Xtreme version 9 User manual

2

3
I. Contents of Your
Xtreme Version 9 Package……………... 2
II. Taking Care of Your
Xtreme Version 9……………………….. 4
III. Setting Up Xtreme Version 9 with Your
Vi eo/Au io System……………............ 5
IV. Key Function Gui e……......................... 7
A) Basic Karaoke Control Functions…... 9
1. Volume Control………………….. 9
• Main Mic Volume……………... 9
• Music Volume…………………. 9
• Sub-Mic Volume………………. 10
• Echo Volume…………………... 10
2. Pause / Resume………………….. 10
3. Song Selection…………………… 10
• Ran om………………………... 10
• Continuous Play……………….. 10
• Select / Reserve 11
4. Key 11
• Pitch Control 11
• Male / Female Voice Select 11
• Octave A just 12
5. Tempo 12
6. Change Melo y Instrument 12
B) Recor an Play Functions………….. 13
1. Recor ing 13
2. Playback 13
3. Delete Song (Using Main Mic) 13
4. Delete Song (Using Duet Mic) 13
C) Games……………………………….. 14
1. Song Contest 14
V.
2. Othello Game 14
VI. D) Configuration……………………... 15
VII. Song Chip…………................................. 17
VIII. Songlist Bin er…………………………. 17
IX. Wireless Sub-mic………………………. 18
X Troubleshooting Gui e…………............. 19
XI Specifications…………………………... 20
XII. Technical Service Centers………............ 21

4
POWER SUPPLY PRECAUTIONS:
1. Always make sure to remove batteries before connecting
your V9 to its power a aptor. If two sources of power are
use simultaneously, the batteries might leak an amage
the microphone. This will void the warranty.
2. Use only the A aptor supplie in your V9 package. If
this is lost or amage , replace only with an A aptor
supplie by The Astra Group, Inc. or by authorize Xtreme
Magic Sing ealers. The plug of other a aptors may fit,
but the electrical specifications may be ifferent an
therefore may amage the precise electronics of your V9
unit.
3. Always turn off the V9 before removing or a ing song
chips.
4. Turn off your V9 before unplugging the power a aptor.
5. Always remove batteries when not using the V9
microphone.
CLEANING AND HANDLING:
6. When cleaning, use a soft cloth. Dampen with water if
nee e . Never use alcohol or chemical solutions.
7. Do not rop your V9 or subject it to heavy
impact.
8. Do not use sharp objects (e.g., long fingernails, ball
pens) to press on the keypa .
9. Do not isassemble the microphone. This will void
the warranty.
STORAGE:
10. Avoi storing in irect sunlight, in places with high
temperature, or in moist areas.
11. When transporting your V9 in a vehicle, keep it with
you in the air con itione interior. If your unit was
transporte in the heate trunk of a vehicle, or was left in a
car un er the sun for some time, allow the microphone to
cool off before using. This will prevent it from overheating
while in operation.

5
1. Install your V9 an its attachments as shown
in the following iagrams.
2. Switch on the TV an system. Put the TV in vi eo
mo e.
3. Turn on your V9 by pressing .

6
Caution: Use only the a aptor supplie with your
Version 9 package, or a Magic Sing a aptor supplie
by The Astra Group, Inc. or an authorize Xtreme
Magic Sing ealer. Using other a aptors can amage
your mic even if they have a compatible plug.
Congratulations!
As owner of the
Xtreme Version 9,
you now have a highly useful,
practical an easy-to-use
han hel vi eoke microphone
for family entertainment,
fun activity with your frien s,
or even singing alone
simply to have fun!

7

8
1.
• Turns the power on or off.
2. Pilot LED light
• In icates if the power is on or off by emitting
Light
→ Green light = Power is ON
→ No light = Power is OFF
3. /
• Use to scroll through songs or other menus
an options.
4.
• Use to access ifferent menu functions
5.
• Use with other keys to turn sub-mic on or off,
elete a recor e song, an change a backgroun
melo y instrument.
6.
• Use to access pitch-relate functions.
7.
• Stops / plays your recor ing or a selecte song.
Also use to replay pitch when practicing, or to
select an option in the Configuration menu.

9
1) Volume Control
• Main Mic Volume
Press + + /
To adjust mic volume over 15 steps
• Backgroun Music Volume
Press + + /
To adjust volume of background music over 15 steps

10
• Sub-mic Volume
Press + + /
To adjust volume of sub-mic over 15 steps
• Echo Volume
Press + + /
To adjust echo volume over 15 steps
2) Pause / Resume
Press +
To pause or resume playback of selected song
3) Song Selection
• Ran om • Press +
Mic will randomly play songs
• Continuous Play • Press +
Mic will play songs in continuous se uence from lowest to
highest number

11
• Select / Reserve
Press (Song No.) + +
Select songs to play in the se uence you like. Press song
number, then + , then repeat for next song.
The TV screen displays only 6 songs, but you can pre-select
up to 20 songs to play in se uence.
4) Key
• Pitch Control
Press + + /
To adjust the key or pitch over 15 steps
• Male/Female Voice Select
Press + + +
Press to shift from male to female voice or vice
versa.

12
• Octave A just
Press + + + +
/
To adjust octave level down or up after selecting
male/female voice. Once the right scale is reached, press
to select and play. Press once more and
/ to adjust octave again.
5) Tempo
Press + + /
To increase / decrease tempo of songs
6) Change Melody Instrument
Press + +
Default instrument will change from piano to the next
instrument, successively pressing
will allow you to look
for the preferred instrument until piano is again selected.

13
1) Recording
Press (Song No.) + + +
To start recording the selected song
Press to stop.
Press again to resume recording.
2) Playback
Press +
To display onscreen the list of songs recorded
Press
/ to scroll to the song you want to play.
Press to playback or stop.
3) Delete Song using Main Mic)
Press
Highlight (select) the song you want to delete then press
.
4) Delete Song using Duet Mic)
Press
Highlight (select) the song you want to delete then press
.

14
1) Song Contest
Press + +
It’s fun to play this game by dividing people into two teams.
Each team selects three songs at random which they will
sing by turns. The team which gets a higher score wins. To
stop the game, just press the button.
2) Othello Game
Press + +
This is the famous Othello game, also known as the Reverse
game. It is a two-player game (black and white) and is
normally played on an 8x8 grid. To win, the player must
occupy the board with more of his/her own color pieces than
the opponent’s. At the start of the game, the board has two
pieces for each player placed diagonally on the center of the
board.
• Each player places a piece on the board starting with the
player using the black pieces (the “human” player). A
“valid” move is when you can turn at least one of your
opponent’s pieces into your colored piece. You can do this by
terminating a continuous line by placing your own piece on
the board. All the pieces in the line are then flipped to your
color. The lines can be in any of the eight lateral and
diagonal directions from the position you have chosen. If
there is more than one such line of pieces, all of them are
flipped to your color
Basic Rules of the Game:
1) The player with the black pieces goes first;
the two players go alternately.
2) To make a move, you must be able to flip at
least one of your opponent’s pieces to your

15
color by completing a line of pieces as
described above.
3) If you can make a valid move, you must
make that move.
4) If you can’t make any move, you must pass
your turn and your opponent plays again.
Press three times to enter the configuration
menu. To select the options un er each function, you
can either use / to scroll up or own
then press to select, or simply press the
correspon ing number on the left.
SUB MIC (ON / OFF)
• This option turns the sub mic on or off. It is similar
to pressing an , which also turns the sub-
mic on or off.
SCORE CHECK (AMATEUR /
PROFESSIONAL / STAR SINGER / OFF)
• Use this function to select the level of your singing
ability to match your score. “Amateur” is the easiest
level, “Professional” is more challenging, an “Star
Singer” is the most ifficult. For example, if you
choose “Star Singer,’ it will be har est for you to get

16
a high score if your singing skill oes not qualify to
be that of a star singer.
LYRIC LINE (AUTO / 2 LINE / 3 LINE)
• This function allows you to select how many lyric
lines to see on the TV screen uring song playback.
LYRIC FORMAT (CENTER / LEFT-RIGHT /
MIX ALL
• This function allows you to choose where lyric lines
will be locate on your TV screen.
REAL TIME SCORE (ON / OFF)
• This function allows you to turn on or off the score
isplay while singing.
• Exit.

17
1. Turn off your Version 9 microphone.
2. Open the back cover.
3. Insert the chip firmly with the arrow
pointing towar s the hea of the
microphone.
4. Close the back cover an turn the
power on.
5. Up to 4 song chips may be installe
at a time.
1. Open the bin er rings by pressing the
metal tabs at the top an bottom of the
bin er.
2. Put in the new song list between the
rings.
3. Close the bin er rings.

18
1. The main mic shoul be turne off.
2. Take out the back cover of the main mic an put in
the sub-mic receiving pack.
3. Turn on the main mic by pressing .
4. If you press an , the TV screen will
isplay “SUB-MIC ON.”
5. Open the back cover of the Sub-mic, insert two
AA batteries as in icate an press the power button
to turn it on. The green LED light will blink as a sign
that the sub-mic is alrea y on.
(Note: The batteries need to be replaced when a red
LED light appears.)
6. If you want to stop using the sub-mic, press
an . The TV screen will isplay “SUB-MIC
OFF,” then it will stop functioning.
These buttons on the sub-microphone function
similarly like those on the main microphone:
1. Arrow Down / Up /
2. Play/Stop
3. Power

19
1. If your Version 9 doesn’t power up
• When you are using the power a aptor
→ Make sure that the a aptor is correctly
plugge into the power outlet.
→ See to it that the male plug is appropriately
inserte into the female plug.
• When you are using batteries
→ Make sure that two new AA batteries are in
the compartment.
→ Check if the batteries are inserte in the
correct irection.
→ Check the elasticity of the stainless steel in
the battery compartment.
→ Make sure that the batteries are in goo
con ition.
2. If the user’s voice is not heard on the microphone
• Press the microphone button an check the
volume.
• Check the con ition of the batteries.
3. If the TV does not show pictures or output sound
• Make sure you have ma e the correct
connections accor ing to the correct colors.
• Check TV volume. If set too low, increase.
• Check if the TV is on vi eo mo e.
• Check the con ition of the batteries.
4. When the picture on the TV screen stays still and
the mic won’t turn off
• Press for 3 secon s or longer until the V9
turns off.
When uncertain about the unit’s performance, turn
off the power. While pressing 8 (for PAL TV
system) or 9 (for NTSC), turn the power on. It will
return to the original factory settings.

20
• Voice Fre uency Range : 200-1500 Hz
• Battery : 1.5V x 2 Alkaline
• TV Channel : Video Channel
• Wattage : 500 mA
• Overflow (Under 10V) : Built-in Protection
Circuit for Reverse Voltage
• Dimension : 48 x 45 x 260 mm
• Weight : 478g (including the cable)
• Supply Voltage : 8V DC
• Resolution : 720 x 480 (Interlaced)
• Image Color : True Color
• Operating Temperature : -20ºC to 65ºC
(-4ºF to 149ºF)

21
For your repair services, please contact one of the
following technical centers.
• ENTER INTERNATIONAL PHILIPPINES
INC.
Peter Kim
Marketing Manager
Unit 1, Groun Floor, Buil ing 2, Jannov Plaza
2295 Pasong Tamo Ext., Makati City
TEL: [phone]
FAX: [phone]
E-mail: [e-mail]
• ENTER TECH ES2 TECH CORP
2642 GATES AVE. IRVINE CA 92606
TEL: [phone]
FAX: [phone]
E-mail: [e-mail]
• JOEUN ENTERPRISE
3361 West 1
st
. Street Suite 202 Los Angeles, CA
90004
TEL: [phone]
E-mail: [e-mail]
• KOCONIX.COM
koConix.com
2642 Gates Ave. Irvine, CA 92614
TEL: [phone]
Toll Free: [phone]
E-mail: sale[email protected]m
