WifiWall WifiWall User manual

FCC Warning
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including
interference that may cause undesired operation.
NOTE 1: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
NOTE 2: Any changes or modications to this unit not expressly
approved by the party responsible for compliance could void the
user's authority to operate the equipment.
Note: WiWall 2.4GHz does not
support
5.0GHz Wi networks.
Please check our WiWall 2.4GHz
user’s manual at www.wiwall.com.

Hardware Specications
Dimensions: 6x3 cm
Weight: 30 g
Dual-core processor
2.4Ghz 802.11 b/g/n WiFi
(5.0 Ghz WiFi is not supported)
Bluetooth 4.0 BLE
Mini-USB charging socket
We are honored and pleased to welcome you to the family
of WiWall 2.4GHz users. We are here to make your Wi
connections safe, and to keep improving our products and
services for that.
The enclosed product is a rst of its kind, turn-it-on device,
acting as protocol analyzer that protects simultaneously up to
two Wi devices, such as a smartphone, tablet, Laptop, Wi
Camera, IoT device etc.
Please refer for additional technical specications and how it
works information on our website:
www.wiwall.com.
Don’t WiFi without WiWall
Getting Started
1. Turn on the device, while it is connected to a USB charger
or WiWall 2.4GHz Cradle (if you have one). It is important to
charge the device for at least 6 hours on rst use.
2. On its rst startup, WiWall 2.4GHz will display a new
device pairing screen.
3. Scan WiFi networks using the rst device you wish to pair
(the device to be protected by WiWall 2.4GHz) and search
for “WiWall 2.4GHz_setup” network name.
4. On the WiWall 2.4GHz new device pairing screen check
the displayed connection password and enter that in your
device to connect to WiWall 2.4GHz.
5. In WiWall 2.4GHz select device icon using the lower button
and <ok> to select using the top button.
6. That’s it. You are now paired with WiWall 2.4GHz. WiWall
2.4GHz will restart, and now you can connect your device to
any 2.4GHz Wi network and be protected.
LI-ION polymer battery;
Battery operation: Up to
8 hours if the display is
always on. Up to 10 hours if
the display is turned off.
1.4” OLED display
color: Matte black
