Well Shin WS-533 User manual
Smartbears APP iOS/Android
User Manual
Best Smart Home Solution
Internet of Things
APP ver. 3.5.3 E
REVISED EDITION: 13:4:PM-12-October-2017
Total: 72 pages
www.wellshin.com.tw
5 SmartBearS Internet of thing alarming apparatus controls project
5 i. The front of smart home HUB
5 ii. Status indicator LED
6 iii. The bottom of smart home HUB
6 iv. Smart home HUB back and interface
7 The SmartbearS monitor product feature
7 Professional security monitor network
7 Professional alarm system.
7 Professional smart home system
8 SmartBearS IP Camera Control Center Specication:
10 SmartbearS APP functions:
10 Install SmartbearS APP
10 Start to use SmartbearS APP
11 1. SmartbearS APP interface
12 2. Menu introduction
12 2.1 How to add and configure smart HUB?
13 2.2 How to set the APP password?
14 3. System Client-Main page
16 4. System Setting interface introduction
17 4.1 How to add security alarm?
21 4.2 How to "add" health care product?
23 4.3 How to add smart home device?
25 4.4 How to add IR remote control?
31 4.5 How to 'set' an alarm/health/smart home appliances?
34 4.6 System Setting - Scenario Mode Settings - Smart Scene Setup
35 4.7 System Setting- Area Settings - Area Setup
36 4.8 System Setting - Camera Settings - Set up idle time before camera
returns to default position 10 mins
37 4.9 System Setting - Camera Settings - Password Settings
38 4.10 System Setting - Camera Settings - Monitor Position Settings
39 4.11 System Setting - Camera Settings - Video Settings
40 4.12 System Setting -Camera Settings - Wi-Fi Settings
40 4.13 System Setting - Camera Settings - PPPOE Settings
40 4.14 System Setting - Camera Settings - Advanced Settings
41 5.1 "Device" interface introduction
42 5.1.1 "Unlock" interface introduction
43 5.1.2 Dimmable interface introduction
45 5.1.3 "Outlet" interface introduction
46 5.1.4 "Switch" interface introduction
46 5.1.5 "Curtain" interface introduction
47 5.1.6 "Valve" interface introduction
47 5.1.7 "Door, Window" interface introduction
48 5.1.8 "Pet Feeder" interface introduction
INDEX
II
INDEX
48 5.1.9 "Fan" interface introduction
48 5.1.10 "Rolling Gate" interface introduction
49 5.1.11 "Shrink Door" interface introduction
49 5.1.12 "Auto Bed" interface introduction
49 5.1.13 "ECO" interface introduction
49 5.1.14 "Sort" interface introduction
50 5.2 "Surveillance" interface introduction
52 5.2.1 "Door Bell" interface introduction
54 5.2.2 "RemoteCtrl" interface introduction
54 5.2.3 "PIR" interface introduction
54 5.2.4 "DoorMag" interface introduction
54 5.2.5 "SOS(Fire)" interface introduction
54 5.2.6 "SOS(Police)" interface introduction
54 5.2.7 "Gas" interface introduction
54 5.2.8 "Smoke" interface introduction
54 5.2.9 "CO" interface introduction
55 5.2.10 "PM2.5" interface introduction
55 5.2.11 "Water" interface introduction
55 5.2.12 "TempHumi" interface introduction
55 5.2.13 "Sort" interface introduction
56 5.3 "Home Appliance" interface introduction
57 5.3.1 "Air Conditioning" interface introduction
58 5.3.2 "TV" interface introduction
59 5.3.3 "DVD" interface introduction
60 5.3.4 "IP TV" interface introduction
61 5.3.5 "Fan" interface introduction
61 5.3.6 "Stereo" interface introduction
62 5.3.7 "Projector" interface introduction
62 5.3.8 "D|Humidifier" interface introduction
62 5.3.9 "Sweep Droid" interface introduction
63 5.3.10 "Sort" interface introduction
64 5.4 "Scene" interface introduction
66 5.4.1 "Arm" interface introduction
66 5.4.2 "Disarm" interface introduction
66 5.4.3 "Home" interface introduction
66 5.4.4 "Away" interface introduction
66 5.4.5 "Sleep" interface introduction
66 5.4.6 "Custom 1" interface introduction
66 5.4.7 "Custom 2" interface introduction
66 5.4.8 "Custom 3" interface introduction
66 5.4.9 "Custom 4" interface introduction
66 5.4.10 "Custom 5" interface introduction
66 5.4.11 "Custom 6" interface introduction
66 5.4.12 "Custom 7" interface introduction
66 5.4.13 "Custom 8" interface introduction
III
Copyright © 2017 by Well Shin Technology Co., Ltd. All rights reserved. None of the information provided here
may be used, duplicated, reproduced, either partially or completely, without prior permission of Well Shin.
Information provided here may consist of uncertainty, Well Shin reserves the right to revise or explain all the time.
66 5.4.14 "List" interface introduction
66 5.4.15 "Area" interface introduction
66 5.4.16 "Sort" interface introduction
67 5.5 "Health Care" interface introduction
68 5.5.1 "Diaper Humidity" interface introduction
68 5.5.2 "Crying Detector" interface introduction
68 5.5.3 "Medication Reminder" interface introduction
68 5.5.4 "Online Doctor" interface introduction
68 5.5.5 "Medical Teleconference"interface introduction
68 5.5.6 "Sort" interface introduction
69 5.6 "Surveillance" interface introduction
70 5.6.1 "Listen" interface introduction
70 5.6.2 "Speak" interface introduction
70 5.6.3 "Snapshot" interface introduction
70 5.6.4 "Record" interface introduction
70 5.6.5 "PTZ(Monitor)" interface introduction
70 5.6.6 "PTZ(Private)" interface introduction
70 5.6.7 "Sort" interface introduction
71 Notice
71 NCC
71 FCC
71 IC
INDEX
IV
SmartBearS Internet of thing alarming apparatus controls project
i. The front of smart home HUB
Item model ：WS-533
ii. Status indicator LED
Indicator light: slowly flickering = interval one sec; fickering = 0.5 sec
①
②
③
④
⑤
⑥
⑦
⑧
LED Indicator
Status D8 D9 D8,D9 D10 D11
1. The light always on Device enable
or malfunction
Presentation the
device is running
normally
2. Slowly flickering Arm success
Presentation
device enabled
of record
3. Alternately flickering
The light of
device includes
arm and record
4. The lights at the
same time light Reset success
5. Slowly flickering for
1 time
Receive outside
RF indicator of
device
6. Flickering for 3 times The HUB sends
RF data
7. Continually flickering The alarm
has working
① . Light sensor
② . Night vision LED
③ . Manual focus
④ . Infrared emission
⑤ . Infrared reception
⑥ . Equipment operation LED, LED: D8/D9
⑦ . MIC
⑧ . Device senses light of RF, LED: D10/D11
5
iii. The bottom of smart home HUB
①
①
②
⑤
⑥
③
④
②
③
⑦ ⑧ ⑨ ⑩
① . Loudspeaker
② . ASK RF Antenna
③ . Siren
④ . Speaker
⑤ . Mic
⑥ . Temperature/Humidity detector
⑦ . Wi-Fi hot spot/4G card slot
⑧ . micro SD slot
⑨ . LAN
⑩ . Power
. FSK antenna
① . Mounting bracket joint nut
② . Restoration
③ . The HOB ID and QR code
iv. Smart home HUB back and interface
6
Internet of Things best smart home solution
The HUB combined simple operating system and advanced integration with fully
automatic intelligence into your smart life.
The SmartbearS monitor product feature
1 M2M the internet of things platform.
2 Professional security monitor network.
3 Professional alarm system.
4 The smart home system.
5 Make things convenient for the client express setup.
6 Support 3G/4G smart phones.
7 Support WI-FI connect.
Professional security monitor network
1. Support to connect M2M platform of IOT and smart home network. Support M2M access IOT
platform and smart home network
2. Support new technology,dispense use foreign network IP address. Support plug and play with the
latest technology, without public IP address
3. Connect to the network, login account can complete installation.
4. Support HD screen,H.264 high efficiency coding. Support vision function.
5. Support cloud platform operation. 32 sets of clouds presets.
6. Support for NAS recode,NVR,SD card video snapshots,remote computer/mobile video photos.
7. Support temperature and humidity measurement
8. separate video channels to maximize user privacy
Professional alarm system.
1. Support remote control for the situation mode choice,alarm area and disarm,emergency distress or
professional privacy.
2. Supports infrared ,magnetic,water,gas,smoke,and other wireless detection alarms.
3. Support 99 road wireless protection zone,can form multi-group of control area combination ,with
various prevention schemes.
4. Support snap-shot, email alarm, built-in buzzer, external high decibel alarm, and immediate report
of detailed user contact information (PC).
5. Support for mobile detection zones.
6. Support alarm,cloud,client,user mail multiple automatic tracking alarm.
7. Support alarm and not online alarm
8. Support user multiple permissions to authorize security or property companies to contact
information function (PC).
9. PC client brings the alarm information detail in system.
Professional smart home system
1. Integration smart home HUB and multiple control device.
2. The main function of remote, simply control TV and air conditioners and other infrared devices.
3. The addition of wall lamp and switch,can be control lighting equipment.
4. The addition of curtains,doors and windows
5. The addition of smart plug,remote control appliance.
6. Remote control of wireless water pipe valves,wireless gas pipeline valves and pet feeders.
7. Integration one million appliance data. easily control.
8. Support custom remote control learing mode , free collocation.
9. Support smart phone remote operation.
7
SmartBearS IP Camera Control Center Specification:
CMOS Sen-
sor
Image Sensor Progressive scan 1/2.5" CMOS
Maximum Resolu-
tion 2592*1944
Lens 1/2.5/inch f: 2.2mm 300 mega pixel
System
CPU ARM9TM 32-bit, 32MHZ
System Embedded LINUX
Image Set-
tings
Video Compression H.264. Support Multi Stream
Camera Settings 25fps（50Hz）、30fps（60Hz ） Frequency
Image Resolution High:1280*720 Medium:640*480 Low:320*240
Image Mirror Support Up/Down, Left/Right mirror
Day/Night Switch Support IR-CUT auto switch
Image Available
IR Model Automatic
Night Vision ￠ 5*10 IR LED, IR Range 10-15m
Audio
Speaker Built-in Speaker 1W8R
Sound Monitor Bulit-in MIC
Network
Ethernet 10/100Mbps
Protocols RTSP、TCP/IP、FTP、DHCP、PPPoE、NTP、UPnP、P2P
ONVIF Support ONVIF2.0
Smart Con-
trol
Operating FSK-way communication
Radio Frequecny 433.5MHZ
IR Control Application Electronic Appliance
8
PTZ Control
Vertical/Horizontal 115° / 350°
Default View Spot Phone - 4 set, PC - 25 set
Storge
Recording Schedule Setting, Auto Recording by Power On
Video Compression AVI
Storage PC Client / Micro SD / Android / iOS / NAS
Playback PC Client / Mobile Device Client
Video Download Support Remote, Micro SD Recording Video File adn Pictures
Interface
DC-In * 1 DC 12V/1A, Power Consumption ≤ 7W
LAN*1 Standard 8C RJ-45
TF CARD*1 Micro SD, Support Up to 64GB
USB*1 Standard A Type, Support USB Wi-Fi, 4G USB Model
Temperature and
Humidity Sensor*1 ￠ 3.5mm4 Audio Plug
MIC*1 ￠ 3.5mm4 Audio Plug, Mic-In Supported
Audio OUT*1 ￠ 3.5mm4 Audio Plug, External Supported
Alarm OUT*1 ￠ 3.5mm4 Audio Plug, Support External 5V/500MA Treble Alarm
Back Postion*1 Button+Watch Dog
Environment
Operating Tem-
perature 0o ~ 55oC (32oF ~ 131oF)
Operating Humidity 10% ~ 80% (Unfrozen)
Storge Temperature -10oC ~ 60oC (32oF ~ 140oF)
Storge Humidiyt 0% ~ 90%(Unfrozen)
Specifcation
Dimensions 132*119mm*134.5mm (LxWxH)
Net Weight 380g
9
Android/IOS 使用说明
Android/IOS User Manual
i. Turn on your smart phone/ Pad and connect to the network.
ii. Click the SmartbearS APP on
your screen.
You may find the APP in APP Store、Google Play and search for SmartbearS to download and install.
SmartBearS is a software design through Wi-Fi or 4G wireless network to remote control the
home appliance, security, health care device.
1. Real time monitoring(H.264 format)
2. Remote the IP camera by swipe the screen on smart phone.
3. Monitor and snap shot by smart phone.
4. Remote the home appliance device, TV, Lamp, DVD, Air conditioning etc...
5. Support multi languages(English, Chinese...)
6. Bi-directional voice communication.
7. It support to record the image to smart phone and SD card.
SmartbearS APP start screen
Install SmartbearS APP
SmartbearS APP functions:
Start to use SmartbearS APP
10
Android/IOS User Manual
shopping cart:
click and enter,according client
local place choice relevant official
designated online shopping mall.
Click to open
the menu
Device ID No.
Star: Default system.
A device with a preset
system logo after
the success of the
connected system will
automatically enter
the preset monitoring
system integration
client-main interface
System connect
state information:
connection,
connected,
equipment offline,
DID error,
password error
by mistake
connection
efficiency is
dependent on.
Long Press: you can
into the Default, Config,
Delete interface on long
press the system roll on
the screen.
Delete the
camera from
the camera
roll.
Click the
"Preset",
the star will
appears on
this system
roll.
Click "Config ", will into the setting
interface. it's includes how to change
the camera name, DID, password etc...
there are more introduction on the next
page.
APP name
Intelligent monitoring camera system connection status information.
Connecting
Connected
Device offline
Wrong DID
Worong password
CABU Office
Meeting Room
Wood House
Connected
Device offline
Connecting...
In the case of id number error or password error, see page 12, 2 introduction function menu.
Click: after
connected to the
system, click to the
Smart IP camera that
you would like to visit,
then, you are able
to monitor, record,
snap shot and remote
through your smart
phone.
Preset image
1. SmartbearS APP interface
After start the APP, you will have a screen as below.
11
Android/IOS 使用说明
Android/IOS User Manual
ii. Camera under Internet, please make sure
DHCP server are on in your network, click
"Search" to find the camera, when a camera
found, the 18 digits DID will automatically
show on DID column, input the default
password and click save to complete add
new camera.
i. Camera under Ethernet, you may add the
camera manually by input 18 digit DID with
default password, click save to complete add
camera
There are 3 ways to add the camera,
Please click the Add Camera
The default password for smart IP cam is 1234,
after click "Save", the device will appears on the
camera roll.
Click "QR code", scan the QR code under the
camera, it will automatically show the DID,
and please input the default password and
click save to complete the Add APP.
Click this column to change the
name of the camera.
ew smart HUB: start the SmartbearS app program on your smartphone -->SmartbearS app launch
interface-->the client shows the smart monitor list window--> click function menu--> add camera.
Setup the camera: SmartbearS app interface--> long press: each camera monitoring system can be
set by hand-holding. The system for the camera system for about 2 sec will pop up the preset,set de-
lete menu and click on the settings command.
2. Menu introduction
it will return to the home page.
Adding new camera
APP version check
Setting APP password, after setting when re-
start the APP, it will ask the password to enter
the APP.
2.1 How to add and configure smart HUB?
12
Android/IOS User Manual
APP password can be any
of 4 digits number. Can't be
letters or symbol.
APP password can be any of 4 digits number. Can't be letters or symbol ==> click function menu ==>
click Set App Password
2.2 How to set the APP password?
13
Android/IOS 使用说明
Android/IOS User Manual
2016/08/25 15:56:27 T 28℃, H 45%
3. System Client-Main page
Back
Alarm, Alarm notice
Monitoring screen,
it support single
screen, 4 screen,
previous, next.
System
setting
Monitoring screen: it can
move the camera by
swiping on your smart
phone or tablet.
1. It support monitoring
through internet, Wi-Fi
network on your smart
phone and tablet.
2. Alarm notice on those
device with wireless
transmission, like IR, door
magnet, gas detector etc...
3. Low battery and Off line
warning on those detector
sensor.
Device setting: Remote
controls 1. Smart Curtain,
unlock and lock on door
and windows.
2. Scheduling the on/off
time for lighting and fan
etc...
3. It can be use with smart
power socket, switch and
remote the home appliance.
4. It can schedule by
remote the switch of smart
water valve, gas valve, pet
feeder etc...
Scene setting: it can set
according to the time,
environment, area. for
example: when door
magnet, smoke detector
on, we need the camera
automatically rotate the
the area. arrange the
camera cruise by preset
order to each area when
on out, home, sleep
mode.
Device, De-
fense, Appliance,
Scene, Health,
Surveillance
remote button
Function setting:
integrate with
thousands of
remote control
signal, easy to
use and set up.
click the icon to
see the actual
function. also,
you may swipe to
into the different
page.
The function de-
vice icon can be
adjusted before
and after the use,
In this area, you
can swipe left
and right to view
different pages.
Monitoring area
preset: choose
1, 2, 3 or 4 the
camera will rotate
to the area pre-
set.
Currently connected number. (maximum
8, after 8 will just show disconnected)
Current information
of camera location
Search for
recording record
on smart phone
Create new
security accessory
by QRCODE
Names of IP
cam in use
PTZ
(Monitor)
PTZ
(Privacy)
Shopping cart
Appliance setting: To remote
setting the time for all kind of smart
home appliance, for example: Air
conditioning, TV, IP TV, dehumidifier,
humidifier etc...
Surveillance setting: security monitoring 1.
through network from your smart phone/ tablet
to take snap shot/ image recorder/ e-mail push
notice/ motion sensor/ buzzer alarm...
Health setting: support smart phone/ tablet through
network to monitor the baby or the elder, it has
communication function as well.
Return to the home page anytime when click the button.
Defense: To remote 1.
door bell, door magnet,
gas detector, CO sensor,
fire alarm, flood alarm, IR
related security device. 2.
SOS mode. 3. temperature
and humidity sensor.
14
Android/IOS User Manual
Return to the
main interface
Video pause/play fast forward/
fast back
The mobile phone/camera
records video display area,
including the image date ,
time ,temperature humidity
and other information.
The video recording time filtering
Please refer to P17 page {4.1.1 QR code scanning new alarm perimeter }
4 screen
Single screen
At monitoring setting page,
click the menu show Previous,
Next, Single screen, 4 screen.
The record shows, starting date, time,
resolution, how many user are online etc...
It can check the record on your
smart phone or in the camera.
Introduction to the system client-main interface.
Camera recording list, default
setting are according to the
recording time.
format of the image
On multi screen mode, the screen with blue
outside the box are the current monitoring
camera.
Video
record list
15
Android/IOS 使用说明
Android/IOS User Manual
4. System Setting interface introduction
Smart home situation
mode added example:
arm, disarm, go home, go
out , sleeping,getting up,
theater, party, romance,
opening store, etc
add and set changes to
the mode.
There is no alarm, alarm
or guest in the case.
Camera of the cloud
preset supervisor position
setting.
Set image quality, picture
direction, environment
mode.
Advanced setting: In-
cluding restart HUB, HUB
recovery original set.
Alerts push notifications,
event tweets sned func-
tions switch.
New equipment for smart
home devices add and
set,The door lock, Power
switch,light dimmers,cur-
tains,fans,The addition of
lamp holder, water valve
and other equipment add
and set.
The addition to alarm
peripheral equipment and
set PIR sense, Doorbell,-
door magnets, smoke
detection, The addition of
gas detection equipment
and set.
Peripheral equipment
for medical products
addition and settings
For example: wet
urine detection, baby
equipment such as
sound detection add
and set.
Smart home IR ap-
pliance Device remote
control new addition
add and set, such as:
TV, air condition, DVD
and other devices
Can be changed
to smart devices in
the area, consid-
ering not use of the
same space area
for the convenience
of managing your
equipment, therefore
need set regional
management.
Can change,custom-
ize smart home HUB
to monitor camera
secret code, after
changing password,
please remember.
Configure Wi-
Fi connection only
connect the encrypted
wireless signal.
Start the SmartbearS APP on your smartphone /tablet-->SmartbearS APP statup interface-->client
display intelligence able to monitor the camera list window--> system settings menu (pop up like the
right menu)--> clicks on the corresponding set addition /set menu .
16
Scroll up and
down to see
more option
Android/IOS User Manual
Alarm adding ways
The new "alarm perimeter" device can be select-
ed in the security in the four ways:
『Create new security accessory by QRCode』
『Create new security accessory by scanning』
『Create new security accessory by training』
『Create embedded alarm device』
4.1 How to add security alarm?
①
②
③
④
① Enter alarm setting
② Create new security accessory by QRcode
③ Touch begin QRcode scan
④ Camera scans the QRcode of a de-
vice,when successful,the name of the
alarm will appear,and turn on save.
NOTE: "QR code scanning new alarm peripheral" IOS version can only be filled with two-dimensional
barcode scanning method in the filling equipment, Android version there is not limit.
4.1.1 Create new security accessory by QRCode
17
Wireless Control Emergency Bracelet 704
Wireless Control Emergency Bracelet
Android/IOS 使用说明
Android/IOS User Manual
① Enter alarm settings.
② Enter create new security
accessory by scanning.
③ The camera is on the LAN.
Please confirm that the DHCP serv-
er in the LAN has been opened, The
client connect Wi-Fi local network,
click "search" the automatic list
display. (If there are multiple smart
alarm devices, click select to add in
the search list.
Enter name and default password
123456, select 'save' to add a smart
security accessory.
4.1.2 Create new security accessory by scanning
Search has been
added this HUB and
no add any HUB.
18
Android/IOS User Manual
① Enter alarm settings.
② manual operation create new
alarm.
③ Start Train and begin activate
the device.
4.1.3 Create new security accessory by training
③ When the signal is received, the
address is displayed Name, se-
lect storage,add smart home alarm
equipment (see right chart).
19
Android/IOS 使用说明
Android/IOS User Manual
① Enter alarm settings
② Click create embedded alarm
device.
③ Select one of the embedded
alarm type,and then input the
threshold.
4.1.4 Create embedded alarm device
④ Enter the name,and select
"save" to create the built-in
alarm perimeter(see right chart)
20
Table of contents
