Whirlpool AMW509/IX Operating instructions

MICROWAVE OVEN
EN User and maintenance manual

I

ENGLISH
LANGUAGES
EN PAGE
TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS ............. 2
DECLARATION OF CONFORMITY ..............................5
SAFEGUARDINGTHE ENVIRONMENT......................5
INSTALLATION................................................... 6
INSTALLINGTHE APPLIANCE ...................................... 6
PRIORTO CONNECTING................................................6
AFTER CONNECTING......................................................6
THE APPLIANCE ................................................ 7
ACCESSORIES....................................................................7
CONTROL PANEL DESCRIPTION ...................... 8
KNOB ANDTOUCH KEYS............................................... 8
LEFTHAND DISPLAY......................................................8
RIGHTHAND DISPLAY................................................... 8
SETTINGTHE CLOCK.......................................................9
ON/OFF................................................................................9
JET START............................................................................ 9
PAUSE/RESUME/RESTART COOKING........................9
COOLING DOWN..............................................................10
SELECTING A FUNCTION .............................................. 10
SETTING FOOD CLASSES.............................................. 10
SETTING THE WEIGHT ....................................................11
TURNING FOOD................................................................ 11
SETTINGTHE GRILL LEVEL............................................ 11
SETTINGTHETEMPERATURE.......................................11
SETTINGTHE MICROWAVE POWER ..........................12
SETTINGTHE DURATION...............................................12
QUICK PREHEAT ...............................................................12
KEY LOCK.............................................................................12
FUNCTION DESCRIPTIONSTABLE ................... 13
COOKINGTABLE................................................ 15
TESTED RECIPES................................................ 18
RECOMMENDED USE ANDTIPS ....................... 19
CLEANING AND MAINTENANCE...................... 20
TROUBLESHOOTING GUIDE............................. 21
AFTERSALES SERVICES ................................... 21
SCRAPPING OF HOUSEHOLD APPLIANCES.... 21

EN 2
IMPORTANT SAFETY INSTRUCTIONS
These instructions are also available on website: www.whirlpool.eu
YOUR SAFETY AND THAT OF OTHERS ISVERY IMPORTANT
This manual and the appliance itself provide important safety
warnings, to be read and observed at all times.
This is the danger symbol, pertaining to safety, which alerts
users to potential risks to themselves and others.
All safety warnings are preceded by the danger symbol and the
following terms:
DANGER Indicates a hazardous situation which, if not
avoided, will cause serious injury.
WARNING Indicates a hazardous situation which, if not
avoided, could cause serious injury.
All safety warnings give specic details of the potential risk present
and indicate how to reduce risk of injury, damage and electric shock
resulting from improper use of the appliance.
Carefully observe the following instructions:
- Use protective gloves to perform all unpacking and installation
operations.
- The appliance must be disconnected from the power supply before
carrying out any installation work.
- Installation and maintenance must be carried out by a qualied
technician, in compliance with the manufacturer’s instructions and
local safety regulations. Do not repair or replace any part of the
appliance unless specically stated in the user manual.
- Power cable replacement must be carried out by a qualied
electrician. Contact an authorised service centre.
- Regulations require that the appliance is earthed.
- The power cable must be long enough for connecting the Appliance,
once tted in its housing, to the main power supply.
- For installation to comply with current safety regulations, an all-pole
disconnect switch with minimum contact gap of 3 mm must be used.
- Do not use multiple plug adaptors if the oven is tted with a plug.
- Do not use extension leads.
- Do not pull the power supply cable.
- The electrical components must not be accessible to the user after
installation.
SAFETY RECOMMENDATIONS

EN 3
SAFETY RECOMMENDATIONS
- Do not touch the appliance with any wet part of the body and do not
operate it when barefoot.
- This appliance is designed solely for use as a domestic appliance for
cooking food. No other type of use is permitted (e.g.: heating rooms
or outdoor use).The Manufacturer declines all responsibility for
inappropriate use or incorrect setting of the controls.
- This appliance is intended to be used built-in. Do not use it
freestanding.
- The appliance and its accessible parts become hot during use.
Care should be taken to avoid touching heating elements.
- Very young (0-3 years) and young children (3-8 years) shall be kept
away unless continuously supervised.
- Children from 8 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and knowledge
can use this appliance only if they are supervised or have been given
instructions on safe appliance use and if they understand the
hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance should not be done by unsupervised
children.
- During and after use, do not touch the heating elements or interior
surfaces of the appliance: risk of burns. Do not allow the appliance to
come into contact with cloths or other ammable materials until all
the components have cooled down completely.
- At the end of cooking, exercise caution when opening the appliance
door, letting the hot air or steam exit gradually before accessing the
appliance. Do not obstruct the vent apertures.
- Use oven gloves to remove pans and accessories, taking care not to
touch the heating elements.
- Do not place ammable materials in or near the appliance: a re may
break out if the appliance is inadvertently switched on.
- Do not use the microwave oven for heating anything in airtight
sealed containers. The pressure increases and may cause damage
when opening or may explode.
- Do not use the microwave oven for drying textiles, paper, spices,
herbs, wood, owers, fruit or other combustible materials. Fire could
result.
- Do not leave the appliance unattended, especially when using paper,
plastic or other combustible materials in the cooking process. Paper
can char or burn and some plastics can melt if used when heating
foods.
- Use containers suitable for use in a microwave oven only.

EN 4
- Overheating the liquid beyond boiling point can occur without
evidence of bubbling. This could result in a sudden boil over of the
hot liquid.
- Do not use microwave oven for deep-frying, because the oil
temperature cannot be controlled.
- After heating baby food or liquids in a baby bottle or in a baby food
jar, always stir and check the temperature before serving.
Ensure the lid and the teat is removed before heating.
- If alcoholic beverages are used when cooking foods (e.g. rum,
cognac, wine), remember that alcohol evaporates at high
temperatures. As a result, there is a risk that vapors released by the
alcohol may catch re upon coming into contact with the electrical
heating element.
- Do not use microwave oven for cooking or reheating whole eggs
with or without shell since they may explode even after microwave
heating has ended.
- If material inside/outside the appliance should ignite or smoke is
observed, keep appliance door closed and turn the appliance o.
Disconnect the power cord or shut o power at the fuse or circuit
breaker panel.
- Do not over-cook food. Fire could result.
- Cleaning is the only maintenance normally required. Failure to
maintain the appliance in a clean condition could lead to
deterioration of the surface that could adversely aect the life of the
appliance and possibly result in a hazardous situation.
- Never use steam cleaning equipment.
- Do not use harsh abrasive cleaners or sharp metal scrapers to clean
the appliance door glass since they can scratch the surface, which
may result in shattering of the glass.
- Do not use corrosive chemicals or vapors in this appliance.
This type of appliance is specically designed to heat or cook food. It
is not designed for industrial or laboratory use.
- Do not remove any cover.The door seals and the door seal areas
must be regularly inspected for damage. If these areas are damaged
the appliance should not be operated until it has been repaired by a
trained service technician.
- Service only to be carried out by a trained service technician.
It is hazardous for anyone other than a trained person to carry out
any service or repair operation, which involves the removal of any
cover, which gives protection against exposure to microwave energy.
SAFETY RECOMMENDATIONS

EN 5
DECLARATION OF CONFORMITY
This oven, which is intended to come into contact with foodstus, complies with European Regulation
( ) n. 1935/2004 and has been designed, manufactured and sold in conformity with the safety
requirements of the“LowVoltage”directive 2006/95/CE (which replaces 73/23/CEE and subsequent
amendments), the protection requirements of“EMC”2004/108/CE.
SAFEGUARDING THE ENVIRONMENT
Disposal of packaging materials
The packaging material is 100% recyclable and is
marked with the recycle symbol ( ).The various
parts of the packing must therefore be disposed of
responsibly and in full compliance with local
authority regulations governing waste disposal.
Energy saving tips
- Only pre-heat the microwave oven if specied
in the cooking table or recipe.
- Use dark lacquered or enameled baking moulds
as they absorb heat far better.
- Switch the appliance o 10/15 minutes before
the set cooking time. Food requiring prolonged
cooking will continue to cook even once the
appliance is switched o.
Scrapping the product
- This appliance is marked in conformity with
European Directive 2012/19/EU, Waste Electrical
and Electronic Equipment (WEEE).
- By ensuring this product is disposed of
correctly, you will help prevent potential
negative consequences for the environment
and human health, which could otherwise be
caused by inappropriate waste handling of this
product.
- The symbol on the product or on the
accompanying documentation indicates that it
should not be treated as domestic waste but
must be taken to an appropriate collection
centre for the recycling of electrical and
electronic equipment.
SAFETY RECOMMENDATIONS

EN 6
INSTALLATION
After unpacking the appliance, make sure that it has not been damaged during transport and that the
appliance door closes properly.
In the event of problems, contact the dealer or the nearest After-sales Service.
To prevent any damage, only remove the appliance from its polystyrene foam base at the time of installation.
MOUNTINGTHE APPLIANCE
Read all the safety recommendations at pages 2, 3, 4, 5 before installing the appliance.
Follow the mounting instructions at page I when installing the appliance.
PRIORTO CONNECTING
Check that the voltage on the rating plate corresponds to the voltage in the home.
Do not remove the microwave inlet protection plates located on the side of the microwave oven cavity
wall.They prevent grease & food particles from entering the microwave inlet channels.
Ensure the microwave oven cavity is empty before mounting.
Ensure that the appliance is not damaged. Check that the microwave oven door closes rmly against the
door support and that the internal door seal is not damaged. Empty the microwave oven and clean the
interior with a soft, damp cloth.
Do not operate this appliance if it has a damaged mains cord, if it is not working properly, or if it has been
damaged or dropped. Do not immerse the mains cord in water. Keep the cord away from hot surfaces.
Electrical shock, re or other hazards may result.
If the power supply cord is too short, have a qualied electrician or serviceman installer an outlet near the
appliance.
The power supply cord must be long enough for connecting the appliance, once tting in its housing, to
the main power supply.
For installation to comply with current safety regulations, an all-pole disconnect switch with minimum
contact gap of 3 mm must be utilized.
AFTER CONNECTING
The appliance can be operated only if the microwave oven door is rmly closed.
The earthing of this appliance is compulsory. The manufacturer will accept no responsibility for injury to
persons, animals or damage to objects arising from the non-observance of this requirement.
The manufacturers are not liable for any problems caused by the user’s failure to observe these
instructions.
BEFORETHE USE

EN 7
USINGTHE APPLIANCE
THE APPLIANCE
1. Control panel
2. Cavity
3. Door
4. Upper heating element
5. Light
6. Data plate (not to be removed)
7. Glass plate turntable
ACCESSORIES
Fig. A Fig. B
Fig. C Fig. D
Fig. E Fig. F
A. Turntable support.
Use only with the glass plate turntable.
B. Glass plate turntable.
Use with all cooking cycles.
To be placed on the turntable support.
C. Wire rack.
To cook and bake.
D. Baking plate (only in some models).
Never use in combination with microwaves.
E. Crisp plate (only in some models).
Use the glass turntable as support.
F. Crisp handle (only in some models).
To remove the hot crisp plate.
The number and the type of accessories may vary according to which model is purchased.
ACCESSORIES NOT SUPPLIED
Other accessories can be purchased separately from the After-Sales Service.
NOTE: all of the accessories are dishwasher-safe.

EN 8
CONTROL PANEL DESCRIPTION
LEFT-HAND DISPLAY TOUCH KEYS KNOB TOUCH KEYS RIGHT-HAND DISPLAY
°C / W
KNOB ANDTOUCH KEYS
°C / W
ROTARY SWITCH KNOB
Turn this to navigate through the
functions and adjust all of the cooking
parameters.
6TH SENSE BUTTON KNOB
Press to select, set, access or conrm
functions or parameters and eventually
start the cooking program.
PAUSE – To pause a cooking cycle.
°C / W
POWER –To adjust the temperature, grill
level or microwave power.
ON/OFF –To switch the appliance ON or
OFF at any time. START – To run the cooking functions.
BACK –To return to the previous display
screen.
TIME –To set the clock and adjust the
duration of a cooking cycle.
LEFTHAND DISPLAY
This display shows the main cooking functions.
The selectable functions are displayed more
brightly.
The symbols indicate the function. For a full
description, see the table on page 13.
RIGHTHAND DISPLAY
This display shows the clock, the clusters for the
6th Sense and Manual cooking functions
and the details of all functions, and it helps to
adjust all cooking parameters.
USINGTHE APPLIANCE
