Whirlpool MWO 625 SL User manual

Gebrauchsanweisung
Instructions for use
Mode d’emploi
Gebruiksaanwijzing
Istruzioni per l’uso
Brugsanvisning
Bruksanvisning
Käyttöohje
Manual de utilização
Instrucciones para el uso
Instrukcje użytkowania
Használati utasítás
ИнструкциЯза употреба
Návod k použití
Návod na použitie
Instruc∑iuni de utilizare
Инструкции по эксплуатации

ENGLISH Page 4
Page 2 2
GREEK ΕΓΧΕΙΡΙΔΙΟ ΟΔΗΓΙΩΝ
FRANÇAIS Mode d’emploi Page 40
3

SAVE THESE INSTRUCTIONS CAREFULLY
Read these instructions carefully before using your
Model:
Microwave Oven
Following these instructions will ensure many years of
trouble-free use.
MWO 625 SL
and keep in a safe place.
4

1450W
900W
25L
Specifications
Model:
Rated Voltage:
Rated Input Power(Microwave):
Rated Output Power(Microwave):
Oven Capacity:
Turntable Diameter:
External Dimensions:
Net Weight:
270MM
Approx.1
230V~ 50Hz
485 X 410 X 29 MM 2.5
MWO 625 SL
2.88 kg
(a) Do not attempt to operate this oven with the door
open.It is important not to break or tamper with
(b) Do not place any object between the oven front face
and the door or allow soil or cleaner residue to accumulate
on sealing surfaces.
(c) WARNING: If the door or door seals are damaged, the
oven must not be operated until it has been repaired by
a competent person.
ADDENDUM
If the apparatus is not maintained in a good state of
cleanliness, its surface could be degraded and affect the
lifespan of the apparatus and lead to a dangerous situation.
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY
the safety interlocks.
5

To reduce the risk of fire, electric shock, injury to
persons or exposure to excessive microwave oven
energy when using your appliance, follow basic
precautions, including the following:
1. Warning: Liquids and other foods must not be heated
in sealed containers since they are liable to explode.
2. Warning: It is hazardous for anyone other than a
competent person to carry out any service or repair
operation that involves the removal of a cover which
gives protection against exposure to microwave energy.
3. This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been givensupervision or
instruction concerning useof the appliance in a safe way
andunderstand the hazards involved.Children shall not
play with the appliance.Cleaning and user maintenance
shallnot be made by children unless they are older than
8 and supervised.
4. Keep the appliance and its cord out of reach of
children less than 8 years.
5. Only use utensils suitable for use in microwave ovens
6. The oven should be cleaned regularly and any food
deposits should be removed.
7. Read and follow the specific:"PRECAU- TIONS TO
AVOID POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY".
8. When heating food in plastic or paper containers,
keep an eye on the oven due to the possibility of ignition.
IMPORTANT SAFETY INSTRUCTIONS
WARNING
(check page 12).
6

9. If smoke is emitted, switch off or unplug the appliance
and keep the door closed in order to stifle any flames.
10. Do not overcook food.
11. Do not use the oven cavity for storage purposes.
Do not store items, such as bread, cookies, etc. inside
the oven.
12. Remove wire twist-ties and metal handles from
paper or plastic containers/bags before placing them in
the oven.
13. Install or locate this oven only in accordance with the
installation instructions provided.
14. Eggs in the shell and whole hard-boiled eggs should
not be heated in microwave ovens since they may
explode, even after microwave heating has ended.
15.This appliance is intended to be used in household
and similar applications such as:
-staff kitchen areas in shops, offices and other working
environments;
-by clients in hotels, motels and other residential type
environments;
-farm houses;
-bed and breakfast type environments.
16. If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
17. Do not store or use this appliance outdoors.
18. Do not use this oven near water, in a wet basement
or near a swimming pool.
19. The temperature of accessible surfaces may be high
when the appliance is operating. The surfaces are liable
to get hot during use.Keep cord away from heated
surface, and do not cover any vents on the oven.
7

20. Do not let cord hang over edge of table or counter.
21. Failure to maintain the oven in a clean condition
could lead to deterioration of the surface that could
adversely affect the life of the appliance and possibly
result in a hazardous situation.
22.The contents of feeding bottles and baby food jars
shall be stirred or shaken and the temperature checked
before consumption, in order to avoid burns.
23. Microwave heating of beverages can result in
delayed eruptive boiling, therefore care must be taken
when handling the container.
24.The appliance is not intended for use by persons
(including children) with reduced physical , sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
25.Children should be supervised to ensure that they do
not play with the appliance.
26.The appliances are not intended to be operated by
means of an external timer or separate remote-control
system.
27.Accessible parts may become hot during use. Young
children should be kept away.
28.Steam cleaner is not to be used.
29.During use the appliance becomes hot. Care should
be taken to avoid touching heating elements inside the
oven.
30.Only use the temperature probe recommended for
this oven.(for ovens provided with a facility to use a
temperature-sensing probe.)
8

31. WARNING: The appliance and its accessible parts
become hot during use.Care should be taken to avoid
touching heating elements. Children less than 8 years
of age shall be kept away unless continuously
supervised.
32.The microwave oven must be operated with the
decorative door open.(for ovens with a decorative door.)
33.The rear surface of appliance shall be placed against
a wall.
34.The microwave oven shall not be placed in a cabinet
unless it has been tested in a cabinet.
READ CAREFULLY AND KEEP FOR FUTURE
REFERENCE
9

To Reduce the Risk of Injury to Persons
Grounding Installation
DANGER
Electric Shock Hazard
Touching some of the
internal componentscan
cause serious personal
injury or death.Do not
disassemble this
appliance.
WARNING
Electric Shock HazardImproper
use of the grounding can
result inelectric shock.
Do not plug into an outlet
untilappliance is properly
installed and grounded.
This appliance must be
grounded. In theevent of
an electrical short circuit,
grounding reduces the
risk of electricshock by
providing an escape wire
forthe electric current.
This appliance isequipped
with a cord having a
groundingwire with
a grounding plug. The
plug mustbe plugged into
an outlet that is properly
installed and grounded.
Consult a qualified
electrician orserviceman
if the grounding instructio
nsare not completely
understood or if doubtexists
as to whether the appliance
isproperly grounded.
If it is necessary touse an
extension cord , use only
a 3-wire
1. A short power-supply cord
is provided to reduce the risks
resulting from becoming
entangled in or tripping over a
longer cord.2. If a long cord set
or extension cord isused:
1)The marked electrical rating
of the cordset or extension cord
should be at least asgreat as
the electrical rating of the
appliance.
2)The extension cord must be
a grounding-type 3-wire cord.
3)The long cord should be
arranged so thatit will not drape
over the counter top ortabletop
where it can be pulled on
bychildren or tripped over
unintentionally.
10

CLEANING
Be sure to unplug the
appliance from thepower
supply.
1. Clean the cavity of the oven after using with a slightly damp
cloth.
2. Clean the accessories in the usual way in soapy water.
3. The door frame and seal and neighbouring parts must be
cleaned carefully with a damp cloth when they are dirty.
4. Do not use harsh abrasive cleaners or sharp metal scrapers
to clean the oven door glass since they can scratch the surface,
which may result in shattering of the glass.
5. Cleaning Tip---For easier cleaning of the cavity walls that the
food cooked can touch: Place half a lemon in a bowl, add 300ml
(1/2 pint) water and heat on 100% microwave power for 10
minutes. Wipe the oven clean using a soft, dry cloth.
UTENSILS
CAUTION
Personal Injury Hazard
It is hazardous for
anyone other than a
compentent personto
carry out any service
or repairo peration that
involves the removalof
a cover which gives
protection against
exposure to microwave
energy.
Utensil Test:
1. Fill a microwave-safe container with 1 cup of cold
water (250ml) along with the utensil in question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the utensil is warm, do
not use it for microwave cooking.
4. Do not exceed 1 minute cooking time.
There may be certain non-metallic utensils that are not
safe to use for microwaving. If in doubt, you can test the
utensil in question following the procedure below.
11

Materials you can use in microwave oven
Utensils Remarks
Aluminum foil Shielding only. Small smooth pieces can be used to cover thin parts of
meat or poultry to prevent overcooking. Arcing can occur if foil is too
close to oven walls. The foil should be at least 2.5cm away from
oven walls.
Follow manufacturer’s instructions. The bottom of browning dish must be
at least 5mm above the turntable. Incorrect usage may cause the
turntable to break.
Microwave-safe only. Follow manufacturer's instructions. Do not use
cracked or chipped dishes.
Always remove lid. Use only to heat food until just warm. Most glass jars
are not heat-resistant and may break.
Heat-resistant microwave glassware only. Make sure there is no metallic
Follow manufacturer’s instructions. Do not close with metal tie. Make
slits to allow steam to escape.
Use for short–term cooking/warming only. Do not leave microwave
Use to cover food for reheating and absorbing fat. Use with supervision
for short-term cooking only.
Use as a cover to prevent splattering or a wrap for steaming.
Microwave-safe only. Follow the manufacturer’s instructions. Should be
labeled "Microwave Safe". Some plastic containers soften as the food
inside gets hot. "Boiling bags" and tightly closed plastic bags should be
slit, pierced or vented as directed by package.
Microwave-safe only. Use to cover food during cooking to retain
moisture. Do not allow plastic wrap to touch food.
Thermometers Microwave-safe only (meat and candy thermometers).
Wax paper Use as a cover to prevent splattering and retain moisture.
Browning dish
Glass jars
Glassware
Oven cooking
bags
Paper plates
and cups
Paper towels
Parchment
paper
Plastic
Plastic wrap
Dinnerware
trim. Do not use cracked or chipped dishes.
unattended while cooking.
Materials to be avoided in microwave oven
Utensils Remarks
Aluminum tray
Food carton with
metal handle
Metal or metal-
trimmed utensils
Metal twist-ties
Paper bags
Plastic foam
Wood
Metal shields the food from microwave energy. Metal trim may
cause arcing.
May cause a fire in the microwave.
Plastic foam may melt or contaminate the liquid inside when exposed
to high temperature.
Wood will dry out when used in the microwave oven and may split
or crack.
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing and could cause a fire in the microwave.
12

A) Control panel
B) Turntable shaft
C) Turntable ring assembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system
F
G
A
C B
ED
SETTING UP YOUR OVEN
Names of Oven Parts and Accessories
Your oven comes with the following accessories:
Glass tray 1
Turntable ring assembly 1
Instruction Manual 1
Hub (underside)
Glass tray
Turntable ring assembly
a. Never place the glass tray upside down. The glass
tray should never be restricted.
b. Both glass tray and turntable ring assembly must
always be used during cooking.
c. All food and containers of food are always placed
on the glass tray for cooking.
d. If or
turntable assembly cracks or
breaks, contact the KIC Call Centre for assistance.
Turntable Installation
Turntable shaft
the glass tray
Remove all packing material and accessories.
Examine the microwave for any damage such
Countertop Installation Cabinet: Remove any protective film found
on the microwave oven cabinet surface.
Do not remove the light brown Mica cover
that is attached to the oven cavity to
protect the magnetron.
as dents or broken door. Do not install if
microwave is damaged.
13

Installation
1.Select a level surface that
provideenough open space
for the intakeand/or outlet
vents.
(1) The minimum installation
height is 85cm.
(2) The rear surface of
appliance shall be placed
against a wall.
Leave a minimum clearance
of 30cm above the oven, a
minimum clearance of 20cm
is required between the oven
and any adjacent walls.
(3) Do not remove the legs
from the bottom of the oven.
(4) Blocking the intake and/
or outlet openings can
damage the oven.
(5) Place the oven as far
away from radios and TV
as possible. Operation of
microwave oven may
cause interference to your
radio or TV reception.
2. Plug your oven into a
standard household outlet.
Be sure the voltage and
the frequency is the same
as the voltage and the
frequency on the rating
label.
20cm
30cm
20cm
min85cm
0cm
WARNING: Do not install
oven over arange cooktop
or other heat-producing
appliance. If installed near
or over a heatsource, the
oven could be damaged
and the warranty would be
void.
The accessible
surface may be
hot during operation.
14

Control Panel and Features
OPERATION
(2) Timed Defrost
(4) Clock
(6)
Number Buttons:0-9
cooking: press once to stop oven; twice to stop and clear all entries.
(1) TimeCook
(3) Power
(5)
Auto menu: Popcorn, Potato, Pizza, Frozen vegetable, Beverage, Reheat
Weighted Defrost
Timer
(7)
(9) Memory function
(10) Stop: clears all previous setting pressed before cooking starts. During
(11) Start
(8)
MWO 625 SL
(1)
(2)
(3)
(4)
(7)
(8)
(10)
(9)
(5)
(6)
(11)
15

1. Power Level
11 power levels are available.
Level
Power
Display
10
100%
PL10
9
90%
PL9
8
80%
PL8
7
70%
PL7
6
60%
PL6
5
50%
PL5
4
40%
PL4
3
30%
PL3
2
20%
PL2
1
10%
PL1
2. Clock Setting
(1) Press " ", "00:00" will display.
(2) Press the number keys and enter the current time. For example,
time is 12:10 now, please press "1,2,1,0" in turn.
(3) Press " " to finish clock setting. ":" will flash and the clock will be lighted.
(4) If the numbers input are not within the range of 1:00--12:59, the setting will be invalid
until valid numbers are input.
3. Kitchen Timer
(1) Press " ", 00:00
(2) Press the number keys and enter the timer time.(the maximum cooking time is
99 minutes and 99 seconds)
(3) Press " " to confirm setting.
(4) When the timer time arrives, the buzzer will ring 5 times.
If the clock be set (12-hour system), LED will display the current time.
Note: 1) The kitchen time is differ from 12-hour system,Kitchen Timer is a timer.
2) During kitchen timer, any programme cannot be set. Press " "
to cancel the kitchen timer function.
4. Microwave cook
(2) Press number keys to input the cooking time; the maximum cooking time is 99
minutes and 99 seconds.
0
0%
PL0
Note: (1) In the process of clock setting, if the " " button is pressed or if
there is no operation within 1 minute, the oven will go back to the former setting
automatically.
(2)If the clock need to be reset, please repeat step 1 to step 3.
(1) Press " " once, LED will display "00:00".
(3) Press " " once, LED will display a flashing "PL10". The default power is 100%
power. Now you can press number keys to adjust the power level.
(4) Press " " to start cooking.
OPERATION
will flash.
16

7. Timed Defrost
(1) Press " ", LED will display "dEF2".
(2) Press number pads to input defrosting time. The effective time range is 00:01~99:99
(3) The default microwave power is power level 3. If you want to change the power level,
press " " once, and the LED will display "PL 3", then press the number pad
of the power level you wanted.
(4) Press " " to start defrosting. The remain ing time will be displayed.
Note:1) In the process of setting, if the " " button is pressed or if there is
no operation within 1 minute, the oven will go back to the former setting automatically.
2) If "PL0" selected, the oven will work with fan or no power.
3)During microwave cooking, " can be pressed to change the power you
need. After pressing " ",the current power flash for 3 seconds, now you can
press number button to change the power. The oven will work with the selected power for
the rest time.
6. Weighted Defrost
(1) Press " ", LED will display "dEF1".
(2) Press numerical buttons to input weight to be defrosted.
Input the weight ranged between 100~2000 g.
(3) If the weight input is not within 100~2000 g, the input will be invalid.
(4) Press " " to start defrosting and the cooking time remained will be
displayed.
(2) In waiting state, instant cooking at 100% power level with 30 seconds' cooking time can
be started by pressing " ". Each press on the same button will increase
cooking time by 30 seconds. the maximum cooking time is 99 minutes and 99 seconds.
Note: during microwave cooking and timed defrost,time can be added by pressing
" " button.
5. Speedy Cooking
(1) In waiting state, instant cooking at 100% power level can be started by select a cooking
time from 1 to 6 minutes by pressing number pads1 to 6. Press " " to
increase the cooking time; the maximum cooking time is 99 minutes and 99 seconds.
Example: to cook the food with 50% microwave power for 15 minutes.
a. Press " " once."00:00" displays.
b.Press "1","5","0","0" in order.
c.Press " "once, then press "5" to select 50% microwave power.
d.Press " " to start cooking.
ing defrost
17

9.POTATO
a) Press " POTATO " repeatedly until the number you wish appears in the display,
"1","2","3" will display in order.
"1"SET : 1 potato (approximate 230 gram)
"2"SETS: 2 potatoes (approximate 460 gram)
"3"SETS: 3 potatoes (approximate 690 gram)
For example, press " " once , "1" appears.
b) Press " " to cook, buzzer sounds once.When cooking finish,buzzer
sounds five times and then turn back to waiting state.
8.POPCORN
a)Press " " repeatedly until the number you wish appears in the display,
"50","100"g will display in order.
For example, press " " once , "50" appears.
b) Press " " to cook, buzzer will sound five times and then turn back to waiting state.
10.FROZEN VEGETABLE
a) Press " " repeatedly until the number you wish appears in the
display, "150","350","500" g will display in order.
For example, press " " once , "150" appears.
b) Press " " to cook, buzzer sounds once.When cooking finish,buzzer
sounds five times and then turn back to waiting state.
1. When selecting 85-100 g of popcorn, it is
suggested that you fold down a triangle on each
corner of the bag before cooking. Refer to the
picture at right.
Important Information About Microwave Popcorn Feature:
2. If/When the popcorn bag expands and no longer
rotates properly, please press
button onceand open the oven door and adjust the
to ensure even cooking.
bag position
18

14. MEMORY FUNCTION (MEMO)
a) Press " " repeatedly until the number you wish appears in the
display, "1","2","3" cup will display in order. One cup is about
120ml. For example, press " " once , "1" appears.
b) Press "
sounds five times and then turn back to waiting state.
12.REHEAT
a) Press " " repeatedly until the number you wish appears in the
display, "250","350","500" g will display in order.
For example, press " " once , "250" appears.
b) Press " " to cook, buzzer sounds once.When cooking finish,buzzer
sounds five times and then turn back to waiting state.
13.PIZZA
a) Press " " repeatedly until the number you wish appears in the
display, "100","200","400" oz will display in order.
For example, press " " once , "100" appears.
b) Press " " to cook, buzzer sounds once.When cooking finish,buzzer
sounds five times and then turn back to waiting state.
(1) Press "MEMO" to choose memory 1-3 procedure. The LED will display 1,2,3.
(2) If the procedure has been set, press " " to use it. If not, continue to
set the procedure. Only one or two stages can be set.
(3) After finishing the setting, press " " once to save the procedure and
turn back to the waiting states.If press " " again,it will start cooking.
Example: to set the following procedure as the second memory, that is memory 2.
to cook the food with 80% microwave power for 3minutes and 20 seconds.
The steps are as follow:
a. In waiting states, press "
b.Press " " once,then press "3","2","0" in order.
c. Press " " once,"PL10" display,then press "8" and "PL8" displays.
d. Press " " to save the setting. Buzzer sounds once then turn back to
waiting states. If you press " " again, the procedure begins.
e. If the electricity is not cut off, the procedure will be saved all the time. If it is, the
procedure need to reset.
f. If you want to run the saved procedure, in waiting states, press "
screen displays "2", then press " " to run.
11.BEVERAGE
" to cook, buzzer sounds once.When cooking finish,buzzer
" twice,stop pressing until the screen displays "2".
" twice,
19

20
19. OTHER SPECIFICATIONS
(1) In standby state , if the set clock digital tube displays current time, the icon " : " would
flash; otherwise, it shows " 0:00 ".
(2) In setting function state, LED displays corresponding setting.
(3) In working or pause state, LED displays surplus cooking time.
When the cooking is over, the buzzer will sound 5 "beep" to alert user the cooking is finished.
18. COOKING END REMINDING FUNCTION
16. ENQUIRING FUNCTION
(1) In cooking state, press " ", the LED will display clock for three seconds.
(2) In the microwave cooking state, press " " to enquire microwave power level,
and the current microwave power will be displayed. After three seconds, the microwave
will turn back to the previous state. In multi-stage state, the enquiring way can be done
by the same way as above.
17. LOCK FUNCTION FOR CHILDREN
15. Multi-stage cooking
At most 2 stages can be set for cooking. In multi-stage cooking, if one stage is
defrosting, then defrosting shall be placed at the first stage automatically.
Note: Auto cooking cannot work in the multi-stage cooking.
Example: if you want to cook with 80% microwave power for 5 minutes + 60% microwave
power for 10 minutes. The cooking steps are as following:
(1) Press " " once,then press "5","0","0" to set the cooking time;
(2) Press " " once,then press "8" to select 80% microwave power.
(3) Press " " once,then press "1","0","0","0" to set the cooking time;
(4) Press " " once,then press "6" to select 60% microwave power.
(5) Press " " to start cooking.
Lock: When the door is close and the oven is powered, it will enter lock state, LED displays
“” or displays clock if you set.
Unlock: Open the door or press “ ” three seconds, buzzer sound a long beep. It is unlocked.
Lock auto: In waiting state, if no operation in one minute, a long beep will sound and it indicate
the oven enter lock state, LED displays “ ”
Unlock: Open the door or press “ ” three seconds, buzzer sound a long beep. It is unlocked.
or displays clock if you set.
