I. Overview
X8121r is multi-mode ADSL Router, compliant with ANSIT1.413
Issue 2, ITU G.992.1 (G.dmt) Annex A/B, G.992.2 (G.lite). X8121r
provides high-speed Internet access via one WAN port over ATM
over ADSL, and also connects to a corporate network via one
10/100BaseT Ethernet port. X8121r allows the service provider to
deploy ADSL rapidly over existing wire infrastructure (POTS or ISDN
line).

X8121r User’s Manual Version 1.1
7 / 71
II. Features
High speed asymmetrical data transmission on a single twisted
copper pair
Full rate operations up to 8Mbps downstream (12Mbps to be
provided) and up to 1Mbps upstream. G.lite operation up to
1.5Mbps downstream and 512Kbps upstream
One 10/100BaseT Ethernet port for PC connection
DHCP server support for easy LAN IP address management
Supports PPPoE (RFC2516), PPP (RFC2364), and IP (RFC
2225/RFC1577) over ATM over ADSL
RFC2684 (RFC1483) Bridged/Routed for both LLC/VC MUX
Allows LAN users to access the Internet through Network
Address Translation (NAT, IP sharing) simultaneously
Local OAM&P through command line interface via RJ-45
Ethernet port or RS-232 Craft port (optional)
Configuration and management via Telnet and Web browser
through the Ethernet and ADSL interfaces
Supports applications such as TFTP, DHCP, Telnet, HTTP, and
FTP
Firmware upgradeable through TFTP
Interoperability complies with TR-48, U-R2
Supports dying gasp detection (optional)

X8121r User’s Manual Version 1.1
8 / 71
III. Packaging
This package consists of the following items:
X8121r ADSL device unit
RJ-45 Cable
RJ-11 Cable
AC Adapter
User’s Manual CD

X8121r User’s Manual Version 1.1
9 / 71
IV. Appearance
Front Panel
Label
LED
Status
Color
Description

100M
ON
Green
100M Ethernet transmitting.

10M
ON
Green
10M Ethernet transmitting.

PWR
ON
Green
Power supply is connected.

WAN
Blinking
Green
Training with DSLAM.
ON
Green
ADSL link is ready.

ALM
Blinking
RED
Booting up.
ON
RED
Error.






X8121r User’s Manual Version 1.1
10 / 71
Rear Panel
Label
Description

PWR
Power jack; connect to a power adapter.

ETHERNET
RJ-45 port; connect to a PC or LAN.

RESET
Reset the modem back to factory settings by
holding down on this button.

WAN
RJ-11 or RJ-45 port; connect to the ADSL
outlet.
X8121r uses RJ-11 Cable.
X8121r-B uses RJ-45 Cable.





X8121r User’s Manual Version 1.1
11 / 71
V. Hardware Installation
1. Connect one end of the ADSL cable to the WAN port of
X8121r and the other end to the ADSL wall outlet. (X8121r
uses RJ-11 cable and X8121r-B uses RJ-45 cable)
2. Use a RJ-45 cable to connect one end to the Ethernet port of
X8121r, and the other end to the LAN or a PC with an
Ethernet adapter installed.
3. Plug in the AC adapter to the AC power socket, and then
connect the DC jack to the PWR inlet of X8121r.
Note: Be sure to use a RJ-45 crossover cable while connecting to a hub.
Power Supply
ADSL Outlet
PC

X8121r User’s Manual Version 1.1
12 / 71
VI. Management
X8121r supports simple, flexible, and easy-to-operate methods for
management purposes. X8121r can be managed via the following
paths:
Local Ethernet Port (Telnet) –connect the Ethernet port
to your local area network or directly to a PC. “Telnet”
X8121r from any workstation in the LAN. The default local
Ethernet IP address is “192.168.1.1”.
Local Ethernet Port (Web Browser) –connect the
Ethernet port to your local area network or directly to a PC.
Launch your web browser and enter default local Ethernet
IP address “192.168.1.1” into the address bar.
ADSL Port from Remote Site –while the ADSL
connection is in service, you may remotely “Telnet” X8121r
from a workstation connected to the CO equipment.
Note: As operating an ADSL device requires technical know-how and
experience. It is recommended that only qualified technical staffs
manage X8121r. Therefore, a password authentication is required when
you enter the web interface. To obtain the password, see the Default
Values section.

X8121r User’s Manual Version 1.1
13 / 71
VII. Default Values
X8121r is pre-configured with the following parameters; you
may also re-load the default parameters by rebooting the router into
the Default configuration from the web browser.
Default Mode: Bridge Login Name: admin
Password:admin
Bridge Mode Setting WAN and ADSL
Ethernet (local) IP: 192.168.1.1 Local Line Code: Auto
Subnet Mask: 255.255.255.0 Trellis Mode: Enable
Full Duplex: Auto FDM Mode: Fdm
Protocol: RFC1483, Bridge Mode Coding Gain: Auto
VPI/VCI: 8/35 Transmit Power Attenuation: 0dB
Class (QoS): UBR
Spanning Tree: Disable
Packet Filter: Any
Router Mode Setting DHCP Server: Disable
Ethernet (local) IP: 192.168.1.1 DNS Relay: Disable
Subnet Mask: 255.255.255.0
Note: The User Name and Password are case-sensitive.

X8121r User’s Manual Version 1.1
14 / 71
VIII. Software Upgrade
You may easily upgrade X8121r embedded software by
obtaining the compressed upgrade kit from the service provider then
following the steps:
Extract the ZIP file for updated firmware.
Connect X8121r via the local Ethernet port or remote
ADSL link. Make sure that X8121r Ethernet IP address
and your terminal are properly configured, then you can
successfully “ping” X8121r. The default local IP address is
192.168.1.1.
Under DOS prompt, execute the FTP command “open <IP
address of X8121r>”, then input user name and
password.
Execute upload command “put tepatch.bin“.
This upgrading process may last as long as 60 seconds.
Then reboot to the default values of X8121r with new
software.
Note 1: X8121r software may also be upgraded through the web
interface. See Chapter 2: G. Admin, 3. Image Upgrade
Note 2: Strictly maintain stable power to X8121r while upgrading its
software. If the power fails during the upgrading process, contents in
the memory could be destroyed, and the system may hang. In such a
case, you must call the dealer or system integrator for repairs.

X8121r User’s Manual Version 1.1
15 / 71
Chapter 2
Web Interface Management
I. Overview
The Web management is provided in order to manage the ADSL
device as easily as possible. It provides a very user-friendly
configuration and graphical interface through a Web based platform.
You can configure a bridge or a router, as you feel appropriate. In the
section below, each configuration item is described in detail.
II. Preparation
1) Please refer the hardware installation procedure to install
modem.
2) You should configure the PC to the same IP subnet as the
modem.
For example: The modem: 192.168.1.1
Your PC: 192.168.1.x
3) Let your PC access the modem, and make sure that the
PING function is working properly. The default IP address
of this modem could be found in the default settings
section.
4) Open the Web browser (Internet explorer or Netscape),
enter the default IP address “192.168.1.1” for the website
address to access the web management page.
5) The Login dialog box will pop up first.

X8121r User’s Manual Version 1.1
16 / 71
III. Login
The window Enter Network Password will pop up while
starting the configuration. With the window open, type admin for
both the Username and the Password. You can also edit the
Username and Password or add new users. (For further details,
see G. Admin: 1. User Config)
After you log into the web interface, you will notice that it is
divided into seven different sections, or tabs. From this point on,
each tab is described in detail along with instructions for
configuration. The seven tabs are:
A. Home
B. LAN
C. WAN
D. Bridging
E. Routing
F. Services
G. Admin

X8121r User’s Manual Version 1.1
17 / 71
A. HOME
After logging in, the first tab that will be displayed is the Home
tab. Under this tab, the System View page is displayed. This
page displays a summary of the interfaces and their settings.

X8121r User’s Manual Version 1.1
18 / 71
This page is divided into five sections. The table below
describes each section.
Section Name
Description
Device
Displays model name, hardware/software
version, device mode, uptime, current time,
time zone, daylight savings time, and domain
name.
DSL
Displays operation status, last state, DSL
version, and DSL standard.
WAN Interface
Displays the WAN interface name,
encapsulation type, IP address, subnet mask,
lower interface, VPI/VCI values, and
operational status.
LAN Interface
Displays the LAN interface name, MAC
address, IP address, subnet mask, lower
interface, transmission speed, duplex type
and operational status.
Services Summary
Displays the interface name, and
enabled/disabled features, such as: NAT, IP
filter, RIP, DHCP relay, DHCP client, DHCP
server, and IGMP.
To add, change, or remove any of the interface settings, click on
the interface name.
Click on the Modify button to set the device date, time, time
zone, and other related settings. Click on the Submit button
when completed.

X8121r User’s Manual Version 1.1
19 / 71
B. LAN
Click on the LAN tab to view its sub-menu’s and configure the
LAN settings. The four sub-menu’s are: LAN Config, DHCP
Mode, DHCP Server, and DHCP Relay. Each sub-menu is
described below.
1. LAN Config
Click on the LAN Config link to change the LAN IP address/
subnet mask, decide where the LAN is getting its IP address
from, and enable or disable IGMP. Follow the steps below in
order to set up the LAN.
I. Get LAN Address: Select Manual if you would like to enter
your own IP address. Select External DHCP Server if a
DHCP server other than this device assigns the IP
addresses. Select Internal DHCP Server if you would like
this device to assign the IP addresses.
II. LAN IP Address: Enter the LAN IP address into these text
boxes.
III. LAN Network Mask: Enter the subnet mask of the LAN IP
address into these text boxes.
IV. IGMP: Depending on your ISP’s settings, choose to enable
or disable IGMP.
V. Click on the Submit button when completed.

X8121r User’s Manual Version 1.1
20 / 71
2. DHCP Mode
Click on the DHCP Mode link to select a DHCP setting. From
the drop down list, select DHCP Server, DHCP Relay, or None.
Click on the Submit button when completed.
3. DHCP Server
Click on the DHCP Server link to view the DHCP Server
settings. The table displays the DHCP server settings, this
includes: start IP, end IP, domain name, gateway address, and
status. Click on the Add button to enable a DHCP server and
fill in the IP information based on your ISP settings.
