WatchDog LT User manual

Watchdog Tracker LT
“Quick-Start” Setup Guide
Package Contains:
*Please inspect package contents and immediately notify
Elecsys Technical Support at [phone] or email
[e-mail] if there are any discrepancies.
Prior to beginning installation of this product, locate
the serial number of the device on the label attached
to the back of the enclosure and record it for use in
setting up the website.
Ser. #_________________________
Tracker LT Wiring Diagram
Basic Testpoint Monitoring: Connect the brown wire to the pipeline lead, connect the yellow wire
to the reference electrode lead.
Single Coupon (instant-off) Test Station Monitoring: Connect brown wire to the pipeline lead,
yellow wire to the reference electrode lead, and blue/white wire to the coupon lead (Tracker LT
supports single coupon connection only).
Critical Bond Monitoring: Connect the red/white lead to the “shunt +” connection, and connect the
orange/white wire to the “shunt –“ connection. If structure-to-soil connections are desired, connect
the brown wire to the critical structure lead, connect the yellow wire to the reference electrode lead,
and connect the blue/white wire to the second structure lead.
Activation and LCD Display
1. To activate the Tracker Monitor Unit, Press and hold the button on the side of the unit for approximately 4 seconds
until the “Power” LED turns on solid then release to initialize communication to the website. While initializing
communication with the cellular network, the LED will flash in a steady “On/Off” sequence. The LED will turn off
when the initial communication is completed. When communication is made with the website, the website will
send the latest configuration to the unit.
2. The Tracker unit will obtain measurements for all of the configured channels and forward the data to the website.
3. The Tracker unit will automatically go into “sleep” mode until the next measurement cycle.
Tracker Setup Guide P/N 81-0059-00 REV B
Adapter (for 3”
riser pipe
installations)
Tracker LT Monitor Unit
Includes monitor unit with connection
harness cable attached and antenna.

Watchdog Tracker LT
Website Configuration
Select & setup unit configuration
1. Locate the serial number from the label on
the back of the Watchdog Tracker unit.
2. Logon to Pipeline Watchdog
https://secure.pipelinewatchdog.com
3. Select the “My Network” menu and click
on “Search the Network”.
4. On the search page, select the “Serial
Number” option in the “Search By” field.
5. Input the serial number for your unit in the
“Criteria” field and click on “Search” to
locate the site for the unit.
6. Click “Go To Site” for the unit to access
the site page. *If the unit is not found
contact Technical Support at 913-825-
6366 or email
[e-mail] for
assistance before proceeding.
7. On the “Site Page” click “Configure Unit”
on the right side of the screen in the “Unit
Information” section.
8. Select the field application setting
appropriate for the site at which the unit
will be deployed.
9. Review and change the default channel
activation and alarm settings if necessary
to match your application.
10. Review and change the Sampling,
Logging, and Reporting Time intervals if
necessary.
11. Click on “Send Configuration” to queue
the configuration to download to the unit
when it is activated.
12. This completes the configuration selection.
If a configuration change is required at
any time, repeat these steps and send a
new configuration to the device.
Configurations are transmitted to the unit
on the next communication from the unit.
Watchdog Tracker LT
Field Installation
The Tracker LT is sent from the factory with the
connection cable routed through a cordgrip on the
back/bottom of the enclosure. There is an access
hole on the side of the unit used for routing the cord
when it is necessary to mount the unit directly post,
junction box, etc. If re-routing the cable, use the
cordgrip on the side hole, and cap the bottom hole
with the plug from the side hole.
Note: When mounting the Tracker, use the included
“riser pipe adapter” for installation on the top of the
riser pipe, or use the mounting holes on the case
flanges for mounting to a durable surface.
Mounting the Tracker to a PVC
marker pole
1. Thread the connection cable through the hole
in the base of the adapter.
2. Secure the adapter to the monitoring unit using
the supplied nuts and bolts.
3. Wire the unit according to the wiring diagram in
the next column for the appropriate field
application (test station, bond, etc.).
4. Secure the unit to the riser pipe using screws,
or bolts.
Mounting to a post, utility pole, or
junction box
1. Re-route the connection cable through the side
hole, using the cordgrip, as described above if
necessary, and plug the hole on the bottom of
the unit.
2. Secure the unit to the pole using 5/8” wood
screws with washers (for wooden posts), or
5/8” self-tapping metal screws with washers
(for metal poles and junction boxes. The
mounting hardware is not supplied with the
Tracker unit.
3. Wire the unit according to the wiring diagram in
the next column for the appropriate field
application (test station, bond, etc.).
.Watchdog Tracker LT
Connection
Connecting the Tracker to the
measurement points at the site
1. Connect to the terminals at the measurement
points using standard crimp-on ring or spade
connectors (not supplied). If connecting to
bare wire leads use in-line splices or wire nuts.
2. Connect leads from the connection harness as
appropriate for the field application using the
following wiring guide:
Wire Color Connects to:
Brown Pipe Structure
Yellow Reference Cell
Blue/Wht Protected Coupon* or
Structure 2
Wht/Red Bond Shunt+
Wht/Yellow Bond Shunt–
*If “On Potential” and “Off Potential” is to be
measured, the “Protection On/Off” switch in the
test station must be set to the “Off” position.
Illustrated wiring diagram is on the previous page.
Note: Not all wires are used in all applications.
“Tape off” any unused wires to insulate from
interference or shorting.

Mechanical Drawing, Tracker LT Enclosure with Riser Pipe Adapter –Side View
Mechanical Drawing, Tracker LT Enclosure–Top View
