Workzone WZEN 20 Instruction Manual

Now you have purchased a Workzone® product you
can rest assured in the knowledge that as well as your
3 year parts and labour guarantee you have the added
peace of mind of dedicated helplines and web support.
ELECTRIC STAPLE GUN
OPERATING INSTRUCTIONS  USER GUIDE
MODEL: WZEN 20, 03/2014
ELECTRIC STAPLE GUNELECTRIC STAPLE GUN

2
Contents
Page
3Welcome
4-8 General Information and Safety Instructions
9Assembly and Parts List
10-11 Getting Started
12 Features
13-17 Instructions
18 FAQ
19 Warranty Card
GB IRE WZEN 200151 649 1500 1890 946244 www.einhell.co.ukAFTER SALES SUPPORT

3
Welcome 1
Congratulations!
You have made an excellent choice with the purchase of this
quality Workzone® product.
By doing so you now have the assurance and peace of mind which comes
from purchasing a product that has been manufactured to the highest
standards of performance and safety, supported by the high quality
standards of ALDI.
We want you to be completely satised with your purchase so
this Workzone® product is backed by a comprehensive manufacturer’s
3 year warranty and an outstanding after sales service through our
dedicated Helpline.
We hope you will enjoy using your purchase for many years to come.
If you require technical support or in the unlikely event that your purchase
is faulty please telephone our Helpline for immediate assistance. Faulty
product claims made within the 3 year warranty period will be repaired
or replaced free of charge provided that you have satisfactory proof of
purchase (keep your till receipt safe!). This does not aect
your statutory rights. However, be aware that the warranty will
become null and void if the product is found to have been
deliberately damaged, misused or disassembled.
GB IRE WZEN 200151 649 1500 1890 946244 www.einhell.co.ukAFTER SALES SUPPORT

4
General Information
and Safety Instructions 2
CAUTION: Read all safety regulations and instructions. Any failures
made in following the safety regulations and instructions may result
in an electric shock, re and/or serious injury. Keep all safety regulations
and instructions in a safe place for future use.
The term 'electric tool' used in the safety regulations refers to electric
tools operated from the mains power supply (with a power cable) and
to battery operated electric tools (without a power cable).
Workplace safety
•Keep your work area clean and well illuminated. Untidy or unlit work
areas can result in accidents.
•Do not use this tool in a potentially explosive environment containing
combustible liquids, gases or dust.
•Electric tools generate sparks, which can in turn ignite dust or vapours.
•Keep children and other persons away from the electric tool while it
is being used.
•Stay alert, allowing yourself to get distracted can cause you to lose
control of the tool.
Electrical safety
•The tool’s connector plug must be able to t into the socket outlet. Do not
modify the plug in any way! Do not use adapter plugs in conjunction with
electrically grounded tools. Unmodied plugs and matching socket outlets
reduce the risk of an electric shock.
•Avoid touching grounded surfaces, such as those of pipes/tubes, heaters,
cookers and refrigerators.
•There is an increased risk of getting an electric shock if you are
electrically grounded.
•Keep the tool away from rain and moisture/wet conditions.
•Penetration of water into an electric tool increases the risk of an
electric shock.
GB IRE WZEN 200151 649 1500 1890 946244 www.einhell.co.ukAFTER SALES SUPPORT

5
•Do not use the cable to carry the tool, hang it up or pull the plug out of
the socket. Keep the cable away from sources of heat, oil, sharp edges
and moving tool parts.
•Damaged or tangled cable increases the risk of an electric shock.
•If you intend to use an electric tool outdoors, ensure that you only use
an extension cable that is approved for outdoor applications. Using an
extension cable that is approved for outdoor applications reduces the
risk of an electric shock.
•If operation of the electric tool in a damp environment can not be avoided,
use an earth leakage circuit-breaker. The earth-leakage circuit-breaker
reduces the risk of an electric shock.
Personal safety
•Be alert, work conscientiously and exercise appropriate caution when
using the electric tool. Do not use the tool if you are tired or are under
the inuence of drugs/medication or alcohol. One moment of carelessness
or lack of attention when using the electric tool can cause serious
bodily injury!
•Always wear personal protective equipment (PPE), including safety
goggles. Wearing personal protective equipment such as protective
headgear and ear defenders reduces the risk of sustaining an injury.
•Make sure that the tool cannot start up accidentally. Ensure that the
electric tool is switched o before you connect the tool to the power
supply, or pick up or carry the tool. Physically touching the switch with
your nger when carrying the tool or connecting the tool to the power
supply switched on can lead to accidents.
•Avoid abnormal working postures. Make sure you stand squarely and keep
your balance at all times. This way, you will be able to have better control
over the tool in unexpected situations. Wear suitable clothes. Never wear
loose tting clothes or jewellery. Keep hair, clothes and gloves away from
moving parts. Loose clothing, dangling jewellery and long hair can be
caught by moving parts.
General Information
and Safety Instructions 2
GB IRE WZEN 200151 649 1500 1890 946244 www.einhell.co.ukAFTER SALES SUPPORT

6
Using, and the treatment of electric tools
•Do not overload your tool. Only use suitable electric tools to perform your
work. Using the right electric tool allows you to work better and more
safely within the tool’s quoted capacity range.
•Do not use an electric tool with a defective ON / OFF switch. An electric
tool that can no longer be switched on or o is dangerous and must
be repaired.
•Do not use this tool if the Power Cord is damaged. Have the cord repaired
by an authorised specialist. Do not attempt to repair the cord yourself
before making any adjustments to the tool, changing accessories or
putting the tool down. This precaution eliminates the possibility of
inadvertently starting the tool.
• This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
• Supervise young children to ensure they do not play with the appliance.
• Take good care of your tool. Check that moving parts properly function
and do not jam, that parts are not broken o or damaged in any way and
that the tool can be used to its full capacity. Have damaged parts repaired
prior to using the tool. The cause of many accidents can be traced back to
poorly maintained electric tools.
•Keep your blades sharp and clean. Properly maintained blades with sharp
edges jam less frequently and are easier to use.
•Make sure to use electric tools, accessories, attachments, etc. in accordance
with these instructions. Take the conditions in your work area and the job
in hand into account. Using electric tools for applications other than those
intended can lead to dangerous situations.
Service
•Have your tool repaired only by authorized specialists using original
replacement parts. This will ensure that your tool remains safe to use.
General Information
and Safety Instructions 2
GB IRE WZEN 200151 649 1500 1890 946244 www.einhell.co.ukAFTER SALES SUPPORT

7
Additional safety instructions
•Always assume that the tool contains fasteners. Careless handling of the
tacker can result in unexpected ring of fasteners and personal injury.
•Do not point the tool towards yourself or anyone nearby. Unexpected
triggering will discharge the fastener causing an injury.
•Do not actuate the tool unless the tool is placed rmly against the
workpiece. If the tool is not in contact with the workpiece, the fastener
may be deected away from your target.
•Disconnect the tool from the power source when the fastener jams in the
tool. While removing a jammed fastener, the tacker may be accidentally
activated if it is plugged in.
•Do not use this tacker for fastening electrical cables. It is not designed for
electric cable installation and may damage the insulation of electric cables
thereby causing electric shock or re hazards.
•Always remove the plug from the wall socket whenever the tool is not
being used, before carrying out any maintenance work or changing the
staples or nails.
•Wear the necessary Personal Protective Equipment (PPE), in particular
safety goggles and ear defenders, when working with the Electric
Staple Gun.
•Always keep the magazine and all guides free of foreign bodies. Before
using the tool always make sure that there are no foreign bodies in the
magazine or guides.
•Make sure that the tool is kept clean and also that the air vents are free
and clean.
•Never use the tool with staples or nails which are not suitable for it. The
use of other staples and nails may cause injury or damage the tool. Read
the operating instructions for notes on which staples and nails are suitable.
•If the Electric Staple Gun is in use over a long period, the tool may heat up
as it is designed for intermittent operation. After using the tool for a long
period, remove the plug from the wall socket and allow the tool to cool.
•When working with the Electric Staple Gun, keep your ngers and other
body parts away from the stapler head.
General Information
and Safety Instructions 2
GB IRE WZEN 200151 649 1500 1890 946244 www.einhell.co.ukAFTER SALES SUPPORT

8
General Information
and Safety Instructions 2
GB IRE WZEN 200151 649 1500 1890 946244 www.einhell.co.ukAFTER SALES SUPPORT
CAUTION: Read the operating instructions to reduce the risk of inquiry.
Wear safety goggles. Wear ear defenders.
Read the operating instructions to reduce the risk of inquiry.
•Never use the stapler to fasten electric cables.
•Never allow children to use the Electric Staple Gun.
•Do not use the tool when other persons or animals are in the near vicinity.
Never shoot staples or nails into the air. Staples and nails shot at short
distance can lead to serious injuries.
•Make sure that there are no other persons in the direct vicinity when
working with the Electric Staple Gun.
•Use the Electric Staple Gun only for joining soft materials such as wood
or fabrics.
•Take special care when working with thin materials. Make sure that the
staples or nails are not too long or they may stick out of the workpiece or
may even pass all the way through. Make sure that no part of your body
is on the other side of the workpiece.
•Make sure that the workpiece is held securely by a clamping device or
a vice. Never hold the workpiece you wish to staple simply in your hands.
Always guide the power cable away from the back of the tool. Make sure
not to staple the power cable of the Electric Staple Gun by accident.
•Never leave the loaded tool unsupervised.
•Never operate the Electric Staple Gun without staples or nails.
•If a staple or nail becomes jammed in the feed shaft, remove the plug
from the wall socket and remove the jammed staple or nail as described
in the operating instructions.
•Do not lose these safety regulations.
IMPORTANT: Do not lose these safety regulations.

Fig 1
9
GB IRE WZEN 200151 649 1500 1890 946244 www.einhell.co.ukAFTER SALES SUPPORT
Assembly and Parts List 3
6
7
3
4
5
2
1
Fig 2
A4
Fig 5 Fig 6
Fig 3
4
Fig 7
Fig 4
b

10
Getting Started 4
GB IRE WZEN 200151 649 1500 1890 946244 www.einhell.co.ukAFTER SALES SUPPORT
Layout (Fig. 1/2)
1. Trigger
2. Trigger interlock
3. Stapling controller
4. Magazine slide
5. Magazine
6. Filling level indicator
7. Electric Staple Gun head
IMPORTANT: When using equipment, a few safety precautions must
be observed to avoid injuries and damage. Please read the complete
operating manual with due care. Keep this manual in a safe place,
so that the information is available at all times. If you give the equipment
to any other person, give them these operating instructions as well.
We accept no liability for damage or accidents which arise due to
non-observance of these instructions and the safety information.
Proper use
•The Electric Staple Gun is designed for stapling and fastening textiles,
leather and wood with the appropriate staples and nails. The Electric
Staple Gun is designed for intermittent operation. If operated continuously,
the stapler will become hot and the increasing heat will reduce its
performance. When hot, interrupt your work and allow the stapler to cool.
•The machine is to be used only for its prescribed purpose. Any other
use is deemed to be a case of misuse. The user / operator and not the
manufacturer will be liable for any damage or injuries of any kind
caused as a result of this.
•Please note that our equipment has not been designed for use in
commercial, trade or industrial applications. Our warranty will be voided
if the machine is used in commercial, trade or industrial businesses or for
equivalent purposes.
11

Getting Started 4
CAUTION: Read all safety regulations and instructions. Any errors made
in following the safety regulations and instructions may result in an
electric shock, re and/or serious injury. Keep all safety regulations and
instructions in a safe place for future use.
CAUTION:
• For your own safety, use only staples and nails listed in the directions
for use. The use of staples and nails other than those listed in the
directions for use may result in risk of injury.
• Be sure to pull out the power plug whenever the tool is not being
used, each time before carrying out any maintenance, and whenever
you want to change the staples or nails!
• It is important to wear suitable protective clothing, in particular safety
goggles and ear defenders, when working with the Electric Staple Gun.
11
GB IRE WZEN 200151 649 1500 1890 946244 www.einhell.co.ukAFTER SALES SUPPORT

13
12
GB IRE WZEN 200151 649 1500 1890 946244 www.einhell.co.ukAFTER SALES SUPPORT
Features 5
Technical data
Supply voltage 230 V ~ 50 Hz
Shots per minute 20
Staple width 11.2 - 11.4 mm
Staple length 8 - 16 mm
Staple thickness 1.16 - 1.26 mm
Nail length 14 - 16 mm
Nail thickness 1.16 - 1.26 mm
Weight 1.2 kg
Protection class II/
Sound and vibration
Sound and vibration values were measured in accordance with EN 60745.
L sound pressure level 73 dB(A)
K uncertainty 3 dB
L sound power level 86 dB(A)
K uncertainty 3 dB
pA
pA
WA
WA
Wear ear defenders
The impact of noise can cause damage to hearing. Total vibration values
determined in accordance with EN 60745.
Vibration emission value a 4.6 m/s
K uncertainty 1.5 m/s
2
h
2
WARNING: The specied vibration value was established in accordance
with a standardized testing method. It may change according to how
the electric equipment is used and may exceed the specied value in
exceptional circumstances. The specied vibration value can be used to
compare the equipment with other electric power tools. The specied
vibration value can be used for initial assessment of a harmful eect.
Power Consumption

13
GB IRE WZEN 200151 649 1500 1890 946244 www.einhell.co.ukAFTER SALES SUPPORT
12
Instructions 6
Keep the noise emissions and vibrations to a minimum
•Only use appliances which are in perfect working order.
•Service and clean the appliance regularly.
•Adapt your working style to suit the appliance.
•Do not overload the appliance.
•Have the appliance serviced whenever necessary.
•Switch the appliance o when it is not in use.
•Wear protective gloves.
Residual risks
Even if you use this electric power tool in accordance with instructions,
certain residual risks cannot be rules out. The following hazards may
arise in connection with the equipment’s construction and layout:
•Lung damage if no suitable protective dust mask is used.
•Damage to hearing if no suitable ear protection is used.
•Health damage caused by hand-arm vibrations if the equipment is used
over a prolonged period or is not properly guided and maintained.
Starting up
Inserting the staples (Fig. 2-4)
•Remove the plug from the wall socket.
•Press the lever (a) on the magazine slide (4) downwards (Fig. 2).
•Pull the magazine slide (4) to the rear as far as the stop (Fig. 3).
•Load the magazine with staples or nails (Fig. 4).
When you load the magazine with nails, make sure that these rest against
the left inner side (b) of the magazine. Then slide the magazine slide back
in until it stops and snaps noticeably into place.

Instructions 6
IMPORTANT: It must be possible to move the magazine slide without
applying much force. Watch out for jammed staples or nails.
Setting the stapling force (Fig. 1)
You can pre-select the stapling force of the Electric Staple Gun to suit
the length of the staples or nails used and the strength of the material.
To do so, set the stapling force control (3) to the desired force. (Rotate
the wheel clockwise to increase the force, or counter-clockwise to
decrease the force). The ideal stapling force is best determined by
carrying out a trial on a
test piece.
Operation (Fig. 1/5/6)
Before starting your work, always check the lling level indicator (6) to
see if the magazine (5) contains staples or nails and is properly closed
with the magazine slide (4).
Triggering shots
The built-in trigger interlock prevents the Electric Staple Gun from being
triggered accidentally. Triggering is only possible as follows:
•Push the trigger interlock (2) into the 'ON' position.
•Press the head of the Electric Staple Gun against the material and
operate the trigger (1).
•If the Electric Staple Gun is no longer in operation – even for short
periods – push the trigger interlock (2) into the 'OFF' position to
prevent unintentional operation.
Inserting staples
Load the staples into the magazine as shown in Fig. 5.
Inserting nails
Load the nails into the magazine as shown in Fig. 6.
15
14
GB IRE WZEN 200151 649 1500 1890 946244 www.einhell.co.ukAFTER SALES SUPPORT

Instructions 6
15
GB IRE WZEN 200151 649 1500 1890 946244 www.einhell.co.ukAFTER SALES SUPPORT
14
Stapling textiles, materials, leather, etc.
Press the head of the Electric Staple Gun against the object where you
want to staple and operate the trigger.
Stapling wood strips
Use only nails to staple wood strips. Do not press the Electric Staple Gun too
rmly against the wood strip or you might damage the surface.
Filling level indicator (Fig. 1)
The lling level indicator (6) shows you if there are still enough staples or
nails in the magazine (5). If necessary, rell the magazine (5) as described
above. Avoid operating the trigger (1) if there are no staples or nails in the
magazine (5).
Cleaning, maintenance and ordering of spare parts
Always remove the mains power plug from the wall socket before starting
any cleaning work.
Cleaning
•Keep all safety devices, air vents and the housing free of dirt and dust as far
as possible. Wipe the equipment with a clean cloth or blow it with
compressed air at low pressure.
•We recommend that you clean the tool immediately after you use it.
•Clean the tool regularly with a dampened cloth and some soft soap. Do not use
cleaning agents or solvents; these may be aggressive to the tool’s plastic
parts. Ensure that no water can get into the interior of the tool.
Maintenance
There is a risk of staples becoming jammed particularly when the Electric
Staple Gun is held at any angle when operated. In this case, switch the tool
o immediately and pull the power plug.
IMPORTANT: Always remove the mains power plug from the wall
socket before doing any work on the Electric Staple Gun.

16
GB IRE WZEN 200151 649 1500 1890 946244 www.einhell.co.ukAFTER SALES SUPPORT
17
Instructions 6
Removing jammed staples (Fig. 2/3/7)
Pull the magazine slide (4) to the rear as far as the stop (Fig. 2/3).
Carefully remove the jammed staples with a pair of pliers. Push the
magazine slide (4) back in until it stops and snaps noticeably into place.
•There are no parts inside the equipment which require additional
maintenance.
Ordering spare parts
Please quote the following data when ordering replacement parts:
• Type of machine: WZEN 20
•Article number of the machine: 42.578.62
•Identication number of the machine: 11013
•Replacement part number of the part required For our latest prices
and information please go to www.einhell.co.uk
Disposal and recycling
At the end of its working life, do not throw this appliance out
with your household rubbish. The European Directive 2002/96/
EC on Waste Electrical and Electronic Equipment (WEEE) requires
that old household electrical appliances must not be disposed
of in the normal unsorted municipal waste stream. Old appliances must
be collected separately in order to optimise the recovery and recycling
of the materials they contain and reduce the impact on human health
and the environment.
The crossed out 'Wheeled Bin' symbol on the product reminds you
of your obligation that when you dispose of the appliance, it must
be separately collected.
Contact your local authority for information concerning the correct
disposal of your old appliance.

16
17
GB IRE WZEN 200151 649 1500 1890 946244 www.einhell.co.ukAFTER SALES SUPPORT
Instructions 6

18
GB IRE WZEN 200151 649 1500 1890 946244 www.einhell.co.ukAFTER SALES SUPPORT
FAQ 7
How do I claim
for a warranty
matter?
1. Fill in the Warranty card and send to the Einhell
UK Ltd Address.
2. Contact Einhell UK Ltd, using one of the
Telephone numbers for AFTER SALES SUPPORT.
3. Or contact via the Einhell UK Ltd website.
How do I obtain
spare parts (not
covered by the
warranty)?
Make sure you have the information from the
product data label, or page 15 of this user guide,
and then:
1. Contact Einhell UK Ltd, using one of the
Telephone numbers for AFTER SALES SUPPORT,
and choose the option for Spare Parts.
2. Or contact via the Einhell UK Ltd website,
where spares information & prices are available.
What do I do if I
accidentally cut
the mains cable?
To avoid danger, get an electrician or suitably
qualied person to:
1. Fit a waterproof connector to re-join the cable.
2. Or replace the mains cable into the unit.

GB IRE WZEN 200151 649 1500 1890 946244 www.einhell.co.ukAFTER SALES SUPPORT
ELECTRIC STAPLE GUN
IRL
GB 0151 649 1500
1890 946244 www.einhell.co.uk
MODEL: WZEN 20, 03/2014
Monday to Thursday 8:45am - 5pm,
Friday 8:45am - 3pm.
Return your completed warranty card to:
Unit 9, Stadium Court
Wirral International Business Park
Plantation Road
Bromborough
Wirral
CH62 3QG
www.einhell.co.uk/warranty
AFTER SALES SUPPORT
Description of malfunction:
Your details:
Name
Address
Email
Date of purchase*
Location of purchase
*We recommend you keep the receipt with this warranty card
YEAR WARRANTY
18
Warranty Card 8
19
IMPORTANT!
KEEP THIS FORM SAFE: Only complete and return this form to the address below in the unlikely event of a
warranty claim, if you are requested by the manufacturer to return the item for replacement. Then please
complete this form and send it together with your receipt (proof of purchase) to the address below.
