Philips AZ302 User manual

CD Soundmachine
Register your product and get support at
www.philips.com/welcome
User Manual
AZ302

Important notes for users in the U.K.
Mains plug
This apparatus is fitted with an approved 13 Amp plug.To change a fuse in this type of
plug proceed as follows:
1. Remove fuse cover and fuse.
2. Fix new fuse which should be a BS1362 3 Amp, A.S.T.A. or BSI approved type.
3. Refit the fuse cover.
If the fitted plug is not suitable for your socket outlets, it should be cut off and an
appropriate plug fitted in its place. If the mains plug contains a fuse, this should have a
value of 3 Amp. If a plug without a fuse is used, the fuse at the distribution board
should not be greater than 3 Amp.
Note:The severed plug must be disposed of to avoid a possible shock hazard should it
be inserted into a 13 Amp socket elsewhere.
How to connect a plug
The wires in the mains lead are coloured with the following code: blue = neutral (N),
brown = live (L). As these colours may not correspond with the colour markings iden-
tifying the terminals in your plug, proceed as follows:
•Connect the blue wire to the terminal marked N or coloured black.
•Connect the brown wire to the terminal marked L or coloured red.
•Do not connect either wire to the earth terminal in the plug, marked E (or e) or
coloured green (or green and yellow).
Before replacing the plug cover, make certain that the cord grip is clamped over the
sheath of the lead - not simply over the two wires.
Copyright in the U.K.
Recording and playback of material may require consent. See Copyright Act 1956 and
The Performer’s Protection Acts 1958 to 1972.

8
1
@
25
4
6
7
3
0
1

6 x R14 • UM-2 • C-CELLS
OFF
MWFM
CD
DBB
ON OFF
LINE-IN
9
@
#
!
$
2

ALL
X
PROG
3
4
5
6
7
8

Congratulations on your purchase and
welcome to Philips!
To fully benefit from the support that
Philips offers, register your product at
www.philips.com/welcome.
Supplied Accessories
– AC power cord
Top/front panels (See 1)
1 VOLUME – adjusts volume level.
243 – For MP3-CD only: select albums.
3MODE –selects different play modes:
e.g. REPEAT or SHUFFLE (random
order) .
4 2 ; – starts or pause CD playback
§ ∞
– selects the next/previous track
– searches forwards/backwards (press and
hold the button) within the current track
9 – stops disc playback;
– erases a program
5PROG – programs tracks and reviews the
program
6LIFT TO OPEN – opens/closes the CD
door.
7TUNING – tunes to radio stations
8 Display – shows the CD functions
Back panel (See 1 and 2)
9 Source selector:CD, FM, MW, OFF
– selects CD or radio source of sound
– power off switch
0Telescopic antenna - improves FM recep-
tion.
!AC MAINS~ - inlet for power cord.
@ DBB – turns the bass enhancement on/off.
# LINE-IN – inlet for external audio source.
Bottom panel
$Battery door – Press on the arrow and
push to insert 6 x 1.5V R-14/ UM-2/ C-
cells.
CAUTION
–Visible and invisible laser radia-
tion. If the cover is open, do not
look at the beam.
–High voltage! Do not open.You
run the risk of getting an electric
shock.The machine does not con-
tain any user-serviceable parts.
–Modification of the product
could result in hazardous radia-
tion of EMC or other unsafe oper-
ation.
English Controls

Power Supply General Operation
Power Supply
Whenever convenient, use the power supply
cord if you want to conserve battery life.
Make sure you remove the plug from the set
and wall outlet before inserting batteries.
Batteries (not included)
1 Open the battery door and insert 6 batteries,
type R-14,UM-2 or C-cells,(preferably
alkaline) with the correct polarity as indicated by
the "+" and "–" symbols inside the compartment.
2 Replace the battery door, making sure the
batteries are firmly and correctly in place.The
set is now ready to operate.
Batteries contain chemical substances, so
they should be disposed of properly.
• Incorrect use of batteries can cause electrolyte
leakage and will corrode the compartment or
cause the batteries to burst:
• Do not mix battery types: e.g. alkaline with
carbon zinc. Only use batteries of the same type
for the set.
• When inserting new batteries, do not try to mix
old batteries with the new ones.
• Remove the batteries if the set is not to be used
for a long time.
Using AC power
WARNING: Always check you have
completely switched off the set, before
you change or disconnect power supply.
1 Check if the power voltage, as shown on
the type plate located on the bottom
of the set, corresponds to your local power
supply. If it does not, consult your dealer or
service center.
2 Connect the power cord to the AC
MAINS~ inlet and the wall socket.The set is
now connected and ready for use.
3 To switch the set off completely, withdraw the
power cord from the wall socket.
4Install the unit near the AC outlet and where
the AC power plug can be easily reached.
•Disconnect the power cord from the wall
socket to protect your set during heavy
thunderstorms. Children could seriously injure
themselves as the free end of the cable may
still be live if only the connector is removed
from the MAINS socket at the back of the
unit.
The type plate is located on the bottom
of the set.
Helpful hints:
–To avoid unnecessary energy consumption,
always adjust the
Source selector to OFF
after using the set.
General operation
Switching on and off and selecting the
function
1 To select your sound source, adjust the
Source selector to: CD, FM or
MW.
2To switch off the set, adjust the Source
selector to OFF position.
3To switch to LINE IN mode, connect an
external audio source to the LINE-IN inlet.
Helpful hints:
•The set switches to LINE IN mode
automatically when an external audio source
is connected, no matter the set is in CD,FM
or
MW mode.
• The LINE-IN inlet is not for earphones.
Adjusting volume and sound
Adjust the sound with the VOLUME and
DBB controls.

Tuner MP3-CD/CD Player
Radio reception
1 Adjust the Source selector to FM or
MW.
2 Tu r n TUNING to tune to a station.
Helpful hints:
To improve radio reception
• For FM,extend, incline and turn the
telescopic antenna for best reception. Reduce
its length if the signal is too strong.
• For MW,the set uses a built-in antenna.
Direct this antenna for best reception by
turning the whole set.
About MP3
The music compression technology MP3
(MPEG1 Audio Layer 3) significantly reduce
the digital data of an audio CD while
maintaining CD quality sound.
•Getting MP3 files: you can either download
legal music files from the internet to your
computer hard disc, or create such files by
converting audio CD files in your computer
through appropriate encoder software.
(128kbps bit rate or higher is recommended
for MP3 files.)
•Creating a MP3 CD: burn the music files
from your computer hard disc on a CDR or
CDRW using your CD burner.
Helpful Hints:
– Make sure that the file names of the MP3 files
end with .mp3 .
– Total number of music files and albums: around
400 (with a typical file name length of 20
characters)
– The length of file names affects the number of
tracks for playback. With shorter file names, more
files can be burned on a disc.
Playing a disc
•This CD player plays Audio Discs including
CD-Recordables (CD-R), CD-Rewritables
(CD-RW) and MP3 CD.
•CD-ROM, CD-I, CDV,VCD, DVD or
computer CDs are not possible for playback.
IMPORTANT!
•CDs encoded with copyright protection
technologies by some record companies may
be unplayable by this product.
1Adjust the Source selector to CD.
2Open the CD door, and insert a CD with
the printed side facing up, then press the CD
door gently to close.
➜Display shows ---,and later the total
number of tracks. (See 3)
3Press
2; to start playback.
4To pause playback, press 2; .
➜
Display: 2flashes. (See 4)
5To resume, press 2; again.
6To stop CD playback, press 9 .
Helpful hints:
CD play will also stop when:
–you open the CD door;
–you select FM , MW or OFF sound source;
–the CD has reached the end.

MP3-CD/CD Player
Selecting a different track
•Press ∞/ § once or repeatedly until the
desired track number appears in the display.
For MP3-CD: First press 43 once or more
to find your album.
•In the pause/stop position, press 2; to start
playback.
Finding a passage within a
track
1During playback, press and hold ∞or § .
➜ The CD is played at high speed and with
reduced volume.
2When you recognize the passage you want,
release ∞or §to resume normal playback.
Helpful hints:
– When your searching reaches the end of the
last track, the CD goes to stop mode.
Programming track
numbers
You may store up to 20 tracks in the desired
sequence. If you like, store any track more
than once.
1In the stop position, press PROG to
activate programming.
➜Display: PROG and P01 flash. (See 5)
2Press ∞ or § to select your desired track
number.
For MP3-CD: first press 43 once or more
to find your album.
3Press PROG to store the desired track
number.
➜Display: PROG and P02 flash for you
to program the next track.
4Repeat steps 2 to 3to select and store all
desired tracks in this way.
➜If you attempt to store more than 20
tracks, no track can be selected and the
display shows ------.
5To play your program, press 2 / ; .
Helpful hints :
– When playback of your program comes
to the stop position, your set will return
to normal playback.To re-enter program
mode, press PROG in the stop position.
Reviewing the program
In the stop position, press PROG repeatedly
to see your stored tracks.
Erasing a program
You can erase the contents of the memory
by:
– in the stop position, press PROG to enter
program mode, and then press
9.
– selecting FM , MW or OFF ;
– opening the CD door;

MP3-CD/CD Player
Different play modes:
REPEAT. and SHUFFLE
(See 6,7)
You can select and change the various play
modes before or during playback, and
combine REPEAT modes with PROG (PRO-
GRAM).
– plays the current track continuously.
–repeats the entire CD/program.
For MP3:
ALB –plays all tracks of current album
repeatedly.
– plays all tracks in random order.
1To select play mode, press MODE once or
more.
➜ The display shows the related icon.
2Press 2; to start playback if in the stop/pause
position.
3To return to normal playback, press MODE
repeatedly until the modes are no longer
displayed.
– You can also press 9to cancel your play
mode.

Maintenance & Safety (See 8)
CD player and CD handling
•If the CD player cannot read CDs correctly,
use a cleaning CD to clean the lens before
taking the set to repair.
•The lens of the CD player should never be
touched!
•Sudden changes in the surrounding
temperature can cause condensation on the
lens of your CD player. Playing a CD is then
not possible. Do not attempt to clean the
lens but leave the set in a warm environment
until the moisture evaporates.
•Always close the CD door to avoid dust on
the lens.
•To clean the CD, wipe in a straight line from
the center towards the edge using a soft,
lint-free cloth. Do not use cleaning agents as
they may damage the disc.
•Never write on a CD or attach any stickers
to it.
Safety information
•Place the set on a flat, hard and stable surface
so that the system does not tilt.
•Where the MAINS plug or an appliance cou-
pler is used as the disconnect device, the dis-
connect device shall remain readily operable.
•Do not expose the set, batteries, CDs to
humidity, rain, sand or excessive heat caused
by heating equipment or direct sunlight.
•The apparatus shall not be exposed to drip-
ping or splashing.
•Adequate ventilation with a minimum gap of
15cm (6 inches) between the ventilation
holes and surrounding surfaces is necessary
to prevent heat build-up.
•Do not cover the ventilation openings with
items such as newspapers, table-cloths, cur-
tains, etc.
•No objects filled with liquids, such as vases,
shall be placed on the apparatus.
•No naked flame sources, such as lighted can-
dles, should be placed on the apparatus.
•The mechanical parts of the set contain self-
lubricating bearings and must not be oiled or
lubricated.
•To clean the set, use a dry cloth. Do not use
any cleaning agents containing alcohol, ammo-
nia, benzene or abrasives as these may harm
the housing.

Problem
–Possible cause
•Remedy
No sound /power
–Volume not adjusted
•Adjust the VOLUME
–Power cord not securely connected
•Connect the AC power cord properly
–Batteries dead/ incorrectly inserted
•Insert (fresh) batteries correctly
–CD contains non-audio files
•Press ∞,§ once or more to skip to a CD audio
track, instead of the data file.
Display does not function properly / No
reaction to operation of any of the
controls
–Electrostatic discharge
•Switch off and unplug the set. Reconnect after a
few seconds
---,Er or no indication
–No CD inserted
• Insert a CD
–CD badly scratched or dirty
• Replace/ clean CD, see Maintenance
–Laser lens steamed up
•Wait until lens has cleared
–CD-R/CD-RW is blank or not finalized
• Use a finalized CD-R/CD-RW or suitable CD
Audio disc only
Note:
Make sure the CD is not encoded with copy-
right protection technologies, as some do not
conform to the Compact Disc standard.
The CD skips tracks
–CD damaged or dirty
•Replace or clean CD
–Program/shuffle is active
•Quit program/shuffle mode
Note: A CD badly scratch or dirty may result in
improper operation.
Sound skips during MP3 playback
–MP3 file made at compression level exceeding
320kbps
•Use a lower compression level to record CD
tracks into MP3 format
–Disc damaged or dirty
•Replace or clean disc
Troubleshooting
If a fault occurs, first check the points listed below before taking the set for repair.
If you are unable to remedy a problem by following these hints, consult your dealer or service centre.
WARNING: Do not open the set as there is a risk of electric shock. Under no
circumstances should you try to repair the set yourself, as this will
invalidate the guarantee.

Environmental information
All unnecessary packaging material has been omitted.The packaging can be easily separated
into three materials: cardboard, polystyrene and plastic.
Your set consists of materials which can be recycled if disassembled by a
specialized company. Please observe the local regulations regarding the
disposal of packaging, dead batteries and old equipment.
Disposal of your old product
Your product is designed and manufactured with high quality materi-
als and components, which can be recycled and reused.
When this crossed-out wheeled bin symbol is attached to
a product it means the product is covered by the
European Directive 2002/96/EC.
Please inform yourself about the local separate collection system for electrical
and electronic products.
Please act according to your local rules and do not dispose of your old products
with your normal household waste.The correct disposal of your old product will
help prevent potential negative consequences for the environment and human
health.

Meet Philips at the Internet
http://www.philips.com
Printed in China PDCC-JS-0741
W
CLASS 1
LASER PRODUCT
AZ302
