or external thermostats

heatingrequesthasbeensatisfied,theappliance

will switch off automatically.

NOTE

If the appliance fails to ignite during the ignition

sequence,itwillre-attemptignitionseveraltimes

before going to a lockout condition. Should this

occur, please allow a period of two minutes

before re-setting.

2.3.3 STATUS LED (fig. 1)

The appliance status LED indicates whether the

boilerisin OFFmode,ON modeorfaultcondition.

Status LED flashing Green

Indicates the appliance is in the OFF mode, with

electrical supply and frost protection active.

Status LED permanently Green*

IndicatestheapplianceisONmode, with heating

or hot water or both activated.

Status LED permanently Red

Thisindicatesthat theapplianceis inapermanent

fault condition and may require to be reset

(indicated by the relevant fault code displayed)

see section 2.6.

*Also illuminated during a temporary fault

condition.

Current status

Stand-by mode

Purging

Ignition

Heating mode

N/A

Fan operation

Timer delay

Pump over run

N/A

Self check

Left display shows

Fig. 2

2.4 ADJUSTINGTHEOPERATINGTEMPERATURE

Usually your installer will have adjusted the

operatingtemperaturestosuityourrequirements,

however should you wish to view or alter them,

please use the following procedure:

Operating temperature

●to view or alter the heating operating

temperature, briefly press the button;

●theoperatingtemperaturewillbeshownonthe

right side of the display (see fig. 2);

●usethe

buttontoadjusttheoperating

temperature if required;

●press the button to save the new setting.

2.5 DIGITAL DISPLAY

The digital display shows the current mode of

operation and/or status of the boiler.

Should a fault develop, the display will show a

unique fault code that can be used to help rectify

thecauseofthefault.Duringthenormaloperation,

the left side of the display indicates the current

mode of operation, whilst the right side will show

the current temperature.

Displays during normal operation

Shouldafaultoccur,theleftsideofthedisplaywill

showwhetherthefaultistemporaryorpermanent

(indicatedby‘b’or‘E’),whilsttherightsideofthe

display indicates the unique fault code.

Should a fault code be displayed, check the

fault code table to identify the cause and

course of action to take. Always wait 2-

minutes before pressing the reset button.

Reason

Ignition anomaly

No flame detected

Internal fault

Power failure

Internal fault

Appliance overheat

Internal fault

Appliance overheat

Temperature anomaly

Condensate pipe blocked

Insufficient fan speed

Fan problem

Fan speed problem

Fan problem

Temperature anomaly

Internal fault

Programming fault

Insufficient fan speed

Code

E 00

E 02

E 03

E 04

E 05

E 06

E 07

E 11

E 12

E 13

E 14

E 15

E 16

E 17

B 18

E 18

B 19

E 19

B 24

B 25

E 25

B 26

B 28

E 28

B 29

E 29

B 30

E 30

E 31

E 32

E 33

E 36

E 37

E 38

E 44

E 60

B 65

2.6 FAULT CODE TABLE

Action required
