WeGo ENDURO 100 User manual

JoinWeGo.com
USER MANUAL
measure your heart rate
for a better, healthier you!
heart rate monitor

JoinWeGo.com
WEGO™ENDURO 100 lUser Manual
CONTENTS
Welcome to WeGo™1
Key Functions 2
Watch Reset 2
General Operations 3-7
All Modes 3
Time Mode 3
How to Wear 4
Pulse Mode 5
Pulse Setting Mode 6
Chrono Mode 7
Regulatory & Safety Notices 8-9
Care & Maintenance 10
Trouble Shooting 11
Warrant y 12-13
The WeGo™Line of Products 14

1
WEGO™ENDURO 100 lUser Manual
WELCOME TO WEGO™
WeGo™allows users to SEAMLESSLY TRACK their fitness progress and goals. Our line of activity trackers
and heart rate monitors are engineered for QUALITY and VA LUE , using the LATEST TECHNOLOGY in
data tracking. WeGo’s line includes products for all individuals—regardless of their fitness level or activity type.
BE HEALTHIER
prevent injury
and overtraining
BE SMARTER
achieve the most
effective workout
BE HAPPIER
improve personal
fitness levels

2
WEGO™ENDURO 100 lUser Manual
KEY FUNCTIONS
S1 – Start/Split
S2 – Stop
S3 – Mode
S4 – EL backlight
2-3 min auto exit if no
key operation
This is a 5.3 KHz HRM watch Men’s version. Features
include HRM functionality that can display your heart
rate while you are exercising. 12H or 24H display
format can also be selected. There is also an EL back
light for 2 to 3 seconds after pressing the S4 button.
Push button main function
WATCH RESET:
WARNING: All settings will be reset to default values
Reset the watch by pressing and holding S1, S2, S3,
and S4 together. All segments will display plus EL on,
followed by a beep sound. The watch will then perform
a self diagnostic test. The software code will also be
displayed.
This watch is water resistant up to 5 ATM.
Battery Type: CR2032

3
WEGO™ENDURO 100 lUser Manual
ALL MODES
The watch has 3 main modes.
Press S3 to scroll through all the modes. The modes
are TIME, Pulse, and Chronograph.
TIME MODE
How to enter TIME mode and view the Day and Date:
In Time mode, press S1 to view the Day, Month
and Date.
GENERAL OPERATIONS
TIME SETTING MODE
How to set the TIME:
• Press and hold S2 while in Time screen. The hour digit will
start to blink.
• Press S1 to change the value of the blinking digit.
• Press S3 to go to the next setting screen.
• Press S2 to exit setting.
If there is no push button operation for 2-3 minutes, the watch
will auto return to Time mode.

4
WEGO™ENDURO 100 lUser Manual
GENERAL OPERATIONS
The HRM belt is on standby and ready to send data to
your watch. Wear the belt directly on your skin just below
your breastplate. It should be snug enough to stay in place
during your run.
•
Push one tab on the strap through the slot in the HRM
transmitter.
•
Wet both electrodes with a damp cloth on the back of
the HRM belt. This will help create a strong electrical
connection between your chest and the HRM transmitter.
•
Wrap the chest belt around your rib cage just below the
pectoral muscles and attach the other end of the strap to
the HRM transmitter. The elastic strap should be adjusted
so that it is snug enough so that it will not move during
use but not so tight as to restrict breathing.
•
The HRM belt is now ready to transmit data to the watch.
HOW TO WEAR YOUR HEART RATE BELT MONITOR:

5
WEGO™ENDURO 100 lUser Manual
GENERAL OPERATIONS
PULSE MODE
How to enter PULSE mode
•
Press S3 from Time mode to go to Pulse mode.
•
The watch will automatically search for HRM signal
upon entering the PULSE mode.
•
Once signal is received, your heart rate will be
displayed on the screen. If signal is not received,
after 1 minute of searching, it will display “- - -“.
•
Press S1 to re-link.

6
WEGO™ENDURO 100 lUser Manual
GENERAL OPERATIONS
PULSE SETTING MODE
•
Press and hold S2 to set. The HR digit will start to blink.
•
Press S1 to increase the value of the blinking digit.
Press and hold S1 to fast increase.
•
Press S3 to go to next setting screen.
• Press S2 to exit setting.
•
If Zone Alarm (SND) is ON, a beep sound will be given
every second when heart rate is below the LO (Low)
limit. And 2 beep sounds if the heart rate is above the
HI (High) limit. Up or down arrow will also be displayed
respectively.
•
If Zone Alarm (SND) is OFF there will be no beep sound
or Up or Down arrow indicator.
• High and Low limit can be set between 40 to 240 BPM.
•
If there is no button operation in setting mode after 2-3
minutes, the watch will auto return to PULSE mode.

7
WEGO™ENDURO 100 lUser Manual
GENERAL OPERATIONS
CHRONO MODE
How to enter CHRONO mode, Start, Take Split, Stop
and Reset
•
Press S3 from Pulse mode to go to Chronograph mode.
•
Press S1 to start, re-start or split.
•
Press S2 to stop.
•
Press S2 again to reset.
•
The chronograph will show 1/100 seconds resolution for
the first hour and 1 second resolution for the succeeding
hours.
•
If Zone Alarm (SND) is ON, there’s a beep sound when
the heart rate is below the LO (Low) limit and if the
heart rate is above the HI (High) limit.
•
If Zone Alarm (SND) is OFF there will be no
beep sound.

8
WEGO™ENDURO 100 lUser Manual
REGULATORY & SAFETY NOTICES
WARNING:Heart rate monitoring systems maybe
inaccurate. Over exercising may result in serious injury
or death. If you feel faint stop exercising immediately.
This is not a medical device. Should not be used to
diagnose or treat any medical condition. Consult your
doctor for prevention, diagnosis and treatment. See
the user guide for further guidance.
This is not a toy. Keep away from children.
BAT TE RY S AFE T Y IN FO RMAT ION
• Do not allow children to play with button cell
batteries, and keep button cell batteries out of your
child’s reach.
• Never put button cell batteries in your mouth for any
reason as they are easily swallowed accidentally.
• If a button cell battery is ingested, immediately seek
medical attention.
• Non-rechargeable batteries are not to be recharged
• Rechargeable batteries must be removed before
recharging
• Rechargeable batteries should only be recharged
under adult supervision
• Exhausted batteries are to be removed
• Do not mix old and new batteries
• If this product will not be used for an extended period
of time, remove the batteries from the product
• The supply terminals are not to be short-circuited
• Batteries are to be inserted with correct polarity
• Clean the battery contacts and also those of the
product prior to battery installation
• As always, dispose of batteries in an eco-friendly
manner
I MP O RTA NT
Do not press the Button under water.
Do not wear product while diving.

9
WEGO™ENDURO 100 lUser Manual
REGULATORY & SAFETY NOTICES
The WEEE symbol on the product or on its packaging
indicates that the product must not be disposed of
with normal household waste. Instead such marked
waste equipment must be disposed of by arranging to
return to a designated collection point for the recycling
of waste electrical and electronic equipment. By
separating and recycling this waste equipment at the
time of disposal will help to conserve natural resources
and ensure that the equipment is recycled in a manner
that protects human health and the environment.
Keep this manual and packaging for future reference
since it contains important information

10
WEGO™ENDURO 100 lUser Manual
BATTERY REPLACEMENT
Battery replacement will be required from time to
time, and should occur when:
1. The display fades in part or completely
2. The heart rate function will not activate
3. Backlight System does not operate
4. The battery icon is visible
To replace the battery of your WeGoTM Heart Rate
Watch, we recommend you take it to a watch repair
service center or certified jeweler. This will ensure
that the water resistance will be retained after
battery replacement.
• NEVER attempt to disassemble or service your unit.
• DO NOT expose the unit to extreme heat, shocks,
magnetic fields, electrical noise, strong vibration or
long-term exposure to direct sunlight.
• DO NOT drop or step on the watch.
• TO CLEAN THE UNIT: wipe with a lightly moistened
cloth. Apply mild soap to the area if there are
stubborn stains or marks. Do not expose the unit
to strong chemicals such as gasoline, cleaning
solvents, acetone, alcohol or insect repellents, as
they may damage the unit’s seal, case and/or finish.
• STORE the unit in a dry place when you are not
using it.
CARE & MAINTENANCE

11
WEGO™ENDURO 100 lUser Manual
POTENTIAL CAUSES FOR NO HEART RATE READING OR LONG RESPONSE TIME
CAUSE: Dry skin
SOLUTION: Apply conductive gel thoroughly to chest
area (for Chest-Strap measurement) or finger (for
Finger-Touch measurement). Tap water may help if
conductive gel is not available.
CAUSE: Chest strap is not contacting with skin
SOLUTION: Make sure the chest strap is firmly over
the chest and the Watch is securely on wrist.
CAUSE: Muscle tremors caused by pressing on sensors
too hard (finger touch)
SOLUTION: Decrease finger pressure on the Sensor Pads.
CAUSE: dead skin on wrist, finger or chest.
SOLUTION: Rub off excessive dead skin with a towel.
CAUSE: a thin layer of body grease insulates the ECG
signal preventing the chest strap or watch from detecting
ECG heart rate
SOLUTION: Wipe chest/wrist and the back of Chest Strap/
watch with a tissue or soft towel.
CAUSE: Hairy skin
SOLUTION: Apply conductive gel to chest area or wrist.
CAUSE: Low battery
SOLUTION: Replace the battery in watch/transmitter
and try again.
CAUSE: Electrical field interference from RF devices (chest-
strap measurement) such as Overhead power lines, etc.
SOLUTION: Leave the area where RF source potentially exist.
TROUBLE SHOOTING

12
WEGO™ENDURO 100 lUser Manual
GUARANTEE CERTIFICATE – FOR PURCHASES MADE IN THE U.S.
If at any time within one (1) year from the purchase date of this product, it fails to perform properly because
of defects in material or manufacturing, return it prepaid to: EB SPORT GROUP, 585 OAK RIDGE ROAD, HAZLETON, PA 18202
Complete this Guarantee Certificate and enclose it (or a copy of it) with the product. Please contact Customer
Service at 866-694-4575 or [e-mail] for a return authorization number, prior to
sending in your product.
(PLEASE PRINT CLEARLY)
Name: Phone:
Address:
Store Purchased From:
Date of Purchase: Purchase Price:
State: Zip:
Problem With Product:
WARRANTY

13
WEGO™ENDURO 100 lUser Manual
REPLACEMENT
This product has been carefully designed, manufactured and packaged. If any parts are missing or damaged,
please contact us at the address above and we will replace the unit at no charge. (Guarantee does not cover
crystal or battery.)
FOR PURCHASES MADE IN THE UK
Should you experience problems with this item, please return it to the point of purchase. This will not affect
your statutory rights. Alternatively return it to the address shown below for a repair/replacement.
EB Brands UK, Berkeley Business Park, Wainwright Road, Worcester WR4 9FA
www.JoinWeGo.com
Distributed in the UK by EB Brands UK, Worcester WR4 9FA
WARRANTY

14
WEGO™ENDURO 100 lUser Manual
HEART RATE MONITORS
THE WEGO™LINE OF PRODUCTS
ELITE+
• Sleep Quality
• Goal Setting
• User Replaceable Battery
• Sync Wireslessly
HYBRID+
• Sleep Quality
• Goal Setting
• Sync Wireslessly
• Water Resistant
• Replaceable Straps
• Silent Alarm Vibration
R E L AY
• Caller ID/Text Notification
• Auto Sleep
• Sleep Quality
• Sync Wireslessly
• Water Resistant
• Replaceable Straps
• Silent Alarm Vibration
ACTIVITY TRACKERS
CARDIO/ENDURO 100
• 5.3k Chest Strap
• Time, Chronograph, Heart Rate
• BPM, HR Zone/Alarm
• Date, Lap/Split Time
• Water Resistant 50M
PUL SE / PACE
• No Chest Strap Required
• Time, Alarm, Chronograph, HR
• HR Zone/Alarm, BPM and %
Max HR Display
• Date, Dual Time Zone,
Daily Alarms, Lap/Split Time
• Water Resistant 50M
PULSE/PACE PLUS
• Optical Heart Rate Technology
• Time, Chronograph, HR
• Quick On-Demand HR Reading
• HR Zone, % Max HR
• Custom User Profile
• Water Resistant 1ATM
ENDURO 200
• 5.3k Chest Strap
• Time, Alarm, HR, Data Record
• HR Zone/Alarm, Avg/Max HR, BMI
• Run/Lap Memory, Calorie Burn,
Recovery HR Monitor/Timer
• Dual Time Zone, Daily Alarms,
Lap/Split Time, Night Mode
• Water Resistant 50M
ENDURO 300
• Optical Heart Rate Technology
• Time, Alarm, Chronograph, HR
• HR Zone, % Max HR, Calorie Burn
• Custom User Profile
• USB Rechargeable Battery and
Charger Included
• Water Resistant 1ATM
WeGo™ is the fitness motivator that
makes it easy to track daily activities.
These easy to use activity trackers
and heart rate monitors can help
support a happy, healthy lifestyle.

JoinWeGo.com
WEGO™ENDURO 100 lUser Manual
CAUTION: This is not a medical device. Should not be used to diagnose or treat any medical condition. Consult your doctor for prevention, diagnosis and
treatment. See the user guide for further guidance. This is not a toy. Keep away from children.
CALIFORNIA PROPOSITION 65 WARNING: This product may contain chemicals known to the State of California to cause cancer, birth defects and/or
reproductive harm.
WARNING: Heart rate monitoring systems may be inaccurate. Over exercising may result in serious injury or death. If you feel faint stop exercising immediately.
Made in China. WeGo™is a trademark of EB Sport Group, Hazleton, PA 18202. Distributed in the United Kingdom by EB Brands (UK), Worcester WR4 9FA.
All Rights Reserved ©2015. Designed and engineered by EB Labs.
