Laird WB45NBT
WB45NBT Quick Start Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/wi-fi
2
Laird Technologies
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
REVISION HISTORY
Version
Revision Date
Change Description
Approval
1.0
22 July 2014
Initial Release
Andrew
Chen
1.1
21 Nov 2014
Removed paragraph on Starting WebLCM from the Laird CLI
Andrew
Chen
1.2
7 July 2015
Added Note on No Serial Communication
Steve DeRosier

Laird WB45NBT
WB45NBT Quick Start Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/wi-fi
3
Laird Technologies
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
CONTENTS
Introduction to the Laird WB45NBT ........................................................................................................... 4
Product Description ..................................................................................................................................... 4
Quick Start Guide –WB45NBT .................................................................................................................... 5
Inventory of Equipment .............................................................................................................................. 5
Additional Required Tools .......................................................................................................................... 5
Hardware Installation and Configuration .................................................................................................... 5
Basics of the BB45NBT Board ..................................................................................................................... 8
Host Software Installation and Initial Communication with the BB45NBT ................................................... 8
Laird CLI Basics........................................................................................................................................... 9
Configuring the WB45NBT with WebLCM ............................................................................................... 11
WB45NBT File System .............................................................................................................................. 12

Laird WB45NBT
WB45NBT Quick Start Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/wi-fi
4
Laird Technologies
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
INTRODUCTION TO THE LAIRD WB45NBT
The Laird WB45NBT Wireless Bridge module is a wireless communications subsystem that may be integrated
into a variety of host devices via a number of available electronic and logical interfaces.
Interfaces
Features
Specifications
Fast Ethernet
Serial UART
USB
SPI
I2C
80 pin board with mating options
Mounting holes
ARM9 processor (396 MHz)
64 MB of LPDDR (Lower Power DDR)
memory
128 MB of NAND flash storage
Length: 40 mm
Width: 40 mm
Height: 3.8 mm
PRODUCT DESCRIPTION
The Laird WB45NBT provides complete enterprise-class Wi-Fi connectivity with an integrated TCP/IP stack, full
support for IEEE 802.11a/b/g/n and Bluetooth 4.0 dual-mode air standards, and a fully integrated security
supplicant providing 802.11i/WPA2 Enterprise authentication, data encryption, and BT protocol stacks.
The WB45NBT is a fully integrated module with RF shielding and three U.FL type antenna connectors. The
Main antenna (for Wi-Fi) and the Auxiliary antenna (for Bluetooth) work separately to get the best
coexistence performance.
Note: For additional information on the hardware aspects of the WB45NBT, please refer to the Hardware
Integration Guide download on the WB45NBT Product Page.

Laird WB45NBT
WB45NBT Quick Start Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/wi-fi
5
Laird Technologies
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
QUICK START GUIDE –WB45NBT
Inventory of Equipment
Qty.
Item
1
WB45NBT device
1
BB45NBT Breakout board
2
U.FL ultra-micro coax cable male to male SMA plus 2 nuts and washers
2
Dual band 2.5G and 5G antenna with reverse female SMA connector
4
Standoffs and nuts
3
Small Philips head screws
1
USB A to micro USB 1m cable
1
1m CAT 5 e cable
1
USB-to-RS232 DB9/DB25 adapter
1
Micro USB to USB A type convertor
1
Power supply 12V 1A negative center with wall (US/European) adapter cable
Additional Required Tools
Qty.
Item
1
Small Philips head jeweler’s screw driver
Hardware Installation and Configuration
To assemble the WB45NBT evaluation kit, follow these steps:
1. Attach the standoffs to the underside of the BB45NBT board.
2. Connect the 2 U.FL coax cables to the 2 U.FL connecters on the underside of the WB45NBT board.
Figure 1 shows the location of the Wi-Fi and Bluetooth antennas.
Note: To prevent damage, you must connect the U.FL ultra-micro coax cables to the connectors on
the WB45NBT prior to fitting the WB45NBT to the BB45NBT evaluation board.

Laird WB45NBT
WB45NBT Quick Start Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/wi-fi
6
Laird Technologies
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
Figure 1: Location of the Wi-Fi and Bluetooth U.FL connectors on the SDB-WB45NBT
3. Plug the WB45NBT module into the 80-pin high-density Molex connector situated near the central
aperture on the BB45NBT Breakout board. Ensure that the 2 U.FL cables and SMA connectors are
passed through the aperture in the BB45NBT board.
4. Using the small Philips head jeweler’s screw driver, secure the WB45NBT using the 3 small Philips
screws to the BB45NBT board.
5. Using the nuts and washers provided, attach the respective SMA connectors on the end of the U.FL
cables to the apertures in the BB45NBT board marked BT_ANT and WLAN_ANT as shown in Figure 1.
6. Turn the BB45NBT board the correct way up and connect the dual band antennas with an SMA
connector to each of the BT-ANTand WLAN-ANT SMA connectors on the top side of the BB45BNT
board.
7. Connect the Wi-Fi and Bluetooth antennas to the male SMA connectors at the end of the 2 U.FL cables
connected in step 2 above.
8. You can power the BB45NBT from either mains power or the USB power socket. Figure 2 shows both
of these connectors and the power switch. Select which power supply you wish to employ:
a. DC Jack: Ensure the Power / USB Power switch is set to “From USB Port.” This is effectively the
“off” position if you’re intending to use DC power. Connect the power supply to the wall outlet
and put the barrel into the DC connector (J3) on the BB45NBT breakout board as shown in
Figure 2.
b. USB Port: Ensure the Power / USB Power switch is set to “From DC Jack.” This is effectively the
“off” position if you’re intending to use USB power. Connect the USB A connector to your PC or
USB hub USB port. Connect the micro USB connector to the BB45NBT board USB power socket
shown in Figure 2. No LEDS should be lit on the board.
Wi-Fi Antenna
cable connected to
U.FL connector
BT Antenna cable
connected to U.FL
connector
BT Antenna PCB
Mounting Point
(secured with nut
and washer)

Laird WB45NBT
WB45NBT Quick Start Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/wi-fi
7
Laird Technologies
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
Figure 2: Alternative power sources
Figure 3: BB45NBT Evaluation Board
BT Antenna Hole
USB
Wi-Fi
Antenna Hole
Ethernet
Jack
WB45NBT 80-Pin Connector
Debug UART
UART0
UART3
DC
Power
Jack
IRQ/SW1
Button
Reset
Button
DC/USB
Power Switch
See Figure 2
RED LED - D20
Power Switch
USB Power Port
DC Jack
USB power
port

Laird WB45NBT
WB45NBT Quick Start Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/wi-fi
8
Laird Technologies
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
Basics of the BB45NBT Board
The Laird WB45NBT is a flexible communications module providing a variety of interfaces which are made
available on the BB45NBT. Additional information regarding all interfaces and their usage and configuration
is available in the WB45 Reference Manual.
The WB45NBT is configurable via either the command line or the web-based version of the Laird
Configuration Manager (LCM). WebLCM is explained further in Configuring the WB45NBT with WebLCM.
This section briefly details each interface available on the BB45NBT board.
Debug UART –used for CLI communications with the WB45NBT module
UART0 –Spare UART
UART 3 –unused
USB
-Available for either USB HOST or device / gadget operation.
-By default, the port is in Ethernet gadget mode.
-The IP address of the port defaults to 192.168.3.1.
-The WebLCM is always available on this port.
Ethernet jack
-The WebLCM is always available on the Ethernet port
-The IP address for this port is provided by the SHCP server the WB45NBT is connected to
Host Software Installation and Initial Communication with the BB45NBT
The following items are used in this section:
Qty.
Item
1
BB45NBT Breakout board with WB45NBT module fitted as described above
1
USB to RS232 cable
1
Power supply 9V / 1A with wall (US/European) adapter cable or USB A to Micro USB cable
To set up the WB45NBT, follow these steps:
1. Ensure you have loaded the driver for your USB-to-RS232 cable. Depending on your cable, the drivers
may be automatically installed by your operating system. If they are not, you will need to download
and install the device drivers for the cable.
2. Connect the USB A-type connector of the USB-to-RS232 cable to the computer. Your computer should
recognize the USB-to-serial adapter and load the appropriate drivers.
3. Connect the DB9 connector of your USB-to-RS232 cable to the port marked Debug UART shown in the
BB45NBT overview diagram Figure 3.
4. To send commands to the WB45NBT you will need to download and set up a terminal emulator, such
as Putty or TeraTerm, on your host. Note that a variety of emulators are available.
To download and set up TeraTerm, follow these steps:
1. Navigate to the Source-Forge (TeraTerm) website: http://en.sourceforge.jp/projects/ttssh2/releases/
2. Download the emulator.
3. Run the downloaded file and navigate through the installer. Select the standard default settings when
prompted.

Laird WB45NBT
WB45NBT Quick Start Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/wi-fi
9
Laird Technologies
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
4. Open TeraTerm.
Upon opening, TeraTerm prompts for connection information. We are using a serial connection (not
the default TCP/IP).
5. Select Serial.
6. From the Port drop-down menu, choose the COM port which has a description similar to the USB-to-
RS232 cable you are using: e.g. Prolific Serial-to-USB Comm Port . Remember this COM port number.
7. Set the serial port’s settings to match the WB45NBT’s communications protocol. To adjust settings,
navigate to Setup > Serial port.
Adjust the settings (as needed) according to the following:
Port
Must match the COM port of your USB-to-RS232 cable.
Baud Rate
115200 (TeraTerm defaults to 9600 baud communications)
Data
8 bit
Parity
None
Stop
1 bit
Flow Control
None
8. Press OK to save the settings and to return to the terminal.
Note: Assuming all settings have been set properly, you should now be able to communicate with
the WB45NBT. The terminal presented now is the Linux shell onboard the WB45NBT, and
behaves likewise.
9. Slide the Power switch (shown in Figure 2) to either the From DC Jack or From USB Power Port to
match your chosen method of powering the BB45NBT board to apply power to the WB45NBT. The Red
LED D20 will light on the BB45NBT board.
Wait until the WB45NBT has completed booting and you see the prompt:
Summit Data Communications
summit login:
10. Enter the username and password. The default user name is root and the default password is summit .
Note: When entering the password, don't be alarmed if text or asterisks do not show. This is normal
operation in Linux.
After logging in, the following should display to indicate that you are now in the Linux shell:
#
Important Note About “No Serial Output”
In some BB45NBT boards, the UART_3V3 jumper nearest the Debug UART port can become loose or
unseated, which results in no serial output.

Laird WB45NBT
WB45NBT Quick Start Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/wi-fi
10
Laird Technologies
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
If you find you have no serial output, check that this jumper is very tightly seated (Figure 4).
Figure 4: UART_3V3 Jumper
Laird CLI Basics
The Laird CLI provides a command line interface to control the Wi-Fi features of the WB45NBT.
The Linux shell prompt is represented by the “#” symbol. From the prompt, enter sdc_cli to start the Laird
CLI. When the Laird CLI starts, the prompt will change to “sdc#”.
Full information on the commands available within the CLI is available from the Laird website.
Information regarding using the CLI commands is also available by typing help at the sdc# prompt.
Additional help is available for the commands iface,profile,global and auto-profile using the syntax
<command> help at the sdc# prompt.
To see the status of the WB45NBT, type status at the sdc# prompt. The returned status should resemble
the following.
Status: AP mode
Config name: Default
SSID:
Channel: 0
RSSI: 0
Device Name:
MAC: 00:17:23:e0:38:e4
IP: 192.168.1.1
AP Name:
AP MAC:
AP IP:
Bit Rate: auto
Tx Power: 0 mW
Beacon Period: 0
DTIM: 0
The WB45NBT defaults to start in AP mode. This allows the user to associate and attach to the WB45NBT as
one would a normal access point and use the integrated Laird WebLCM tool to configure the WB45NBT. The
Status line highlighted in yellow above shows that the WB45NBT is operating in AP mode.

Laird WB45NBT
WB45NBT Quick Start Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/wi-fi
11
Laird Technologies
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
To exit from the sdc# prompt at any time, enter the command exit. You will be returned to the Linux shell
prompt, #.
Configuring the WB45NBT with WebLCM
Once the WB45NBT is operating in AP mode, you may configure the WB45NBT using the WebLCM tool. To
configure the device, complete the following steps:
1. Associate your computer with the WB45NBT by scanning the available Wi-Fi access points in your area.
Connect to the wb45n_xxxxxx AP where xxxxxx is the last 3 octets of the MAC address (highlighted in
blue in the status example above). For the device example above, the device’s SSID name would be
wb45n_e038e4.
Note: Wi-Fi access is protected by WPA2-PSK level security. When prompted by your computer’s
Wi-Fi client, enter the default password, which is lairdtech.
2. Open your web browser and enter the IP address 192.168.1.1 in the address bar. The WebLCM server
uses a secure link running over the https protocol. The certificates used will not be signed by your
browser, so you will see a warning similar to that shown in Figure 5 (this example shows the warning
in Google Chrome):
Figure 5: Accept the certificate issued by the WB45BNT
3. Click Proceed Anyway button (or the equivalent to “Continue” on your browser).
4. Log in to the web server. The user name is root and password is summit. When you log in, you are
directed to WebLCM’s Status tab as shown in Figure 6 .

Laird WB45NBT
WB45NBT Quick Start Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/wi-fi
12
Laird Technologies
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
Figure 6: The WebLCM Status tab
5. Click the Wifi tab to display the profiles page. Here, you may add your required Wi-Fi profiles.
6. When you have added a profile or profiles to the WB45NBT, you must select a profile to make active.
Select the desired profile from your list and click Activate. The profile will now be active when AP mode
is disabled.
Note: You must create an active profile prior to disabling AP mode.
7. To disable AP mode, click the Advanced tab and then click Disable in the AP Mode section.
8. Check the status of the AP connection by typing sdc_cli status at the command line in your terminal.
Note: The web server that hosts the WebLCM on the WB45 is passively waiting for a connection
attempt to the WB45 on port 80. Once a connection attempt is made on that port, the
WebLCM will become active for a period of 10 minutes. If no activity is detected for 10
minutes then the web server will return to a passive state where it is waiting for a connection
on port 80.
WB45NBT File System
This section details some important contents of the WB45NBT file system. For more in depth information
consult the WB45NBT reference manual.
Table 1: Main components
Directory
Content of note
Comment
/usr/bin
sdcsupp
Laird Supplicant
sdc_cli
Laird CLI
/usr/lib
libsdc_sdk.so.1.0
Laird SDK library
libsdc_sdk.so.1
A symbolic link to SDK library
/etc/network
wireless.sh
Networking scripts. See the WB45
reference manual for details.
/etc/init.d
startup scripts
The lowest numbered startup scripts
are executed first.

Laird WB45NBT
WB45NBT Quick Start Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/wi-fi
13
Laird Technologies
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
/etc/init.d/opt/
optional startup scripts
Create a symlink to the item to be
started:
# ln -s /etc/init.d/opt/<name-of-
script> /etc/init.d
/etc/ssl
default wifi certificate location
for all certificates
DO NOT put your certificates in
/etc/ssl/certs directory
/lib/firmware/ath6k/AR6003/hw2.1.1
fw-4.bin
Symbolic link to the AR6003
firmware.
fw_v3.4.0.83.bin
The AR6003 firmware
