WINFORM Trinity User manual

Cod. MNTR_ENG ED 01 REV 01 dtd 21/07/2020
MEDICAL ENGINEERING
CERTIFIED COMPANY
USER MANUAL

1
Contents
1. Applicable standards .................................................................................................................4
2. Important information for the operator: Safety ......................................................................4
3. Labels...........................................................................................................................................7
4. Technical features......................................................................................................................8
5. Functions .....................................................................................................................................9
6. Room sanitization functions with ozone............................................................................... 10
7. Water sanitization functions with ozone............................................................................... 11
8. Material supplied ..................................................................................................................... 13
9. Maximum ozone exposure limits........................................................................................... 13
10. Important information for the operator: Ozone toxicity.................................................. 13
11. Certifications ........................................................................................................................ 13
12. Warranty................................................................................................................................ 14
13. Device transporting and unloading rules ......................................................................... 14
14. Packaging integrity check .................................................................................................. 14
15. Technical Assistance/Repairs............................................................................................ 14
16. Triple filter substitution ....................................................................................................... 15
17. Disposal of the device......................................................................................................... 16
18. Commissioning the Device................................................................................................. 17
19.Acceptable environmental conditions .............................................................................. 17
20. Cleaning the device and the accessories ........................................................................ 18

2

3
Dear Customer,
First and foremost, thank you for choosing a WINFORM product.
The device you have purchased was built in compliance with European standards and meets
the strictest quality controls.
We recommend that you read the accompanying manuals carefully.
For any information or clarifications regarding the use of the device, please contact our
Customer Service at
Tel. [phone]
Fax.[phone]
WINFORM MEDICAL ENGINEERING S.R.L.

4
This manual has been prepared by the manufacturer to provide "operators" with information
concerning the use and maintenance of the machine within the limits of safety and health
protection dictated by the regulations in force and as indicated by the manufacturer.
Caution: it is forbidden to remove pages, make corrections, erasures, modifications.
Caution: this manual must be delivered with the equipment.
The instruction manual must be kept with the utmost care and must accompany the
equipment throughout its operating life. If the equipment is sold, the manual must be handed
over to the new owner, together with the declaration of conformity.
A copy of the user manual must be kept near the device.
Should you lose it, please ask the manufacturer for a copy.
1. Applicable standards
The following rules are applied:
2014/35/CE
2014/30/CE
EN 60335-1
EN 60335-2-65
EN 60947-1 + AMD1
EN 61000-6-1
EN 61000-6-2
EN 61000-6-
EN 61000-6-4
2. Important information for the operator: Safety
Safety measures:
•Do not operate the Ozonizer until you have made sure that no person or animal is
in the ozonized premises.
•Before turning on the equipment, remove the triple filter, located in the front
compartment from the plastic packaging.
•When not in use, the Ozonizer must be stored in a locked room accessible only
by authorized and supervised personnel.
•During water ozonation keep the equipment as far as possible from the water
container to prevent accidental impacts can get the equipment wet.
•Do not cover the air intake on the back of the ozone outlet or the air outlet on the
top. Improper ventilation can cause mechanical failure and will void the warranty.
•Do not position the device on unstable or vibrating surfaces.
•Do not smell the device to check if the generator is dispensing ozone.
•Do not sanitize the aquarium water with the fish inside it.

5
•The ozone outlet pipes must not twist, knot or roll up during operation.
•If you use the appliance in "OZONE" mode to ozone the water inside a small room,
do not stay inside the room during operation. After the operation, ventilate for at
least 10 minutes.
•Store the equipment in a cool and dry area.
•Do not disassemble the equipment even in case of mechanical failure. For any
technical assistance, contact Winform technical support.
•Do not sojourn in the ozonized areas until they have been thoroughly ventilated.
•Only connect the device to electrical systems that comply with the laws and
regulations in force, which include devices that safeguard the lives of people and
animals.
•The device must not be subjected to strong impacts. Do not activate the device in
case of a severe impact strong enough to damage the outer casing but contact
WinForm Medical Engineering srl.
•Never disconnect the power supply cable during operation.
•Equipment radiating high frequencies near the device may cause malfunction.
•Never use the equipment with a wet or damaged power supply cable or plug.
•The device must be protected from jets of water and other liquids, it must not be
used in a very dusty environment, and the presence of vaporised liquids. Avoid
direct exposure to sunlight and heat sources.
•If the device operates abnormally, if it emits unusual odours, noises, or sounds,
turn it off and unplug the power supply cable from the mains. Contact WinForm
Medical Engineering srl.
•Do not insert any objects into the grids, slots, fittings, and ventilation outlets, as
high voltage is present inside the device.
•Do not place the device in confined spaces without proper ventilation.
•Do not move the device while in use. Before any movement, even the slightest,
switch off the equipment.
•If water enters the equipment, immediately disconnect it from the power supply,
if connected, and drain it from the water. Before using it, wait until the equipment
is completely dry.
Caution: do not stay in the room during “OZONE” mode operation and for 30min after
the device is switched off.
Caution: always ventilate the room after the treatment in “OZONE” mode.
Before using the device, read the instructions and safety data sheet carefully.
•Caution: Only use this device as intended.
•Caution: failure to comply with the regulations may result in the risk of personal injury or
damage to property.
•Note It is recommended not to breathe directly above, or near the ozone vents. The
ozone concentration at those points is extremely high and harmful for your health: "a
one-minute-long exposure is enough to remain seriously intoxicated by the gas released
by the generator".

6
•Keep the device out of reach of children or disabled persons.
•Keep the device away from sources of heat.
•Should the instrument fall into water, do not use it and request assistance from a
WINFORM technician.
•Do not open the device for any reason.
•The electrical safety of this device is only ensured when it is connected to an electrical
system equipped with an effective earth socket and a differential switch in compliance
with the law. It is mandatory to check this fundamental safety requirement. If in doubt,
seek assistance from a qualified technician.
•The use of any appliances connected to the electrical system requires compliance with
precise fundamental safety standards:
oDo not touch the equipment with wet or damp hands or feet.
oDo not plug or unplug the device into the socket with wet hands.
oDo not pull the power supply cable to disconnect the plug from the mains.
oDo not leave the equipment exposed to the weather.
oDo not allow the equipment to be operated by children.
oBefore carrying out any cleaning or maintenance operations, switch off the
system by following the proper procedure described in this manual and once off,
unplug the equipment from the power mains.
oIn case of failure or malfunction, switch off the equipment and do not tamper with
it. For any intervention, please contact the customer service or an authorized
technician.
oIf damaged, the power supply cable must be replaced by the manufacturer or
similarly qualified authorised personnel.
oOnly use original spare parts.
oFor maintenance, follow the instructions in this manual scrupulously or contact
the technical support service department.
Warning: The equipment must not be used close to or above other appliances.
If it is necessary to use it above or close to other appliances, observe its performance to
make sure it complies with its configuration.
Warning: Winform Medical Engineering srl is relieved of any liability inherent in the improper
use of the equipment described in this manual.
Warning: Using accessories other than specified, except for those sold by the manufacturer,
may cause the device to malfunction.
Warning: It is advisable to place it on a stable surface, to avoid hazards due to the device
falling.

7
3. Labels
The equipment bears labels that make it possible to identify it precisely and which indicate
the main technical characteristics, the CE marking, the address of the manufacturer and
reminders/warnings for use.
To better understand the meaning of each symbol/label affixed on the device, please find a
Symbol key below.
SERIAL LABEL
The device’s serial label contains its technical data, including the model, the serial number
assigned, the manufacture date, the mandatory symbols.
The label is on the back of the device near the power connector.
Caution: We recommend checking that the UNIQUE serial number of the device, shown on
the serial label located on the rear of the device, matches the one in the CE declaration of
conformity.
Meaning of the symbols on this label:
Generic Caution
CE marking
Device’s date of manufacture
Product to be disposed of separately
Carefully read the instructions

8
4. Technical features
Ozone production
500 mg/h
CADR
“Clean Air Delivery Rate”
200 m3/h
Negative ions production
8 000 000 ions/m3
Voltage
230V/50Hz
Timer:
OZONE mode
From 1 to 60 min
Timer :
PURIFICATION mode
IONIZATION mode
UV LAMP mode
From 1 to 12 hours
Dimensions (aprox.) in mm
78(w) x 250(l) x 400(h) mm
Weight
1,7 Kg
Certifications
CE

9
5. How to use
1. Press the ON/OFF button.
2. Press the left button to choose among the following modes:
2.1 Air purification through the triple filter (press once) - the red LED labelled
"Purify" turns on.
2.2 Air purification through triple filter and UV lamp (press twice) - the red LEDs
labelled "Purify" and "UV" turn on.
2.3 Air purification and ionization (press three times) - the red LEDs labelled
"Purify" and "ION" turn on.
2.4 Air purification through triple filter, UV lamp and ionization (press four times) -
the red LEDs "Purify", "UV" and "ION" turn on.
2.5 Ozonation (press five times) - the red LED labelled “Ozone” turns on.
3. Keep the central button pressed for at least three seconds to adjust the time:
-the "purification", "ionization" and "UV lamp" modes can be adjusted from 1 to 12
hours.
-The "ozonation" mode can be adjusted from 1 to 60 minutes.
Once the desired time has been set, the display flashes for three seconds and then
starts operating.
For the first use, read point 18 (commissioning the device).
Caution: make sure that no person or animal stays in the rooms subject to ozonation
when the equipment is in "OZONE" mode for air ozonation.
Caution: do not stay in the room during operation when the equipment has been set
in "OZONE" mode.
LED
FUNZIONE
Purify
Air purification through the triple filter
Purify + UV
Air purification through triple filter and UV lamp
Purify + ION
Air purification and ionization
Purify + UV + ION
Air purification through triple filter, UV lamp and ionization
Ozone
Ozonation

10
Attention: Always allow adequate ventilation (eg by opening the windows of the
room) before staying in the room after the treatment in “OZONE” mode (from 15 to 30 min
depending on the duration).
6. Room sanitization functions with ozone
Here below a table with the indications (in minutes) of the air sanitization and deodorization
treatment based on the size of the space to be sanitized.
Room dimensions in
square meters
(sq/m)
Operating time
(minutes)
1
1
5
6
10
12
20
24
25
30
30
36
35
42
40
48
50
60
For the internal treatment of the refrigerator or wardrobe, use Trinity for no more than 10
minutes. The treatment allows the removal of odors and sanitization.
To sanitize the passenger compartment of the cars, leave Trinity to act for 15 minutes,
possibly with the internal air recirculation activated. At the end of the treatment, ventilate
with doors open for at least 5 minutes.
Read the safety rules stated on point 2 of the manual.

11
7. Water sanitization functions with ozone
To ozonize the water, first you need to connect the small tube supplied to the ozone exit
hole placed on the side of Trinity. Then you must connect the stone to the opposite end of
the tube.
We recommend you no to stay nearby during water treatment.
*Food sanitization process it is useful for making the food safer and to guarantee a longer duration
over time, but is not intended as a replacement for the blast chilling or pasteurization processes.
Applications
Treatment
Fruit and vegetables sanitization,
pesticides degradation and
prolongation of conservation time
Place fruits and vegetables in a 5-Liter bowl.
The water must cover completely the fruits or the
vegetables inside.
Dishes sanitization
Place the dishes for 2 min in a 3-Litre container
Water ozonation for floor sanitization
Ozonate the water placed into the bucket for 5 minutes.
The sanitization of the floor must be carried out after
the normal periodic cleaning. Do not add detergent or
other products to the ozonated water
Sanitization of toothbrushes
Place head of the toothbrush/es in a glass big enough
to contain it/them and the stone. Otherwise you can
please the toothbrush/es on the bottom of a bowl.
Fill the glass or the bowl with enough water to cover the
brush head (or the full toothbrush) and proceed with 20
minutes of ozonation.
Water purification
To destroy microorganisms such as bacteria and
viruses and prevent their proliferation.
Ozonate each litre of water for 3 minutes.
Ozonated water for hand sanitization
Ozonate each litre of water you need for 3 minutes and
dip your hands for a few seconds in this water.
Otherwise you can spray it using a sprayer.
Fish and meat
Foods lose odour and fatty parts. The ozone molecules
attack microorganisms such as bacteria and germs,
preventing their proliferation, therefore allowing foods
lasting longer*.
Ozonate for 5 min in a container of water and food
Washing textile products
Washing clothes or textile products with ozonized water
allows us to sanitize them and remove odours.
Ozonate for 10/15 minutes.
Drinking ozonated water
Ozonate each litre of water for 3 min to activate and
regulate biological processes and intestinal bacterial
flora.
Don't drink more than one glass a day.
Drink freshly treated water or within 20 min from the
treatment.

12
Read the safety rules stated on point 2 of the manual.

13
8. Material supplied
No. 1 equipment
No. 1 Power supply cable
No. 1 tube for water ozonation
No.1 CE declaration
No.1 Instruction manual
No.1 Safety Data Sheet
No.1 stone for water ozonation
9. Maximum ozone exposure limits
Exposure limits
-8 hours a day for 5 days a week (continuous exposure limit) - 0.1 ppm
-15 minutes (short-term exposure) - 0.3 ppm
10. Important information for the operator: Ozone toxicity
Above the maximum exposure limit, there is a risk of inflammation of the respiratory tract.
Ozone has a distinctive odour which can be detected at concentrations of approx. one-tenth
of the maximum exposure limit, in 15 minutes (olfactory perception 030.005 ppm).
A strong ozone smell usually indicates approaching the exposure limit value.
CAUTION:
•People with olfactory impairments should not use this product when working in “OZONE”
mode.
•Do not check for ozone leakage by inhaling the ozone directly from the equipment.
•Inhalation of high ozone concentrations for a short period, or low ozone concentrations
for long periods, can be highly harmful.
•WARNING: Long-term inhalation of high concentrations of ozone gas in the air may cause
nasal and/or lung irritation.
Read the safety data sheet provided with the equipment.
11. Certifications
Caution:
The regulations in force make it mandatory to adequately store the user manual and the CE
Declaration of Conformity.
A copy of the user manual must be kept near the device.
Should you lose them, please ask the manufacturer for a copy.

14
12. Warranty
This device has a 24-month warranty from the date of purchase.
Warranty is limited solely to manufacturing or material defects.
The warranty does not cover damage caused by improper application, negligence,
accidents, improper use or changes made to the instrument by personnel not authorised by
WINFORM Medical Engineering S.r.l.
Any interventions performed by unauthorised personnel, and/or the use of non-original
spare parts, shall VOID the Certification of the Device.
13. Device transporting and unloading rules
The equipment is packaged in a way that guarantees its protection during loading, transport
and unloading. The packaging consists of a double corrugated cardboard box combined
with protections in shock-absorbing material. The packaging bears the conditions to be
complied with for transport and storage of the device.
Please note that all loading and unloading operations must be performed in compliance with
the safety regulations in force.
Materials packaged in wooden crates or cardboard boxes must be transported and handled
with appropriate equipment (forklifts, etc.) if their weight exceeds or is equal to 10 kg.
Personnel must be appropriately protected from harm deriving from handling the packages.
Protective glasses must be used when removing nails with automatic or manual tools.
The same precautions must be used when cutting any metal straps on the packaging.
Personnel not involved in handling the packages must not walk under suspended parts or
go near while they are being handled.
Failure to comply with or inadequacy of the appropriate precautionary measures, releases
WinForm Medical Engineering from all liability for legal compensation proceedings for
damage to persons or property.
14. Packaging integrity check
On delivery of the device, the person tasked with receiving it must check that the packaging
is intact, and that what has been received matches the accompanying documents.
If said person finds that the packaging is damaged and/or tampered with and that the
contents do not match the accompanying documents, he/she must refuse the delivery
and/or store the equipment separately in an area duly marked with the wording “non-
conforming material”.
He/she must then promptly contact WinForm Medical Engineering to report the non-
conformity. In no case must equipment that shows obvious signs of damage/tampering be
used.
15. Technical Assistance/Repairs
Technical Assistance and repair operations must be carried out SOLELY (except for
replacing the fuses) by technicians authorised by WinForm Medical Engineering srl.

15
This, in fact, is the only way to guarantee that original spare parts, approved during the
Certification of the Device, are used.
Any interventions performed by unauthorised personnel, and/or the use of non-original
spare parts, shall VOID the Certification of the Device.
Technical Assistance contacts: mail: [email protected] Tel. + 39 0421 222026
16. Triple filter substitution
Open the filter cover on the front of the equipment, take out the double filter and replace it
with a new one. To purchase the filter:
-contact the company on phone number + 39 0421 222026
-or write an email to [email protected]
-or visit www.winform.shop .

16
17. Disposal of the device
WinForm Medical Engineering, in compliance with the requirements of It. decree 151 dated
25/07/05, which implements Directive 2002/96/EC on waste electrical and electronic
equipment (WEEE), is registered with a consortium for electronic and electrical equipment
collection (Consorzio Remedia). Please remember that the device must be disposed of in
compliance with the regulations in force. For this purpose, we inform the consumer of the
following:
INFORMATION FOR DOMESTIC OR PROFESSIONAL EQUIPMENT USERS
Pursuant to art. 13 of It. Legislative Decree dated 25 July 2005, no. 151
“Implementation of Directives 2002/95/EC, 2002/96/EC and 2003/108/EC regarding reducing
the use of hazardous substances in electric and electronic equipment, as well as waste disposal”
the crossed-out wheelie bin symbol on the equipment or its packaging means that the product
must be disposed of separately from other waste at the end of its service life. Therefore, the
user must bring the equipment at the end of its life to appropriate separate electronic and
electro-technical waste collection centres or bring it back to the retailers when purchasing a
new equivalent equipment, in a one to one ratio.
Pursuant to the previously cited standard, for professional users (companies or entities),
separate collection of this equipment once it reaches the end of its life is organised and
managed:
a) directly by the user, should the user decide to get rid of the device without replacing it
with new equivalent equipment intended for the same functions;
b) by the manufacturer, intended as the subject who first introduced and commercialised
the new equipment that replaced the previous one in Italy, or resells said equipment under its
own brand in Italy, if, when deciding to get rid of the equipment at the end of its life, the user
purchases an equivalent product intended for the same functions. In the latter case, the user
can ask the manufacturer to collect this equipment no later than 15 consecutive calendar days
after the above-mentioned new equipment is delivered. Appropriate separate collection to then
send the decommissioned equipment for recycling, treatment and environmentally compatible
disposal contributes to avoiding possible negative effects on the environment and on health
and promotes reuse and/or recycling of the materials the equipment consists of. Sanctions
provided for by current legal standards will be applied to users who dispose of the product
illegally.

17
18. Commissioning the Device
For the first use of the equipment, remove Trinity from the box and plastic packaging. Open
the filter cover, placed on the front of it, remove the triple filter and remove it from the plastic
package, then replace it inside the compartment and close the door.
Connect the base of the equipment by screwing it with the 4 screws found in the package
inside the box.
Respect the indications contained in the following paragraphs.
The execution of procedures other than those described in the following paragraphs can
lead to dangerous situations for the operator.
Strictly follow the instructions below to avoid damage to things and people.
19. Acceptable environmental conditions
The device must be commissioned in an environment that complies with specific conditions
set by the Manufacturer:
Environmental Conditions
Ambient temperature: +10° / +30°
Humidity: RH <75%
Atmospheric pressure: from 500 hPa to 1060 hPa
Failure to comply with these provisions may impair the operation of the device.
Surfaces
The instrument should be placed on a flat and stable surface.
Avoid slippery surfaces.
Avoid uneven surfaces.
display
Front Side
Triple-filter compartment door

18
Electrical system
The equipment must be connected only to electrical systems designed and installed in
compliance with the law by authorised Operators who hold the necessary qualifications.
The equipment should be connected only to 230 V.ac 50 Hz mains.
The absorption of the device is 20 Watt 43.4VA.
20.Cleaning the device and the accessories
The external surface of the device can be cleaned easily with a soft cloth moistened with
water.
