Wenshing WS-VIDEO-USB User manual

WENSHING®© Wireless Digital Security Camera
Wireless Digital USB Receiver
2.4GHzGFSK Hopping
Model: WS-CAMERA-USB / WS-VIDEO-USB
Vision History
Version
Date
Changes
V1.01
Nov.01,2010
1st Edition
V1.02
Dec.15,2010
2st Edition
V1.03
Jan.17,2011
3st Edition
V1.04
Feb.11,2011
4st Edition

WS-CAMERA-USB / WS-VIDEO-USB P.1
Definition of Parts
Wireless Digital Security Camera
Wireless Digital USB Receiver
DC in 5V
Antenna
Tripod Screw Hole
Illuminator
lens
Illuminator Switch/ Pairing button
Power Switch
Microphone
USB interface
Power Indicator
Connecting Indicator

WS-CAMERA-USB / WS-VIDEO-USB P.2
Specification
Wireless Digital Security Camera
Lens：1/4”CMOS sensor (640x480)
Omni directional Microphone
Battery：Built in 450mALi-ion battery
Operation period：1 hour
Illumination：White LED
Power supply：B Type Mini USB DV 5V/1A
Weight：40.2g (include the battery and antenna)
Wireless Digital USB Receiver
Support system：Microsoft Windows2000/XP/Vista/WIN7
Resolution:
4-split screen: 5~8 framesat 320x240 (QVGA)
Single screen: 0~16 framesat 640x480 (VGA)
Weight：22.4g
RF Spec
Frequency：ISM 2400~2483MHz hopping
Transmission Power：100mW (20dBm)
Modulation Mode：GFSK
Operating Environment
Operating Temperature：0℃~+50℃
MemorizingTemperature：-10℃~+60℃
Certification：FCC/NCC
Certification
FCC Wireless Digital Security Camera：OYQWS-CAMERA
FCC Wireless Digital USB Receiver：OYQWSVIDEOUSB
NCC Wireless Digital Security Camera：CCAB10LP5650T2
NCC Wireless Digital USB Receiver：CCAB10LP5660T5
USB 介面

WS-CAMERA-USB / WS-VIDEO-USB P.3
Dimension Diagram
Wireless Digital Security Camera

WS-CAMERA-USB / WS-VIDEO-USB P.4
Wireless Digital USB Receiver
