YA Revolution Z-7789 User manual

DE – Betriebsanleitung
FR – Mode d‘emploi
IT – Istruzioni per l’uso
EN – Instruction manual
Revolution Z-7789 DE FR IT EN

3 Revolution Z-7789
2 Revolution Z-7789
EN

3 Revolution Z-7789
2 Revolution Z-7789
EN
Finally arrived at YA! Take a seat and enjoy the world of YA! You will see: It is a wonderfull place to be.
The appliance must only be used for the intended purpose according to these instructions.
Keep the instructions carefully and pass them on to further users.
The manufacturer reserves the right to change design, accessories or equipment without prior
notice.
Dear customer

5 Revolution Z-7789
4 Revolution Z-7789
EN
Carefully read the instructions before use. Keep the instructions, if you need to read it again
or if you want to pass on the appliance.
■ The appliance must only be connected to a voltage supply in accordance with the rating label on
the supplied adapter. Voltage supply information to be found on the label of the adapter.
■ This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety. Children should be supervised to ensure that they do not play with the appliance.
■
Do not allow power cable to hang down within easy reach.
■ Keep children away from packing material (e.g. plastic bags).
■ Disconnect the mains plug in case of faults during use, before cleaning or moving the appliance
from place to place, after use.
■ Never pull the plug out of the socket by the cable or with wet hands. Don’t pull the cable
over sharp edges. Don’t jam it. Don’t bend it.
■ If the supply cable is damaged, it must be replaced by the manufacturer or its service agent or
 similarlyqualiedpersoninordertoavoidhazard.
■ Regularly check if the mains cable / appliance / extension lead is defective.
■ Only trained personnel should repair electrical appliances. Unskilled repairs can cause
considerable danger to the user.
■ Do not use attachments not recommended by the manufacturer.
■ Neverputtheappliance/cableonhotsurfacesornearopenames.
Safety instructions

5 Revolution Z-7789
4 Revolution Z-7789
EN
■ Never subject the appliance, power cable or plug to moisture, water or any other liquid.
■ Never attempt to open the casing of the appliance.
■ Positiontheappliancesothatithassufcientventilation.Neverblocktheventilationopenings.
Ensure that no objects or liquids enter the ventilation openings.
■
The equipment contains a laser radiating laser rays according to the limit of laser product of class 1.
■ Batteriesmustnotbeexposedtoexcessiveheatsuchadirectsunlight,reandthelike.
■ If the battery leaks, remove it, clean the contacts of the appliance and wash your hands.
■ If you do not use the appliance for a long time, remove the battery.
■ Where the mains plug is used as the disconnect device, it shall remain readily operable.
■ Listening with headphones for long periods at full volume may cause damage to the hearing.
■ Switch the appliance off and pull the plug out of the mains when it is not in use. Don’t wind the cable
around the appliance The appliance is only cut from the mains if the plug is pulled out!
WARNING: Do not use this appliance near bathtubs, showers, basins or
other vessels containing water.
Safety instructions

7 Revolution Z-7789
6 Revolution Z-7789
EN
Safety instructions
Electrostatic precautions:
An electrostatic discharge at any point of the device can lead to a functional failure, or to turn off
the device. This is an intentional response and serves to protect the equipment. If this happens,
please unplug, wait several seconds and then plug the device back on line. Thus, the device is
reset to its normal state.
WARNING
There is a danger of explosion if batteries are exchanged improperly. Only replace
batteries with ones of the same type.
■
Do not put any container (f. ex. vases, etc.) containing liquids on or in the surroundings of the
appliance.
■ Subjecttotechnicalmodications.Noliabilityfortypographicalerrors.

7 Revolution Z-7789
6 Revolution Z-7789
EN
Key to symbols
WARNING
This symbol and WARNING heading is used when failure to follow or non compliancy with the
operating and work instructions as well as with prescribed work procedures and the like, may
cause injuries or fatal accidents.
CAUTION
This symbol and CAUTION heading is used when failure to follow or non compliancy with the
operating and work instructions as well as with prescribed work procedures and the like, may
cause damage to the appliance.
NOTE
This symbol and the heading NOTE apply to technical requirements that the user must pay
attention to during the activities.

9 Revolution Z-7789
8 Revolution Z-7789
EN
Proper use of the appliance
Improper use of the appliance
The appliance is designed for household use and not for industrial operation. Any other use is
improper and could endanger persons.
No warranty for any possible damage can be accepted if the appliance is improperly used,
incorrectly operated or repaired unprofessionally. In such a case, any warranty claim is void.

9 Revolution Z-7789
8 Revolution Z-7789
EN
Pull out the mains plug and sever the cable. Return electrical appliances to a shop of
sale or dispose of product and battery separately in accordance with local regulations.
The crossed out “wheeled bin” symbol on the product reminds you of your obligation,
that when you dispose of the appliance, it must be separately collected. Consumers
should contact their local authority or retailer for information concerning the correct
disposal of their old appliance.
Disposal of old electrical appliances

11 Revolution Z-7789
10 Revolution Z-7789
EN
Scope of delivery
1 x Revolution Z-7789 Audio System
2 x Speaker
2 x Stand (for speakers)
1 x Stand (for audio system)
1 x Docking Station
1 x Mains plug/mains cable
1 x Remote control (incl. battery)
7 x Different adaptors
7 x Screws and dowels
1 x Instruction manual

11 Revolution Z-7789
10 Revolution Z-7789
EN
Technical data
Powersupply   AC100V-240V~50/60Hz  
Power consumption Standby: 1 W
during operation: 42 W
Dimension Appliance: 426 x 229 x 160 mm ohne Ständer
Speaker: 260 x 229 x 160 mm without stand
Docking Station: 86 x 192 x 110 mm
Weight Appliance: 1.8 kg
Speaker: 2.3 kg
Docking station: 0.34 kg
Speaker 28 W x 2 + 15 W x 2
Amplier   10Wx2
Protection Class 2

13 Revolution Z-7789
12 Revolution Z-7789
EN
Operation
Attach the stand to the unit (base and speaker)
Place the stand under the unit and slide it forward
Removing the stand
Press the knob and pull away the stand.
Connecting the speakers
Unpack the speakers and connect the cables to the right-hand
side of the unit.
2 connections for left-hand speaker and right-hand speaker.
Locate the speakers in the room to give the best sound quality.
CLICK
Press

13 Revolution Z-7789
12 Revolution Z-7789
Technische Daten
ON / STANDBY
2
1
EN
Operation
Operation of the appliance
The appliance is equipped with an AC adaptor, rating DC = 15 V, 3 A and a plug:
■ Only connect the appliance with the supplied adaptor and mains supply.
Use of other adaptors may damage the unit or cause it to malfunction.
■ 1. Plug the tail end of the AC-adaptor into the DC-jack (socket)
2. Connect the mains plus to the mains
■ Press ON / STANDBY to switch on the appliance
Appliance Remote control
■ The appliance cannot be completely switched off. It is either in operation or in Standby mode.
■ The display is dimmed in standby mode, time is displayed.
■ Power consumption is reduced in standby mode.
Remote control
■ Carefully remove the transparent plastic foil from the battery compartment and
test if the appliance reacts on the remote control with ON / STANDBY .

15 Revolution Z-7789
14 Revolution Z-7789
EN
Operation
Wall installation
■ This unit can be fastened to the wall.
■ Screws: 3.5 x 34 mm (7 screws supplied)
WARNUNG
The unit may only be mounted on vertical walls. Check before installation whether the wall
  canbearthreetimestheweightoftheunit.Bringinaqualiedcraftsmanifindoubt,andin
any case to drill the holes.

15 Revolution Z-7789
14 Revolution Z-7789
EN

17 Revolution Z-7789
16 Revolution Z-7789
3 942 81 7
5
23
31
32
21
22
33
34
36
35
30
24
25
26
27
28
29
6 13
10
14 18
11
15 19
12
16
17
20
EN
Overview Revolution Z-7789

17 Revolution Z-7789
16 Revolution Z-7789
EN
1 USB / SD
2 USB IN
3 SD CARD IN
4 Display
5 CD tray (automated)
6 Stand
7 PREV
8 PLAY/PAUSE / FM Stereo
9 NEXT
10 STOP / INFO
11 RECORD
12 MENU
13 OPEN / CLOSE
14 FUNCTION
15 VOLUME / JOG MODE
16 ENTER
17 MULTI JOG Wheel
18 Sensor remote control
19 ON / STANDBY
20 Speaker (left & right)
21 Light
22 Stand
23 Headphone socket
24 Subwoofer OUTPUT
25 Antenna wire
26 Connection for left-hand speakers
27 Connection for right-hand speakers
28 DC Jack (socket) (15 V)
29 AUX INPUT
30 Connection for LAN RJ45
31 Connection for iPod
iPod docking station
32 Display mains current and audio source
33 Dock for adaptor
34 Stand
35 Dock for iPod
36 iPod docking station

19 Revolution Z-7789
18 Revolution Z-7789
1
2
3
6
9
12
4
7
10
13
15
16
17
19
18
20
21
5
8
11
14
EN
Overview remote control Revolution Z-7789
1 ON / STANDBY
2 Numbers button
3 MENU
4 UP
5 FUNC
6 PREV
7 SELECT
8 NEXT
9 SLEEP
10 DOWN
11 REC
12 PLAY/PAUSE / FM Stereo
13 STOP
14 OPEN / CLOSE
15 VOLUME +
16 VOLUME -
17 PROG / PLAY MODE
18 EQ (Equalizer)
19 MUTE
20 INFO
21 Battery compartment

19 Revolution Z-7789
18 Revolution Z-7789
EN
Set clock
The appliance is supplied with a digital clock. Time is displayed in two modes:
1. Standby mode Display shows actual time
2. ON mode The display shows the current time and additional information on the
playback mode, title running time, etc.
Switch on appliance Press ON / STANDBY
Press MENU
Choose display
(Set clock) PREV resp. NEXT
Conrm PressSELECT resp. ENTER
Choose display (12H/24H) PREV resp. NEXT
Conrm PressSELECT resp. ENTER
Set hour PREV resp. NEXT
Conrm PressSELECT resp. ENTER
Set minutes PREV resp. NEXT
Conrm PressSELECT resp. ENTER
NOTE If no key is pressed for 10 seconds, the appliance automatically returns to its initial
function. The programming is not saved.

21 Revolution Z-7789
20 Revolution Z-7789
EN
Set alarm
This appliance is supplied with a Timer function. It is used for programming to enable the appliance
to shut off or on automatically. This function can be use as an alarm clock.
CAUTION The timer only works if the clock and the playback function
( CD / USB / CARD iPod / FM )have been set.
Switch on appliance Press ON / STANDBY
Press MENU
Choose display
(Set TIMER) PREV resp. NEXT
Conrm PressSELECT resp. ENTER
Choose display (ENABLE) PREV resp. NEXT
Conrm PressSELECT resp. ENTER
Choose display (YES) PREV resp. NEXT
NOTE NO shows a listing of the most recent alarm messages.
