Yamaha CD S2000 - SACD Player User manual

HiFi Began with Yantaha
Yamaha's involvement with and passion for music goes back
more than acentury, to when we built our first reed organ
in
1887. Now we are the world's leading producer of pianos and
other musical instruments, and are involved with music
in many
other ways as well.
We manufacture professional recording
equipment, we design concert halls and we assist artists at
concerts with set up and sound tuning.
This knowledge and experience benefits our production
of
audio components in many ways. We introduced our first HiFi
(High Fidelity) turntable
in 1954. Thereafter we were one of the first
to offer mass-produced, high quality audio equipment,
and introduced many legendary stereo components.
We hope you enjoy the genuine HiFi experience of
Yamaha Natural Sound.

Excellence in Audio Achievement
1.92()- +
1.96()s
1970s +
~
First HiFi System introduced in 1920
We introduced numerous HiFi components
(turntables, FMlAM tuners, integrated
amplifiers, preamplifiers, power amplifiers
and speakers) in 1955 -1965.
Natural Sound Speaker Series introduced
in 1967
NS-20 Monitor Speaker
CA-1000 Integrated Amplifier
Featuring A-Class operation, the CA-lOOO set
the standard for integrated amplifiers.
•
1.980s •
;
1990s ~
20()()s 1
NS-690 Monitor Speaker
NS-1000M Monitor Speaker
Atruly legendary speaker still revered by HiFi
enthusiasts.
B-1 Power Amplifier
An innovative power amp that used FETs in all
stages.
C-2 Control Amplifier
Received top prize at the Milan International Music
and HiFi Show
NS-10M Studio Monitor Speaker
Became of the most popular studio monitors
in the world.
A-1 Integrated Amplifier
PX-2 Turntable
Yamaha's first straight arm turntable.
B-6 Power Amplifier
Pymmid-shaped power amplifier.
GT-2000/L Turntable
First CD Player (CD-1) introduced in 1983
B-2x Power Amplifier
MX-10000 Power Amplifier and
CX-10000 Control Amplifier
Redefined the capabilities of separate components.
AX-1 Integrated Amplifier
GT-CD1 CD Player
MX-1 Power Amplifier and
CX-1 Preamplifier
Soavo-1 and Soavo-2 Natural Sound
Speaker Systems
A-S2000 Stereo Amplifier and
CD-S2000 Super Audio CD Player
G·,
P."I)
.- ~ .
-,
_ • _ .1 ....
------
~.
~ ~,,~ .. ~:

CD-52000
•Full-stage balancedsignal transmission achieves the ultimate in CD
reproduction
•Full-stage balanced signal transmission beginning with the DAC
•Silent loader
and high precision CD drive
•Independentpowersupplies with digital
and analog completely
separated
•Pure Direct
•Left-rightsymmetricaldesign with rigid, stable construction
•Super soundfrom Super Audio CDs
•Supplied accessories
Please check that you have received all of the following parts.
•AC power cable
•Remote control
•Batteries (AA, R6, UM-3) (x2)
•Audio pin cable
•Safety brochure
Contents
Controls and functions 6
Connections 14
Specifications 18
Playable disc format 19
Troubleshooting 21
•About this manual
• :'¥~ indicates atip for your operation.
•This manual
is printed prior to production. Design and specifications are subject to change in part as aresult of improvements. etc. In
case ofdifl"t:rences between the manual and the product. the product has priority.
•Tht: color
of imagt:s in this manual may vary trom the original.
•Read
tht: safely brochure bt:fore using this unit.
4En

•Front panel
(~YAMAHA
o
POWER
ON
o
OFF
SA·Co/CD
oPUREOtRECT o
o
\(1---------1
G) POWER
Press upward or downward to tum on or off this unit.
,0,
~tj)-:
The POWER indicator above lights up when this unit is turned
on.
®Remote control sensor
Receives signals from the remote control.
@SA-CD/CD
Switches the playback layer of ahybrid SA-CD between
SA-CD and CD.
•The SA-CD/CD indicator above lights up when the SA-CD
layer is selected.
•This setting is retained even if you turn ofTthis unit.
6En
@PURE DIRECT
Turns on the PURE DIRECT mode to improve audio
quality.
When this unit
is in the PURE DIRECT mode:
•The PURE DIRECT indicator above lights up.
•The digital output is turned off.
•The front panel display
is turned off.
~'\(,<-:
• The least indicators and messages are still displayed in the front
panel display.
•Press again to tum olTthe PURE DIRECT mode.
•This setting is retained even if you turn olTthis unit.
®Disc tray
Loads adisc.

1<.:1<:J/<i<:'l
c-...c- .... /t>{::>-;
C>- oo
00o
o
_________ 1. ~7
zggggs
-----
®~(Open/Close)
Opens or closes the disc tray.
,I,
~ltl~
You can also close the disc tray by:
•pressing
c>- (Play) on the front panel or on the remote control
or by pressing the front edge of the disc tray gently.
•pressing anumeric button on the remote control.
(j) "'.1<;1<.'<1 (Skip/Search backward),
i><>Jf>C>< (Skip/Search forward)
r>c>/r.>l>i :Skips to the next track.
I<}<]/<)<J :Skips back to the beginning of the current track.
KJ<.J/<J<.J (twice): Skips to the previous track.
Press and hold
1<Xl/<:<l or (>{>/I>l>l to search backward/
forward.
Each time you press and hold Kl<l/<}<.] or t>C>/C>C>l ,the search
speed increases
by 4levels.
® c>- (Play)
Starts playback.
® 00 (Pause)
Pauses playback. Press c>- or 00 to resume playback.
@) 0(Stop)
Stops playback.
@Playback status indicator
®Disc type indicator
©Time display mode indicator
@Playback mode indicator
@Multi-information display
See pages 20 for more information on MP3/WMA
playback.
7En •

•Rear panel
})
BALANCED OUT
COAXIAL
OUTPUT
DIGITAL OUT
ANALOG OUT
OPTICAL
See page 14 for connection information.
CD BALANCED OUT jacks
®ANALOG OUT jacks
@OPTICAL DIGITAL OUT jack
@COAXIAL DIGITAL OUT jack
8En

(Asia and General models)
VOLTAGE
SELECTOR
ACIN
®VOLTAGE SELECTOR
(Asia and General models only)
The VOLTAGE SELECTOR on the rear panel
of this unit
must be set for your local main voltage BEFORE plugging
the AC power cable into the AC wall outlet.
See page
16 for further information.
® ACIN
Use this inlet to plug in the supplied power cable.
See page
16 for connection information.
rJ) Foot
The feet
of this unit include built-in spikes. Using the
spikes can reduce the effect
of vibrations on the set. When
using the spikes, remove the magnet foot
by pulling it.
-f:---'i- Spike
Caution
When using the feet's built-in spikes, the spikes may scratch the
shelf or floor on which this unit is installed. Use the supports
when placing this unit on expensive furniture, etc.
~(j{-:.
If this unit is unstable, you can adjust the foot height by rotating
it.
9En
•

•Remote control
.. c:--------,
SA-COICD PURE DIRECT OPENiCLOSE
,,~;
e
:.!i
l
I
DIMMER
DISPLAY
~)
,:1:
00
1!9)
123
@ @ @
45 6
@ @ @
789
@@ @
0
ENTER
CLEAR
@
~
y)
REPEAT PROGRAM
.i?)
;:~~
@
~
:j~~
·~4.l
:-6/
i~l
(6)
:7.';
\11
1
(.YAMAHA
10 En
CD Infrared signal transmitter
Sends infrared signals to this unit.
®SA-CD/CD
Switches the playback layer ofa hybrid SA-CD between
SA-CD and CD.
,0,
:<i>~
•The SA-CD/CD indicator on the front panel lights up when the
SA-CD layer
is selected.
•This setting is retained even
if you turn 011' this unit.
@DIMMER
Selects brightness level for the front panel display. Each
time you press DIMMER, the brightness level changes
in
the following order:
Max (brightest)
~ Level I(default) ~ Level 2 ~ Level 3
(darkest)
~ Max
,0,
:<i>~
This setting is retained even if you tum olTthis unit.
@Numeric buttons
Use to select atrack directly.
This operation is ineffective for MP3 or WMA discs.
®REPEAT
Repeats playback of asingle track or all tracks. Each time
you press REPEAT during playback, the repeat playback
mode changes as follows:
•REP S(single repeat playback): On reaching the end
of
the current track, playback repeats from the beginning
of the current track.
•REP ALL (all repeat playback): On reaching the end
of
the last track, playback repeats from the beginning of
the first track.
This operation is ineffective for MP3 or WMA discs_
® <Kl (Search backward), t>t> (Search forward)
Searches tracks backward/forward.
Each time you press <l<J or !O>C> •the search speed increases by 4
levels.
(J) .. ,;j<J (Skip backward), ",""" (Skip forward)
[,>to... :Skips to the next track.
• ""'<;] :Skips back to the beginning of the current track.
K,'-:J (twice): Skips to the previous track.

®OPEN/CLOSE
Opens or closes the disc tray.
®PURE DIRECT
Turns on the PURE DIRECT mode to improve audio
quality.
When this unit
is in the PURE DIRECT mode:
•The PURE DIRECT indicator above lights up.·
•The digital output
is turned off.
•The front panel display
is turned off.
,',
~<i>~
•The least indicators and messages are still displayed in the front
panel display.
•This setting
is retained even if you tum off this unit.
@DISPLAY
Switches the time display. Each time you press DISPLAY
during playback, the time display changes as follows:
•Elapsed time
of the current track (default setting). The
TRACK indicator lights up
in the front panel display.
•Remaining time
of the current track. The TRACK and
REMAIN indicators light up
in the front panel display.
•Total remaining time
of the disc. The TOTAL and
REMAIN indicators light up
in the front panel display.
@CLEAR
Erases the last programmed track when this unit is in the
program editing mode. See "Program playback" on this
page.
You can erase all programmed tracks when the playback is
stopped.
@ENTER
Confirms atrack number entered when you are
programming tracks.
@RANDOM
Turns on or off the random playback mode.
Notes!
. "t
•This operation is ineffective for MP3 or WMA discs.
•The random playback mode
is canceled when playback is
stopped or the disc is ejected.
@PROGRAM
Turns on or off the program playback mode. See "Program
playback" on this page.
@ 00 (Pause)
Pauses playback. Press t> or 00 to resume playback.
@ t> (Play)
Starts playback.
@0(Stop)
Stops playback.
See pages 20 for more information on MP3/WMA
playback.
•Program playback
In the program playback mode, you can play back tracks
in aprogrammed sequence.
iiqf,sj
•This operation is ineffective for MP3 or WMA discs.
•The programmed tracks are erased when the disc is ejected or
this unit is turned off.
1Press PROGRAM while playback is stopped.
This unit is set to the program editing mode.
2Select atrack by using the numeric buttons
and ENTER.
3Repeat step 2to program the next track.
You can program up to 24 tracks.
4Press 1>.
Playback starts from the beginning of the
programmed sequence.
11 En
•

•Installing batteries in the remote control
1Press the 'iT part and slide the battery
compartment cover off.
2Insert the two supplied batteries
(AA, R6, UM-3) according to the polarity
markings (+ and
-) on the inside of the
battery compartment.
3Slide the cover back until it snaps into place.
12 En
•Using the remote control
The remote control transmits adirectional infrared beam.
Be sure to aim the remote control directly at the remote
control sensor on the front panel
of this unit during
operation.
===::X':::I1 L::~=.~
A" 00000
o. I
.:;:;.,~-~===I====---r==r-'
•
•
•
30. •300Approximately 6m(20 ft)
-------.-~

14 En
Select one of these connections.
If
your amplifier is equipped with XLR
balanced
input jacks, we recommend
balanced connection
for optimum
audio performance.
_-----r-=========\---I\..
OUTPUT
~
~ ~
~
lID lID
liJ liJ
BALANCED OUT ANALOG OUT BALANCED OUT
a
DIGITAL OUT
"'
Amplifier

•Connecting to the BALANCED OUT jacks
Connect your amplifier with the XLR balanced output
jacks. The pin assignments for these jacks are shown
below. Refer to the owner's manual supplied with your
amplifier and veritY that its XLR balanced input jacks are
compatible with the pin assignments.
1: ground
n
2: hot
~
3: cold
When connecting, be sure to match the pins and insert the
connector
of the "female" XLR balanced cable. When
disconnecting, pull out the "female" XLR balanced cable
while pressing down the latch lock on the plug.
"Female" XLR connector
"Male" XLR connector
15 En I

•VOLTAGE SELECTOR
(Asia and General models only)
Caution
The VOLTAGE SELECTOR on the rear panel of this unit
must be set for your local voltage BEFORE plugging the
power cable into the AC wall outlet. Improper setting
of
the VOLTAGE SELECTOR may cause damage to this
unit and create apotential fire hazard.
Rotate the VOLTAGE SELECTOR clockwise or
counterclockwise to the correct position using astraight
slot screwdriver.
Voltages are as follows:
........................ AC I10/120/220/230-240
V, 50/60 Hz
Voltage indication
VOLTAGE
SELECTOR
•Connecting the power cable
Plug the power cable into the AC IN connector when all
connections are complete, and then plug
in the power
cable to the AC outlet.
16 En

AUDIO SECTION
•Total Harmonic Distortion
SA-CD 0.0017% or less
CD .0.002% or less
•Signal
to Noise Ratio (IHF-A Network) 116 dB or more
•Dynamic Range
SA-CD
110 dB or more
CD 100 dB or more
•Frequency Response
SA-CD .
CD .2Hz to 50 kHz
(-3 dB)
. 2 Hz to
20 kHz
Taking care of this unit
When you wipe this unit, do not use chemical solvents
(ex. alcohol or thinner etc.); this might damage the
finish. Use aclean, dry cloth. For heavy dirt, dampen a
soft cloth
in detergent diluted with the water, wring it
out, and then clean this unit up with the cloth.
The screws on the side panels may loosen as wood
expands and contracts.
In this case, tighten the screws.
•Output Level (I kHz, 0dB) ..... . 2.0±0.3 Y
LASER DIODE PROPERTIES
Type
SA-CD .
CD ..Semiconductor laser (AIGalnP) .Semiconductor laser (AIGaAs)
•Wavelength
SA-CD 650 nm
CO 780 nm
•Output Power
SA-CD .
CD .. 5 mW (max) . 7mW(max)
GENERAL
•Power Supply
[U.S.A. and Canada models] AC 120
Y, 60 Hz
[Asia and General models] AC 110/120/220/230-240
Y, 50/60 Hz
[China model] AC 220
Y. 50 Hz
[Korea model] AC 220
Y, 60 Hz
[Australia model] .AC 240
Y, 50 Hz
[U.K. and Europe models] AC 230
Y, 50 Hz
•Power Consumption 30 W
•
Oft~state Power Consumption . . 0 W
•Dimensions (W x H x D) 435 x
137 x440 mm
(17-1/8" x5-3/8" x17-5/16")
•Weight .
15 kg (33Ibs. Ioz.)
•Specitications are subject to change without notice.
18 En

Music CDs made by copying onto aCD-R or CD-RW
(including MP3
or WMA format files).
CD-R, CD-RW digital audio discs
•Supported disc types
This unit is designed to play back compact discs bearing
the marks shown below. Never attempt to load any other
types
of discs into this unit. This unit can also play back 8-
cm (3-inch) compact discs.
Super Audio CD
[Q]m5~
DIGITAL AUDIO
l:i=:;.iI·f$1ilt:i
ffiJo~~
DIGITAL AUDIO
IReWrjtablel
ffiJo~~
IReWntablel
..;;{l1'J:N IlU P/() (n
Audio format based upon the current CD standards but
includes agreater amount
of information that provides
higher quality sound. There are three types
of discs: single
layer, dual layer and hybrid discs. The hybrid disc can be
played on existing CD players as well as Super Audio CD
players since
it contains both standard audio CD and
Super Audio CD information.
This unit does not show text data on the /Tont panel display.
Compact discs (digital audio)
[Q]DO~~
DIGITAL AUOIO
The most popular discs for commercially available audio
CDs.
Not~l
•Be sure to use aCD-R or CD-RW disc made by areliable
manufacturer.
•Be sure to use a
CD-R or CD-RW disc which has at least one of
the following phrases on the disc or disc case.
-FOR
CONSUMER
-FOR CONSUMER USE
-FOR MUSIC USE ONLY
•Be sure to use afinalized
CD-R or CD-RW disc.
CD-TEXT discs
@m~~@
DIGITAL AUDIO
ITEXT I
The discs recorded with text data such as album titles,
track titles, and artist names. These discs can be played
back with ordinary CD players.
This unit does not show text data on the front panel display.
NOTE:
This unit may not be able to play back some CD-RW discs or
discs on which recording was not made correctly.
To prevent amalfunction of this unit:
•Do not use any nonstandard shaped
disc (heart, etc.) available
in the ~
market as it might damage this unit.
•Do not use adisc with tape, seals,
or
paste on it. Such adisc may get stuck
in this unit
or cause damage to this
unit.
19 En
I

•About MP3 and WMA discs
You can play back MP3 and WMA files recorded on a
CD-R or CD-RW with similar uses
as amusic CD.
MP3
MP3 (MPEG-I Audio Layer-3) is astandard technology
and format for compressing an audio sequence into a
small-sized file. However, the original level
of sound
quality
is preserved during playback.
•This unit plays back MP3 files in alphanumeric order.
•Up to 648 folders and files (combined) and up to 299 folders are
recognized: however, some folders and tiles may not be
rccognized depending on their directory structurc.
•Dcpending on recording conditions such as recording software
settings, this unit may not bc able to play back the disc or tiles
in the order they were recorded.
•This unit is compatible with asampling frequency of 44.1 kHz.
•This unit is compatible with abitrate of 32, 40, 48, 56, 64, 80,
96, 112, 128, 160, 192,224,256, or 320 kbps. Variable bitrate is
not supported.
•The disc must be 1509660 compatible.
•The text data contained in the tiles are not displayed on this
unit.
WMA
WMA (Windows Media Audio) is aMicrosoft file format
for encoding digital audio files similar to MP3 although
WMA can compress files at ahigher rate than MP3.
•This unit plays back WMA files in alphanumeric order.
•Up to 648 folders and tiles (combined) and up to 299 folders are
recognized: however, some folders and files may not be
recognized depending on their directory structure.
•This unit is compatible with asampling frequency of 44.1 kHz.
•This unit is compatible with abitrate 01'48, 64, 80, 96, 128, 160,
or 192 kbps. Variable bitrate is not supported.
•The disc must be 1509660 compatible.
•Copyright-protected WMA tiles cannot be played back with
this unit.
•The text data contained in the files are not displayed on this
unit.
20 En
•Handling compact discs
•Always handle adisc with care so that its surface is not
scratched.
•Compact discs are rarely worn out during playback, but
damage to the disc surface when the disc
is being
handled can adversely affect the disc playback.
•Be sure to use afelt-tip pen or similar writing tool
when writing on the label side
of adisc. Do not use a
ball-point pen, pencil, or other hard-tipped writing
tools as these may damage the disc and may adversely
affect the disc playback.
•Do not warp discs.
•When adisc
is not currently being used, remove it from
this unit and store
it in an appropriate case.
•When removing or storing adisc, be careful not to
scratch the playing surface.
•Compact discs are not affected
by small particles of
dust or fingerprints on their playing surface, but even
so they must be kept clean. Wipe the disc surface with
aclean, cry cloth. Do not wipe the disc surface with a
circular motion; wipe it straight outward from the
center.
•Do not try to clean the disc surface with any type
of
disc cleaner, record spray, anti-static spray or liquid, or
any other chemical-based liquid as such substances
may irreparably damage the disc surface.
•Do not expose discs to direct sunlight, high
temperature, or high humidity for along period
of time
as these conditions may warp or otherwise damage the
disc.
•
To play back an 8-cm (3-inch) compact disc, place it in
the inner recessed area of the disc tray. Do not put a
normal 12-cm CD on top
of an 8-cm CD.
