Zanussi ZNME32FW0 User manual

ZNME32FW0
EN User Manuel 1

EN -2-
EN FIRE Warning; Risk of re / ammable materials

EN -3-
INDEX
BEFORE USING THE APPLIANCE .................................................................................4
General warnings............................................................................................................4
Old and out-of-order fridges or freezer ...........................................................................8
Safety warnings ..............................................................................................................8
In󰀬alling and operating your fridge freezer.....................................................................9
The di󰀬ance between the appliance and back wall mu󰀬 be minimum 42mm and
maximum 75mm. ..........................................................................................................10
Before Using your Fridge..............................................................................................10
Dimensions ...................................................................................................................11
THE VARIOUS FUNCTION AND POSSIBILITIES........................................................12
Information about New Generation Cooling Technology...............................................12
Display and Control Panel ............................................................................................13
Operating your Fridge Freezer .....................................................................................13
Freezer Temperature Settings.................................................................................13
Cooler Temperature Settings ..................................................................................13
Super Freeze Mode ................................................................................................13
Door Open Alarm Function......................................................................................14
Temperature Adju󰀬ment Warnings...............................................................................14
Accessories ..................................................................................................................15
Ice Tray ...................................................................................................................15
The Freezer Box .....................................................................................................15
Extra Chill Compartment .........................................................................................16
The Fresh Dial.........................................................................................................16
ARRANGING FOOD IN THE APPLIANCE ....................................................................17
Refrigerator compartment.............................................................................................17
Freezer compartment ...................................................................................................18
CLEANING AND MAINTENANCE..................................................................................21
Defro󰀬ing................................................................................................................22
TRANSPORTATION AND CHANGING OF INSTALLATION POSITION ....................22
Repositioning the Door .................................................................................................22
BEFORE CALLING YOUR AFTER SALES SERVICE .................................................23
Hints for Energy Saving ................................................................................................26
THE PARTS OF THE APPLIANCE AND THE COMPARTMENTS ..............................27
TECHNICAL DATA...........................................................................................................28
INFORMATION FOR TEST INSTITUTES ......................................................................28
Get usage advice, brochures, trouble shooter, service and repair information:
WWW.ZANUSSI.COM/SUPPORT

EN -4-
BEFORE USING THE APPLIANCE
General warnings
Please read the in󰀬ruction manual carefully before in󰀬alling and
using your appliance. We are not responsible for the damage
occurred due to misuse.
Follow all in󰀬ructions on your appliance and in󰀬ruction manual,
and keep this manual in a safe place to resolve the problems
that may occur in the future.
This appliance is not intended to be used as a built-in appliance.
In case of di󰀨erent in󰀬allation from free󰀬anding respecting space
required in use dimensions, the appliance will function correctly
but energy consumption migh increase slightyle.
WARNING: Keep ventilation openings, in the appliance
enclosure or in the built-in 󰀬ructure, clear of ob󰀬ruction.
WARNING: Do not use mechanical devices or other means
to accelerate the defro󰀬ing process, other than those
recommended by the manufacturer.
WARNING: Do not use electrical appliances inside the food
󰀬orage compartments of the appliance, unless they are of the
type recommended by the manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: When positioning the appliance, ensure the
supply cord is not trapped or damaged.
WARNING: Do not locate multiple portable socket-outlets or
portable power supplies at the rear of the appliance.
WARNING: In order to avoid any hazards resulting from the
in󰀬ability of the appliance, it mu󰀬 be xed in accordance with
the following in󰀬ructions:
If your appliance uses R600a as a refrigerant (this information
PART - 1.

EN -5-
will be provided on the label of the cooler) you should take care
during transportation and in󰀬allation to prevent the cooler
elements from being damaged. R600a is an environmentally
friendly and natural gas, but it is explosive. In the event of a leak
due to damage of the cooler elements, move your fridge away
from open ames or heat sources and ventilate the room where
the appliance is located for a few minutes.
• Keep all packaging away from children and dispose of it
appropriately.
• While carrying and positioning the fridge, do not damage the
cooler gas circuit.
• Do not 󰀬ore explosive sub󰀬ances such as aerosol cans with
a ammable propellant in this appliance.
• This appliance is intended to be used in household and
dome󰀬ic applications such as:
- 󰀬a󰀨 kitchen areas in shops, o󰀩ces and other working
environments.
- farm houses and by clients in hotels, motels and other
residential type environments.
- bed and breakfa󰀬 type environments;
- catering and similar non-retail applications.
• If the socket does not match the refrigerator plug, it mu󰀬 be
replaced by the manufacturer, a service agent or similarly
qualied persons in order to avoid a hazard.
• A specially grounded plug has been connected to the power
cable of your refrigerator. This plug should be used with
a specially grounded socket of 13 amperes according to
country where the product will be sold. If there is no such
socket in your house, please have it in󰀬alled by an authorized
electrician.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or

EN -6-
mental capabilities or lack of experience and knowledge if they
have been given supervision or in󰀬ruction concerning use
of the appliance in a safe way and under󰀬and the hazards
involved. Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children without
supervision.
• Children aged from 3 to 8 years are allowed to load and
unload refrigerating appliances. Children are not expected
to perform cleaning or user maintenance of the appliance,
very young children (0-3 years old) are not expected to use
appliances, young children (3-8 years old) are not expected to
use appliances safely unless continuous supervision is given,
older children (8-14 years old) and vulnerable people can
use appliances safely after they have been given appropriate
supervision or in󰀬ruction concerning use of the appliance.
Very vulnerable people are not expected to use appliances
safely unless continuous supervision is given.
• If the supply cord is damaged, it mu󰀬 be replaced by the
manufacturer, an authorised service agent or similar qualied
persons, in order to avoid a hazard.
• This appliance is not intended for use at altitudes exceeding
2000 m.
To avoid contamination of food, please respect the
following in󰀬ructions:
• Opening the door for long periods can cause a signicant
increase of the temperature in the compartments of the
appliance.
• Clean regularly surfaces that can come in contact with food
and accessible drainage sy󰀬ems
• Store raw meat and sh in suitable containers in the
refrigerator, so that it is not in contact with or drip onto other
food.

EN -7-
• Two-󰀬ar frozen-food compartments are suitable for 󰀬oring
pre-frozen food, 󰀬oring or making ice cream and making ice
cubes.
• One-, two- and three-󰀬ar compartments are not suitable for
the freezing of fresh food.
• If the refrigerating appliance is left empty for long periods,
switch o󰀨, defro󰀬, clean, dry, and leave the door open to
prevent mould developing within the appliance.
Service
• To repair the appliance contact the Authorised Service Centre.
Use original spare parts only.
• Please note that self-repair or nonprofessional repair can
have safety consequences and might void the guarantee.
• The following spare parts will be available for 7 years after
the model has been discontinued: thermo󰀬ats, temperature
sensors, printed circuit boards, light sources, door handles,
door hinges, trays and baskets.
• Please note that some of these spare parts are only available
to professional repairers, and that not all spare parts are
relevant for all models.
• Door gaskets will be available for 10 years after the model
has been discontinued.

EN -8-
Old and out-of-order fridges or freezer
• If your old fridge or freezer has a lock, break or remove the lock before discarding it,
because children may get trapped inside it and may cause an accident.
• Old fridges and freezers contain isolation material and refrigerant with CFC. Therefore,
take care not to harm environment when you are discarding your old fridges.
Disposal of your old appliance
The symbol on the product or on its packaging indicates that this product may not
be treated as household wa󰀬e. In󰀬ead it shall be handed over to the applicable
collection point for the recycling of electrical and electronic equipment. By ensuring
this product is disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which could otherwise be
caused by inappropriate wa󰀬e handling of this product. For more detailed information
about recycling of this product, please contact your local city o󰀩ce, your household wa󰀬e
disposal service or the shop where you purchased the product.
Notes:
• This appliance is produced to be used in homes and it can only be used in dome󰀬ic
environments and for the specied purposes. It is not suitable for commercial or common
use. Such use will cause the guarantee of the appliance to be cancelled and our company
will not be responsible for the losses to be occurred.
• This appliance is produced to be used in houses and it is only suitable for cooling / 󰀬oring
foods. It is not suitable for commercial or common use and/or for 󰀬oring sub󰀬ances
except for food. Our company is not responsible for the losses to be occurred in the
contrary case.
Safety warnings
• Do not connect your fridge freezer to the mains electricity supply using an extension lead.
• Do not use damaged, torn or old plugs.
• Do not pull, bend or damage the cord.
• Do not use plug adapter.
• This appliance is designed for use by adults. Do not allow children to
play with the appliance or hang o󰀨 the door.
• Never touch the power cord/plug with wet hands. This may cause a
short circuit or electric shock.
• Do not place glass bottles or cans in the ice-making compartment as
they will bur󰀬 when the contents freeze.
• Do not place explosive or ammable material in your fridge. Place
drinks with high alcohol content vertically in the fridge compartment and
make sure their tops are tightly closed.

EN -9-
• When removing ice from the ice-making compartment, do not touch it.
Ice may cause fro󰀬 burns and/or cuts.
• Do not touch frozen goods with wet hands. Do not eat ice-cream or
ice cubes immediately after they are removed from the ice-making
compartment.
• Do not re-freeze thawed frozen food. This may cause health issues such as
food poisoning.
In󰀬alling and operating your fridge freezer
Before using your fridge freezer for the r󰀬 time, please pay attention to the following points:
• The operating voltage for your fridge freezer is 220-240 V at 50Hz.
• The plug mu󰀬 be accessible after in󰀬allation.
• Your fridge freezer may have an odour when it is operated for the r󰀬 time. This is normal
and the odour will fade when your fridge freezer 󰀬arts to cool.
• Before connecting your fridge freezer, ensure that the information on the data plate
(voltage and connected load) matches that of the mains electricity supply. If in doubt,
consult a qualied electrician.
• Insert the plug into a socket with an e󰀩cient ground connection. If the socket has no
ground contact or the plug does not match, we recommend you consult a qualied
electrician for assi󰀬ance.
• The appliance mu󰀬 be connected with a properly in󰀬alled fused socket. The power
supply (AC) and voltage at the operating point mu󰀬 match with the details on the name
plate of the appliance (the name plate is located on the inside left of the appliance).
• We do not accept responsibility for any damages that occur due to ungrounded usage.
• Place your fridge freezer where it will not be exposed to direct sunlight.
• Your fridge freezer mu󰀬 never be used outdoors or exposed to rain.
• Your appliance mu󰀬 be at lea󰀬 50 cm away from 󰀬oves, gas ovens and heater cores,
and at lea󰀬 5 cm away from electrical ovens.
• If your fridge freezer is placed next to a deep freezer, there mu󰀬 be at lea󰀬 2 cm between
them to prevent humidity forming on the outer surface.
• Do not cover the body or top of fridge freezer with lace. This will a󰀨ect the performance
of your fridge freezer.
• Clearance of at lea󰀬 150 mm is required at the top of your appliance. Do not place
anything on top of your appliance.
• Do not place heavy items on the appliance.
• Use the adju󰀬able front legs to make sure your appliance is level and 󰀬able.
You can adju󰀬 the legs by turning them in either direction. This mu󰀬 be
done before placing food in the appliance.
• Clean the appliance thoroughly before use (see Cleaning and Maintenance).
• Before using your fridge freezer, wipe all parts with a solution of warm water
and a teaspoon of sodium bicarbonate. Then, rinse with clean water and
dry. Return all parts to the fridge freezer after cleaning.
• In󰀬all the two pla󰀬ic di󰀬ance guides (the parts on the black vanes -condenser- at the

EN -10-
rear) by turning it 90° (as shown in the gure) to prevent the condenser from touching
the wall.
The di󰀬ance between the appliance and back wall mu󰀬 be minimum
42mm and maximum 75mm.
Before Using your Fridge
• When using your fridge for the r󰀬 time, or after transportation, keep it
in an upright position for at lea󰀬 3 hours before plugging into the mains.
This allows e󰀩cient operation and prevents damage to the compressor.
• Your fridge may have a smell when it is operated for the r󰀬 time. This is normal and
the smell will fade away when your fridge 󰀬arts to cool.
Electrical information (For UK type plug)
Warning! This appliance mu󰀬 be earthed.
The mains lead of this appliance has been tted with a specially earthed plug.
Important: Do not use the appliance without the fuse cover in position. Should the
fuse need to be replaced, it mu󰀬 be replaced with a 13A fuse, ASTA approved to BS1362.
The plug mu󰀬 be used with a specially earthed socket of 13 amperes. If there is no such
socket in your house, please have one in󰀬alled by an authorised electrician.
The mains lead of this appliance has been tted with a BS
1363A 13A fused plug. To change a fuse in this type of plug,
follow the 󰀬eps below:
1. Remove the fuse cover and fuse.
2. Fit replacement 13A fuse, ASTA approved to BS 1362 type,
into the fuse cover.
3. Replace fuse cover.
Internal lighting
WARNING!
Risk of electric shock.
• Concerning the lamp(s) inside this product and spare part lamps sold separately: These
lamps are intended to with󰀬and extreme physical conditions in household appliances,
such as temperature, vibration, humidity, or are intended to signal information about the
operational 󰀬atus of the appliance. They are not intended to be used in other applications
and are not suitable for household room illumination.

EN -11-
Dimensions
3 the height, width and depth of the
appliance including the handle,
plus the space necessary for free
circulation of the cooling air, plus
the space necessary to allow
door opening to the minimum
angle permitting removal of all
internal equipment
Overall dimensions 1
H1 mm 1860
W1 mm 595
D1 mm 650
Space required in use 2
H2 mm 2010
W2 mm 695
D2 mm 739
1 the height, width and depth of the
appliance without the handle
2 the height, width and depth of the
appliance including the handle,
plus the space necessary for free
circulation of the cooling air
Overall space required in use 3
W3 mm 967
D3 mm 1179
H1 H2
W1
D1
W2
D2
D3
90o
W3

EN -12-
THE VARIOUS FUNCTION AND POSSIBILITIES
Information about New Generation Cooling Technology
Fridges with new-generation cooling technology have a di󰀨erent operating
sy󰀬em to 󰀬atic fridges. Other (󰀬atic) fridges may experience a build up
of ice in the freezer compartment due to door openings and humidity in
the food. In such fridges, regular defro󰀬ing is required; the fridge mu󰀬
be switched o󰀨, the frozen food moved to a suitable container and the
ice which has formed in the freezer compartment removed.
In fridges with new-generation cooling technology, a fan blows dry cold
air evenly throughout the fridge and freezer compartments. The cold air
cools your food evenly and uniformly, preventing humidity and ice build-up.
In the refrigerator compartment, air blown by the fan, located at the top
of the refrigerator compartment, is cooled while passing through the gap
behind the air duct. At the same time, the air is blown out through the
holes in the air duct, evenly spreading cool air throughout the refrigerator
compartment.
There is no air passage between the freezer and refrigerator compartments,
therefore preventing the mixing of odours.
As a result, your fridge, with new-generation cooling technology, provides
you with ease of use as well as a huge volume and ae󰀬hetic appearance.
PART - 2.

EN -13-
Display and Control Panel
Using the Control Panel
1. Enables the setting of the freezer.
2. Enables the setting of the cooler.
3. Freezer set value screen.
4. Cooler set value screen.
5. Economy mode symbol.
6. Super freeze symbol.
7. Alarm symbol.
Operating your Fridge Freezer
Once you have plugged in the product, all symbols will be displayed for 2 seconds and the
initial values will be shown as -18 °C on the freezer adju󰀬ment indicator, and +4 °C on the
fridge adju󰀬ment indicator.
Lighting (If available)
When the product is plugged in for the rst time, the interior lights may turn on 1 minute
late due to opening tests.
Freezer Temperature Settings
• The initial temperature value for the freezer setting indicator is -18 °C.
• Press the freezer set button once.
When you r󰀬 press the button, the previous value will blink on the screen.
• Whenever you press this button, temperature will decrease respectively.
• If you continue to press the button, it will re󰀬art from -16 °C.
NOTE: Eco mode gets activated automatically when the temperature of the freezer
compartment is set to -18°C.
Cooler Temperature Settings
• The initial temperature value for the cooler setting indicator is +4 °C.
• Press the cooler button once.
• Whenever you press this button, temperature will decrease respectively.
• If you continue to press the button, it will re󰀬art from +8 °C.
Super Freeze Mode
Purpose
• To freeze a large quantity of food that cannot t on the fa󰀬 freeze shelf.
• To freeze prepared foods.
• To freeze fresh food quickly to retain freshness.
How to use
To enable the super freeze mode, press and hold the freezer temperature setting
button for 3 seconds. Once the super freeze mode has been set, the super freeze
symbol on the indicator will be lit and the machine will beep to conrm the mode has
been switched on.
During Super Freeze Mode:
• The temperature of the Cooler may be adju󰀬ed. In this case, Super Freeze mode will
continue.
1 2
35674

EN -14-
• Economy mode cannot be selected.
• Super Freeze mode can be cancelled in the same way it is selected.
Notes:
• The maximum amount of fresh food (in kilograms) that can be frozen within 24 hours is
shown on the appliance label.
• For optimal appliance performance in maximum freezer capacity, activate super freeze
mode 3 hours before you put fresh food into the freezer.
Super freeze mode will automatically cancel after 24 hours, depending on the
environmental temperature or when the freezer sensor reaches a su󰀩ciently low
temperature.
Recommended Settings for the Freezer and Cooler Compartment Temperature
Freezer Compartment Cooler
Compartment Remarks
-18 oC4 oC For regular use and best performance.
-20 oC, -22 oC or -24 oC4 oCRecommended when environmental
temperature exceeds 30 °C.
Super Freeze mode 4 oCMust be used when you wish to freeze food in a
short period of time.
-18 oC, -20 oC, -22 oC or -24 oC2 oC
These temperature settings must be used
when the environmental temperature is high or
if you think the refrigerator compartment is not
cool enough becuse the door is being opened
frequently.
Door Open Alarm Function
If cooler door is opened more than 2 minutes, appliance sounds ‘beep beep’.
Temperature Adju󰀬ment Warnings
• It is not recommended that you operate your fridge in environments colder than 10°C
in terms of its e󰀩ciency.
• Do not 󰀬art another adju󰀬ment while you are already making an adju󰀬ment.
• Temperature adju󰀬ments should be made according to the frequency of door openings,
the quantity of food kept inside the fridge and the ambient temperature in the location
of your fridge.
• In order to allow your fridge to reach the operating temperature after being connected to
mains, do not open the doors frequently or place large quantities of food in the fridge.
Please note that, depending on the ambient temperature, it may take 24 hours for your
fridge to reach the operating temperature.
• A 5 minute delay function is applied to prevent damage to the compressor of your fridge
when connecting or disconnecting to mains, or when an energy breakdown occurs. Your
fridge will begin to operate normally after 5 minutes.
• Your appliance is designed to operate in the ambient temperature (T/SN = 10°C - 43°C)
intervals 󰀬ated in the 󰀬andards, according to the climate class displayed on the
information label. We do not recommend operating your appliance out of the 󰀬ated
temperature limits in terms of cooling e󰀨ectiveness.

EN -15-
Climate class Meaning Ambient Temperature
TTropical This refrigerating appliance is intended to be used at
ambient temperatures ranging from 16 °C to 43 °C.
ST Subtropical This refrigerating appliance is intended to be used at
ambient temperatures ranging from 16 °C to 38 °C.
NTemperate This refrigerating appliance is intended to be used at
ambient temperatures ranging from 16 °C to 32 °C.
SN Extended temperate This refrigerating appliance is intended to be used at
ambient temperatures ranging from 10 °C to 32 °C.
Important in󰀬allation in󰀬ructions
This appliance is designed to work in di󰀩cult climate conditions (up to 43 degrees C or 110
degrees F) and is powered with ‘Freezer Shield’ technology which ensures that the frozen
food in the freezer will not defro󰀬 even if the ambient temperature falls as low as -15 °C. So
you may then in󰀬all your appliance in an unheated room without having to worry about frozen
food in the freezer being spoilt. When the ambient temperature returns to normal, you may
continue using the appliance as usual.
Accessories
Ice Tray
• Fill the ice tray with water and place in the freezer compartment.
• After the water has completely frozen, you can twi󰀬 the tray as shown below to remove
the ice cubes.
The Freezer Box
The freezer box allows food to be accessed more
easily.
Removing the freezer box:
• Pull the box out as far as possible
• Pull the front of the box up and out
Carry out the opposite of this operation when
retting the sliding compartment.
Always keep hold of the handle of the box while
removing it.
Freezer boxes

EN -16-
Extra Chill Compartment
Ideal to preserve the ta󰀬e and texture of fresh
cuts and cheese. The pull out drawer assures an
environment with a lower temperature compared
to the re󰀬 of the fridge, thanks to the active
circulation of cold air.
To remove the Chiller Shelf:
• Pull the chiller shelf towards you by sliding
it on the rails.
• Pull the chiller shelf up from the rail and
remove it from the fridge.
After the chiller shelf has been removed, it can support a maximum 20 kg load.
Chiller shelf
(In some models)
The Fresh Dial
If the crisper is full, the fresh dial located in front of the
crisper should be opened. This allows the air in the crisper
and the humidity rate to be controlled, to increase the life
of food within.
The dial, located behind the shelf, mu󰀬 be opened if any
condensation is seen on the glass shelf.
(In some models) Fresh dial
Visual and text descriptions in the accessories section may vary according
to the model of your appliance.

EN -17-
ARRANGING FOOD IN THE APPLIANCE
Refrigerator compartment
• Fresh food compartment is the one marked (on the rating plate) with .
• To reduce humidity and avoid the consequent formation of fro󰀬, always 󰀬ore liquids in
sealed containers in the refrigerator. Fro󰀬 tends to concentrate in the colde󰀬 parts of
the evaporating liquid and, in time, your appliance will require more frequent defro󰀬ing.
• Never place warm food in the refrigerator. Warm food should be allowed to cool at room
temperature and should be arranged to ensure adequate air circulation in the refrigerator
compartment.
• Make sure no items are in direct contact with the rear wall of the appliance as fro󰀬 will
develop and packaging will 󰀬ick to it. Do not open the refrigerator door frequently.
• We recommend that meat and clean sh are loosely wrapped and 󰀬ored on the glass
shelf ju󰀬 above the vegetable bin where the air is cooler, as this provides the be󰀬
󰀬orage conditions.
• Store loose fruit and vegetable items in the crisper containers.
• Store loose fruit and vegetables in the crisper.
• Storing fruit and vegetables separately helps prevent ethylene-sensitive vegetables
(green leaves, broccoli, carrot, etc.) being a󰀨ected by ethylene-releaser fruits (banana,
peach, apricot, g etc.).
• Do not put wet vegetables into the refrigerator.
• Storage time for all food products depends on the initial quality of the food and an
uninterrupted refrigeration cycle before refrigerator 󰀬orage.
• To avoid cross-contamination do not 󰀬ore meat products with fruit and vegetables.
Water leaking from meat may contaminate other products in the refrigerator. You should
package meat products and clean any leakages on the shelves.
• Do not put food in front of the air ow passage.
• Consume packaged foods before the recommended expiry date.
NOTE: Mo󰀬 e󰀩cient use of energy is ensured in the conguration with the drawers in
the bottom part of the appliance, and shelves evenly di󰀬ributed, position of door bins
does not a󰀨ect energy consumption.
NOTE: Potatoes, onions and garlic should not be 󰀬ored in the refrigerator.
The table below is a quick guide to show you the mo󰀬 e󰀩cient way to 󰀬ore the major
food groups in your refrigerator compartment.
Food Maximum storage time How and where to store
Vegetables and fruits 1 week Vegetable bin
Meat and sh 2 - 3 Days Wrap in plastic foil, bags, or in a meat
container and store on the glass shelf
Fresh cheese 3 - 4 Days On the designated door shelf
Butter and margarine 1 week On the designated door shelf
PART - 3.

EN -18-
Food Maximum storage time How and where to store
Bottled products e.g.
milk and yoghurt
Until the expiry date
recommended by the
producer
On the designated door shelf
Eggs 1 month On the designated egg shelf
Cooked food 2 Days All shelves
Freezer compartment
• Freezer compartment is the one marked with .
• The freezer is used for 󰀬oring frozen food, freezing fresh food, and making ice cubes.
• To use the maximum capacity of the freezer compartment, use the glass shelves for the
upper and middle section, and use the lower basket for the bottom section.
• Use the fa󰀬 freezing shelf to freeze home cooking (and any other food which needs to
be frozen quickly) more quickly because of the freezing shelf’s greater freezing power.
Fa󰀬 freezing shelf is the bottom drawer of the freezer compartment.
• For freezing fresh food; wrap and seal fresh food properly, that is the packaging should
be air tight and shouldn’t leak. Special freezer bags, aluminum foil polythene bags and
pla󰀬ic containers are ideal.
• Do not 󰀬ore fresh food next to frozen food as it can thaw the frozen food.
• Before freezing fresh food, divide it into portions that can be consumed in one sitting.
• Consume thawed frozen food within a short period of time after defro󰀬ing
• Never place warm food in the freezer compartment as it will thaw the frozen food.
• Always follow the manufacturer's in󰀬ructions on food packaging when 󰀬oring frozen
food. If no information is provided food, should not be 󰀬ored for more than 3 months
from the date of purchase.
• When purchasing frozen food, make sure that it has been 󰀬ored under appropriate
conditions and that the packaging is not damaged.
• Frozen food should be transported in appropriate containers and placed in the freezer
as soon as possible.
• Do not purchase frozen food if the packaging shows signs of humidity and abnormal
swelling. It is probable that it has been 󰀬ored at an unsuitable temperature and that
the contents have deteriorated.
• The 󰀬orage life of frozen food depends on the room temperature, the thermo󰀬at setting,
how often the door is opened, the type of food, and the length of time required to transport
the product from the shop to your home. Always follow the in󰀬ructions printed on the
packaging and never exceed the maximum 󰀬orage life indicated.
• The maximum amount of fresh food (in kg) that can be frozen in 24 hours is indicated
on the appliance label.
NOTE: If you attempt to open the freezer door immediately after closing it, you will nd that it will
not open easily. This is normal. Once equilibrium has been reached, the door will open easily.
Important note:
• Never refreeze thawed frozen food.
• The ta󰀬e of some spices found in cooked dishes (anise, basilica, watercress, vinegar,
assorted spices, ginger, garlic, onion, mu󰀬ard, thyme, marjoram, black pepper, etc.)

EN -19-
changes and they assume a 󰀬rong ta󰀬e when they are 󰀬ored for a long period of time.
Therefore, add small amounts of spices to food to be frozen, or the desired spice should
be added after the food has thawed.
• The 󰀬orage time of food is dependent on the type of oil used. Suitable oils are margarine,
calf fat, olive oil and butter. Unsuitable oils are peanut oil and pig fat.
• Food in liquid form should be frozen in pla󰀬ic cups and other food should be frozen in
pla󰀬ic folios or bags.
The table below is a quick guide to show you the mo󰀬 e󰀩cient way to 󰀬ore the major
food groups in your freezer compartment.
Meat and sh Preparation Maximum storage time
(months)
Steak Wrap in foil 6 - 8
Lamb meat Wrap in foil 6 - 8
Veal roast Wrap in foil 6 - 8
Veal cubes In small pieces 6 - 8
Lamb cubes In pieces 4 - 8
Minced meat In packaging without using spices 1 - 3
Giblets (pieces) In pieces 1 - 3
Bologna sausage/
salami
Should be kept packaged even if it has a
membrane
Chicken and turkey Wrap in foil 4 - 6
Goose and duck Wrap in foil 4 - 6
Deer, rabbit, wild
boar In 2.5 kg portions or as llets 6 - 8
Freshwater sh
(Salmon, Carp,
Crane, Catsh)
After cleaning the bowels and scales of the
sh, wash and dry it. If necessary, remove the
tail and head.
2
Lean sh (Bass,
Turbot, Flounder) 4
Fatty shes (Tuna,
Mackerel, Bluesh,
Anchovy)
2 - 4
Shellsh Clean and in a bag 4 - 6
Caviar In its packaging, or in an aluminium or plastic
container 2 - 3
Snails In salty water, or in an aluminium or plastic
container 3
NOTE: Thawed frozen meat should be cooked as fresh meat. If the meat is not cooked after
defrosting, it must not be re-frozen.

EN -20-
Vegetables and Fruits Preparation Maximum storage time
(months)
String beans and
beans Wash, cut into small pieces and boil in water 10 - 13
Beans Hull, wash and boil in water 12
Cabbage Clean and boil in water 6 - 8
Carrot Clean, cut into slices and boil in water 12
Pepper Cut the stem, cut into two pieces, remove the
core and boil in water 8 - 10
Spinach Wash and boil in water 6 - 9
Cauliower
Remove the leaves, cut the heart into pieces
and leave it in water with a little lemon juice
for a while
10 - 12
Eggplant Cut into pieces of 2cm after washing 10 - 12
Corn Clean and pack with its stem or as sweet corn 12
Apple and pear Peel and slice 8 - 10
Apricot and Peach Cut into two pieces and remove the stone 4 - 6
Strawberry and
Blackberry Wash and hull 8 - 12
Cooked fruits Add 10 % of sugar to the container 12
Plum, cherry,
sourberry Wash and hull the stems 8 - 12
Maximum storage
time (months)
Thawing time at
room temperature
(hours)
Thawing time in oven
(minutes)
Bread 4 - 6 2 - 3 4-5 (220-225 °C)
Biscuits 3 - 6 1 - 1,5 5-8 (190-200 °C)
Pastry 1 - 3 2 - 3 5-10 (200-225 °C)
Pie 1 - 1,5 3 - 4 5-8 (190-200 °C)
Phyllo dough 2 - 3 1 - 1,5 5-8 (190-200 °C)
Pizza 2 - 3 2 - 4 15-20 (200 °C)
Dairy products Preparation Maximum storage
time (months) Storage conditions
Packet
(Homogenized) Milk In its own packet 2 - 3 Pure Milk – in its own packet
Cheese - excluding
white cheese In slices 6 - 8
Original packaging may
be used for short-term
storage. Keep wrapped in
foil for longer periods.
Butter, margarine In its packaging 6
