Watcher Total Protection WP-7122 User manual

Dome Camera and Mounting Kit Setup Guide
Dome Camera WP-7122
Mounting Box 8161BP
Cam-Kit SC5
Te escoping Po e Mounts CE-CP6W, CE-CP6B,
CE-CP12W, or CE-CP12B
Watcherprotect.com ♦ Watcher Products ♦ 877-289-2824

Attaching WP-7122 Camera to Telescoping Pole Mounts
If a WP-7122 is going to be suspended from a ceiling using pole mount CE-CP6W, CE-CP6B,CE-CP12W, or
CE-CP12B, an adapter mounting kit must be used Using Mounting Box #8161BP and Cam-Kit SC5, a WP-
7122 dome camera can easily be attached to a pole
8161BP Mounting Box SC5 Cam-Kit
1 Remove mounting kits from packaging *See SC5 manual for attaching camera to Cam-Kit.
2 Remove bracket from the SC5 Cam-Kit
Watcherprotect.com ♦ Watcher Products ♦ 877-289-2824 2

3 The bracket comes in the locked position
4 Turn the bracket to the unlocked position
Watcherprotect.com ♦ Watcher Products ♦ 877-289-2824 3

5 Separate the bracket from the mounting kit
6 Place the 8161BP Mounting Box mounting side up
Watcherprotect.com ♦ Watcher Products ♦ 877-289-2824 4

7 Line up the bracket from SC5 with the mounting holes on the 8161BP Mounting Box Make sure the
clips are facing up
8 Secure the bracket to the mounting box using the provided screws
Watcherprotect.com ♦ Watcher Products ♦ 877-289-2824 5

9 Attach the SC5 to the 8161BP Mounting Box
10 Turn the SC5 to the lock position
11 Attach painted set screw to secure bracket
Watcherprotect.com ♦ Watcher Products ♦ 877-289-2824 6

Attaching Mounting Box to Pole
The 8161BP Mounting Box can be used with either a 1/2” pole or a 3/4” pole The mount has a nut that will
need to be removed for a thicker pole
Leave nut inserted for 1/2” poles Remove nut for 3/4” poles
Either a 1/2” or 3/4” Conduit Set-Screw Connector will be needed to attach the mount to the pole
1 Insert pole into the conduit connector
Watcherprotect.com ♦ Watcher Products ♦ 877-289-2824 7

2 Align the connector set-screw hole to the screw hole on the adjustable pole
3 Secure with conduit set-screw
4 Screw 8161BP Mounting Box to conduit connector
Watcherprotect.com ♦ Watcher Products ♦ 877-289-2824 8

5 If not already attached, attach SC5 to bottom of 8161BP and lock it into place with painted set screw
6 The mounting kit is now connected to the telescoping pole Using the existing screws, finish attaching
dome camera WP-7122 to the mount *See SC5 manual for attaching camera to Cam-Kit.
Watcherprotect.com ♦ Watcher Products ♦ 877-289-2824 9
