OVERVIEW 3
Overview
This manual provides installation instructions for the Webster IRP
(interactive rear projection) systems:
•IRP model 4500 is self-contained system that can be moved
from room to room.
•IRP models 4100 and 5100 are wall or cabinet mounted systems
that require user-supplied projector mounting assembly. They
can be mounted to a wall, in a conference room where there is
space behind the wall, or in a customized projector cabinet.
Refer to CAD drawings that accompany this manual for
architectural specifications that are necessary for installing
these systems.
Refer to the Webster User Guide for instructions regarding software
installation, projection alignment, and operating the system.
IRP_Install_1.fm Page 3 Monday, February 3, 2003 4:19 PM

Interactive Rear Projection (IRP)
4OVERVIEW
Spatial Requirements
Spatial requirements for the Webster IRP systems depend upon the
model you are installing.
IRP 4500 SPATIAL REQUIREMENTS
IRP 4500 is a self-contained, rear projection console unit. It has a 47"
by 35" (1190 mm x 89o mm) translucent screen for viewing.
The console measures 53-5/16" wide (1354 mm) by 80-1/2" high
(2045 mm) by 30-3/4" deep (781 mm) and has large casters for easy
moving. No disassembly or folding is required to fit through standard
office doors.
46.80" (1189 mm)
SCREEN
81.12"
(2060 mm)
4.65"
(118 mm)
58.48" (1485 mm)
SCREEN
35.06"
(891 mm)
SCREEN
IRP_Install_1.fm Page 4 Monday, February 3, 2003 4:19 PM

OVERVIEW 5
To fit through smaller than standard doors, the console can be
reduced in height by partial disassembly. Refer to “Removing and
Replacing the IRP 4500 Screen”on page 32.
A computer to be used with the IRP 4500 must not be more than 10"
(254 mm) wide by 20" (508 mm) high by 20" (508 mm) deep; a tower
case is preferred.
IRP 4100 SPATIAL REQUIREMENTS
IRP 4100 is a wall or cabinet mounted rear projection screen that
includes a metal frame fitted with cabling and an IR receiver for the
electronic pen.
Screen
Power
PC
Compartment
Center Panel
Accessory
Compartment
IRP_Install_1.fm Page 5 Monday, February 3, 2003 4:19 PM

Interactive Rear Projection (IRP)
6OVERVIEW
The translucent screen measures 47" (1190 mm) by 35" (890 mm)
(58.5" [1490 mm] diagonal).
The wall mounted unit measures 53" (1350 mm) wide by 48"
(1230 mm) high by 3.5" (90 mm) deep.
IRP 5100 SPATIAL REQUIREMENTS
IRP 5100 is a wall or cabinet mounted rear projection screen that
includes a metal frame fitted with cabling and an IR receiver for the
electronic pen.
The translucent screen measures 54" (1370 mm) by 40.5" (1030 mm)
(67.5" [1710 mm] diagonal).
The wall mounted unit measures 60.5" (1540 mm) wide by 54"
(1370 mm) high by 3.5" (90 mm) deep.
Technical Description
Two laser scanners are used to collect data about the position and
movement of the electronic pen. These operations take place in real
time, with the data being interpreted and forwarded to the host
computer.
The beams from the two scanners sweep across the writing surface,
and the laser light reflected from the pen is collected on its return
path off the scanner mirror of origin and focused on the respective
photodiode. Gathering information from the two scanners at
essentially the same time allows the exact position of the pen to be
tracked by triangulation anywhere on the writing surface.
Scanners
IRP_Install_1.fm Page 6 Monday, February 3, 2003 4:19 PM

OVERVIEW 7
For the scanner data to accurately show the pen position on the
writing surface, the scanned laser beams are aligned in a pre-
determined pattern with respect to the writing surface, both in
azimuth and in pitch. Additional encoded retro-reflectors (calibration
strips) located at the corners of the writing surface provide feedback
for establishing and maintaining these alignments.
In addition to being a passive element that reflects the laser scanner
beams for positional information, the electronic pen is an active
source of information. The status of the pen tip-switch and the two
barrel button switches are transmitted via a separate IR link to a
separate IR receiver located behind the translucent writing surface.
There the signals are decoded and sent on to the Digital Signal
Processor, where this additional information is combined with the
pen position before being sent to the host computer.
IRP_Install_1.fm Page 7 Monday, February 3, 2003 4:19 PM

Interactive Rear Projection (IRP)
8 INSTALLING THE IRP 4100 AND 5100
Installing the IRP 4100 and 5100
Components
•Laser-scanned electronic writing surface
•Electronic pen (with battery)
•Wall or cabinet mounting frame including:
•Wiring harness
•Three-pronged IEC power cable, type SJT
•Serial cable for computer connection
•Calibration kit
•Two infra-red receiver modules for electronic pen
•Webster User Guide
•Webster CD-ROM
•CAD drawings including architectural specifications
Installation
IRP models 4100 and 5100 are designed for custom applications and
installations. Installation usually involves providing a wall opening
appropriate for the mounting frame, and providing a projector and
mirrors appropriate for your application.
CAD drawings included with the 4100 and 5100 systems provide
architectural specifications for the wall opening and for mounting
the system.
Refer to the Webster User Guide for information regarding using the
software and operating the system.
IRP_Install_1.fm Page 8 Monday, February 3, 2003 4:19 PM

INSTALLING THE IRP 4100 AND 5100 9
Image Adjustments
When properly installed and adjusted, the projected image should
just fill the entire screen. The edges of the image should be straight
and parallel to the edges of the screen. The distance between the
edges of the screen and the edges of the image should be no more
than 0.2”(5mm) on all sides.
To adjust the image:
1Display an image that has very clear boundaries on all four
sides. Some users may find it easier to use their computer's
Desktop screen, while others may wish to run an application
that enables them to display a full-screen, all white image (such
as a paint program, or the Webster application window with the
Current Board selected and shown in full-screen view).
2If the image on your screen is too large or too small, adjust the
projector zoom until the image nearly fills the IRP screen without
extending beyond its edges in any direction.
Refer to the documentation that came with your projector for
specific instructions on how to find and adjust the projector
zoom control.
3If the image on your screen is not in focus, adjust the projector
focus until the image is clear and sharp.
Refer to the documentation that came with your projector for
specific instructions on how to find and adjust the projector
focus control.
4If the image is not square with your screen or you cannot obtain
a clear image, contact the vendor who designed and/or installed
your custom projector installation and work with them to
complete the image adjustments.
IRP_Install_1.fm Page 9 Monday, February 3, 2003 4:19 PM

Interactive Rear Projection (IRP)
10 INSTALLING THE IRP 4500
Installing the IRP 4500
Read through this entire section regarding installation before
actually beginning work. The IRP 4500 is a combination of high
precision mechanical, optical, and electronic components. Although
the installation needs to be done carefully, it can be handled by
most people who can follow detailed directions and have
mechanical assembly skills. However, knowing exactly what to
expect and all the steps involved will save you time and reduce the
chances of making needless mistakes.
Components
The IRP 4500 system includes:
•Rear-projection console with customized projector mounting
platform and laser-scanned, electronic writing surface
•Three- pronged IEC power cable, type SJT
•Serial cable for computer connection
•Webster User Guide
•Webster CD-ROM
•Calibration kit
•Batteries (spare for electronic pen)
•Electronic pen with battery
•VGA cable
•Installation and maintenance toolkit
•(Optional) Pedestal for mounting a user supplied miniature CCD
video camera on the side of the console
•(Optional) Magnetic pen holder to hold electronic pen, spare
battery, and projector remote control
•(Optional) Keyboard/mouse tray kit
REMOVAL FROM SHIPPING PALLET
A separate document titled Information for Unpacking and
Installation comes on the outside of the IRP 4500 packaging when it
is on the shipping pallet. Refer to that document to remove the unit
and other cartons from the pallet and to place them where you will
continue with the installation.
IRP_Install_1.fm Page 10 Monday, February 3, 2003 4:19 PM

INSTALLING THE IRP 4500 11
If cannot move your IRP 4500 to the place of installation because the
unit is too tall to fit through a door opening or other passage, refer to
“Removing and Replacing the IRP 4500 Screen”on page 32 or in the
separate document located inside the left front compartment of the
console.
Installation
Installing the IRP 4500 involves mounting the projector, mounting
optional equipment, and making cable connections.
MOUNTING THE PROJECTOR
To mount your projector:
1Remove your projector and projector accessories from their
packaging.
2Connect the PROJECTOR POWER cable in the IRP 4500 cable tray to
the IEC power connector on the projector.
3Mount the projector on the adjustable projector plate in the rear
of the console. Projector plates vary according to the projector you
use. Samples are shown below.
4Power on the projector.
INSTALLING THE OPTIONAL KEYBOARD/MOUSE TRAY
If you purchased the keyboard/mouse tray option, it comes packaged
in a separate carton.
IRP_Install_1.fm Page 11 Monday, February 3, 2003 4:19 PM

Interactive Rear Projection (IRP)
12 INSTALLING THE IRP 4500
The tools required to assemble the keyboard tray are listed on the
Keyboard tray kit packing list and are located in the IRP 4500 toolkit
envelope shipped inside the accessory compartment on the left front
of the console.
Use the keyboard tray kit packing list and accompanying assembly
diagram to identify the parts of the keyboard tray assembly.
To assemble and install the keyboard/mouse tray:
1Using the 5/32" allen wrench (provided), remove the two
shipping restraining bars, one on each side of the console. Keep
these bars and screws with your pallet and packing materials if
the unit will need to be reshipped.
2Note the general arrangement and orientation of the kit parts
and determine which set of holes on the side of the console to
use for mounting the carriage and arm assembly. You can mount
Insert tray assembly into
carriage assembly as shown.
Adjust tray tension here with 3/16"
Allen wrench provided in tool kit.
Mount carriage assembly
to frame with two 10-32
screws provided.
IRP_Install_1.fm Page 12 Monday, February 3, 2003 4:19 PM

INSTALLING THE IRP 4500 13
the assembly on either side of the console, but the left side is
usually recommended.
3Fasten the carriage and arm assembly to the console with the
two cap screws and tighten with the 5/32" allen wrench.
4Slip the keyboard tray and pedestal assembly into the carriage
and arm assembly.
5Place the keyboard mouse pad on the tray.
6Make sure the tray moves easily in its various directions. Adjust
the tension in the two pivot points, as desired, using the 3/16"
allen wrench.
INSTALLING OPTIONAL MAGNETIC PEN HOLDER
The optional magnetic pen holder can be placed on any metal
surface of the console and moved at any time.
ASSEMBLING THE OPTIONAL VIDEO CAMERA PEDESTAL
Your video camera pedestal comes packaged in a separate carton.
The tools required to assemble the video camera pedestal are listed
on the video camera pedestal kit packing list and are located in the
IRP 4500 toolkit envelope shipped inside the accessory
compartment (left-rear) of the console.
Store projector remote
Store pen spare battery
Store electronic pen
IRP_Install_1.fm Page 13 Monday, February 3, 2003 4:19 PM

Interactive Rear Projection (IRP)
14 INSTALLING THE IRP 4500
Use the video camera pedestal kit packing list and accompanying
assembly diagram to identify the parts of the video camera pedestal
assembly.
To assemble the optional video camera pedestal:
1Note the general arrangement and orientation of the kit parts
and determine which set of holes on the side of the console to
use for mounting the pedestal assembly. You can mount the
assembly on either side of the console, but the right side is
usually recommended.
2Fasten the pedestal assembly to the console with the two cap
screws and tighten with the 5/32" allen wrench (provided).
Secure camera with
1/4-20 screw
Attach with 10-32 screws
using 5/23" Allen wrench
IRP_Install_1.fm Page 14 Monday, February 3, 2003 4:19 PM

INSTALLING THE IRP 4500 15
Cable Connections
NOTE:NOTE
Disconnect the IRP 4500 main power cable and turn off the MAIN
POWER, PROJECTOR POWER, and SPEAKER POWER switches on the
power panel before proceeding. Do not reconnect the power cable or
turn on any of the power switches until all cabling and connections
have been completed.
PREPARING TO INSTALL CABLES
Locate and have ready to use:
•A grounded extension cord to reach a power receptacle. (An 8-
foot (24oo mm) IEC Type SJT power cord is included with the IRP
4500.)
For safety and continued conformance to UL Standard 1950, a
type SJT power cord with grounded connections on both ends
must be used. Always use with a grounded socket outlet. Do not
use a cable that has been damaged.
•An RS-232 serial interface extension cable (“straight-through”)
to connect your host computer to the Webster screen in the
console.
A 12-foot (3700 mm) serial cable is included with the IRP 4500,
which is adequate if you are putting your host computer in the
IRP 4500 PC compartment.
The IRP 4500 RS-232 serial cable has a full complement of nine
wires. Any RS-232 extension cable should also have the full
complement of nine wires. (Although only three wires are used
for data and ground, control signals on two other wires are used
by Webster to generate carrier detect (DCD). For further
information, refer to Application Note AN1001 on “PC Serial Port
Cabling Specifications for Webster”.
•A 6-foot (18oo mm) VGA cable is included with the IRP 4500,
which is adequate if you are putting your host computer in the
PC compartment.
If you want to connect an auxiliary display monitor to your
computer in addition to the IRP 4500, you can use your original
IRP_Install_1.fm Page 15 Monday, February 3, 2003 4:19 PM

Interactive Rear Projection (IRP)
16 INSTALLING THE IRP 4500
VGA cable with the projector VGA loop-through connector.
•An audio cable to connect your host computer to the projector.
(A 6-foot (18oo mm) stereo mini-plug cable is included with the
IRP 4500, which is adequate if you are putting your host
computer in the PC compartment.
•Depending on the positioning of your keyboard tray, keyboard,
mouse, and host computer, it may be necessary for you to
obtain extension cables for your keyboard and/or mouse.
•Phone line and network cables of various types and lengths may
be required to complete the communication connections with
your host computer.
•Some additional audio and video patch cables are included
with the IRP 4500. Other cables may be required to meet your
specific needs.
Refer to “Troubleshooting the Cable Connections”on page 43.
ROUTING CABLES IN THE IRP 4500 CONSOLE
The IRP 4500 can accommodate your host computer either in the PC
compartment or outside the console unit.
PC Compartment
Projector
Power Panel
Accessory Compartment
Toolkit
IRP_Install_1.fm Page 16 Monday, February 3, 2003 4:19 PM

INSTALLING THE IRP 4500 17
The accessory compartment on the left side of the console is
planned primarily for access to the inside of the power control panel,
but it can also be used for some accessory equipment of your own
choosing.
The power control panel, shown below, has IEC-type cable
connectors on the inside as well as the outside, and there are AC
power drop cords running inside from the panel to both the PC and
accessory compartments.
You will need to connect various cables to the IRP 4500 power
control panel on the left hand side of the console, to the projector in
the rear of the unit, and to your host computer. Cables may run
inside or outside the console unit, to or from the projector, and to or
from your host computer.
Cable access openings to the inside of the console are located above
and to the right of the power control panel. There are additional
openings at bottom rear of the console on either side, at either end
of the built-in cable tray that runs between the right and left-hand
sides of the console.
You have your choice as how to route your cables. It is usually better
to group and route cables together, depending on their type, source,
and destination. Use the built-in cable tray whenever possible.
When you are satisfied with the final organization and routing of your
cables, you may want to use tie wraps to provide strain relief and
maintain order for the cables within the console unit.
IRP_Install_1.fm Page 17 Monday, February 3, 2003 4:19 PM

Interactive Rear Projection (IRP)
18 INSTALLING THE IRP 4500
HOST COMPUTER CONNECTIONS IN THE CONSOLE (OPTIONAL)
Ordinarily, you will be powering the computer on and off along with
the entire system using the IRP 4500 MAIN POWER switch located on
the power panel, on the left side of the console.
To route cables in the IRP 4500 console:
1If you choose to put your host computer in the PC compartment
of the IRP 4500 console, assure that the computer will fit
comfortably in the space to allow adequate access for reaching
switches, seeing lights, and connecting cables. It will be most
convenient if your cable connectors are at the rear of the
compartment for access through the access panel in the rear.
2Connect the COMPUTER POWER supply cord pre-wired in that
area to your computer.
3Connect the VGA cable supplied with the IRP 4500 between your
computer and your projector (refer to your projector manual for
information about connections).
4If you want to use your computer display monitor for an auxiliary
display, connect your original VGA cable between your monitor
and the projector.
5Place your computer keyboard and mouse on the IRP 4500
keyboard tray (refer to “Installing the Optional Keyboard/Mouse
Tray”on page 11) and connect the cables to your host computer.
Depending on the location of these components, it may be
necessary for you to obtain extension cables for your keyboard
and/or mouse.
6You can put other accessory equipment of your own choosing in
the accessory compartment of the IRP 4500 console if it does
not get too crowded. You can connect the AC power supply cord
pre-wired in that area to your accessory equipment.
IRP_Install_1.fm Page 18 Monday, February 3, 2003 4:19 PM
