Xema BlueKeyboard User manual

1/25
BlueKeyboard for BlackBerry - User’s Manual v2.0 - © 2005 Xema, Inc.
BlueKeyboard for BlackBerry
User’s Manual
v2.0
© 2005 Xema, Inc.
All rights reserved.

2/25
BlueKeyboard for BlackBerry - User’s Manual v2.0 - © 2005 Xema, Inc.
BlueKeyboard End-User License Agreement
IMPORTANT-READ CAREFULLY: This BlueKeyboard End-User License Agreement ("EULA") is a
legal agreement between you (either an individual or a single entity) and Xema, Inc. (“XEMA”) for
the software(s) identified above, which includes the User's Guide, any associated software
components, any media, any printed materials other than the User's Guide, and any online or
electronic documentation ("SOFTWARE"). By installing, copying, or otherwise using the
SOFTWARE, you agree to be bound by the terms of this EULA. If you do not agree to the terms of
this EULA, do not install or use the SOFTWARE.
1. THE SOFTWARE IS LICENSED, NOT SOLD.
2. GRANT OF LICENSE.
When you purchase a BlueKeyboard with license you will be provided with a key code. You should
enter the key code as prompted by the SOFTWARE.
3. RESTRICTIONS.
You may not reverse engineer, de-compile, or disassemble the SOFTWARE, except and only to the
extent that such activity is expressly permitted by applicable law notwithstanding this limitation.
You may not rent, lease, or lend the SOFTWARE. You may permanently transfer all of your rights
under this EULA, provided the recipient agrees to the terms of this EULA.
4. SUPPORT SERVICES.
XEMA may provide you with support services related to the SOFTWARE. Use of Support Services is
governed by XEMA polices and programs described in the user manual, in online documentation,
and/or other materials provided by XEMA, as they may be modified from time to time. Any
supplemental SOFTWARE code provided to you as part of the Support Services shall be considered
part of the SOFTWARE and subject to the terms and conditions of this EULA. With respect to
technical information you provide to XEMA as part of the Support Services, XEMA may use such
information for its business purposes, including for product support and development.
5. TERMINATION.
Without prejudice to any other rights, XEMA may terminate this EULA if you fail to comply with
the terms and conditions of this EULA. In such event, you must destroy all copies of the
SOFTWARE.
6. COPYRIGHT.
The SOFTWARE is protected by copyright laws and international treaty provisions. You
acknowledge that no title to the intellectual property in the SOFTWARE is transferred to you. You
further acknowledge that title and full ownership rights to the SOFTWARE will remain the
exclusive property of XEMA and you will not acquire any rights to the SOFTWARE except as
expressly set forth in this license. You agree that any copies of the SOFTWARE will contain the
same proprietary notices which appear on and in the SOFTWARE.
7. NO WARRANTIES.
XEMA expressly disclaims any warranty for the SOFTWARE. the SOFTWARE and any related
documentation is provided "as is" without warranty of any kind, either express or implied,
including, without limitation, the implied warranties or merchantability, fitness for a particular
purpose, or non infringement. The entire risk arising out of use or performance of the SOFTWARE
remains with you.

3/25
BlueKeyboard for BlackBerry - User’s Manual v2.0 - © 2005 Xema, Inc.
8. LIMITATION OF LIABILITY.
In no event shall XEMA or its suppliers be liable to you for any consequential, special, incidental,
or indirect damages of any kind arising out of the delivery, performance, or use of the SOFTWARE,
even if XEMA has been advised of the possibility of such damages. in any event, XEMA’s liability
for any claim, whether in contract, tort, or any other theory of liability will not exceed the greater
of U.S.$1.00.
9. MISCELLANEOUS.
Should you have any questions concerning this EULA, or if you desire to contact the XEMA for any
reason, please contact by electronic mail at: [email protected].
END OF EULA

4/25
BlueKeyboard for BlackBerry - User’s Manual v2.0 - © 2005 Xema, Inc.
Contents
Page 2
4
5
7
8
17
19
21
22
24
25
BLUEKEYBOARD END-USER LICENSE AGREEMENT (EULA)
CONTENTS
PREFACES
HARDWARE FUNCTIONS
FEATURES
SYSTEM REQUIREMENTS
THE BLUEKEYBOARD DRIVER
HANDHELD COMPATIBILITY
COMPUTER HARDWARE/SOFTWARE
DRIVER INSTALLATION
PRE-INSTALLATION CHECK LIST
INSTALL THE DRIVER FROM CD TO COMPUTER
INSTALL THE DRIVER FROM COMPUTER TO BLACKBERRY HANDHELD
PAIRING THE BLUETOOTH
DRIVER REGISTRATION & CONFIGURATION
KEY CODE, SOUND LEVEL, REPEAT RATE, REPEAT DELAY, FUNCTION KEYS
KEYS ASSIGNMENT
GENERAL KEY USAGE
TEXT EDITING KEY USAGE
BLACKBERRY ENTERPRISE SERVER (BES) CONFIGURATION
FAQ
CONTACT INFORMATION

5/25
BlueKeyboard for BlackBerry - User’s Manual v2.0 - © 2005 Xema, Inc.
Preface
The BlueKeyboard - the Bluetooth keyboard and its driver - that runs on BlackBerry OS™ powered
Bluetooth devices will allow you to input data wirelessly using Bluetooth technologies. With
features listed below it will give user a new experience in mobile computing.
HOW TO PREPARE THE CRADLE…

6/25
BlueKeyboard for BlackBerry - User’s Manual v2.0 - © 2005 Xema, Inc.
HARDWARE FEATURES:
 Bluetooth technology
 Compact foldable design
 Detachable fold-out cradle for device
 63 full size keys
 QWERTY layout with dedicated number keys
 Lock open for laptop stability
 Power on/off Switch
 Bi-color LED for Bluetooth connection and power status
 90 hrs continuous operation time, 168 hrs standby time
 Open dimension: 279mm x 95mm x 13mm
 Close dimension: 143mm x 95mm x 19mm
 Key lifetime: 10 millions presses
 Manufacturer warranty: 1 year
SOFTWARE FEATURES:
 Support USA, Germany, and Spanish keyboard layout
 Shortcuts and user programmable keys for specific tasks
 Multitasking - easy switching between applications
 Extended symbol/character mapping
 Typomatic rate control - adjustable repeat rate and repeat delay
 Auto On/Off backlight for easy typing and reading
 Audible keyboard connect/disconnect indicators with volume control
ATTENTION! BlackBerry Enterprise Server (BES) user!
Please contact your BES administrator and refer to BlackBerry Enterprise Server (BES)
Configuration section on this manual to get the BlueKeyboard works.

7/25
BlueKeyboard for BlackBerry - User’s Manual v2.0 - © 2005 Xema, Inc.
System Requirements
THE BLUEKEYBOARD DRIVER
The driver CD comes together with the Bluetooth keyboard you bought. In case you don’t have
the CD, please download the driver from BlueKeyboard website at: www.bluekeyboard.com.
HANDHELD COMPATIBILITY
The BlueKeyboard has been tested with the BlackBerry device models as listed below. If your
device is not listed, there is possibility it will work. However, Xema cannot guarantee it will work.
At least 25 KB free space on your device is needed to install the BlueKeyboard driver.
7100G
7100R
7100T
7100V
7100X
7250
7290
7520
COMPUTER HARDWARE/SOFTWARE
A computer with at least one USB port.
Microsoft Windows 98SE/ME/2K/XP. This user manual is based on Win XP.
BlackBerry Desktop Software with Desktop Manager 4.0 or above.
USB Cable which come together with your BlackBerry device.

8/25
BlueKeyboard for BlackBerry - User’s Manual v2.0 - © 2005 Xema, Inc.
Driver Installation
PRE-INSTALLATION CHECK LIST
Make sure the USB cable connected to your BlackBerry handheld and computer.
Uninstall all old keyboard drivers from your BlackBerry handheld.
This installation is a two steps process. The first step is to install the BlueKeyboard driver from CD
(or from internet download) into your computer. The second step is to install the driver from your
computer to the BlackBerry handheld. Please follow step-by step below.
A. INSTALL THE DRIVER FROM CD TO COMPUTER
A1. Insert the driver installation CD into the computer and let it run. The first BlueKeyboard setup
window appears like below; click [BlackBerry] button.
•If the installation CD doesn’t run automatically, please double click BlueKeyboard
Setup.exe file which located under <CD-Drive>:/Drivers/BlueKeyboard 2.0/ folder.
•If you download the driver from BlueKeyboard website, please decompress the downloaded
package and run the BlueKeyboard Setup.exe file.

9/25
BlueKeyboard for BlackBerry - User’s Manual v2.0 - © 2005 Xema, Inc.
A2. Select your preferred language and click [OK] to continue to setup wizard.
A3. The setup wizard starts when you click [NEXT].

10/25
BlueKeyboard for BlackBerry - User’s Manual v2.0 - © 2005 Xema, Inc.
A4. Please read the End-User License Agreement (EULA) and click [I Agree] to continue with the
driver installation; otherwise click [Cancel] to cancel the installation.
A5. Select the driver(s) you want to install and click [Next].

11/25
BlueKeyboard for BlackBerry - User’s Manual v2.0 - © 2005 Xema, Inc.
A6. The default installation location is as stated on [Destination Folder] field; replace it with
your preferred location if you like. Click [Next] to continue.
A7. Type the start menu folder for shortcuts and enter to [Install].

12/25
BlueKeyboard for BlackBerry - User’s Manual v2.0 - © 2005 Xema, Inc.
A8. The program starts to copy all selected files to your computer. Click [Finish] and the first
step of installation is done!

13/25
BlueKeyboard for BlackBerry - User’s Manual v2.0 - © 2005 Xema, Inc.
B. INSTALL THE DRIVER FROM COMPUTER TO BLACKBERRY HANDHELD
B1. Launch the BlackBerry Desktop Manager on your computer, make sure your computer
Connected to BlackBerry device then click the [Application Loader] to start the wizard.
B2. Click [Next] and the Application Loader Wizard will prepare the drivers installation on your
BlackBerry handheld.

14/25
BlueKeyboard for BlackBerry - User’s Manual v2.0 - © 2005 Xema, Inc.
B3. If BlueKeyboard is not listed on the Application Name list, use the [Add] button to locate
the file in the installation directory. As explained on Step A6 above, the default file location is
C:/Program Files/ Xema/BlueKeyboard.
B4. Select the driver file and Click [Open] to continue the installation.
•BlueKeyboard_US.alx is the driver for United State keyboard layout.
•BlueKeyboard_DE.alx is the driver for Germany keyboard layout.
•BlueKeyboard_ES.alx is the driver for Spanish keyboard layout.

15/25
BlueKeyboard for BlackBerry - User’s Manual v2.0 - © 2005 Xema, Inc.
B5. The BlueKeyboard should be listed on the Application Name list now. Make sure the
Action column says ‘Install’. Click [Next] to continue.
6B. This is the last step before the Application Loader program installs the BlueKeyboard driver
to your BlackBerry handheld. You can read a summary of what you are about to install on the
window. Click [Finish] to finalize the installation process.

16/25
BlueKeyboard for BlackBerry - User’s Manual v2.0 - © 2005 Xema, Inc.
B7. [Close] the Application Loader Wizard once the installation done successfully. Now you
should see BlueKeyboard icon (the icon with two hands typing a keyboard) on your BlackBerry
handheld screen like picture below.

17/25
BlueKeyboard for BlackBerry - User’s Manual v2.0 - © 2005 Xema, Inc.
Pairing the Bluetooth
Check list:
Disable any other Bluetooth keyboard you may have installed or be using.
Check the battery power.
Steps below show you how to pair the Bluetooth of the BlackBerry handheld to the BlueKeyboard.
BlackBerry screens shown here are taken from BlackBerry 7290 series.
1. Turn on the keyboard power; make sure the green LED
is blinking. From the Home Screen of BlackBerry
device, click [Options] icon.
2. Scroll down the list and click [Bluetooth].
3. If ‘Bluetooth: Disabled’ screen appear, click the
BlackBerry trackwheel and select Enable Bluetooth.
Please by pass this step if your device’s Bluetooth had
been enabled.
4. Once the Bluetooth enabled, click the trackwheel again
to Add Device.

18/25
BlueKeyboard for BlackBerry - User’s Manual v2.0 - © 2005 Xema, Inc.
5. …and BlackBerry’s Bluetooth start searching for new
available devices…
6. After finished the searching, BlackBerry handheld will
list down all found devices. Select and click the
‘KEYBOARD’.
7. When asked for passkey, please enter 0000 (four
zero) and press enter.
8. If you hear ‘beep beep’ sound briefly and the
KEYBOARD listed on Paired Devices list as shown in
figure on the left, you had successfully paired the
Bluetooth.

19/25
BlueKeyboard for BlackBerry - User’s Manual v2.0 - © 2005 Xema, Inc.
Driver Registration and Configuration
For security purpose, the BlueKeyboard driver was designed to have unique activation code (key
code) which works with unique Bluetooth keyboard. The BlueKeyboard comes with many
adjustable features to let user set their own preferred state. This section of manual will explain
the key code registration and the adjustment.
1. Turn on the keyboard power; make sure the green LED is blinking. Locate the BlueKeyboard
key code; it is a hexadecimal number in format of XXX-XXX-XXX (for example: 3D1-DFD-
EAA).
2. From the Home Screen of BlackBerry device, click
[BlueKeyboard] icon as shown on the right.
3. Enter the key code into the Key Code field. The key code
is case-sensitive, all alphabets must be CAPITAL. Scroll
the cursor to [Register!] button and click.
4. You will hear ‘beep-beep’ sound briefly and a ‘CODE
ACCEPTED!’ message if the key code is correct,
otherwise you will get ‘WRONG CODE!’ message.
Click [OK] to continue.
Attention!
We recommend you to write down the key code and keep
it in save place.

20/25
BlueKeyboard for BlackBerry - User’s Manual v2.0 - © 2005 Xema, Inc.
5. The status change to ‘Keyboard Connected!’ which
means the keyboard is ready to use.
Note: Bluetooth connection normally takes a few seconds
to connect or disconnect; therefore when turning on/off
the keyboard power there will be a delay before the
status field display any changes.
6. Now you can use keyboards’ up and down arrow keys to scroll the cursor on BlackBerry screen.
Use keyboards’ left and right arrow keys to change the value you preferred.
Sound Level option allows you to set the volume of beep sound when the keyboard connect or
disconnect with your BlackBerry handheld. Two beeps will be heard when the keyboard makes
connection; one beep when it is disconnected.
Repeat Rate option allows you to set the speed at which any typed character will repeat when
press and hold down a key. The higher the value the quicker the key will repeat.
Repeat Delay option allows you to set the length of time before any typed character begins to
repeat when you hold down a key. The higher the value the longer it will take before a key will
start repeating.
Keyboard Test field is where you test the effect of repeat rate and repeat delay option.
7. The BlueKeyboard comes with 10 user programmable
Function Keys. This feature gives user an easy access
to any of installed applications on BlackBerry handheld by
pressing the appropriate combination keys on the
keyboard.
Please use keyboards’ up and down arrow keys to scroll
the cursor to desired function key and use keyboards’ left
and right arrow keys to select desired application.
For example (see figure on the right) BlackBerry will
launch Alarm application when user pressing [Fn] and
[1] keys together.
Keyboard registration and setting finished. Press keyboards’ [Home] key to go back to BlackBerry
home screen.
