Wersi SONIC OAX1 User manual

OAX1 - OAX500 - OAX600 - OAX700
OAX800 - PERGAMON OAX1000
Operating Manual
Brand Owner and Development

Imprint & User Content
2Operating Manual
Imprint & User Content
Operating Manual for
Keyboard OAX1
Orgel OAX500LS
OAX600, OAX600LS
OAX700, OAX700LS
OAX800LS
PERGAMON OAX1000
Software version on release:
V2.86
Date: 9. November 2021
OAX Ideas and Design: Ulrich Wildhack
OAX Programming: Ulrich Wildhack, Part time: Torsten Reichold, Tom Kolorz, Dennis Noppeney
Copyright © 2021 by
MUSIC STORE professional GmbH
Istanbulstraße 22-26
51103 Cologne
Germany
E-Mail: [email protected]
Website: www.wersi.net
All rights reserved.
We reserve the right to make technical changes to the hardware and software of the OAX instruments
without prior notice. We do not guarantee that all the properties described in this manual will be consistent
with those of an OAX instrument currently delivered.
Reproduction, translation, microfilming as well as storage and processing in electronic systems is not
permitted without our express consent and violates the copyright law.

OAX-System 3
User Content
Imprint & User Content................................................................................................................ 2
1Safety instructions.................................................................................................... 14
2Legal notices............................................................................................................. 15
3First commissioning.................................................................................................. 16
3.1 Connections.........................................................................................................................16
General connections behind the cover flap...................................................................................16
Additional connections OAX 500 - 600...........................................................................................17
Additional connections OAX 700....................................................................................................17
Additional connections OAX 800 - 1000.........................................................................................17
3.2 Connect...............................................................................................................................18
3.3 Switching on and off ............................................................................................................19
Turn On...........................................................................................................................................19
Switch off........................................................................................................................................19
Switch off/restart (reset)................................................................................................................19
3.4 Connections/controls at the front ........................................................................................20
Headphone.....................................................................................................................................20
Pitch Bend and Modulation Controller ..........................................................................................20
USB-Connecters..............................................................................................................................20
DVD/Blu-ray-Drive (not OAX 1) ....................................................................................................20
3.5 Remote control for LED-light control in music desk (not OAX 1)............................................21
4Overview of the control panels................................................................................. 23
4.1 Tempo/Data Wheel and Transposer.....................................................................................23
4.2 Sound Buttons.....................................................................................................................24
Subcategories for each sound button............................................................................................26
Favorites for each sound button....................................................................................................26
Own mapping for each sound button ............................................................................................27
4.3 How can I use the drawbar sound?.......................................................................................28
Changing between the different organ models .............................................................................28
The Live Controls OAX 1 - 500 - 600 - 700......................................................................................30
The Live Controls OAX 800 - 1000..................................................................................................31
The WERSI OX7...............................................................................................................................32
4.3.4.1 Additional setting options.........................................................................................................34
The WERSI VB3...............................................................................................................................36
4.3.5.1 VB3 Rotor-Settings....................................................................................................................38
Saving your own drawbar settings.................................................................................................39
4.4 Accordion LIVE operation.....................................................................................................40
4.5 Silbermann Church Organ ....................................................................................................44
Historical Information ....................................................................................................................44
Quickly select the Silbermann organ via the Total Presets............................................................45
How can you make music with the Silbermann organ?.................................................................46
4.5.3.1 Historical View 1 .......................................................................................................................48
4.5.3.2 Modern view 2..........................................................................................................................49
4.5.3.3 Church acoustics.......................................................................................................................49
Register the manuals on your organ..............................................................................................50
Possibilities of the standard and sound controller.........................................................................51
Save registrations in a Total Preset................................................................................................52
4.6 Select Total Presets..............................................................................................................53

Imprint & User Content
4Operating Manual

OAX-System 5

Imprint & User Content
6Operating Manual

OAX-System 7

Imprint & User Content
8Operating Manual

OAX-System 9

Imprint & User Content
10 Operating Manual
4.7 Switch on or off the sounds on the manuals .........................................................................53

OAX-System 11
OAX 1 - 500 - 600 - 700...................................................................................................................53
OAX 800..........................................................................................................................................54
OAX 1000........................................................................................................................................54
4.8 Global Manual Controls .......................................................................................................54
Global Manual Controls for OAX 1 - 500 - 600 - 700......................................................................55
Global Manual Controls for OAX 800 and OAX 1000 .....................................................................56
4.8.2.1 Preset Edit.................................................................................................................................56
4.8.2.2 Manual Edit...............................................................................................................................57
Description of the General Global Manual Controls......................................................................59
4.8.3.1 WERSIChord..............................................................................................................................60
4.8.3.2 Fast operation Reverb...............................................................................................................60
4.8.3.3 Fast operation Chorus...............................................................................................................62
4.8.3.4 Fast operation Delay.................................................................................................................63
4.8.3.5 LM-Hold ....................................................................................................................................64
4.9 Accompaniments Styles .......................................................................................................65
Subcategories for each Accompaniment button ...........................................................................67
Favorites for each Accompaniment button ...................................................................................68
Own mapping for each Accompaniment button............................................................................68
4.10 Accompaniments MIDI and AUDIO.......................................................................................69
ACC Controls OAX 1 - 500 - 600 - 700.............................................................................................69
ACC Controls OAX 800 - 1000.........................................................................................................70
Sound To Styles (only OAX 1 - 500 - 600 - 700)..............................................................................70
4.11 Effect-Sounds ......................................................................................................................70
4.12 Usper panel Accompaniment Controls..................................................................................72
4.13 User panel General Volume, Microphone and Light ..............................................................73
OAX 1..............................................................................................................................................74
OAX 500..........................................................................................................................................74
OAX 600 - 700.................................................................................................................................75
OAX 800 - 1000...............................................................................................................................75
OAX 800UP - 1000UP......................................................................................................................76
4.14 Control manual volumes ......................................................................................................76
Volume of sounds on manuals for OAX 1 - 500 - 600 - 700 ...........................................................77
Volume of the sounds on the manuals for OAX 800......................................................................77
Volume of the sounds on the manuals for OAX1000.....................................................................77
Volume of styles, MIDI and audio files...........................................................................................77
4.15 Pitch- and Modulation .........................................................................................................78
Wheels for OAX 1 - 500 - 600 - 700 - 800 –PERGAMON 1000.......................................................78
Wheels for OAX 1000UP.................................................................................................................78
5The simple EASY display or the PROFI display ........................................................... 79
6The EASY-Display...................................................................................................... 80
6.1 Overview upper, lower and pedal ........................................................................................81
The OAX 1000 with three manuals.................................................................................................81
6.2 The EASY Manual Controller.................................................................................................82
6.3 The accompaniment in the EASY Mode ................................................................................85
Styles Settings.................................................................................................................................85
6.3.1.1 Chord recognition.....................................................................................................................85
6.3.1.2 Style Volumes ...........................................................................................................................87
Settings for MIDI sequences...........................................................................................................88
6.4 Play styles, MIDI sequences or AUDIO files directly from the USB stick..................................90
6.5 Import styles from USB stick ................................................................................................91
6.6 Import MIDI sequences or audio files from the USB stick ......................................................92

Imprint & User Content
12 Operating Manual
7The PROFI-Display.....................................................................................................93
7.1 Keyboard split point only for OAX1 keyboard .......................................................................95
7.2 Up to 16 sounds in PROFI mode............................................................................................96
7.3 Profi Manual Controls........................................................................................................100
The Manual Controller.................................................................................................................102
The Sound Controller ...................................................................................................................102
Dynamic, expression pedal, volume, and modulation curves .....................................................104
7.3.3.1 Select dynamic, expression pedal, volume, or modulation preset ........................................106
7.3.3.2 Recreate dynamic, expression pedal, volume, and modulation curves.................................107
7.3.3.3 Save your own newly-changed curve.....................................................................................109
Further adjustment options.........................................................................................................109
7.4 Profi ACC-Controls .............................................................................................................110
Styles Settings ..............................................................................................................................110
7.4.1.1 Range of chord recognition....................................................................................................111
7.4.1.2 Chord recognition...................................................................................................................112
7.4.1.3 Style Volumes.........................................................................................................................113
7.4.1.4 More ACC Settings (Styles and MIDI-Sequences)...................................................................114
Settings for MIDI sequences ........................................................................................................115
7.4.2.1 Settings Karaoke.....................................................................................................................118
7.5 Settings .............................................................................................................................120
7.6 Volume control in PROFI mode...........................................................................................122
7.7 WERSIChord ......................................................................................................................123
7.8 Sound list ..........................................................................................................................123
General notes on the sound list...................................................................................................123
Load sound onto a selector..........................................................................................................124
Finding sounds .............................................................................................................................125
Import of new sounds..................................................................................................................126
7.9 Accompaniment List ..........................................................................................................127
The 16 main groups......................................................................................................................127
The subgroups..............................................................................................................................128
Load ACC to play via the list.........................................................................................................128
The list of accompaniments.........................................................................................................129
Find styles, MIDI, or Audio files....................................................................................................130
Importing your own accompaniments.........................................................................................131
Sort your own accompaniments..................................................................................................133
7.9.7.1 Sort your own accompaniments on the eight USER subgroups.............................................133
Assign your own styles to the 12 style groups or change the existing assignment.....................135
Rename accompaniments............................................................................................................135
Exporting accompaniments .........................................................................................................135
7.10 Effects ...............................................................................................................................136
Set an effect preset as default or global......................................................................................137
General operation of effect programming ..................................................................................137
Set and save your own effects presets ........................................................................................138
7.10.3.1 The Reverb 1 and Reverb 2 programs................................................................................139
7.10.3.2 The Chorus .........................................................................................................................140
7.10.3.3 The delay............................................................................................................................141
7.11 CD-Player (not OAX1).........................................................................................................142
7.12 Audio Recorder..................................................................................................................143

OAX-System 13
8Select and save TOTAL PRESETS .............................................................................. 145
8.1 Overview Total Presets ......................................................................................................145
Select Total Presets via Bank Names............................................................................................145
Select Total Presets via List ..........................................................................................................147
Save your own Total Presets ........................................................................................................148
Save sheets in Total Preset...........................................................................................................151
Total Preset Live-Settings.............................................................................................................153
8.2 The Music Archive .............................................................................................................154
Open and close the music archive................................................................................................154
Choosing a title.............................................................................................................................155
Find specific titles.........................................................................................................................156
Creating favorites .........................................................................................................................158
Add your own songs to the music archive ...................................................................................159
Edit your own Total Presets in the Music Archive........................................................................160
9Changing mapping for sounds and accompaniment................................................. 161
9.1 Create or edit your own mapping.......................................................................................161
Map a Sound or Accompaniment.................................................................................................162
Delete individual mapping............................................................................................................162
Swap mapping places...................................................................................................................164
Delete Mapping for a button........................................................................................................164
9.2 Delete or freeze Favorites .................................................................................................. 165
Freeze favorites............................................................................................................................165
Delete favorites for a button........................................................................................................166
9.3 Global mapping an favorite settings ...................................................................................167
Direct select and mapping selection ............................................................................................167
Delete all favorites .......................................................................................................................169
Delete all your own mappings......................................................................................................170
10 Sound To Style (STS) ............................................................................................... 171
11 Activations ............................................................................................................. 172

Safety instructions
14 Operating Manual
1Safety instructions
If possible, read the entire operating manual - or at least these instructions and the chapter: "First
commissioning" - before putting the instrument into operation.
For your own safety, be sure to follow the basic precautions described below to avoid the risk of serious
injury or even fatal accidents, electric shocks, short circuits, damage, fire or other hazards.
These precautions include the following points, but they do not constitute a complete list or a final list.
Power supply
1. Use only the correct power supply required for the instrument.
2. Check the power supply with all connectors and the power cord at regular intervals for damage and
contamination.
3. Never place the power supply cables near strong heat sources such as heat eras or the like, do not
bend it excessively, do not place heavy objects on it and do not place it in places where you can step
on it, stumble over it and over it could roll.
4. Always pull the power cord on the plug and never on the cable from the socket to avoid damage.
5. If possible, do not connect the instrument to multiple sockets if other high-performance devices,
such as lighting systems, are already running over it.
6. During prolonged absence or thunderstorms, disconnect the power cord from the power outlet to
avoid damage caused by, for example, surges.
Installation site - Danger from water - Cleaning
Place the instrument in a stable place.
Avoid setting-up locations near strong heat sources or places that are subject to a sharp change in
temperature or humidity.
Ensure that the instrument on its back always has flawless ventilation.
Never place the instrument in close proximity to powerful radios such as fluorescent tubes,
televisions, mobile phones and others to avoid radiation that causes noise and degradation of sound
quality in your instrument can.
Do not place open flames (candles) or drinks on the instrument.
If electrically conductive objects or a liquid enter your instrument, immediately turn off
the instrument and unplug the power plug!
Do not return the instrument to operation until it has been inspected by a qualified WERSI customer service
technician. Never try to open the instrument yourself and make repairs or technical changes yourself.
Never put your instrument into operation immediately if you have just brought it from an unheated
environment (e.g. car) into a warm room. Wait until the instrument reaches room temperature to
avoid electrical damage from condensation and creep currents.
To clean your instrument, use only a soft cloth, at most slightly moistened, and not chemical
detergents or cleaning cloths.

OAX-System 15
2Legal notices
Software Copyrights
Their instrument comes from the latest generation of the WERSI-OAX series. The central control of all
functions is carried out and controlled by a PC system equipped with the Microsoft WINDOWS® 10 operating
system. The instrument is used to supply various PC programs that are copyrighted by either the
manufacturer or other companies. You will only receive these programs with the right to use them
exclusively on your instrument. The operation on other PC systems or instruments, the copying of the
programs (except for security purposes) as well as the transfer to third parties is expressly prohibited,
constitutes a violation of copyright and is therefore punishable. The license terms for the WINDOWS®
operating system can be found in the original documentation of Microsoft®.
Music Copyrights
Please also observe the copyright provisions for the public reproduction of protected music. This applies both
to the pieces of music you play yourself and to pieces of music that you play either from an audio CD or as an
MP3 or MIDI file through your instrument.
Warranty and notes on the operating system and hardware
Within the scope of the statutory provisions, the manufacturer assumes the warranty for instruments in
the unchanged hardware and software equipment supplied by the manufacturer.
The hardware used is controlled by the SystemCode and is calculated from all components used in
your instrument. The System Code is a distinctive fingerprint of your instrument. If components
(boards, RAM, processor ....) are replaced in your instrument, the System Code changes- This will
cause activations to be lost and the instrument will no longer be usable.
We expressly point out that in the event of malfunctions that have arisen:
by installing additional software programs that have not been supplied or expressly authorized by
WERSI and released for use and are therefore not compatible with or not used for the operating
system due to, for example, the current version of WINDOWS® programmed so-called "drivers"
by installing components that do not work optimally with the WERSI-OAX system
by installing replacement and auxiliary components not supplied by WERSI
warranty claim expires.
Therefore, before planning to install or install "foreign" software or hardware,
be sure to contact WERSI first.
In addition, it is extremely important for your instrument to function correctly that the entire WERSI folder,
including its subfolders, and the WINDOWS folder are not modified on the hard drive. No files and folders
may be deleted, moved and no other files stored in it (except for official software updates).
In case of malfunctions after interventions in the WINDOWS file system, only a modified
WERSI/WINDOWS version may be reinstalled!
Since in this case your self-created data is deleted, you always ensure a data backup –at appropriate
intervals or after larger storages!

First commissioning
16 Operating Manual
3First commissioning
3.1 Connections
General connections behind the cover flap
The connectors of the instrument can be found behind a flap on the back of the instrument. Use the two
handles on the right and left sides of the back to open. There you will find the following connections:
3 x DIN connectors (5-pin) connectors for MIDI 1 IN/THRU/OUT
3 x DIN connectors (5-pin) connectors for MIDI 2 IN/THRU/OUT
MIDI over USB (The OAX1 and OAX500 instruments do not have a "MIDI Over USB" port)
2 x mono outputs LINE OUTPUT 1 with LEFT (left channel) + RIGHT (right channel)
2 x mono outputs LINE OUTPUT 2 with LEFT (left channel) + RIGHT (right channel)
Connection of threshold via Sub-D jack with two side foot switches (is already wired)
Connection 17-button pedal via Sub-D jack (is already wired)
OAX 1 –500
1 x asymmetrical microphone input via 6.35 mm jack
2 x asymmetrical mono inputs LINE INPUT 1 with LEFT (left channel) + RIGHT (right channel) via 6.35
mm jack

OAX-System 17
OAX 600 –700 –800 - 1000
1 x symmetrical microphone input via 3-pole XLR recessed socket combined with 6.35 mm TRSjack.
With the small button to the left of the microphone input, a 48 volt phantom power for special
microphones can be switched on.
2 x symmetrical mono inputs LINE INPUT 1 with LEFT (left channel) + RIGHT (right channel) combined
via 3-pole XLR recessed socket with 6.35 mm TRS jack. With the small button to the left of the inputs,
the signal can be lowered by -20dB.
You will also see diverse connectors such as
PC mouse
PC keyboard
more USB ports
and other
With the current connection from 110V to 240V (47 Hz to 53Hz), the instrument can be operated
with different mains voltages (e.g. Europe and the USA).
Additional connections OAX 500 - 600
For the OAX500 and OAX600 models, the back of the net input and an audio-out with the jacks for left and
right are located at the bottom.
Additional connections OAX 700
For the OAX700 model, the front right of the full pedal is the mains input and an audio-out with the jacks for
left and right.
Additional connections OAX 800 - 1000
On the OAX 800 and OAX 1000 models, the main input is located on the front right of the full pedal, an audio-
out and audio-in with the jacks for left and right respectively.

First commissioning
18 Operating Manual
3.2 Connect
1. Open the flap on the back and guide the supplied power cord through the provided opening on the
left bottom (view from behind) of the SONIC top. Then connect the cable to the mains input on the
back of the instrument. Then connect the power cord to a properly installed and secured power
outlet.
The main power switch is located directly at the main power supply input. Turn the switch on (I). This
does not turn on the instrument yet.
To connect the power cord, use a power strip with a switch, DO NOT turn off the power strip before
the instrument is completely turned off.
The instrument does not always need to be disconnected from the power grid after playing.
However, this is recommended in case of prolonged absences or thunderstorms, e.g. to avoid
overvoltage damage caused by lightning.
2. Connect the instrument to an active speaker system or a mixing console through the audio outputs.
Of course, you can also use a headphone for the first commissioning. When using the LINE OUT's,
guide the audio cables through the provided opening on the left bottom (view from behind) of the
SONIC top and connect the cables to the right and left outputs of the desired LINE OUT's 1 or 2.
A direct speaker output for connecting passive speakers is not available.

OAX-System 19
3.3 Switching on and off
The on/off switch for normal play operation is located as a tip button on the far right of the control panel.
Turn On
Briefly press the Power On-Off tap button.
The instrument now automatically starts its startup process.
First, the WINDOWS® operating system is started and then the WERSI-OAX music system is
automatically loaded.
The boot process is finished when the control panel buttons stop flashing and either the
simple EASY display or the "PROFI display" is visible on the touch screen.
If the instrument is not shut down properly when it is turned off, a changed display surface appears the next
time you start it. For more information, see the Issues chapter in the Programming Manual SONIC.
Switch off
1. Briefly press the Power On-Off tap button.
2. A small menu appears on the display asking if you really want to turn off the
instrument.
3. Confirm this question by tapping the Yes display button and the instrument will now
start its shutdown process on its own.
To connect the power cord, use a power strip with a switch, DO NOT turn off the power strip before
the instrument is completely turned off.
If the on/off switch has been pressed accidentally, you can now by tapping on the No button to undo
the shutdown operation.
Switch off/restart (reset)
For example, if your instrument stops responding due to incorrect operation, you can start a RESET (Reset =
Restart) process by pressing the Power On-Off tap button for longer (several seconds until the shutdown
process begins).
Please use this shutdown procedure in case of emergency. In no case do you always turn off the
instrument via the longer hold of the Power On-Off tip button.

First commissioning
20 Operating Manual
3.4 Connections/controls at the front
Headphone
To the left of the submanual is headphone output HEADPHONE.
Connect your standard stereo headphones here.
Stereo jack: 6.3 mm
Recommended impedance: not too low, we recommend between 80 and 250 ohms.
Once you have plugged in the headphones, the two AUDIO outputs are muted in the default setting. This
means that the connected active boxes are no longer to be heard. To change this default setting, see the
Programming Manual SONIC.
Pitch Bend and Modulation Controller
On the left side of the submanual you will find the control unit for the pitch bend and the modulation wheel.
Pitch Bend
Movement bottom/top
Pitch change downwards or upwards. The Pitch
Bend always jumps back into the middle
position.
Modulation
position below -> no change
position above -> full effect
Change of sound, mode of action depending on
the sound with change of vibrato or the filters
or e.g. the volume of a new sound element.
Which sounds the two controllers have an effect on can be adjusted separately and stored in a total
presets.
USB-Connecters
[USB = Universal Serial Bus = Connecting from a computer to external accessories]
On the right side of the panel aperture are four USB ports to use your USB memory sticks (for loading/importing
and saving/exporting). Of course, you can also connect a USB mouse or a UBS keyboard there.
You do not need to log your USB stick off the (Windows) system before unplugging/removing it.
DVD/Blu-ray-Drive (not OAX 1)
