Xirgo XT6350 User manual

188 Camino Ruiz
Camarillo, CA 93012
www.xirgotech.com
[email protected]
XT6350UserGuide
Version 2.0

1
Sales Engineering
[email protected]
Contents
Document Change History .......................................................................................................................... 2
Hardware Specification............................................................................................................................... 3
Connector IO Interface................................................................................................................................. 4
Cable Harness Specification........................................................................................................................ 6
LED Defentition ........................................................................................................................................... 7
Current Consumption ................................................................................................................................. 7
Device mounting.......................................................................................................................................... 7
PC Device Configuration ............................................................................................................................. 8
Feature Matrix ............................................................................................................................................. 8
Device Configuration................................................................................................................................... 9
Parameter File ...........................................................................................................................................13
Messages.....................................................................................................................................................14
Script File ...................................................................................................................................................10
Parameter File ...........................................................................................................................................13
Appendices…………………………………………………………………………………………………………………………………………..13
7
Regulatroy Statements..............................................................................................................................28

2
Sales Engineering
[email protected]
Document Change History
Revision
Date
Changes
1.0
2/2/2015
Initial Release
2.0
3/18/2015
Updates by NB for FCC/ICC compliance

3
Sales Engineering
[email protected]

4
Sales Engineering
[email protected]
Hardware Specification:
Cellular Wireless Technology:
2G/GSM/GPRS/EGPRS: 850/900/1800/1900 Bands - Models: XT6350/ XT6355
3G (UMTS): 850/1900 Bands (Bands V, II) - Models: XT6360
CDMA (1xRTT): 850/1900 Bands - Models: XT6350
Parameter
Spec
GPS Specification
Receiver
56 channels
Receiver tracking
sensitivity
-162 dBm
Receiver Cold Start
-148dBm
CEP Accuracy
+/- 2.5m
TTFF
- Cold Start
- Hot Start
<29 sec
< 1 sec
HW Options:
3-axis Accel.
BT/BTLE
Last Gasp Back-up
Battery
Internal 250 mAh rechargeable Li-
Ion
Power Requirements
D.C. Power
9-32V
Physical Connection
Data Connector
24-pin Molex Main
14-pin Molex OBD/J-Bus
Antenna:
Cellular/GPS /BT
Internal
SIM Access (2G/3G)
N/A
Programming
Serial
Xirgo Device Manager (XDMI)
Mechanical
Case Material
PC2407, Black
Dimension
3.05”x 3.08”x 0.8”
Weight
3 oz.
Operating
Temperature
-30C to +75C
Certifications
Product
(CDMA) FCC ID: GKM-XT6350
(3G): FCC ID: GKM-XT6360
IC: 10281A-XT6350
Carrier
Verizon, ATT
Notes:
TTTF: All satellites at -130 dBm ;Accuracy: CEP, 50%, 24 hours static, -130 dBm, > 6 SVs

5
Sales Engineering
[email protected]
Connectors IO Interface:
Main 24-pin Molex Connector (IO Interface):
Pin No.
Pin Name
Comments
1
12/24 Volt Power
2
LED+12V
w/5K limiting resistor (panic LED)
3
Ground
Main Battery GND
4
Ign Out
Buzzer +12V/24V with 560 ohm
5
IN0
Ignition Sense
6
IN1
7
IN2
8
IN3
Panic: pin3 on panic 4-pin Molex
9
IN4
10
OUT0
Buzzer GND
11
OUT1
12
OUT2
Panic: pin4 (LED) on panic 4-pin
Molex
13
Garmin PWR
12V/2A Switched
14
Serial Port-1 TX
Garmin FMI Tx
15
Serial Port-1 RX
Garmin FMI Rx
16
Serial Port-1 GND
Garmin FMI GND
17
Serial Port-2 TX
18
Serial Port-2 RX
19
Serial Port-2 GND
20
1-Wire Serial Main
iButton Data (default)
21
1-Wire Serial Sec.
22
Ext. ADC
23
Spare GND
Panic GND
24
Spare GND

6
Sales Engineering
[email protected]
OBD 14-pin Molex connector (OBD2/JBUS/SWC):
J1962 OBD2
Pin No.
XT6350
Pins
XT6350 Pin Description
9 Pin J-Bus
6 Pin J-Bus
6
1
CAN_HS_H
C
2
J1708_RXD
G
B
3
J1708_TXD
F
A
15
4
L_LINE
10
5
J1850_NEG
2
6
J1850_POS
7
14
8
CAN_HS_L
D
3
9
CAN_MS_H
11
10
CAN_MS_L
1
11
SWC_BUS
7
12
K_LINE
5&4
13
GND
A
E
16
14
Vehicle Power (VBAT)
B
C

7
Sales Engineering
[email protected]
Cable Harness Specification:
24-pin Microfit: Molex 43025-2400
Panic SW/LED Button Conn. Molex 43020-0401 (4 pin 2 row female shell)
I-Button Conn.: Molex 43640-0201 (2 pin Female Shell)
Buzzer Conn.: Molex 43640-0301 (3 pin Female Shell)
Garmin Conn. Molex 43020-1001 (10 pin 2 row female shell)
Garmin pins 2 and 4 looped-in (black wire, 26 AWG)
Molex male pins: 43031-0002
Total length: 5 ft.
Pins 1, 3, and 5 are 18 AWG, All others are 24 AWG.
Fuse: 3A in line with pins with pins 1 (red) and 5 (white), 7 in. from wire end
Wires 1, 3, and 5 to be jacketed up to the fuse
24-pin
No.
Color
Length
AWG
Pin function
Comments
I-Button
Buzz.
Panic SW
LED
Garmin
1
Red
60 in.
18
VBAT
3A fuse, 7 in. from end
2
Orange
7 in.
20
LED+12V
3
3
Black
60 in.
18
Ground
4
White
7 in.
20
Ign Out
1
5
White
60 in.
18
IN0
3A fuse, 7 in. from end
6
Gray
60 in.
20
IN1
7
Brown
60 in.
20
IN2
8
Blue
7 in.
20
IN3
1
9
Red
60 in.
20
IN4
10
Brown
7 in.
20
OUT0
Buzzer GND
2
11
Orange
60 in.
20
OUT1
12
Yellow
7 in.
20
OUT2
4
13
Red
7 in.
20
Garmin PWR
12V/2A Switched
5
14
White/Brown
7 in.
20
Serial Port-1
TX
Garmin FMI Tx
1
15
Green
7 in.
20
Serial Port-1
RX
Garmin FMI Rx
6
16
Orange/Brown
7 in.
20
Serial Port-1
GND
Garmin FMI GND
4
17
Yellow
7 in.
20
Serial Port-2
TX
18
Green
7 in.
20
Serial Port-2
RX
19
Black
7 in.
20
Serial Port-2
GND
20
Gray
7 in.
20
1-Wire Serial
Main
i-Button
1

8
Sales Engineering
[email protected]
21
White
60 in.
20
OWB2
22
Purple
60 in.
20
Ext. ADC
23
Black
7 in.
20
Spare GND
Panic GND
2
24
Blue/Green
7 in.
20
Spare GND
2
LED Definition
Current Consumption
OPERATING MODE
CURRENT CONSUMPTION
Deep Sleep (non-functional mode)
3 mA
Standby
10 mA
Active Receive
65 mA
Device Mounting:
The XT6350 device must be securely installed. The accelerometer will not calibrate if unit is loose
when vehicle is in motion. When mounting the device, use a tie strap to secure the device as noted
below.
BASE
UNIT
LED
Description
Status
Cellular (Amber)
Searching for Cellular Network
LED OFF
Cellular Carrier Lock
Solid
GPS (Green)
Searching for satellite
Solid
GPS Lock
Blinking
Optional
Bluetooth (Blue)
TBD
TBD

9
Sales Engineering
[email protected]
PC Device Configuration:
a. A RS-232 to USB TTL converter cable is required to connect an XT6350 device to a computer for
local configuration. Serial Port # 2 is used for configuration. Connect the XT6350 Tx wire to the
TTL converter cable Rx wire. Connect the XT6350 Rx wire to the TTL converter cable Tx wire.
Connect the XT6350 ground wire to the ground wire of the TTL converter cable. Use a terminal
application to connect to the COM port associated with the TTL converter cable. Use the
following settings:
A. Terminal Application Settings:
a. Bits per second: 115200
b. Data bits: 8
c. Parity: None
d. Stop bits: 1
e. Flow control: None
B. Load Script File with the following command
a. :grscr x 2
C. Load Parameter File with the following command
a. :uyscr x 2
D. Save the configuration
a. :vycfg
Feature Matrix:
Technology
1XRTT
Feature Highlight
XT-4550
Locate
X
Idle
X
Vehicle Disable
X
5 Digital IO
X
2 - 1 Wire Bus
X
Ignition On/Off
X
Mileage
X
Periodic Reporting
X
Speed
X
Direction Change
X
Battery Voltage
X
Battery Disconnect
X
Tow Alerts
X
Movement Start/Stop
X
Acceleration/Deceleration
X
