Xenun XT-009 User manual

XT-009 Gps tracker user manual
1
GSM / GPRS / GPS
VEHICLE TRACKER
XT-009
Preface
Thank you for purchasing our GPS vehicle tracker. This manual shows how to operate the device
smoothly and correctly. Please read this manual carefully before using it. Please note that specification
and information are subject to changes without prior notice in this manual. Any change will be
integrated in the latest release. The manufacturer assumes no responsibility for any errors or
omissions in this document.

XT-009 Gps tracker user manual
2
Index
1. Function Summary----------------------------------------------------------------------------3
2. Application-------------------------------------------------------------------------------------3
3. Hardware Description-------------------------------------------------------------------------3
3.1 Outside ------------------------------------------------------------------------------------3
3.2 Internal mainboard ----------------------------------------------------------------------4
4. Wire connection ------------------------------------------------------------------------------5
5. Specifications----------------------------------------------------------------------------------6
6. Battery and SIM Card installation-----------------------------------------------------------6
7. Startup-----------------------------------------------------------------------------------------6
8. Usage------------------------------------------------------------------------------------------6
9. Tracker mode----------------------------------------------------------------------------------7
9.1 Initialization------------------------------------------------------------------------------7
9.2 Change the password-------------------------------------------------------------------7
9.3 Authorization number-----------------------------------------------------------------7
9.4 SMS format ------------------------------------------------------------------------------8
9.5 Auto tracking -----------------------------------------------------------------------------8
9.6 Tlimit function ---------------------------------------------------------------------------9
9.7 GEO fence --------------------------------------------------------------------------------9
9.8 Movement alert -----------------------------------------------------------------------10
9.9 Overspeed alert ------------------------------------------------------------------------10
9.10 IMEI checking --------------------------------------------------------------------------11
9.11 Firmware version checking -----------------------------------------------------------11
9.12 Time zone setting ----------------------------------------------------------------------11
9.13 SOS button ------------------------------------------------------------------------------12
9.14 SMS LINK --------------------------------------------------------------------------------12
9.15 SMSONE ----------------------------------------------------------------------------------12
9.16 Low battery alert ------------------------------------------------------------------------12
9.17 Message center --------------------------------------------------------------------------13
9.18 GSM ID ------------------------------------------------------------------------------------13
9.19 Motion sensor ----------------------------------------------------------------------------13
9.20 SD Card -----------------------------------------------------------------------------------13
9.21 ACC status alert --------------------------------------------------------------------------14
9.22 Remote oil &energy cut off function --------------------------------------------------14
9.23 OTA feature -----------------------------------------------------------------------------14
10.Monitor Mode--------------------------------------------------------------------------------15
11.GPRS setting-----------------------------------------------------------------------------------16
12.Notes-------------------------------------------------------------------------------------------17
13.Faults and solutions--------------------------------------------------------------------------17

XT-009 Gps tracker user manual
3
1. Overview of function
z SMS/GPRS sending data
z Movement/ Geofence/ Speed/ Low battery alarm
z ACC alarm
z SOS alarm
z Remote cut-off electricity &oil function
z Impact alarm (with collision and acceseleration sensor)
z Voice monitoring
z Main power disconnect alarm
z Micro SD card for saving GPRSdata
z Remotely update firmware
z Distance limit data transmission
2.Application
z Vehicle/ship /motorcycle / rental / fleet management
z Children / elderly / disabled guardianship
z Personnel safety
z People management
z Tracking an offense
3.Hardware description
3.1 Outside
Microphone
SOS Button Working LED Power LED

XT-009 Gps tracker user manual
4
3.2 Internal mainboard
4. Wires connection
SD card SIM card
Red: +12V
Black: -12V
Green connects with ACC
White connects with Relay

XT-009 Gps tracker user manual
5
5. Specification
Content specs
Dimention 73*46*24(mm)
Weight 50g
Network GSM/GPRS
Band 850/900/1800/1900Mhz
GPS chipest SIRF3 chip
GPS sensitivity -159dBm
GPS accuracy 5-10m
Start-up time Cold status 45s Warm status 35s
Hot status 1s
External power supply DC6-36V input
Battery 3.7V 1200mAh battery
Standby 120hous
Storage Temperature -40°C to +85°C
Operation Temperature -30°C to +80°C
Humidity 5%--95% non-condensing
6. Battery and SIM Card installation
Make sure SIM card have no calling transfer, show calling ID is actived and PIN code is off.
1. Open two screws
2. Insert the SIM card and SD card
Open screws Insert SIM card
Insert SD card

XT-009 Gps tracker user manual
6
7.Startup
zPut the SIM card and SD card in right place,connect the battery with tracker or connect the tracker
with car/motorcycle battery 6-36V. it will turn on automatically. the red light will be on if connect
with vehicle battery 6-36V, it will be off if disconnect.
zThe green light will blink 2 times per second first and will be on for 1 second, off for 3 seconds
which means the tracker gets GSM network already.
zIt takes 40~90 seconds to receive GPS signals, in order to get good GPS signal, please put the
tracker outdoor.
8.Usage
This product has two working modes: tracking and monitoring. The default mode is tracking mode,
you can send SMS monitor+password to switch to monitoring mode and then send tracker+
password back to tracking mode.
Connect the battery
Close the screws

XT-009 Gps tracker user manual
7
TO:13188888888
noadmin123456 3166666666
TO:13188888888
noadmin ok
9. Tracking mode
9.1 Initialization
Send begin+password to the tracker, it will reply begin ok to initialize all settings.
9.2 Change password
Send SMS password+old password+space+new password, it will reply password OK.
the default password is 123456
9.3 Set authorized number
zSend SMS admin+password+space+cellphone number to set up the first authorized
number.
it will reply admin ok. Other authorized numbers must be set by the first one.
Max 5 authorized numbers.
zSend SMS noadmin+password+space+authorized number to cancel an
authorizated number
From:13188888888
password ok
TO:13188888888
begin123456
TO:13188888888
password123456 888999
From:13188888888
begin ok
TO:13188888888
Admin123456 13570803284
From:13188888888
ADMIN OK!

XT-009 Gps tracker user manual
8
9.4 SMS format
SMS format from the tracker:
Lat: 22.566901 long: 114.051258 speed: 0.00 14/08/09 06.54 F:3.85V,1,Signal:F imei:354776031555474
05 43.5 460 01 2533 720B
lat:[latitude] long:[longitude] speed:[speed] [date] [time] F:[battery
voltage]V,[charging status],Signal:[GPS signal status] [alarm message]* imei:[imei
number] [number of fixed satellites] [altitude] [MCC] [MNC] [LAC] [CellID]
[latitude] GPS received latitude
[longitude] GPS received longitude
[speed] GPS received speed
[date] GPS received date
[time] GPS received time
F:[battery
voltage]V, battery voltage
[charging status] “1” in charging, “0” no charging
Signal:[GPS signal
status] “F” GPS fix, “L” no GPS fix
[alarm message] it indicates alarm type (help me!, moved,
Speed etc.)
Just ignore this section if no any alarms
imei:[imei number] The identify number of GSM module
[number of fixed
satellites] GPS satellite fixed number
[altitude] GPS received altitude
[MCC] Mobile Country Code
[MNC] Mobile Network Code
[LAC] Location area Code
[Cell ID] GSM cell identities
9.5 Auto-track
zSend SMS t030s005n+password to the unit, it will report the Geo-info at 30s intervals for 5
times.(s: second, m: minute, h: hour).
zThe setting must be in 3 digits and at maximum 255 in value.
TO:13188888888
T030s005n123456
From:13188888888
T030s005n ok

XT-009 Gps tracker user manual
9
zSend SMS t030s***n+password to the unit, it will reply SMS heaps of times
zCancel: Send notn+password to delete the “ auto tracking ”
Remark: the interval must not be less than 5s.
9.6 Tlimit function
zSet up: Send SMS tlimit123456 50 , it will reply “tlimit ok” .If the tracker stop moving, it will
not send any data to cellphone or server, until the distance is more than 50 meters. Can change
to any other meters such as like 100, 500 or 1000, the maximum is 6000meters.
Remark:this function must be used with auto-tracking function together.
zCancel : Send SMS tlimit123456 0 to cancel tlimit function
9.7 Geo-fence
zSetup: Send SMS stockade+password+space+longitude,latitude; longitude,latitude
to the unit to set the restricted district. The unit will send message to the authorized numbers
when it moves out of this district.
zCancel: Send SMS “nostockade+password” to deactivate this function.It will reply
“nostockade ok”.
zThis function will be invalid if the unit move outside the district. You need to re-set it if you want
this function again.
zThe first longitude & latitude is coordinate of the top left corner of the Geo-fence, while the
second longitude & latitude is the coordinate of the bottom right corner.
TO:13188888888
stockade123456
114.124845E,22.567185N;114.777888E,22.555666N
From:13188888888
stockade ok
From:13188888888
lat: 22.566923 long: 114.051331
speed: 0.00 28/11/10 03:33
F:4.32V,0, Signal:F stockade
imei:359587011016261 05 41.5
460 01 2533 720B
From:13188888888
nostockade ok
TO:13188888888
nostockade123456

XT-009 Gps tracker user manual
10
9.8 Movement alarm
This function is using for the owner to get alarm when the tracker moves out of setting distance.
zSetup: Send SMS move+password+distance to the unit to set the movement alert,it will
reply move ok.(the moving distance is from 200mto 6000 meters)
If device is out of moving distance,it will send alert to authorized number one time in each
setting.the reply format is below:
zCancel: Send SMS nomove+password to deactivate the movement alert,it will reply nomove ok !
9.9 Overspeed Alert
This function is used to control the user’s driving speed.
zSetup: Send SMS speed+password+space+ the speed, For example: speed123456 080,it
will reply” speed ok”
zCancel: Send SMS”nospeed+password “to deactivate the overspeed alert,it will reply”
nospeed ok”
zResponse SMS format: speed+080!+Geo-info (suppose the speed is 80km/h).
The tracker will check the speed in 3 minutes interval and alarm if it is overspeed.
TO:13188888888
move123456 200
From:13188888888
move ok
TO:13188888888
nospeed123456
From:13188888888
nospeed ok
From:13188888888
lat: 22.566923 long: 114.051331 speed: 0.00
28/11/10 03:33 F:4.32V,0, Signal:F move
imei:359587011016261 05 41.5 460 01 2533 720B
TO:13188888888
speed123456 080
From:13188888888
speed ok

XT-009 Gps tracker user manual
11
Remark: It is recommended that the speed alarm is set at 30-200km/h
9.10 IMEI check
Send SMS” imei+password: to the unit,it will reply imei350001122222222 ok.
9.11 Firmware version check
Send SMS version +password to the unit，it will reply the firmware version, like XT009 V1.1 OK
9.12 Time Zone setting
Send “time zone+password + GMT time ,reply “time zone ok”. (note: if GMT time is positive, just
write the number 1. If time zone is negative, have to write –1)
TO:13188888888
imei23456
From:13188888888
imei350001122222222 ok
From:13188888888
lat: 22.566923 long: 114.051331
speed: 0.00 28/11/10 03:33
F:4.32V,0, Signal:F speed
imei:359587011016261 05 41.5
460 01 2533 720B
TO:13188888888
Time zone23456 1
From:13188888888
time zone ok
TO:13188888888
Time zone23456 -1

XT-009 Gps tracker user manual
12
9.13 SOS button
zIf you press SOS button for 3 seconds, tracker will send SOS SMS to all authorized numbers.
Alert SMS format:
9.14 SMS LINK
zSend SMS “smslinkone+password”, the tracker will reply only one google map link to the
cellphone immediately .The position can be checked directly by smartphone
Google map link Format：
http://maps.google.com/maps?f=q&hl=en&q=22.567610,114.051227&speed: 0.00 12/11/10
14:36 F:4.22V Signal:F imei:012207000691839
zSend SMS“smslink+password”, it will reply “smslink OK” . when you call the tracker, it will
reply you sms with google map link.
zSend SMS “smstext+password”, it will reply “smstext OK”. The tracker will reply text SMS to
cellphone
9.15 SMS ONE
Send SMS“smsone+password”.The tracker will only send one text SMS to the cellphone or
server,instead of calling to get the coordinate.
9.16 Low Battery/main power cut Alert
zWhen the internal battery voltage is less than 3.7 V, it will send low battery alert to all
authorized numbers.
Format:lat: 22.566923 long: 114.051331 speed: 90.00 28/11/10 03:33 F:4.32V,0, Signal:F low
batt imei:359587011016261 05 41.5 460 01 2533 720B
zWhen main power(6-36V) is off or cut,the device will send sms alert to all authorized numbers.
Format:lat: 22.566923 long: 114.051331 speed: 90.00 28/11/10 03:33 F:4.32V,0, Signal:F
battery imei:359587011016261 05 41.5 460 01 2533 720B
From:13188888888
lat: 22.566923 long: 114.051331 speed:
90.00 28/11/10 03:33 F:4.32V,0, Signal:F
help me imei:359587011016261 05 41.5
460 01 2533 720B

XT-009 Gps tracker user manual
13
9.17 SMS Center
zSetup: Send SMS adminsms+password+space+cell phone number to setup the SMS
center.
The tracker will reply Geo-info & authorized number to sms center number even if the admin
numbers call or sending command to the tracker
zCancel: Send SMS noadminsms+password to cancel the SMS center.
9.18 GSM ID
GSM ID is in each sms or gprs data. The tracker can be found by GSM ID without gps signal. But the
customers have to ask their GSM operator for data base of the GSM ID.
9.19 Motion (Acceseleration)Sensor
zSetup: Send SMS shake+password+space+1-10 to the tracker to set up this function
(1-10 means the level of intensity)
zSend SMS shake+password+space+1 is the least sensitivity . Have to shake the tracker
strongly to get the alert.
zSend SMS shake+password+space+10 is the most sensitivity . Have to shake the tracker
slightly to get the alert
zCancel: Send SMS shake+password+space+0 to remove this function.
9.20 Micro SD card
Put Micro sd card to the tracker SD card slot. The GPRS data can be saved in the SD card if there
is no gsm/gprs network. It will send data to the GPRS server again after connecting gsm/gprs
network.
zSetup: Send SMS sdlog+password+space+1 to activate the sd card-saving function
zSetup: Send SMS readsd+password+space+1 to ask the tracker to send gprs data in the
SD card to the GPRS server.
zCancel: Send SMS sdlog+password+space+0 to deactivate this function
zCancel: Send SMS readsd+password+space+0 to deactivate this function
zRemark: only need to configure one time before using this function.
9.21 ACC status alert
Connecting device to car ACC,when ACC is on ,the tracker will send “accstart “ ,when ACC is off ,the
tracker will send “accstop “
zAlarm format：lat: 22.566923 long: 114.051331 speed: 90.00 28/11/10 03:33 F:4.32V,0,

XT-009 Gps tracker user manual
14
Signal:F ACCstart imei:359587011016261 05 41.5 460 01 2533 720B
zAlarm format：lat: 22.566923 long: 114.051331 speed: 90.00 28/11/10 03:33 F:4.32V,0,
Signal:F ACCstop imei:359587011016261 05 41.5 460 01 2533 720B
(Note: each time when the ACC status changed it’ll send alarm )
9.22. Remote oil & electricity cut-off function
This function is for the car owner to send SMS remotely to stop vehicle. Please note that in certain
country you cannot do this.
zSetup: Send SMS : powercar+password+space+11 it will reply “power car OK” cut off
car oil and electricity .
zCancel: Send SMS :powercar +password+space+00 it will reply “power car OK” restart
car again.
9.23 OTA feature
Can update firmware remotely when the GPRS and SD card work normally
zSetup: Send SMS ：
fota +password+ ,ftp,v120705.bin,121.37.40.240,user,+888999+,21
it will reply “fota OK”
v120705.bin--------the name of the file which you need upgrade，
121.37.40.240-------remote server IP address，
User-------------------remote server user name，
888999----------------remote server password，
21----------------------remote server port,
(Note: separated by comma.)
Ater receiving “fota OK”,the tracker starts downloading the file, 5 minutes later the platform will
receive “Download successful! Restarting…” it means downloading is successful, then the
tracker starts to update firmware automatically. The platform will receive “Remote upgrade
successful !!!” in 2 minutes which means the updating is successful.

XT-009 Gps tracker user manual
15
10. Monitoring mode
zSetup: Send SMS : monitor+password it will reply “monitor OK”
When you call tracker, you can hear voices and sounds around tracker.
zCancel: Send SMS :tracker+password it will reply “tracker OK”
Transfer to tracking mode .
11. GPRS set
zSet IP address and port
Send SMS: adminip+[password]+space+[IP address]+space+[port]
Tracker will reply with SMS “ADMINIP ok!”
Cancel
Send SMS:noadminip+[password]
zSET APN
Send SMS:apn+[password]+space+[APN]
Tracker will reply with SMS “APN ok!”.
Cancel
Old APN will be deleted automatically when you set up a new one.
zSet APN User Name
Send SMS :apnuser+[password]+space+[APN user name]
Tracker will reply with SMS “APNUSER ok!”
Cancel
Old APN user name will be deleted automatically when you set a new APN user name.
zSet APN Password
Send SMS :apnpasswd+[password]+space+[APN password]
Tracker will reply with SMS “APNPASSWORD ok!”.
Cancel
Old APN password will be deleted automatically when you set a new APN password.
After setting up IP & Port & APN & APN user name & APN password, you can use the gprs
function. Tracker will send gprs data to the server.

XT-009 Gps tracker user manual
16
GPRS format:
[serial number],[authorized number],[GPRMC],[type of fix GPS],[message],imei:[imei
number],[number fix satellites],[altitude],[battery status],[charging status],[Length],
[crc16],[MCC],[MNC],[LAC],[CellID]
[serial number] GPS date+GPS time
[authorized
number] Tracker authorized number
[GPRMC] Nmea GPS info string
[type of fix GPS] “F” GPS fix, “L” no GPS fix
[message] it indicates message type
(help me!, speed, moved, etc.)
imei:[imei number] The identify number of GSM module
[number fix
satellites] GPS satellite fixed number
[altitude] GPS received altitude
[battery status] “F:4.11V” full battery, “L:3.65V” low
battery
[charging status] “1” in charging, “0” no charging
[GPSlen] GPS string length
[crc16] CRC16 checksum
[MCC] Mobile Country Code
[MNC] Mobile Network Code
[LAC] Location area Code
[CellID] GSM cell identities
For example:
090907070718,13145826175,GPRMC,070718.000,A,2234.0228,N,11403.0764,E,0.00,,0709
09,,,A*73,F,,imei:354776030042714,05,50.1,F:4.11V,0,132,40512,460,01,2533,720B
Notes:
•GSM ID can be added or deleted according to customer’s requirement.
•Our tracker supports TCP or UDP protocol: please confirm what protocol you need before
order.
•Please use SIM card with GPRS function.
Note:
zThe SMS message must be Text format, can’t be identified for PDU format.
zPlease use the tracker outside for the first time in order to get valid gps signal

XT-009 Gps tracker user manual
17
12. Cautions
Comply with instructions for use will extend the product life cycle.
•Keep the unit dry. Any liquid as rain, moisture, etc, may destroy or damage electronic
mainboard.
•Don’t use or store tracker in dusty places.
•Don’t put tracker in overheated or overcooled places.
•Handle carefully.
•Don’t vibrate or shake it violently.
•Clear tracker with a piece of dry cloth. Don’t clean using chemicals detergent.
•Don’t paint tracker: this may cause some foreign materials left in between parts.
•Don’t disassemble or refit tracker.
•Please use battery (and charger if you need) provided by manufacturer. Using other
batteries and chargers will cause unwanted situation.
•Don’t dismount antenna randomly, or use different antennas. This may interfere
transmission, and increase radiation as well.
13 .Faults and solutions
Faults Solutions
Startup fail Check battery charge or battery correct installation
Hangup fail If authorized number is set, an unauthorized number
call tracker. Please initialize tracker and re-setup
correct authorized number
Monitor fail Check if authorized number is setup or GSM intensity
level
Indicator keep on flashing
quickly Check SIM card to see if it is put in correct place
SD card storing data fail Check SD card to see if it is put in correct place.
Location report in zeroes digits Tracker has no GPS fix: place tracker outdoor,
especially when starting it up
Notes:
•Tracker can send alarm SMS one time for each alarm event, or many time for each alarm
event, according to customer’s requirements.
•Commands can be sent by gprs tracking software or configured by usb cable, with the same
syntax of SMS commands.
