What is the GreyT Telescope?
The Greyt Telescope kit lets you make a linear telescoping system with little to no
effort. Up to 40 inches per stage, up to 4 stages, and more than enough power from the
Falcon 500 motor. Lock your telescope in place with either the Ratchet & Pawl or the
WCP Friction Brake. Use it for fast and secure climbs, or any other ne-controlled linear
mechanisms.
Notable features:
• Congurable, up to 4 stages.
• Easy to assemble and maintain.
• All bearings, no sliders.
• Integrated gearbox and mounting.
• Built in option for Ratchet & Pawl or WCP Friction Brake.
• Works with .060” and .125” tubing.
• No CNC machining required.
• Proper hardstops.
• Improved design, removes common failure point of internal bolts.

GreyT Telescope - User Guide
(Rev 1)
Page 6Table of Contents
wcproducts.com
Calculating Tube Lengths
The image below shows the equations for calculating the length of each tube. Each of
the moving stages are 1/4” longer than the preceding stage, and the rst stage is 1”
longer than the base tube.
Note: The max tube length for each stage (excluding the output stage) is roughly 40”�
The is due to the max safe extension of the CF Springs sold by WCP, which is 40”�

GreyT Telescope - User Guide
(Rev 1)
Page 7Table of Contents
wcproducts.com
Tube Hole Patterns
The holes in the bottom of the Base Tube and top of the Intermediate/Base Tubes
are used to pin the Top Blocks and Gearbox to their respective tubes. The holes in the
bottom of the Intermediate Tube are used to install the Bottom Blocks, Hardstops, and
CF Springs to their respective tubes. The top of the output tube will be determined by
the user. This is the recommended spot for the Telescope String to anchor to, as it is the
easiest place to do so.
Note: An easy way to anchor the string to the output tube is to drill a 3/8” hole in the
end of the tube and run a 3/8” OD shaft through for the string to be tied to.

GreyT Telescope - User Guide
(Rev 1)
Page 9Table of Contents
wcproducts.com
GreyT Bottom Block Assembly Instructions
Assembly instructions are interchangeable between the 1”, 1-1/2”, 2”, and 2-1/2” GreyT
Telescope Bottom Blocks.
Note: Blue Loctite (McMaster P/N 1004A12) is recommended on all bolts that thread
into a tapped hole�
1” Tube Bottom Block 1-1/2” Tube Bottom Block
2” Tube Bottom Block 2-1/2” Tube Bottom Block

GreyT Telescope - User Guide
(Rev 1)
Page 10Table of Contents
wcproducts.com
GreyT Bottom Block - Step 1
The size of the 1/4” ID bearings used in this step are determined by the wall thickness of
tube you are using. For 1/8” wall tube these bearings will be 1/4” ID x 1/2” OD bearings,
and for 1/16” wall tube these bearings will be 1/4” ID x 5/8” OD bearings.
There should be one Bearing Stack-Up for each slot in the GreyT Bottom Block you are
assembling; 4 for the 1” Tube Bottom Block, and 8 for the 1-1/2” to 2-1/2” Tube Bottom
Blocks.
1” Tube Bottom Block 1-1/2” to 2-1/2” Tube Bottom Block

GreyT Telescope - User Guide
(Rev 1)
Page 11Table of Contents
wcproducts.com
GreyT Top Block Assembly Instructions
Assembly instructions are interchangeable between all sizes of the GreyT Top Block. For
the purposes of this User Guide, the 2” GreyT Top Block is used as an example.
Note: Blue Loctite (McMaster P/N 1004A12) is recommended on all bolts that thread
into a tapped hole�

GreyT Telescope - User Guide
(Rev 1)
Page 12Table of Contents
wcproducts.com
GreyT Top Block - Step 1
The 1/4” ID x 1/2” OD bearings will sit in the slots in the Top Block. A ziptie can be used
to hold the 1/4” Dowel Pin in place to make assembly of the Top Block easier.
The table below shows the Dowel Pin size used for each Top Block.
Note: This step must be repeated for both halves of the GreyT Top Block you are
assembling�
Top Block Tube Size Corresponding Dowel Pin Length
1-1/2” 1-1/4”
2” 1-3/4”
2-1/2” 2-1/4”
3” 2-3/4”

GreyT Telescope - User Guide
(Rev 1)
Page 13Table of Contents
wcproducts.com
GreyT Top Block - Step 2
Slide on all components in the order shown in the image below.
The table below shows the #10-32 bolt length, #10-32 spacer length, and CF Spring
width for each size Top Block.
Note: This step will be repeated for both halves of the GreyT Top Block you are
assembling�
Top Block Tube Size Bolt Length Spacer Length CF Spring Width
1-1/2” 2” 1-1/2” 1/2”
2” 2-1/2” 2” 3/4”
2-1/2” 3” 2-1/2” 1”
3” 3-1/2” 3” 1-1/4”

GreyT Telescope - User Guide
(Rev 1)
Page 14Table of Contents
wcproducts.com
GreyT Top Block - Step 3
The assembled halves from Step 2 should bolt together. Make sure the #10-32 Spacers
are fully seated in the Top Block pockets before tightening the bolts.
Warning: The Top Block must be assembled with the CF Springs in the correct
orientation shown in Step 2, and in the image down below.

GreyT Telescope - User Guide
(Rev 1)
Page 15Table of Contents
wcproducts.com
Gearbox Assembly Instructions
Assembly instructions are interchangeable between all congurations of the GreyT
Telescope Gearbox. For the purposes of this User Guide, the 2” Base Gearbox is used as
an example.
Note: Blue Loctite (McMaster P/N 1004A12) is recommended on all bolts that thread
into a tapped hole�
Base Non-Flipped with Brake
Base Non-Flipped with Ratchet
Base Non-Flipped
Base Flipped

GreyT Telescope - User Guide
(Rev 1)
Page 16Table of Contents
wcproducts.com
Gearbox - Step 1
The Drum must be cut to the correct length for the Gearbox Conguration you are
assembling. The table down below shows the correct lengths for each base tube size.
All #10-32 bolts will thread into the 7/8” OD Roller Hubs after they have been pressed
into the Drum. The Roller Hubs should be a press t and may be pressed in with an arbor
press.
Warning: When assembling the drum, it is critical that the hexes for the roller hubs are
lined up. In order to do this it is recommended to press one Hub in, and then line up
the second Hub with the rst Hub using any long piece of 1/2” hex.
Base Tube Size Correct Drum Tube Length
1-1/2” 1-1/16”
2” 1-9/16”
2-1/2” 2-1/16”
3” 2-9/16”

GreyT Telescope - User Guide
(Rev 1)
Page 17Table of Contents
wcproducts.com
Gearbox - Step 2
These bearings will be a light press t and may be pressed in by hand or with an arbor
press. The image below shows the side the bearings must be installed from for all
congurations of the Telescope Gearbox.
If you plan on assembling the Gearbox with the Ratchet & Pawl, the hole marked in green
in the image below must be tapped to 5/16-18. Otherwise, that hole can be left alone.
Note: If you do not plan on assembling the Gearbox with either the Ratchet & Pawl or
WCP Friction Brake, you may omit the 1/2” Hex ID x 1-1/8” OD Flanged Bearing boxed
in blue in the image down below�

GreyT Telescope - User Guide
(Rev 1)
Page 18Table of Contents
wcproducts.com
Gearbox - Step 3
The 1/2” ID x 1-1/8” OD Flanged Bearing will be a light press t and may be pressed in
by hand or with an arbor press. The image below shows the side the bearing must be
installed from for all congurations of the Telescope Gearbox.
The Nutstrips used to mount the GreyT Telescope must be cut to 1-1/2” long and
assembled in the orientation shown in the image below.
Note: The Nutstrips are an optional way of mounting the GreyT Telescope� If you plan
on mounting the Telescope differently or are assembling the Gearbox in the Flipped
conguration, you may omit the Nutstrips and associated Bolts from this step.

GreyT Telescope - User Guide
(Rev 1)
Page 19Table of Contents
wcproducts.com
Gearbox - Step 4
The 1/2” ThunderHex ID x 1-1/8” OD Flanged Bearing will be a light press t and may be
pressed in by hand or with an arbor press. The image below shows the side the bearing
must be installed from for all congurations of the Telescope Gearbox.
The Nutstrips used to mount the GreyT Telescope must be cut to 1-1/2” long and
assembled in the orientation shown in the image below.
Note: Just like in the previous step, the Nutstrips in this step are completely optional�
If you plan on using a different mouting method or are assembling the Gearbox in the
Flipped conguration, you may omit the Nutstrips and associated bolts from this step.
Popular Telescope manuals by other brands

ScopeDome
ScopeDome Clamshell 3M Assembly and installation

Meade
Meade LX50 instruction manual

Meade
Meade Infinity AZ 80 instruction manual

Zhumell
Zhumell Dobsonian owner's manual

NAOJ
NAOJ Telescope kit Assemble instructions

ORION TELESCOPES & BINOCULARS
ORION TELESCOPES & BINOCULARS Skywatcher 120 EQ 9026 Instrucion manual
