Wharfedale Pro DS-5957 User manual

USER MANUAL
MODEL: DS-5957 + AL-604
2.1 HDMI DVD HOME CINEMA KIT
PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor

TABLE OF CONTENTS
SAFETY PRECAUTIONS ------------------------------------------------------------------------------ 01
IMPORTANT SAFETY INSTRUCTIONS ----------------------------------------------------------- 03
NOTICE ----------------------------------------------------------------------------------------------------- 04
PLAYABLE DISCS---------------------------------------------------------------------------------------- 05
ACCESSORIES and PANEL -------------------------------------------------------------------------- 06
BASIC CONNECTION ---------------------------------------------------------------------------------- 07
REMOTE CONTROL ------------------------------------------------------------------------------------ 09
BASIC PLAYBACK ------------------------------------------------------------------------------------- 10
ADVANCED PLAYBACK ------------------------------------------------------------------------------ 11
SPECIAL FUNCTION PLAYBACK ------------------------------------------------------------------ 12
SYSTEM SETUP ----------------------------------------------------------------------------------------- 13
TROUBLE SHOOTING --------------------------------------------------------------------------------- 18
SPECIFICATIONS --------------------------------------------------------------------------------------- 19
SUBWOOFER----------------------------------------------------------------------------------------------20
CONTACT DETAILS------------------------------------------------------------------------------------- 22
PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor

SAFETY PRECAUTIONS
01
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE
SLOT, FULLY INSERT.
The symbol for CLASS II (Double Insulation).
The lightning flash with arrowhead symbol, within an equila-
teral triangle, is intended to alert the user to the presence
of uninsulated "dangerous voltage " within the product's en-
closure that may be of sufficient magnitude to constitute a
risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE, DANGEROUS HIGH VOLTAGES ARE
PRESENT INSIDE THE ENCLOSURE. DO NOT OPEN THE CABINET, REFER
SERVICING TO QUALIFIED PERSONNEL ONLY.
WARNING:
When replace the direct plug in power supply or a separable, cord-connected power
supply, the replacement must be exact duplicate, or one recommended by the manu-
facturer.
CAUTION:
This product utilizes a laser.
Use of controls or adjustments or performance of procedures other than those
specified here in may result in hazardous radiation exposure.
Do not open the cover and do not repair yourself. Refer servicing to qualified personnel.
DANGER: Visible and invisible laser radiation when open and interlock failed or
defeated. Avoid direct exposure to beam.
PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor

SAFETY PRECAUTIONS
02
Manufactured under license from Dolby Laboratories. " Dolby " and the double-D
symbol are trademarks of Dolby Laboratories. Confidential unpublished works.
Copyright 1992-1997 Dolby Laboratories. All rights reserved.
This product incorporates copyright protection technology that is protected by
method claims of certain U. S. Patents and other intellectual property rights owned
by Macrovision Corporation and other rights owners. Use of this copyright protection
technology must be authorized by Macrovision Corporation, and is intended for
home and other limited viewing uses only unless otherwise authorized by Macrovision
Corporation. Reverse engineering or disassembly is prohibited.
Consumers should note that not all high definition television sets are fully compatible
with this product and may cause artifacts to be displayed in the picture.
In case of 525 or 625 progressive scan picture problems, it is recommended that he
used switch the connection to the "standard definition" output. If there are questions
regarding our TV set compatibility with this model 525p and 625p DVD player, please
contact our customer service centre.
Disposal of your old appliance
1. When this crossed-out wheeled bin symbol is attached to a product, it means the
product is covered by the European Directive 2002/96/EC.
2. All electrical and electronic products should be disposed of separately from the
municipal waste stream via designated collection facilities appointed by the government
or the local authorities.
3. The correct disposal of your old appliance will help prevent potential negative
consequences for the environment and human health.
4. For more detailed information about disposal of your old appliance, please contact
your city office, waste disposal service or the shop where you purchased the product.
PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor

03
CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS GIVEN IN THIS MANUAL AND
THOSE MARKED ON THE UNIT. RETAIN THIS BOOKLET FOR FUTURE REFERENCE.
This set has been designed and manufactured to assure personal safety. Improper use can result in electric shock or fire
hazard. The safeguards incorporated in this unit will protect you if you observe the following procedures for installation,
use and servicing. This unit is fully transistorized and does not contain any parts that can be repaired by the user.
DO NOT REMOVE THE CABINET COVER OR YOU MAY BE EXPOSED TO DANGEROUS VOLTAGE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL ONLY.
PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor

04
PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor

* Player is DVD-Video, DVD+/-R, DVD+/-RW, VCD, CD-DA, CD-R, CD-RW compatible.
Region Management Information
This DVD Player is designed and manufactured to respond to the Region Management
Information that is recorded on a DVD disc. If the Region number described on the DVD
disc does not correspond to the Region number of this DVD Player, this DVD player can-
not play that disc.
This Region number of this DVD player is .
Audio &
Video
Audio
Disc size 12cm
single side, single layer / single side, double layer
PAL and NTSC DVD disc
Playback time 135min / 240min max.
Disc size 12cm / 8cm
CD disc
Playback time 74min/20min max.
JPG format disc
Getting Started
JPEG
Disc types
05
PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor

ACCESSORIES and PANEL
06
ACCESSORIES
FRONT PANEL
Audio/Video cable .................... 1
Remote control ......................... 1
Batteries..................................... 2
User Manual............................... 1
SEARCH
REPEAT A-BRPT
MENU
CLEAR
STOPSTEPPAUSE
VOLUME
PAL/NTSC
ANGLE
MUTE
AUDIO
F.FWDF.REV NEXTPREV
ZOOM
SETUP
1 2 3
456
7 8 9
0 10+
SUBTITLE
OSD
V.MODE
PROG
TITLE/PBC
REAR PANEL OUTPUT
1. HDMI OUTPUT
2. 2 CHANNEL OUTPUT
3. COAXIAL OUTPUT
4. VIDEO OUTPUT
5. Y, CB/PB, CR/PR OUTPUT
6. S-VIDEO OUTPUT
7. SCART OUTPUT
8. POWER LINE INPUT
6. STOP
7. PLAY
8. PREVIOUS
9. PAUSE
10. NEXT
1. STANDBY
2. REMOTE CONTROL SENSOR
3. TRAY
4. LED SCREEN
5. OPEN/CLOSE
SCART OUTPUT
DIGITALAUDIO OUT / VIDEO OUT
COAXIAL S-VIDEO
L
RVIDEO
YCB / PB CR / PR
2-CH AUDIO OUT
HDMI
110V-240V~ 50/60Hz
Model no.: DS-5957
POWER SOURCE: 110V-240V~ 50/60Hz 15W
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
CLASS 1
LASER PRODUCT
S/N:
2
Manufactured under license
from Dolby Laboratories.
"Dolby" and the double-D
symbol are trademarks of
Dolby Laboratories. Conf-
idential unpublished works.
Copyright 1992-1997 Dolby
Laboratories. All rights
reserved.
Apparatus Claims of U.S. Patent Nos.
4,631,603; 4,577,216; 4,819,098 and
4,907,093 licensed for limited viewing
uses only.
123457 86
USER MANUAL
PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor

BASIC CONNECTION
07
BASIC CONNECTION
S-VIDEO
VIDEOCOAXIAL
Y CB / PB CR / PR
VIDEO OUT / DIGITAL AUDIOOUT
L
R
2-CH AUDIO OUT
Connecting to a TV with Audio/Video cable
If the TV has an S-video input, connect the DVD player with an S-video cable.
When using an S-video cable, do not connect the yellow video cable.
To video input(yellow)
To audio inputs(red, white)
To S-video input
To S-video output
Connecting to a devices with HDMI faucet
Easy DVD hook-up guide: For the best possible picture, simply follow these guidelines and use the best
cables your TV accepts: Normal: Composite video Good: S-video
Better: Component video Best: HDMI video
HD DVD playback: Enjoy your entire DVD collection in brilliant high definition format. This DVD player
upconvert DVDs to your HDTV's native resolution, whether it's 480p, 720p, 576p or 1080i.
HDMI output: Use this output for HD conversion and experience stunning HD images and crisp digital
audio.
To Scart input
To Scart output
Connecting to a TV with Scart cable
SCART OUTPUT
DIGITALAUDIO OUT / VIDEO OUT
COAXIAL S-VIDEO
L
RVIDEO
YCB / PB CR / PR
2-CH AUDIO OUT
Model no.: DS-5957
POWER SOURCE: 110V-240V~ 50/60Hz 15W
PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor

BASIC CONNECTION
08
Connecting to an amplifier equipped with a digital audio input and TV
To COAXIAL
type digital
audio input
To Y video input
To CB/PB video input
To CR/PR video input
To Y video output To CB/PB video output To CR/PR video output
Coaxial cable
Connecting to a audio system and TV equipped with YUV video input
To audio inputs of the amplifier
To Y video input
To CB/PB video input
To CR/PR video input
To Y video output To CB/PB video output To CR/PR video output
S-VIDEO
VIDEOCOAXIAL
Y CB / PB CR / PR
VIDEO OUT / DIGITAL AUDIOOUT
L
R
2-CH AUDIO OUT
S-VIDEO
VIDEOCOAXIAL
Y CB / PB CR / PR
VIDEO OUT / DIGITALAUDIO OUT
L
R
2-CH AUDIO OUT
PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor

SEARCH
REPEAT A-B RPT
MENU
CLEAR
STOPSTEPPAUSE
VOLUME
PAL/NTSC
ANGLE
MUTE
AUDIO
F.FWDF.REV NEXTPREV
ZOOM
SETUP
1 2 3
456
78 9
0 10+
SUBTITLE
OSD
V.MODE
PROG
TITLE/PBC
09
REMOTE CONTROL
REMOTE CONTROL
1. OPEN/CLOSE DISC TRAY
2. V.MODE
3. OSD (On Screen Display)
4. SUBTITLE
5. TITLE/PBC
6. SEARCH
7. REPEAT
8. A-B REPEAT
9. SETUP
10. ENTER/PLAY
11. ZOOM
12. FAST REVERSE
13. FAST FORWARD
14. PAUSE
15. STEP
Function
16. MUTE
17. ANGLE
18. STANDBY
19. DIGITS AND 10+ BUTTONS
20. PAL/NTSC
21. CLEAR
22. MENU
23. CURSOR
24. PROGRAM
25. NEXT
26. PREVIOUS
27. AUDIO
28. STOP
29. VOLUME +
30. VOLUME -
Function
PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor

BASIC PLAYBACK
10
Fast forward and Fast reverse
1. Press F.FWD to fast forward through the disc.
Each time the F.FWD button is pressed, the
fast forward motion speed changes.
2. Press ENTER/PLAY to resume normal playback.
3. Press F.REV to fast reverse through the disc.
Each time the F.REV button is pressed, the
fast reverse motion speed changes.
4. Press ENTER/PLAY to resume normal playback.
Pause playback
1. Press PAUSE to pause playback (still mode).
The sound will be muted during still mode.
2. Press ENTER/PLAY or PAUSE to resume normal
playback.
Single step playback
1. Press STEP continuous to single step forward
to the next frame in the video.
2. Press ENTER/PLAY to resume normal playback.
Preparations
When you want to view a disc, turn on the TV and
select the video input connected to the DVD player.
NOTES:
1.
Previous and Next
During playing, press PREV key can back to start
of this chapter, then each press this key
Each press of NEXT key during playing will skip
the current chapter and play the next one.
will skip a
chapter until the start of the disc.
Stop playback
1. Press STOP button to go to stop mode, the TV
screen will show the start logo.
2. Press ENTER/PLAY to resume playback from the
location where playback is stopped or from the
beginning of the disc.
3. Press STOP twice to stop completely.
With certain disc
types, such as DVD, the player can resume from
the point where it was stopped.
Basic playback
1. Press STANDBY in the front panel, the DVD
player turns on and the TV screen will display
the start logo. If a disc is already in the tray, it
will begin to play once the power is on.
2. Press OPEN/CLOSE to open the disc tray,
place a disc on the disc tray.
There are two different disc sizes. Place the
disc in the correct guide on the disc tray. If the
disc is out of the guide, it may damage the disc
and cause the DVD player to malfunction.
Do not place a disc which is unplayable in this
DVD player.
3. Press OPEN/CLOSE to close the disc tray, the
playback will automatically start.
Some discs may not playback automatically,
you can press ENTER/PLAY button to start
playback.
4. Some discs may start playback with a menu,
use the cursor button on the remote control to
select menu options and press ENTER/PLAY
to start, or press digits to select a menu options
directly.
PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor

11
ADVANCED PLAYBACK
OSD
Press this button and the screen will display some
information about disc, such as : " Title Elapsed " ,
" Title Remain ", " Chapter Elapsed ", " Chapter
Remain " and " Display Off ".
SUBTITLE
Press this button and the screen will display "SUBTI-
TLE 01/XX XXXXX", "01" indicates the ordinal
number of this language; "XX" indicates total number
of language; "XXXXXX" indicates the language of
country. (The number of language depends on disc).
V.MODE
This button can set VIDEO output among "CVBS" ,
"YUV" , "RGB" , "P-Scan" or "HDMI" .
Note: The screen disappear when press this button,
press this button continuously until the screen turn
normal.If there are picture interferences or no picture,
please press "V.MODE" to correct it.
IMPORTANT NOTE:
THE FOLLOWING FUNCTIONS ARE APPLICABLE ONLY TO DVD DISCS. IF OTHER DISC FORMATS ARE
PLAYED, SCREEN DISPLAYAND OPERATION WILL BE DIFFERENT.
CLEAR
This button can be used to clear any incorrect
information that may have been input.
PAL/NTSC
Press this button will switch among NTSC, PAL and
MULTI(AUTO).
A-B REPEAT
Press " A-B RPT " to begin start-point, press again
to set an end point and complete setting. The
selected section A-B will be repeated. The third
press will cancel this function.
MENU
Press this button to display root menu, select item
according to your preference. (This key is valid to
DVDs possessing multi-layer menu.)
PROGRAM
Press this button and the screen will display info
window , press digits button to input the program
number what you want, when finished, move the
cursor to select the " Start " logo, at this time the unit
will start program playback and the screen will display
"Program" logo.
If you want to cancel this function, press " STOP "
and then press ENTER/PLAY .
ANGLE
For discs with this feature, pressing this key to view
action from different angles.(Depending on the DVD)
SEARCH
Press this button one time, the screen will display
search menu, the second will cancel. in search menu,
you can use UP/DOWN cursor button to select item
what you wanted, Then press ENTER/PLAY button to
confirm.
According to some DVD discs,
The PBC allows the user to play Video CDs interac-
tively. If PBC is ON, the user can use the digits buttons
to select track only in the menu, if PBC is OFF, the
user can select the track directly.
pressing this button
will display the title menu, you can then press the
digits to select the preferred chapter.
TITLE/PBC(Playback Control)
ZOOM
Press this button to zoom into the picture.
Each time the button is pressed, the magnification
level will change.
REPEAT
Press REPEAT and Chapter repeat will be
displayed on screen, the second press will display
Title repeat, the third press will display All repeat,
the four press will cancel repeating.
PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor

12
ADVANCED PLAYBACK
AUDIO CHANNEL CHOOSE
Press this button on remote control to change the
mode of audio.
For example: Audio 1/2: AC 3 2 CH English
Audio 2/2: AC 3 5.1 CH English
Note: When press this button continuously, you must
above 3 seconds interval.
VOLUME and MUTE
Press " + " at the right of VOLUME to increase
volume, " - " to decrease to volume. The first press
of MUTE will display MUTE (no voice), the second
press will return to normal playback.
JPEG DISC PLAYBACK
When playing JPEG disc, a navigation menu will be displayed automatically if the disc is loaded in succession.
In the menu, use UP or DOWN in the cursor to select a file,then press "ENTER/PLAY", the file will be play with
a slide-show. Press PREV or NEXT to select the previous or the next picture. Press PAUSE to pause the
current picture for enjoying, when press ENTER/PLAY, it will return to normal playing. Press ZOOM to start
zoom function. When ZOOM is on, press F.REV and F.FWD to select different enlargement ratio, When ZOOM
is on, press CURSOR key can move the enlargement picture.
HDMI FUNCTION
HDMI, Hi Definition Digital Multimedia Interface supports EDID and DDC2B. This connection operates quickly
and conveniently, providing the best in both audio and video playback.
HDMI can transfer uncompressed, high-resolution picture and multi-channel audio digitally up to speeds of
5 GBps. HDMI can support all ATSC HDTV standards not only meet resolution 1080i,which can supply the
highest picture quality. but also support DVD Audio and other most advanced digital audio format, and support
8 channel 96kHz digital audio transmission. You only need one HDMI line connected, relieve audio connected.
At the same time, the spare space which HDMI standard supplied can apply in the video updating. HDMI can
collocate with HDCP (High-bandwidth Digital Content Protection), avoid copyright film being copyed without
authorization.
AUDIO CD PLAYBACK
When playing Audio CD disc, a navigation menu will be displayed
automatically if the disc is loaded in succession.
In the menu, use UP or DOWN button in the cursors to select the
file, then press "ENTER/PLAY" to play this file. In this page, press
PREV or NEXT can go to the previous or next page.
TRACK01
TRACK02
TRACK03
TRACK04
TRACK05
TRACK06
00:00 00:00
001/010
CD
CD
CD
CD
CD
CD
PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor

SYSTEM SETUP
13
When Last Memory is ON. Each time when you
open the tray to remove the disc.
1.6 LAST MEMORY
LAST MEMORY: This function is convenient when
you want to continue viewing a disc from the point
where you were watching before. Unlike the resume
function, the Last Memory function is effective even
the DVD is removed from the player.
1.5 SCREEN SAVER
SCREEN SAVER: If the screen saver is on,then there
will be an animated picture on the screen whenever
the DVD player is idle for a certain time.
Setup TV screen format, video type and all DVD
functions.
1. GENERAL SETUP PAGE
ANGLE MARK: Users can select a particular camera
angle when playing a DVD which offers multiple
angles.
1.2 ANGLE MARK
1.3 OSD LANGUAGE
On Screen Display (OSD) Language: Users can
select the whole setup menu and on-screen display
language.
SYSTEM SETUP
When you press SETUP button on the remote
control, the setup menu will be displayed. It include
General Setting , Audio Setup , Video Setup,
Preference Setup, Password Setup and Exit Setup
menu.
1.Within the setup menu, you can use UP, DOWN,
LEFT and RIGHT buttons on the remote control
to move the cursor, and then press the
ENTER/PLAY button to make your selection.
Press LEFT can return to the previous menu.
2.To exit setup menu, you can select the exit
setup menu or press SETUP button.
The TV Display which select the different ratio of
display format and the screen of TV, There are
various types of display on screen for different
matches between Disc and TV.
Note:
No matter which display format is selected, a
picture recorded in standard 4:3 format always
displays in the 4:3 aspect ratio.
The display format of DVD titles may vary; please
refer to the information that accompanies your
specific DVD title.
If the DVD title is recorded in 16:9 wide display
format while the TV is a standard 4:3 screen,
horizontal compression of the image will result.
Some DVD titles may be recorded in special
formats. In such cases, the DVD titles will always
appear on the screen in their original format,
regardless of which TV display format you select.
1.1 TV DISPLAY
General Setup Page
Set TV Display Mode
Normal/PS
Normal/PS
Wide
TV Display
Angle Mark
OSD Lang
Captions
Screen Saver
Last Memory
PS
ON
ENG
OFF
ON
OFF
1.4 CAPTIONS
CAPTIONS: For hearing-impaired people.
the picture can be displayed with recorded explanatory
captions.
PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor

SYSTEM SETUP
14
2.1 SPEAKER SETUP PAGE
2.1.1 DOWNMlX SETUP
DOWNMIX MODE: sets front speakers to LT/RT
STEREO.
The first 2 settings (LT/RT,STEREO) downmix the
sound Signal for 2-Speakers. This setting allows
you to enjoy a surround sound effect with onIy two
speakers. For this reason a setup for additional
speakers (described in the following sections) is
disabled when DOWNMlX MODE is set to these
settings.
Analog Audio Setup Page
DOWNMIX
LT/RT LT/RT
Stereo
Set DOWNMIX Mode
2.2 SPDIF SETUP PAGE
2.2.1 SPDIF OUTPUT
SPDIF OUTPUT MODE: Sets the audio outputs.
Spdif Setup Page
Spdif Output
LPCM Output
OFF
48K
SPDIF OFF
SPDIF/RAW
SPDIF/PCM
Setup Spdif
This DVD player includes three kinds of audio output:
1. SPDlF OFF: An analog surround sound format is
output through the back-paneI connections for L, R.
2. SPDIF/RAW or SPDIF/PCM: This surround sound
format is output to a Dolby Digital decoder through
the coaxial connectors on the back-panel of the
product.
Note:
The DVD player simultaneously outputs a Dolby
Digital signal and an analog signal, but you have
to select the Analog output if you want to take
advantage of the Karaoke effects.
2.2.2 LPCM OUTPUT
LPCM (Linear Pulse Code Modulation) OUTPUT:
Includes LPCM 48K and LPCM 96K for audio format.
2. AUDIO SETUP PAGE
Audio Setup Page
Go To Audio Setup Page
Speaker Setup
SPDIF Setup
3.1 COMPONENT
COMPONENT (T
COMPONENT
: Sets the video output. he HDMI option
must select “OFF” , the option is valid.)
3. VIDEO SETUP PAGE
Video Setup Page
Component
TV Mode
Quality
HDMI Setup
RGB CVBS
YUV
RGB
Component
CVBS: Set to COMPOSITE Output
YUV: Set to COMPONENT Output
RGB: Set to RGB Output
PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor

SYSTEM SETUP
15
3.3.2 BRlGHTNESS
BRIGHTNESS: Sets the brightness level of video
output.
Press right button the TV will display a value
Press LEFT/RIGHT button to adjust, then press
ENTER/PLAY button to confirm and return upon
menu.
3.3 Video Quality SETUP PAGE
3.3.1 SHARPNESS
SHARPNESS: Sets the sharpness level of video
output.
Video Quality Setup
Sharpness
Brightness
Contrast
Gamma
HUE
Saturation
LUMA Delay
Sharpness
Mid
00
00
NONE
00
00
1T
HIGH
MEDIUM
LOW
TV MODE: Sets the scan mode to same of your TV.
If there are picture interferences or no picture, please
press "V.MODE" to correct it. he component option
must select YUV , the TV MODE option is valid.
( T
)
3.2 TV MODE SETUP
Press right button the TV will display a value
Press LEFT/RIGHT button to adjust, then press
ENTER/PLAY button to confirm and return upon
menu.
3.3.3 CONTRAST
CONTRAST: Sets the contrast level of Video output.
3.3.4 GAMMA
GAMMA: Sets the gamma value of the Video.
Press right button the TV will display a value
Press LEFT/RIGHT button to adjust, then press
ENTER/PLAY button to confirm and return upon
menu.
3.3.5 HUE
HUE: Sets the hue value of the Video.
3.3.6 SATURATION
SATURATION: sets the saturation of the video.
Press right button the TV will display a value
Press LEFT/RIGHT button to adjust, then press
ENTER/PLAY button to confirm and return upon
menu.
3.3.7 LUMA DELAY
LUMA ( Luminance ) DELAY: Sets the luminance
delay of video output depend on the TV's brightness,
color. It sets 1T commonly for DVD.
3.4 HDMI SETUP PAGE
3.4.1 HDMI
HDMI Setup
HDMI
Resolution
HDCP Setup
VIDEO Format
AUDIO Source
HDMI SRC
HDMI
OFF ON
OFF
OFF
RGB
12S
OFF
HDMI SETUP
Resoiution
3.4.2 RESOLUTION
HDMI
Resolution
AUDIO Source
HDMI SRC
HDCP Setup
VIDEO Format
ON 480I
OFF
RGB
12S
OFF
480P(720)
720P(60HZ)
1080i(60HZ)
576i
576p(720)
720p(50HZ)
1080i(50HZ)
HDMI SETUP
HDMI
Resolution
AUDIO Source
HDMI SRC
HDCP Setup
VIDEO Format
HDCP Setup
3.4.3 HDCP Setup
ON
OFF
RGB
12S
OFF
ON
OFF
PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor

16
SYSTEM SETUP
HDMI SETUP
HDMI
Resolution
AUDIO Source
HDMI SRC
HDCP Setup
VIDEO Format
AUDIO Source
3.4.5 AUDIO SOURCE
ON
OFF
RGB
12S
OFF
SPDIF
12S
HDMI SETUP
HDMI
Resolution
AUDIO Source
HDMI SRC
HDCP Setup
VIDEO Format
VIDEO Format
3.4.4 VIDEO Format
ON
OFF
RGB
12S
OFF
RGB 4:4:4
Ycbcr 4:4:4
3.4.6 HDMI SRC
HDMI SETUP
HDMI
Resolution
AUDIO Source
HDMI SRC
HDCP Setup
VIDEO Format
HDMI SRC
ON
OFF
RGB
12S
OFF
OFF
ON
The preference setting is active only when no disc
or stop completely, and the setting is effective on
next time power on till exchanging the saved setting.
4. PREFERENCE SETUP PAGE
Note: How to Set the TV Type?
You may switch the NTSC/PAL setting of the DVD
player to match the video signal of your TV.
The table below shows what kinds of disc are com-
patible with each setting (AUTO, PAL and NTSC)
Preference Page
TV Type
PBC
Audio
Subtitle
Disc Menu
Parental
Degion
Default
AUTO
ON
ENG
ENG
ENG
USA
PAL
NTSC
Auto
Set TV Standard
4.1 TV TYPE
TV TYPE: This player supports different TV output,
including MULTI(Auto), NTSC, and PAL systems.
lf your TV support only NTSC or PAL and had you
inadvertently selected the wrong TV type, he TV
screen will become flickering and black-and-white.
In this case, you should press the SETUP button
to set as following Note.
4.3 AUDIO
AUDIO: Sets the preferred audio language as the
default when playing DVD. (IF DVD support these
languages)
4.2 PBC
PBC MODE: Sets the PBC (Playback Control) to be
on or off .
PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor

17
SYSTEM SETUP
4.4 SUBTITLE
SUBTITLE: Sets the preferred subtitle language as
the default when playing DVD.(if DVD support these
languages)
4.5 DISC MENU
DISC MENU: Sets the preferred menu language as
the default when playing DVD.(if DVD support these
languages)
4.6 PARENTAL
PARENTAL: The parental control function works in
conjunction with the different censorship classes
assigned to DVDs. These classes help to control the
types of DVDs that the family watches, There are up
to 8 censorship classes for DVDs.
Note:
The PARENTAL is changeable when PASSWORD
MODE set to OFF.
After setting the level of parental control. please
set the password as ON to perform the lock of
changing.
4.7 COUNTRY REGION
COUNTRY REGION Sets the preferred country
region language as the default when playing DVD.
( if DVD support these languages)
5.1 PASSWORD MODE
PASSWORD MODE: Sets the function operation to
be ON for locking the parental function, and OFF for
changing the parental level.
There will be old password confirmation when
ON/OFF interchange.
The initial password is 136900
5. PASSWORD SETUP PAGE
Password Setup Page
Password Mode
Password
ON
ON
OFF
Password Mode
4.8 DEFAULT
DEFAULT: Resets to all the manufacturer's original
settings for this DVD player Press ENTER/PLAY to
perform the reset.
5.2 PASSWORD CHANGE
PASSWORD CHANGE: you can change the
password, please type 6 numerals as new password.
Password Setup Page
Password Mode
Password
On
Change
Change Password
Old Password
New Password
Confirm PWD
OK
PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor

Please check the following guide for the possible cause and solution for a problem before contacting the
nearest service center or dealer for repairs.
SYMPTOMS AND CORRECTIONS
Check to make sure that the power connection is secure.
No power
SYMPTOMS CORRECTIONS
No picture
No sound
Failed to Play
Make sure the connection between the player and the TV is secure.
Make sure that the TV is in good working condition.
Make sure that the TV and AMP are in good working condition
and setup properly.
Check that the disc is properly inserted.
Clean the disc.
Failed to respond to
remote control
Remove obstacles between remote control and unit.
Aim remote control at the sensor on the front panel.
Check batteries and replace them if necessary.
Picture Disturbance
Check the disc for dirt and scratches. Clean or replace disc.
Shut down the unit, wait ten seconds, and restart the unit.
Failed to work
with keys
Power surges or other electrical phenomena.
Shut down the unit, wait ten seconds, and restart the unit.
Make sure the connection between the player and other devices
are secure.
Please press "V.MODE" button continuously until the picture returns
to normal.
18
TROUBLE SHOOTING
PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor
