Wizard ON-CAV6-3G User manual

GPS Tracker User Manual
For Auto, scooter and motorcycle
Please read the manual carefully before use the GPS Tracker so that you can
install the device correctly and activate it quickly on the internet. The outlook
and true color are subject to the actual product.

1．Accessories：
2. Technical parameter
1）.GSM：850/900/1800/1900/Quad band
3G: optional
4G: optional
2）.GPRS: Class12, TCP/IP
3）.Working Voltage：9-24V DC
4）.Working current：≈22mA (12vDC)
5）.Working current：≈12mA (24vDC)
6）.GPS locating time：Cold start≈38s（Open sky）
Warm start≈32s
Hot start≈2s（Open sky）
7）.GPS Precision：10m（2D RM）
8）.Working temperature：-20℃～+70℃
9）.Working humidity：20%～80%RH
10）.Measurement：87（L）×43（W）×14（H）mm

4.Device status indicators
4.1Connect DC 9-24V power supply and the red LED will light continuously.
4.2The green LED glistens when searching the GPS signals. When GPS works, the
LED lights continuously.
4.3The intermediate blue LED (GSM signal state)
GSM signal is normal, blue LED light long bright. No GSM signal, the blue LED
flashes.
GPS LED not fixed, flashes（0.2 sec/2 sec）， Positioning long bright；
GSM LED no signal, flashes（0.2 sec/2 sec）， Signal normal long bright；
Power LED: long bright;
All LEDS will turn off after 5 minutes. When there is a new call, the LEDs will relight and
turn off 5 minutes later.
5.Installation
5.1 Preparation for the installation
5.1.1 Product Check. Open the packing box and check the device‘s model and accessories.
If the model is wrong or the accessories not complete, please contact the dealer.
5.1.2 Choose SIM card. Please insert a SIM card to the device. Please take dealer’s advice
as reference.
5.1.3 SIM card installation. Discharge the cover of the device and uncover the SIM card
holder. Then insert the SIM card and cover SIM card holder
5.1.4 Put back the front cover and screw it up.
5.1.5 Connect the device to the 9-24Vpower supply.（the red LED constant glow）
5.1.6 Install the device in the hidden place of the car；
The SIM card must be with GPRS function and enough deposit. If your SIM card need
input PIN when power on, please cancel it.
5.2 Installation
The GPS tracker must be installed under professional personnel.
Note：
1) Please install the device in the hidden place as followings：

Under Front windshield；
In the front instrument panel；
Under back windshield；
2) Avoid being placed with signal radiators like reverse sensor ；
3) The device has GSM antenna and GPS antenna inside. Please ensure the
receiving side of the device is face up and without metal cover.
Note：The metal cover will lessen the receiving of GPS signals.6. The device
connecting requirements.
6. Device wiring requirements
6.1 The device power supply is DC 9-24V. The red line is positive pole while the
black line is negative pole.
6.2 The negative pole of power supply connects with ground or the metals.
Please do not connect with other ground lines.
6.3 When finishing the power supply wire connection, please make the plug of
power supply to the device.

7.The Device Working
7.1 Power on: the device will be power on when connecting to the current. Then the three
LED indicators will light continuously. The device will upload the data to the
online platform (the default interval of uploading data is 10seconds). When the
car is in static state for a long time, the device will be in energy saving mode
and it will be more smart and precise.
7.2Power off：Pull off the power plug then power off the device.
8.User Settings
8.1 Set class instruction
1)CENTER
Text
command
Parameter
Sample
CENTER Add
710#number#
711#number#
710#13500135000#
711#13800138000#
CENTER Del
D01#
D02#
D01#
D02#
Command
Description
1)Center number can control the oil and power and
resume factory settings
2) Center number can receive the call and text of
vibration alarm and over speeding alarm.
3) SIM must display the income call number to control oil
and power.
4) Only one number can be center number.
5) Change center number must resend the command.
6)Add new center number by CETNER,A, and delete by
CENTER,D
Command
Feedback
Successful Setting：Add admin account 1 OK!

2) View administrator number
Text
command
Parameter
Sample
View
901#
901#
Command
Description
This directive is used to view Device Manager number.
Command
Feedback
Successful Setting：Admin1:
Admin2:
3)Authorized number set
Text
command
Parameter
Sample
Authorized
Add
101# number #
102# number #
103# number #
1：101#13800138000#
2：102#12345678912#
3：103#12345678912#
Authorized
Del
D11#
D12#
D13#
D11#
D12#
D13#
Command
Description
1) Authorization number for SMS control oil.
2) only three numbers to set the authorization number
3) change the authorization number needs to delete the
previous number

Command
Feedback
Successful Setting：Add Authorization account 1 OK!
4) View authorized number
Text
command
Parameter
Sample
View
authorized
C10#
C10#
Command
Description
This directive is used to view the equipment authorization
number
Command
Feedback
Successful Setting：
Authorization 1：
Authorization 2：
Authorization 3：
5)APN
Text
command
Parameter
Sample
APN Setting
802#username#pas
sword]
1：802#intenet#123#123#
Command
Description
APN differs according to the local telecom operators.
For example：APN request password ，please refer to
Sample1，and Sample2 for no password.
Command
Feedback
Successful Setting：SET APN OK！
6) Set / view SERVER
Text
command
Parameter
Sample

SERVER
Parameter
803#SERVER # port#
803#222.217.240.243#8011#
view
SERVER
CIP#
1）CIP#
Command
Description
Change the IP and port when move to a new server
port：10~65535
1 is domain and 0 is IP；
Command
Feedback
Successful Setting：set IP OK!
7)TIMER
Text
command
Parameter
Sample
TIMEER
Parameter
setting
730#uploading interval#
730#20#
Command
Description
Time scope：0，10~60 seconds；0,no data uploading；
10~60,means time interval ；the default value is 15
seconds！
Command
Feedback
Successful Setting：SET TIMER OK！
7) Alert on/off
Text
command
Parameter
Sample
Alert on Com
mand
911#
911#
Alert off co
mmand
910#
910#

Command
Description
This command is used to set the alert on/off, against unk
nown movement or shake.
Command
Feedback
Reply Set successfully
8)STATIC
Text
command
Parameter
Sample
STATIC
SUP# time interval#
SUP#5#
Command
Description
Time scope：1~60 minutes；The device has3Dtransmission
and the default time interval are 5 minutes.
Command
Feedback
Successful Setting：SET STATIC TIME OK！
9) Cancel the continuous upload
Text
command
Parameter
Sample
NUP
NUP#
NUP#
Command
Description
This command is used to cancel sending data to the
platform
If need again to restore the upload , you need to send
TIMEER Parameter setting or STATIC
Command
Feedback
SET OK！
10)RELAY

Text
command
Parameter
Sample
RELAYParame
ter1
222#
222# cut off oil and power
RELAYParame
ter2
333#
333# recover oil and power
Command
Description
1)RELAY control the start and closeness of the relay
2) Only the center number can operate.
3）the device only cut off the oil circuit on the condition
of the driving speed below 20KM/H or in static state.
4)When send the command, the device will reply “please
waiting “When the vehicle speed is over 20KM/H, the
device will cut off the oil or the power when the speed
below 20KM/H.
Command
Feedback
Successful Setting：Fuel cut has already been completed
OK!
11)GMT
Text
command
Parameter
Sample
GMT
801#location,
time#
801#E8#
Command
Description
The default time zone is Beijing time. If time zone need
revised, please operate according to the above command.
Command
Feedback
Successful Setting：Set time zone ok!
12)VIBRATION
Text command
Parameter
Sample

VIBRATION Parameter
123#2#,alarming way#
1) 123#2#3#
Set into vibration
alarm time
V123#2#
1) V123#2#
2) V123#1#
Cancel vibration
alarm
456#
456#
Command Description
the sensitivity value of the vibration is from 1 to
5，1is the most sensitive and o is close. Alarming
ways: 1, calling 2, texting, 3 calling and texting.
Must set the center number and receiving number.
Command Feedback
set vibration alarm level，OK!
13)SPEEDING
Text
command
Parameter
Sample
SPEEDING
Parameter
SSA#120# alarming
way#
1)SPEEDING,120,3#
2)SPEEDING,120#
Command
Description
The speed scope is form 60-220, if the speed is no this
cope, the alarm is off.
Alarming ：1, calling 2, texting, 3 calling and texting.
Must set the center number and receiving number.
Command
Feedback
Successful Setting：set speeding alarm，OK!
14)RESET
Text
command
Parameter
Sample
RESET
930#
930#
Command
Description
Reset the device
Command
Feedback
Successful Setting：Reset system, ok!

15)FACTORY
Text
command
Parameter
Sample
Parameter
940#
940#
Command
Description
Restore the factory setting
Only center number can initial this function
Factory setting will recover to the original setting
Command
Feedback
Successful Setting：FACTORY OK！
16)LANG
Text
command
Parameter
Sample
LANG
Parameter
LANG1#
LANG0#
LANG1# 1:CHINESE，
LANG0#：ENGLISH
Command
Description
；When check the location, it will reply the Chinese
location in Chinese language setting; while reply the URL
link when in English language setting.
Command
Feedback
Successful Setting：SET LANG OK！
17)WHERE
Text
command
Parameter
Sample
WHERE
988#
988#
Command
Description
Check the longitude and altitude and other information
of the device
Command
Feedback
Reply with longitude and altitude, speed and IMEL.
18)URL
Text
command
Parameter
Sample
WHERE
666#
666#
Command
Check the location link of Google map

Description
Command
Feedback
<Datetime:12-07-05 13:21:30>
http://maps.google.com/maps?q=N22.540885,E113.9526
5
19)VERSION
Text
command
Parameter
Sample
VERSION
V00#
V00#
Command
Description
The command is to check the software version
Command
Feedback
VERSION:Xxxx
BUILD:2012-07-05 10:12
20)PARAM
Text
command
Parameter
Sample
PARAM
886#
886#
Command
Description
The command is to check the settings and the default
parameter.
Command
Feedback
IMEI:351190012535936
APN : cmnet
IP:IP and port
TIMER: moving uploading interval
STATIC: static uploading interval
CENTER: center number
LANG: language(CN/EN)
GMT: time zone (E/W8)
21)STATUS
Text
command
Parameter
Sample
STATUS
902#
902#
Command
Description
The command is designed for checking the device’s
working status.

Command
Feedback
External power:ON/OFF
GSM Signal:HIGH/MIDDLE/LOW
GPS:FIXED/UNFIXED
RELAYER:DISABLE/ENABLE
Vibrate Warning:ON/OFF
Pause:ON/OFF
9.Trouble shooting
9.1The device is not online or offline on the web platform
9.1.1First, please check the three LED working state. Ifpossible. You
can call the device’s number to check.
● If not connected, the device is out of signal. If the GSM signals
cannot reach your location, pleasedrive to the open sky.
If reminding the device SIM card is out of deposit, please make
deposit by the telecom operator.
● If you can connect to the device when calling, the SIM card has deposited
and please check with your operator for GPRS function. You also can
check by searching the internet on your mobile phone.
● If reminding the device is power off, please turn back the device and
proceed as followings:
a)Check if the red LED is in constant glow. If the LED is dark, please
check the power connecting. If fuse is broken, please return the
device to the seller.
b)If the blue GSM LED is not in constant glow, please check the
installation of SIM card.
9.1.2 Please check the offline area in order to judge if the network
problem of operators.
9.2 When GPS cannot receive the signals, please drive in the open sky and
ensure there is no metal thins on the device.
9.3 When the device cannot receive the GSM signal, please check the SIM
card installation. If the GSM signals cannot reach your location (such as
the basement), please drive to the open sky.

9.4 The red LED is not glow when power on. Check the fuse of the power
line. If the fuse is fused, please change the fuse with the seller.
