yama_5_5637_1.pke IP Link
®
Device Interface
Communication Sheet Revision: 3/23/2012
Page 1 of 4
This document provides additional assistance with wiring your Extron IP Link enabled product to your device.
Different components may require a different wiring scheme than those listed below.
For complete operating instructions, refer to the user's manual for the specific Extron IP Link enabled product or
the controlled device manufacturer supplied documentation.
Version History:
Device Specifications:
Device Type: CD
Manufacturer: Yamaha
Firmware Version: N/A
Model(s): CD-C600
Driver
Version Date
IP Link
Compiler
GC
Version Notes
1 2/23/2012 1.5.1 3.3.1 Initial version.
Driver Notes:

yama_5_5637_1.pke IP Link
®
Device Interface
Communication Sheet Revision: 3/23/2012
Page 2 of 4
Control Commands & States:
Audio Type CD USB
Disc 1 to 5
Function Clear Program Random
Keypad 0 to 9 Enter
Power Control On Off
Repeat Mode Off Single All
Folder
Transport Play Pause Stop
Search + Search - Skip -
Skip + Open Close
Scan
Status Available:
Device Status No Disc Open³ Closed³
Stop Play Pause
Scan³ Forward¹ Reverse¹
Reading² Status Unavailable
Connection Status Connected Disconnected
Power Control On Off
Transport Play Pause Stop
Search + Search - Open
Close
1 - Not available on iPod mode
2 - Only available for USB/iPod
3 - Only available for CD mode

yama_5_5637_1.pke IP Link
®
Device Interface
Communication Sheet Revision: 3/23/2012
Page 3 of 4
MLC60 Series Supported Commands:
Audio Type CD USB
Disc 1 to 5
Function Clear Program Random
Keypad 0 to 9 Enter
Power Control On Off
Repeat Mode Off Single All
Folder
Transport Play Pause Stop
Search + Search - Skip -
Skip + Open Close
Scan

yama_5_5637_1.pke IP Link
®
Device Interface
Communication Sheet Revision: 3/23/2012
Page 4 of 4
Cable and Adapter Requirements:
F/M RS-232 Straight serial cable
Notes for the Device:
Pin Assignments Diagram:
Note: Captive screw connector may also be used as a serial connection.
General Notes:
Serial communication:
Port Type: RS-232 Parity: None
Baud Rate: 9600 Stop Bits: 1
Data Bits: 8 Flow Control: None
