weintek cMT-iPC15 User manual

User Manual
V1.0.0
Oct 15, 2015
www.setup.com.br
+55 19 2517.8900
Campinas-SP-BRAZIL

Table of Contents
1. Overview ................................................................................................................... 1
2. Specification .............................................................................................................. 1
3. Dimensions ............................................................................................................... 2
4. LED Indicators ........................................................................................................... 3
5. Lithium Battery ......................................................................................................... 3
6. Entering BIOS ............................................................................................................ 3
7. Installing Windows OS .............................................................................................. 3
8. Turning ON/OFF the HMI .......................................................................................... 4
9. Driver ........................................................................................................................ 4
10. Touchscreen Calibration ........................................................................................... 5
Warning
This is Class A Product. In domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.

cMT-iPC15 User Manual
1
1. Overview
cMT-iPC15, based on Windows OS, can connect cMT-SVR using cMT Viewer and
serves as HMI, and it runs third party applications. By using cMT Launcher
dedicatedly designed by Weintek R & D group, it’s easy to customize cMT-iPC15’s
desktop into smartphone-like UI and manage access control of apps. The shortcut
name and icon of the application can be customized and placed in different
categories and different pages.
2. Specification
Display
Display
15” TFT
Resolution
1024 x 768
Brightness (cd/m2)
400
Contrast Ratio
700:1
Backlight Type
LED
Backlight Life Time
>50,000 hrs.
Colors
16.2M
LCD Viewing Angle (T/B/L/R)
70/70/80/80
Touch Panel
Type
4-wire Resistive Type
Accuracy
Active Area Length(X)±2%, Width(Y)±2%
Memory
SSD
32 GB
RAM
4 GB
Processor
Intel Atom E3827
I/O Port
SD Card Slot
SD/SDHC/SDXC
USB Host
USB 2.0 x 2 / USB 3.0 x 1
Ethernet
10/100/1000 Base-T x 2
Audio Output
Built-in Mono Speaker
Audio Line Out –3.5 mm jack x 1
RTC
Built-in
Power
Input Power
24±20%VDC
Power Isolation
Built-in
Power Consumption
2A@24VDC
Voltage Resistance
500VAC (1 min.)
Isolation Resistance
Exceed 50M@ 500VDC
Vibration Endurance
10 to 25Hz(X,Y,Z direction 2G 30 minutes)
Specification
PCB Coating
Yes
Enclosure
Aluminum
Dimensions WxHxD
366 x 293 x 54.2 mm
Panel Cutout
352 x 279 mm
Weight
Approx. 2.76 kg
Mount
Panel mount, VESA mount 75 x 75 mm
Environment
Protection Structure
UL Type 4X (indoor use only) / NEMA4 / IP65
Compliant Front Panel
Storage Temperature
-20° ~ 70°C (-4° ~ 158°F)
Operating Temperature
0° ~ 50°C (32° ~ 122°F)
Relative Humidity
10% ~ 90% (non-condensing)
Certificate
CE
CE marked
UL
Applying
OS Support
*Windows®7 / Windows®8.1
(EasyLauncher + cMT Viewer)
*License of Windows OS is excluded.

cMT-iPC15 User Manual
2
3. Dimensions
Cutout Dimensions:
352mm [13.86"] W x 279mm [10.98"] H
352mm
[13,86"]
279mm
[10,98"]
Front View
350mm
[13,78"]
277mm
[10,91"]
cc
d
a
b
c c
Rear View
Bottom View
gh i j
f
e
Panel-mounting clamp slots, 10 places
Top View 24,2mm
[0,95"]
54,2mm
[2,13"]
5,7mm
[0,22"]
Side View
293mm
[11,54"]
366mm
[14,41"]
a
Fuse
f
USB Host port 3.0
b
Power Connector
g
USB Host port 2.0
c
VESA 75mm Screw
Holes
h
LAN 2
d
Reset Button
i
LAN 1
e
SD CARD SLOT
j
Line Out

cMT-iPC15 User Manual
3
4. LED Indicators
The LED indicators indicate:
Orange LED: Power status
Green LED: SSD writing status
Blue LED: Ethernet communication status
5. Lithium Battery
The cMT-iPC15 requires a CR-2032 lithium battery to keep the RTC running.
After replacing the battery, please enter BIOS to manually set RTC.
6. Entering BIOS
You can enter BIOS settings by the following two ways:
•Connect a USB keyboard and press F2 key at startup.
•Press and hold on one of the four corners of the screen at startup.
7. Installing Windows OS
1. Read the Windows installation disc by connecting a USB CD-ROM drive.
(Or, burn the Windows ISO image to a USB drive, and then insert the USB drive
into HMI.)
2. Press and hold on the center of the screen and then select the device.
(Or, connect a USB keyboard, and press F5 key at startup.)

cMT-iPC15 User Manual
4
8. Turning ON/OFF the HMI
ON:
To turn on the HMI, go to BIOS and set whether to automatically turn on, or press the
power button to turn on, when the HMI is connected to power supply.
Go to BIOS \ Advanced \ South Cluster Configuration \ Miscellaneous Configuration \
State After G3:
S0 State: Automatically turn on when connected to power supply.
S5 State: Press the power button to turn on when connected to power supply.
OFF:
To turn off the HMI, you can either turn off in Windows, or set the function of the
power button in Windows Control Panel \ System and Security \ Power Options \
Change what the power buttons do, and press the power button when HMI is ON.
Unplugging power cord directly can cause stop error and lead to data loss.
9. Driver
After installing Windows OS, install the required software / hardware drivers, in the
same order as listed in the following link.
Download Link:
http://www.weintek.com/Download/cMT/cMT_iPC15/driver/cMT_iPC15_driver.htm

cMT-iPC15 User Manual
5
10. Touchscreen Calibration
To do touchscreen calibration, run HIDeGalaxTouch Tool.
To do an advanced calibration, go to [Advanced] \ [Linearization], and choose from 9
Points or 25 Points Calibration.
