Welco WPM Series User manual

16082600
Specifications
Components
Safety precautions
8
3 - 7
1 - 2
Page
Table of contents
9 - 11
Replacement Tube assembly
Instruction Manual
Peristaltic Tubing Pump
Series
WPM
This symbol indicates information that, if
ignored or applied incorrectly, creates the
possibility of minor or moderate personal
injury or property damage.
Caution

The flow amount may be unstable immediately after the installation, since the tubing is not settled.
It may need some time until it is stabilized.
1) Apply grease (attached with Tube assembly set) to Pump tube and the axle of Cassette Rotor as shown
in the figure. (See gray area of right illustration)
1)PulloutPumptube,andfitRotorintoPumptube.
2)AlignPumptubeandRotorwithRotoraxleinCassette,
andpushthemin.
2) Install Pump tube
,QVHUWDWXEHLQWR&DVVHWWH$OLJQPDUNVRQWKHWXEHZLWKERWWRPRI&DVVHWWH
3XVKWKHWXEHKROGHULQWR&DVVHWWHXQWLOLWFOLFNV
When accurate flow amount is
UHTXLUHGPDUNVDUHQHHGHGWR
alingn with bottom of Cassette.
Applying grease
Applying grease
Apply the grease attached with Tube
assembly set. Grease is specified by each
Tubing materials.
Do not use other grease, otherwise it may
reduce durability or cause other problems.
Caution
Tube holder
Rotor
Rotor
Rotor axle
in Cassette
Pump tube
Cassette
&OLFN
0DUN
PDUN PDUN
Grease application positions
OK NOTGOOD
Rolor
Cassette
Pump tube
0DNHVXUHWKDW
pump tube is hold
between rolor and
cassette.
Install new Tube assembly
Install Rotor
-10 -
