TECHNICAL GUIDE
AFFINITY
MODELS: PC9
GAS-FIRED
CONDENSING / HIGH EFFICIENCY
DOWNFLOW / HORIZONTAL
MODULATING FURNACES
WITH ECM MOTOR
NATURAL GAS
60 - 120 MBH INPUT
Due to continuous product improvement,
specifications are subject to change without notice.
Visit us on the web at www.york.com for the most
up-to-date technical information.
Additional rating information can be found at
www.gamanet.org.
EFFICIENCY
RATING
CERTIFIED
ISO 9001
Certified Quality
Management System
036-21671-001 Rev. A (0106)
FOR DISTRIBUTION USE ONLY - NOT TO BE USED AT POINT OF RETAIL SALE
DESCRIPTION
These Category IV, highly efficient, compact, condensing
type furnaces are designed for residential and commercial
installations in a basement, closet, alcove, recreation room or
garage where the ambient temperature is above 32°F, or
higher. They may be either side wall or thru-roof vented using
approved plastic type combustion air and vent piping. All
units are factory assembled, wired and tested to assure
dependable and economical installation and operation.
WARRANTY
Lifetime limited warranty on both heat exchangers to the orig-
inal purchaser; a 20-year limited warranty from original instal-
lation date to subsequent purchaser.
10-year warranty on the heat exchanger in commercial appli-
cations.
5-year limited parts warranty.
FEATURES
• Modulating heating operation includes:
- Modulating gas valve
- Modulating inducer operation
• Provides increased comfort level & very quiet unit opera-
tion
• Adjustable delay timer allows two stage operation with sin-
gle stage thermostat.
• Compact, easy to install, ideal height 40" cabinet.
• Blower-off delay for cooling SEER improvement.
• Easy to connect power/control wiring.
• Built-in, high level self diagnostics with fault code display.
• Low unit amp requirement for easy replacement applica-
tion.
• Integrated control module for reliable, economical opera-
tion.
• High velocity filter available for easy field installation.
• May be installed as either two-pipe (sealed combustion) or
single pipe vent (using indoor combustion air)
• Top intake & vent connection allows installation in narrow
locations.
• Electronic Hot Surface Ignition saves fuel cost with
increased dependability and reliability.
• Induced combustion system with inshot main burners for
quiet, efficient operation.
• No special vent termination kit required.
• 100% shut off main gas valve for extra safety.
• ECM High-efficiency, direct drive motor with large, quiet
blower.
• 24V, 40 VA control transformer and blower relay supplied
for add-on cooling.
• Hi-tech tubular aluminized steel primary heat exchanger.
• Secondary (condensing) heat exchanger of 29-4C high-
grade stainless steel.
• Timed on, adjustable off blower capability for maximum
comfort.
• Independent door removal for greater durabilty and ease
of access.
• Easy access from front of unit for cleaning, maintenance or
service.
• Protection from intake, exhaust or condensate blockage.
• Insulated blower compartment for quiet operation.
• 3-way transition facilitates fresh air piping.

036-21671-001 Rev. A (0106)
2Unitary Products Group
Annual Fuel Utilization Efficiency (AFUE) numbers are determined in accordance with DOE Test procedures.
Wire size and over current protection must comply with the National Electrical Code (NFPA-70-latest edition) and all local codes.
The furnace shall be installed so that the electrical components are protected from water.
C
19-1/4
1-1/4
1-1/4 5/8
5/8
23-5/8
D
2-1/4
23-1/4
20
B
BOTTOM IMAGE
SUPPLY END
TOP IMAGE
RETURN END
LEFT SIDE
RIGHT SIDE
22-3/4
7/8
7/8
13-7/8
HORIZONTAL CONDENSATE
DRAIN OPENING 2”
JUNCTION BOX
HOLE 7/8”
GAS PIPE ENTRY 1-1/2”
CONDENSATE DRAIN
HOLE 7/8”
SIDE PIPING HOLE 3-3/8”
T-STAT WIRING 7/8” K.O.
HORIZONTAL CONDENSATE
DRAIN OPENING 1-3/4”
22-1/4
25-3/8
26-1/2
27-1/8
29
22-3/4
21-5/8
18-1/2
11-3/4
7-1/2
2-1/4
T-STAT WIRING 7/8” K.O.
HORIZONTAL CONDENSATE
DRAIN OPENING 1-3/4”
HORIZONTAL
CONDENSATE
DRAIN OPENING 1-3/4”
JUNCTION BOX
HOLE 7/8”
GAS PIPE
ENTRY 1-1/2”
CONDENSATE DRAIN
HOLE 7/8”
29
22-3/4
21-1/4
18-1/2
9-1/8
8-1/2
30-1/8
23-11/16
E
FRONT
A
40
DIMENSIONS
Models CFM Cabinet
Size Cabinet Dimension
A (in.) B (in.) C (in.) D (in.) E (IN.)
PC9B12N060DH11 1200 B 17-1/2 16-1/4 15 1-3/4 2-3/8
PC9B12N080DH11 1200 B 17-1/2 16-1/4 15 1-3/4 2-3/8
PC9C16N080DH11 1600 C 21 19-3/4 18-1/2 2-1/8 2-3/4
PC9C16N100DH11 1600 C 21 19-3/4 18-1/2 2-1/8 2-3/4
PC9C20N100DH11 2000 C 21 19-3/4 18-1/2 2-1/8 2-3/4
PC9D20N120DH11 2000 D 24-1/2 23-1/4 22 2-1/2 3
ELECTRICAL AND PERFORMANCE DATA
Models Input Max/Min Output Max/Min Nominal Airflow Cabinet Width AFUE Air Temp. Rise
MBH MBH CFM In. % °F
PC9B12N060DH11 60 / 21 56 / 20 1200 17-1/2 95.0 40 - 70
PC9B12N080DH11 80 / 28 75 / 26 1200 17-1/2 95.0 40 - 70
PC9C16N080DH11 80 / 28 75 / 26 1600 21 95.0 40 - 70
PC9C16N100DH11 100 / 35 93 / 33 1600 21 95.0 40 - 70
PC9C20N100DH11 100 / 35 93 / 33 2000 21 95.0 40 - 70
PC9D20N120DH11 120 / 42 112 / 39 2000 24-1/2 95.0 40 - 70
Models Max. Outlet
Air Temp. Blower Blower Size Total Unit Max.
Over-current
Protect
Min. Wire Size
(awg) @ 75 ft.
One Way
Approximate
Operating Weight
°F HP Amps In. Amps
PC9B12N060DH11 170 1/2 7.7 11 x 8 9 20 14 136
PC9B12N080DH11 170 1/2 7.7 11 x 8 9 20 14 143
PC9C16N080DH11 170 3/4 9.6 11 x 10 12 20 14 159
PC9C16N100DH11 170 3/4 9.6 11 x 10 12 20 14 163
PC9C20N100DH11 170 1 12.8 11 x 11 14 20 12 165
PC9D20N120DH11 170 1 12.8 11 x 11 14 20 12 182

036-21671-001 Rev. A (0106)
Unitary Products Group 3
NOTES:
1. Airflow expressed in standard cubic feet per minute (CFM) and in cubic meters per minute (m3/min).
AIR FLOW DATA
HIGH / LOW SPEED COOLING AND HEAT PUMP CFM
PC9B12N060DH11 PC9B12N080DH11 JUMPER SETTINGS
CFM CFM
High Low High Low COOL Tap ADJ Tap
1330 900 1310 890 A B
1130 800 1100 740 B B
1220 850 1220 830 A A
1040 730 1000 670 B A
1120 770 1090 720 A C
920 650 900 610 C B
950 660 880 610 B C
740 540 680 510 D B
860 610 810 580 C A
690 540 630 500 D A
790 570 730 530 C C
630 530 590 500 D C
PC9C16N080DH11
PC9C16N100DH11 PC9C20N100DH11 JUMPER SETTINGS
CFM CFM
High Low High Low COOL Tap ADJ Tap
1660 1110 2210 1480 A B
1550 1050 1780 1180 B B
1610 1070 2040 1350 A A
1440 960 1620 1050 B A
1470 990 1840 1250 A C
1370 920 1560 1010 C B
1290 850 1470 940 B C
1130 790 1370 890 D B
1230 850 1460 930 C A
1050 720 1250 790 D A
1110 760 1310 810 C C
950 660 1090 690 D C
PC9D20N120DH11 JUMPER SETTINGS
CFM
High Low COOL Tap ADJ Tap
2280 1510 A B
1860 1190 B B
2090 1370 A A
1630 1060 B A
1880 1250 A C
1620 1030 C B
1500 960 B C
1410 880 D B
1490 920 C A
1290 790 D A
1360 840 C C
1140 690 D C
All CFM’s are shown at 0.5” w.c. external static pressure.These units have variable speed motors that automatically adjust to provide constant CFM from 0.0” to 0.6” w.c.
static pressure. From 0.6” to 1.0” static pressure, CFM is reduced by 2% per 0.1” increase in static. Operation on duct systems with greater than 1.0” w.c. external static
pressure is not recommended.
NOTE: At some settings, LOW COOL airflow may be lower that what is required to operate an airflow switch on certain models of electronic air cleaners. Consult the
instructions for the electronic air cleaner for further details.

036-21671-001 Rev. A (0106)
4Unitary Products Group
FILTER PERFORMANCE
The airflow capacity data published in the “Blower Perfor-
mance” table listed above represents blower performance
WITHOUT filters. To determine the approximate blower per-
formance of the system, apply the filter drop value for the fil-
ter being used or select an appropriate value from the “Filter
Performance” table shown.
NOTE: The filter pressure drop values in the “Filter Perfor-
mance” table shown are typical values for the type of filter
listed and should only be used as a guideline. Actual pres-
sure drop ratings for each filter type vary between filter manu-
facturer.
NOTE: All filters must be high velocity cleanable type.
APPLYING FILTER PRESSURE DROP TO
DETERMINE SYSTEM AIRFLOW
To determine the approximate airflow of the unit with a filter in
place, follow the steps below:
1. Select the filter type.
2. Determine the External System Static Pressure (ESP)
without the filter.
3. Select a filter pressure drop from the table based upon
the number of return air openings or return air opening
size and add to the ESP from Step 3 to determine the
total system static.
4. If total system static matches a ESP value in the airflow
table (i.e. 0.20, 0.60, etc,) the system airflow corre-
sponds to the intersection of the ESP column and Model/
Blower Speed row.
5. If the total system static falls between ESP values in the
table (i.e. 0.58, 0.75, etc.), the static pressure may be
rounded to the nearest value in the table determining the
airflow using Step 5 or calculate the airflow by using the
following example.
Example: For a 120,000 Btuh furnace operating on high
speed blower, it is found that total system static is 0.58" w.c.
To determine the system airflow, complete the following
steps:
1. Obtain the airflow values at 0.50" & 0.60" ESP.
Airflow @ 0.50": 2220CFM
Airflow @ 0.60": 2135 CFM
2. Subtract the airflow @ 0.50" from the airflow @ 0.60" to
obtain airflow difference.
2135 - 2220 = -85 CFM
Subtract the total system static from 0.50" and divide this
difference by the difference in ESP values in the table,
0.60" - 0.50", to obtain a percentage.
(0.58 - 0.50) / (0.60 - 0.50) = 0.8
3. Multiply percentage by airflow difference to obtain airflow
reduction.
(0.8) x (-85) = -68
4. Subtract airflow reduction value to airflow @ 0.50" to
obtain actual airflow @ 0.58" ESP.
2120 - 68 = 2152
FILTER SIZES
CFM Cabinet
Size Top Return Filter in
1200 B (2) 14 x 20
1600 C (2) 14 x 20
2000 C (2) 14 x 20
2000 D (2) 14 x 20
FILTER PERFORMANCE - PRESSURE DROP INCHES W.C.
AIRFLOW RANGE MINIMUM OPENING
SIZE FILTER TYPE
DISPOSABLE WASHABLE FIBER PLEATED
1 Opening 1 Opening 1 Opening 1 Opening
Sq. in. In w.c. In w.c. In w.c.
0 - 750 230 0.01 0.01 0.15
751 - 1000 330 0.04 0.03 0.20
1001 - 1250 330 0.08 0.07 0.20
1251 - 1500 330 0.08 0.07 0.25
1501 - 1750 380 0.14 0.13 0.30
1751 - 2000 380 0.17 0.15 0.30
2001 & Above 463 0.17 0.15 0.30
UNIT CLEARANCES TO COMBUSTIBLES
Application Top Front Rear Left Side Right Side Flue Floor/Bottom Closet Alcove Attic Line Contact
In. In. In. In. In. In. In.
Downflow 130 0 0 0 1*Yes Yes Yes NA
Horizontal 0 3 0 1 1 0 0†Yes Yes Yes Yes†
* Combustible floor base or air conditioning coil required for use on combustible floor.
† Line contact only permitted between lines formed by the intersection of the rear panel (top in horizontal position) of the furnace jacket and building
joists, studs or framing.

036-21671-001 Rev. A (0106)
Unitary Products Group 5
For additional connection diagrams for all UPG equipment refer to “Line Voltage System Wiring” document available online at
www.upgnet.com in the Product Catalog Section.
THERMOSTAT CHART - SINGLE STAGE AC
AC20 Single Stage A/C w/Modulating Furnace, 2 Stage Cooling Ready - P(C/M)8/9
THERMOSTAT THERMOSTAT THERMOSTAT
*BN11C01124
MODULATING
FURNACE CONTROL
SINGLE STAGE
AIR CONDITIONING
*BN11C00124 *BP11C50124 *PP11C70224
*DP11C40124
*DN11C00124
C
24-Volt Common
C
24-Volt Common
Optional w/Batteries C
24-Volt Common
C
24-Volt Common
Y
First Stage Cool
Y
First Stage Cool
Y
First Stage Cool
Y/Y2
Single/Second Stage Cool
Y
Single Stage Cool
Y1
First Stage Cool
RC
24-Volt Hot (Cool XFMR)
RC
24-Volt Hot (Cool XFMR)
RC
24-Volt Hot (Cool XFMR)
HUM
Dehumidification - Open on Humidity
Rise
HUMIDISTAT 1
R
24-Volt Hot (Heat XFMR)
RH
24-Volt Hot (Heat XFMR)
RH
24-Volt Hot (Heat XFMR)
R
24-Volt Hot
24V HUMIDIFIER
G
Fan
G
Fan
G
Fan
G
Fan
W
First Stage Heat
W
First Stage Heat
W
First Stage Heat
W
Heat (Modulating)
HM1
Humidistat
Thermostat Installer Setup Number 1 -
System Type - must be set to 0
Selection of GAS/ELEC switch
on thermostat not necessary
Thermostat Installer Setup Number 15 -
Compressor Protection - must be set to 5
NOTE: JUMPER ON FURNACE
CONTROL TO BE IN 'YES' POSITION
IF HUMIDISTAT IS INSTALLED
1OPTIONAL DEHUMIDIFICATION -
HUMIDISTAT CONTACTS OPEN ON
HUMIDITY RISE

036-21671-001 Rev. A (0106)
6Unitary Products Group
THERMOSTAT CHART - TWO STAGE AC
AC20 2 Stage Scroll A/C w/Modulating Furnace, 2 Stage Cooling Ready - P(C/M)8/9
G
Fan
Connection of the "C"
Termainal, 24-Volt
Common, is optional
when used with batteries
Thermostat Installer Setup
Number 1 - System Type -
must be set to 8 -
1 Heat/2 Cool Conventional
Connection of the "C"
Termainal, 24-Volt
Common, is optional
when used with batteries
C
24-Volt Common
THERMOSTAT
*PP32U70124
E2/P Switch must be in
the E2 position and the
Humidistat Jumper on
CFM Control must be in
the 'YES' position for
Dehumidification
THERMOSTAT
*PP32U71124 *PP32U72124
G
Fan
C
24-Volt Common
Y1
First Stage Cool
DHM
Dehumidistat
Step 1 of Thermostat User
Configuration Menu must be set
to MLTI STG
Step 16 of Thermostat User
Configuration Menu must
be set to ON to use
Comfort Alert Features
HM
Humidistat 24V HUMIDIFIER
(Optional)
W
First Stage Heat
E/W1
First Stage Heat
W
Heat (Modulating)
G
Fan
L
Malfunction Light
W2
Second Stage Heat
Comfort Alert
Interface
HUM
Dehumidification - Open on Humidity Rise
Y1
First Stage Cool
Y2
Second Stage Cool
W2
Second Stage Heat
Y2
Second Stage Cool
Y
First Stage Cool
E/W1
First Stage Heat
Y2
Second Stage Cool
R
24-Volt Hot
R
24-Volt Hot
R
24-Volt Hot
Y2
Second Stage Cool
Y/Y2
Single/Second Stage Cool
THERMOSTAT THERMOSTATTHERMOSTAT
*DN22C00124 *DP22U70124*DN22U00124
Y1
First Stage Cool
C
24-Volt Common
C
24-Volt Common
TWO STAGE
AIR CONDITIONING
MODULATING
FURNACE CONTROL
Y1
First Stage Cool
C
24-Volt Common
G
Fan
C
24-Volt Common
Y
First Stage Cool
W2
Second Stage Heat
E/W1
First Stage Heat
RC
24-Volt Hot (Cool XFMR)
C
24-Volt Common
Y2
Second Stage Cool
Step 1 of Thermostat
User Configuration Menu
must be set to MS 2
R
24-Volt Hot
G
Fan
W2
Second Stage Heat
Connection of the "C"
Termainal, 24-Volt
Common, is optional
when used with batteries
G
Fan
Connection of the "C"
Termainal, 24-Volt Common,
is optional
when used with batteries
Thermostat Installer Setup
Number 15 - Compressor
Protection - must be set to 5
R
24-Volt Hot (Heat XFMR)
Y
First Stage Cool
R
24-Volt Hot
Thermostat Installer
Setup Number 0170 -
System Type - must be
set to 8 - 2 Heat/2 Cool
Multistage Conventional
Y2
Second Stage Cool
R
24-Volt Hot (Heat XFMR)
RC
24-Volt Hot (Cool XFMR)
E/W1
First Stage Heat
W2
Second Stage Heat

036-21671-001 Rev. A (0106)
Unitary Products Group 7
ACCESSORIES
PROPANE (LP) CONVERSION KIT -
1NP0680 - All units
This accessory conversion kit may be used to convert natural
gas (N) units for propane (LP) operation. Conversions must
be made by qualified distributor or dealer personnel.
CONCENTRIC VENT TERMINATION -
1CT0302 (2")
1CT0303 (3")
CONDENSATE NEUTRALIZER KIT - 1HT0901
Neutralizer cartidge has a 1/2" plastic tube fittings for installa-
tion in the drain line. Calcium carbonate refill media is also
avaiable from the Source 1 Parts (p/n 026-30228-000).
SIDEWALL VENT TERMINATION -
1HT0901 (2")
For use through rooftop, sidewall. Allows combustion air to
enter and exhaust to exit through single common hole. Elimi-
nates unslightly elbows for a cleaner installation.
COMBUSTIBLE FLOOR BASE -
1CB0317 - 17 1/2” Cabinet
1CB0321 - 21” Cabinet
1CB0324 - 24-1/2” Cabinet
COIL TRANSITION -
1TK0917 - 17 1/2” Cabinet
1TK0921 - 21” Cabinet
1TK0924 - 24-1/2” Cabinet
Required in downflow applications when using G*FD series
coils.
ROOM THERMOSTATS - A wide selection of compatible
thermosets are available to provide optimum performance
and features for any installation.
1H/1C, manual change-over electronic non-programmable
thermostat.
1H/1C, auto/manual changeover, electronic programmable,
deluxe 7-day, thermostat.
1H/1C, auto/manual changeover, electronic programmable.
* For the most current accessory information, refer to the
price book or consult factory.

Subject to change without notice. Printed in U.S.A. 036-21671-001 Rev. A (0106)
Copyright © by York International Corp. 2006. All rights reserved. Supersedes: Nothing)
Unitary 5005 Norman
Products York OK
Group Drive 73069
