Zanussi ZUHE30FW2 User manual

ZUHE30FW2
EN User Manual 2

EN - 2 -
EN FIRE Warning; Risk of re / ammable materials

EN - 3 -
CONTENTS
BEFORE USING THE APPLIANCE ........................................................ 4
General warnings ............................................................................................. 4
Old and out-of-order fridges or freezer............................................................. 8
Safety warnings................................................................................................ 8
Installation warnings......................................................................................... 9
Before using your freezer ................................................................................ 10
Dimensions...................................................................................................... 11
THE VARIOUS FUNCTION AND POSSIBILITIES ................................. 12
Information on No-Frost technology ................................................................ 12
Display and Control Panel............................................................................... 13
Operating your Freezer ................................................................................... 13
Super Freezer Mode ................................................................................................ 13
Freezer Temperature Settings.................................................................................. 13
Warnings about temperature adjustments....................................................... 14
Accessories ..................................................................................................... 15
Ice Tray..................................................................................................................... 15
The Icematic............................................................................................................. 15
ARRANGING FOOD IN THE APPLIANCE ............................................ 15
CLEANING AND MAINTENANCE ......................................................... 19
Defrosting ........................................................................................................ 19
TRANSPORTATION AND CHANGING OF INSTALLATION POSITION 20
Repositioning the Door.................................................................................... 20
BEFORE CALLING YOUR AFTER SALES SERVICE........................... 21
Hints for Energy Saving................................................................................... 22
THE PARTS OF THE APPLIANCE AND THE COMPARTMENTS ........ 23
TECHNICAL DATA ................................................................................. 24
INFORMATION FOR TEST INSTITUTES............................................... 24
Visit our website to:
Get usage advice, brochures, trouble shooter, service and repair information:
www.zanussi.com/support

EN - 4 -
General warnings
This appliance is not intended to be used as a built-in appliance.
WARNING: Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of obstruction.
WARNING: Do not use mechanical devices or other means
to accelerate the defrosting process, other than those
recommended by the manufacturer.
WARNING: Do not use electrical appliances inside the food
storage compartments of the appliance, unless they are of the
type recommended by the manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: When positioning the appliance, ensure the
supply cord is not trapped or damaged.
WARNING: Do not locate multiple portable socket-outlets or
portable power supplies at the rear of the appliance.
WARNING: In order to avoid any hazards resulting from the
instability of the appliance, it must be xed in accordance with
the following instructions:
If your appliance uses R600a as a refrigerant (this information
will be provided on the label of the cooler) you should take care
during transportation and installation to prevent the cooler
elements from being damaged. R600a is an environmentally
friendly and natural gas, but it is explosive. In the event of a leak
due to damage of the cooler elements, move your fridge away
from open ames or heat sources and ventilate the room where
the appliance is located for a few minutes.
• While carrying and positioning the fridge, do not damage the
cooler gas circuit.
• Do not store explosive substances such as aerosol cans
with a ammable propellant in this appliance.
• This appliance is intended to be used in household and
BEFORE USING THE APPLIANCEPART - 1.

EN - 5 -
domestic applications such as:
- sta󰀨 kitchen areas in shops, o󰀩ces and other working
environments.
- farm houses and by clients in hotels, motels and other
residential type environments.
- bed and breakfast type environments;
- catering and similar non-retail applications.
• If the socket does not match the refrigerator plug, it must be
replaced by the manufacturer, a service agent or similarly
qualied persons in order to avoid a hazard.
• A specially grounded plug has been connected to the power
cable of your refrigerator. This plug should be used with a
specially grounded socket of 16 amperes or 10 amperes
according to country where the product will be sold. If there
is no such socket in your house, please have it installed by
an authorized electrician.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children without
supervision.
• Children aged from 3 to 8 years are allowed to load and
unload refrigerating appliances. Children are not expected
to perform cleaning or user maintenance of the appliance,
very young children (0-3 years old) are not expected to use
appliances, young children (3-8 years old) are not expected to
use appliances safely unless continuous supervision is given,
older children (8-14 years old) and vulnerable people can
use appliances safely after they have been given appropriate
supervision or instruction concerning use of the appliance.

EN - 6 -
Very vulnerable people are not expected to use appliances
safely unless continuous supervision is given.
• If the supply cord is damaged, it must be replaced by the
manufacturer, an authorised service agent or similar qualied
persons, in order to avoid a hazard.
• This appliance is not intended for use at altitudes exceeding
2000 m.
To avoid contamination of food, please respect the
following in󰀬ructions:
• Opening the door for long periods can cause a signicant
increase of the temperature in the compartments of the
appliance.
• Clean regularly surfaces that can come in contact with food
and accessible drainage systems
• Store raw meat and sh in suitable containers in the
refrigerator, so that it is not in contact with or drip onto other
food.
• Two-star frozen-food compartments are suitable for storing
pre-frozen food, storing or making ice cream and making ice
cubes.
• One-, two- and three-star compartments are not suitable for
the freezing of fresh food.
• If the refrigerating appliance is left empty for long periods,
switch o󰀨, defrost, clean, dry, and leave the door open to
prevent mould developing within the appliance.

EN - 7 -
Service
• To repair the appliance contact the Authorised Service
Centre. Use original spare parts only.
• Please note that self-repair or nonprofessional repair can
have safety consequences and might void the guarantee.
• The following spare parts will be available for 7 years after
the model has been discontinued: thermostats, temperature
sensors, printed circuit boards, light sources, door handles,
door hinges, trays and baskets.
• Please note that some of these spare parts are only available
to professional repairers, and that not all spare parts are
relevant for all models.
• Door gaskets will be available for 10 years after the model
has been discontinued.

EN - 8 -
Old and out-of-order fridges or freezer
• If your old fridge or freezer has a lock, break or remove the lock before discarding it,
because children may get trapped inside it and may cause an accident.
• Old fridges and freezers contain isolation material and refrigerant with CFC. Therefore,
take care not to harm environment when you are discarding your old fridges.
Disposal of your old appliance
The symbol on the product or on its packaging indicates that this product may not
be treated as household waste. Instead it shall be handed over to the applicable
collection point for the recycling of electrical and electronic equipment. By
ensuring this product is disposed of correctly, you will help prevent potential
negative consequences for the environment and human health, which could
otherwise be caused by inappropriate waste handling of this product. For more
detailed information about recycling of this product, please contact your local city o󰀩ce, your
household waste disposal service or the shop where you purchased the product.
Notes:
• Please read the instruction manual carefully before installing and using your appliance.
We are not responsible for the damage occurred due to misuse.
• Follow all instructions on your appliance and instruction manual, and keep this manual
in a safe place to resolve the problems that may occur in the future.
• This appliance is produced to be used in homes and it can only be used in domestic
environments and for the specied purposes. It is not suitable for commercial or
common use. Such use will cause the guarantee of the appliance to be cancelled and
our company will not be responsible for any losses incurred.
• This appliance is produced to be used in houses and it is only suitable for cooling / storing
foods. It is not suitable for commercial or common use and/or for storing substances
except for food. Our company is not responsible for any losses incurred by inappropriate
usage of the appliance.
Safety warnings
• Do not connect your freezer to the mains electricity supply using an extension lead.
• Do not use damaged, torn or old plugs.
• Do not pull, bend or damage the cord.
• Do not use plug adapter.
• This appliance is designed for use by adults. Do not allow children to play
with the appliance or hang o󰀨 the door.
• Never touch the power cord/plug with wet hands. This may cause a
short circuit or electric shock.

EN - 9 -
• Do not place glass bottles or cans in the ice-making compartment as they
will burst when the contents freeze.
• Do not place explosive or ammable material in your freezer.
• When removing ice from the ice-making compartment, do not touch it. Ice
may cause frost burns and/or cuts.
• Do not touch frozen goods with wet hands. Do not eat ice-cream or ice cubes
immediately after they are removed from the ice-making compartment.
• Do not re-freeze thawed frozen food. This may cause health issues such as food
poisoning.
When the door of the freezer is closed, a vacuum
seal will form. Wait for 1 minute before reopening it.
This application is optional for easy opening of the
door. With this application, a little condensation may
occur around this area and you may remove it.
Installation warnings
Before using your freezer for the rst time, please pay attention to the following points:
• The operating voltage for your freezer is 220-240 V at 50Hz.
• The plug must be accessible after installation.
• Your freezer may have an odour when it is operated for the rst time. This is normal and
the odour will fade when your freezer starts to cool.
• Before connecting your freezer, ensure that the information on the data plate (voltage
and connected load) matches that of the mains electricity supply. If in doubt, consult a
qualied electrician.
• Insert the plug into a socket with an e󰀩cient ground connection. If the socket has no
ground contact or the plug does not match, we recommend you consult a qualied
electrician for assistance.
• The appliance must be connected with a properly installed fused socket. The power
supply (AC) and voltage at the operating point must match with the details on the name
plate of the appliance (the name plate is located on the inside left of the appliance).
• We do not accept responsibility for any damages that occur due to ungrounded usage.
• Place your freezer where it will not be exposed to direct sunlight.
• Your freezer must never be used outdoors or exposed to rain.
• Your appliance must be at least 50 cm away from stoves, gas ovens and heater cores,
and at least 5 cm away from electrical ovens.
• If your freezer is placed next to a deep freezer, there must be at least 2 cm between
them to prevent humidity forming on the outer surface.
• Do not cover the body or top of freezer with lace. This will a󰀨ect the performance of your
freezer.
• Clearance of at least 150 mm is required at the top of your appliance. Do
not place anything on top of your appliance.
• Do not place heavy items on the appliance.
• Clean the appliance thoroughly before use (see Cleaning and Maintenance).

EN - 10 -
• Before using your freezer, wipe all parts with a solution of warm water and a teaspoon of
sodium bicarbonate. Then, rinse with clean water and dry. Return all parts to the freezer
after cleaning.
• Use the adjustable front legs to make sure your appliance is level and stable. You can
adjust the legs by turning them in either direction. This must be done
before placing food in the appliance.
• Install the two plastic distance guides (the parts on the black vanes
-condenser- at the rear) by turning it 90° (as shown in the gure) to
prevent the condenser from touching the wall.
• The distance between the appliance and back wall must be a maximum
of 75 mm.
• For Side by Side niche installation please refer to the Joining Kit provided with the
cabinet freezer and its installation manual (NOTE joining kiti).
Before using your freezer
• When using your freezer for the rst time, or after transportation, keep it in
an upright position for at least 3 hours before plugging into the mains. This
allows e󰀩cient operation and prevents damage to the compressor.
• Your freezer may have a smell when it is operated for the rst time. This is normal and
the smell will fade away when your freezer starts to cool.
Internal lighting
WARNING!
Risk of electric shock.
• Concerning the lamp(s) inside this product and spare part lamps sold separately: These
lamps are intended to withstand extreme physical conditions in household appliances,
such as temperature, vibration, humidity, or are intended to signal information about
the operational status of the appliance. They are not intended to be used in other
applications and are not suitable for household room illumination.

EN - 11 -
Dimensions
3 the height, width and depth of the
appliance including the handle,
plus the space necessary for free
circulation of the cooling air, plus
the space necessary to allow
door opening to the minimum
angle permitting removal of all
internal equipment
Overall dimensions 1
H1 mm 1860
W1 mm 595
D1 mm 650
Space required in use 2
H2 mm 2010
W2 mm 695
D2 mm 688
1 the height, width and depth of the
appliance without the handle
2 the height, width and depth of the
appliance including the handle,
plus the space necessary for free
circulation of the cooling air
Overall space required in use
3
W3 mm 695
D3 mm 1241
W2
D2
W1
D1
D3
90o
W3
H1
H2

EN - 12 -
THE VARIOUS FUNCTION AND POSSIBILITIESPART - 2.
Information on No-Frost technology
No-frost freezers di󰀨er from other static freezers in their operating
principle.
In normal freezers, the humidity entering the freezer due to opening the
door and the humidity inherent in the food causes freezing in the freezer
compartment. To defrost the frost and ice in the freezer compartment,
you are periodically required to turn o󰀨 the freezer, place the food that
needs to be kept frozen in a separately cooled container and remove
the ice gathered in the freezer compartment.
The situation is completely di󰀨erent in no-frost freezers. Dry and cold air
is blown into the freezer compartment homogeneously and evenly from
several points via a blower fan. Cold air dispersed homogeneously and
evenly between the shelves cools all of your food equally and uniformly,
thus preventing humidity and freezing.
Therefore your no-frost freezer allows you ease of use, in addition to its
huge capacity and stylish appearance.

EN - 13 -
Display and Control Panel
Using the Control Panel
1. Freezer temperature set button
2. Super freeze symbol (Super freeze LED)
3. Alarm symbol (Alarm LED)
4. Freezer adjusted temperature indicator
Operating your Freezer
Alarm light
In case of a problem within the freezer, the alarm led will release red light.
Freezer Temperature Set Button
This button allows setting temperature of the freezer. In order to set values for freezer
partition, press this button. Use this button also to activate super freeze mode.
Super Freezer Mode
When Would It Be Used?
• To freeze huge quantities of food.
• To freeze fast food.
• To freeze food quickly.
• To store seasonal food for a long time.
How To Use?
• Press temperature set button until super freezing light comes on.
• Super freezing led will light during this mode.
• Maximum amount of fresh food (in kilograms) to be frozen within 24 hours is shown on
the appliance label.
• For optimal appliance performance in maximum freezer capacity, set the appliance to
active super freeze mode 24 hours before you put the fresh food into the freezer.
During This Mode:
If you press temperature set button, the mode will be cancelled and the setting will be
restored from -16.
Freezer Temperature Settings
• The initial temperature of the setting display is -18 °C.
• Press freezer setting button once.
• Every time you press the button, the setting temperature will decrease. (-16 °C, -18 °C,
-20 °C,.. super freezing)
1 2 3 4

EN - 14 -
• If you press freezer setting button until super freezer symbol is displayed on freezer.
• Settings display and you do not press any button within the following 3 seconds, super
freezing will blink.
• If you keep on pressing, it will restart from last value.
Recommended Temperature Values for Freezer
When to adjust Inner
Temperature
For minimum freezing capacity -16 oC
In normal usage -18 oC
For maximum freezing capacity -22 oC, -24 oC
Warnings about temperature adjustments
• It is not recommended that you operate your freezer in environments colder than 10°C
in terms of its efciency.
• Do not start another adjustment while you are already making an adjustment.
• Temperature adjustments should be made according to the frequency of door openings,
the quantity of food kept inside the freezer and the ambient temperature in the location
of your freezer.
• In order to allow your freezer to reach the operating temperature after being connected
to mains, do not open the door frequently or place large quantities of food in the freezer.
Please note that, depending on the ambient temperature, it may take 24 hours for your
freezer to reach the operating temperature.
• A 5 minute delay function is applied to prevent damage to the compressor of your freezer
when connecting or disconnecting to mains, or when an energy breakdown occurs. Your
freezer will begin to operate normally after 5 minutes.
• Your appliance is designed to operate in the ambient temperature (T/SN = 16°C -
43°C) intervals stated in the standards, according to the climate class displayed on the
information label. We do not recommend operating your appliance out of the stated
temperature limits in terms of cooling effectiveness.
Important installation instructions
This appliance is designed to work in difcult climate conditions (up to 43 degrees C or 110
degrees F) and is powered with ‘Freezer Shield’ technology which ensures that the frozen
food in the freezer will not defrost even if the ambient temperature falls as low as -15 °C.
So you may then install your appliance in an unheated room without having to worry about
frozen food in the freezer being spoilt. When the ambient temperature returns to normal, you
may continue using the appliance as usual.
Climate class Meaning Ambient Temperature
TTropical This refrigerating appliance is intended to be used at ambient
temperatures ranging from 16 °C to 43 °C.
ST Subtropical This refrigerating appliance is intended to be used at ambient
temperatures ranging from 16 °C to 38 °C.
NTemperate This refrigerating appliance is intended to be used at ambient
temperatures ranging from 16 °C to 32 °C.
SN Extended temperate This refrigerating appliance is intended to be used at ambient
temperatures ranging from 10 °C to 32 °C.

EN - 15 -
Accessories
Ice Tray
• Fill the ice tray with water and place in the freezer compartment.
• After the water has completely frozen, you can twist the tray as shown below to remove
the ice cubes.
(In some models)
The Icematic
• Pull the lever towards you and remove the
ice maker tray
• Fill with water to the marked level
• Hold the left end of the lever and set the
ice-tray on the icebox
• When ice cubes have formed, twist the
lever to drop the ice cubes into the icebox.
Do not ll the icebox with water in order
to make ice. It will break.
(In some models)
Visual and text descriptions in the accessories section may vary according
to the model of your appliance.
ARRANGING FOOD IN THE APPLIANCEPART - 3.
• The freezer is used for storing frozen food, freezing fresh food, and making ice cubes.
• For freezing fresh food; wrap and seal fresh food properly, that is the packaging should
be air tight and shouldn’t leak. Special freezer bags, aluminum foil polythene bags and
plastic containers are ideal.
• Do not store fresh food next to frozen food as it can thaw the frozen food.
• Before freezing fresh food, divide it into portions that can be consumed in one sitting.
• Consume thawed frozen food within a short period of time after defrosting
• Never place warm food in the freezer compartment as it will thaw the frozen food.
• Always follow the manufacturer's instructions on food packaging when storing frozen
food. If no information is provided food, should not be stored for more than 3 months
from the date of purchase.

EN - 16 -
• When purchasing frozen food, make sure that it has been stored under appropriate
conditions and that the packaging is not damaged.
• Frozen food should be transported in appropriate containers and placed in the freezer
as soon as possible.
• Do not purchase frozen food if the packaging shows signs of humidity and abnormal
swelling. It is probable that it has been stored at an unsuitable temperature and that the
contents have deteriorated.
• The storage life of frozen food depends on the room temperature, the thermostat
setting, how often the door is opened, the type of food, and the length of time required to
transport the product from the shop to your home. Always follow the instructions printed
on the packaging and never exceed the maximum storage life indicated.
• The maximum amount of fresh food (in kg) that can be frozen in 24 hours is indicated
on the appliance label.
• Use the fast freezing shelf to freeze home cooking (and any other food which needs to
be frozen quickly) more quickly because of the freezing shelf’s greater freezing power.
Fast freezing shelf is the bottom drawer of the freezer compartment.
If you would use maximum freezing capacity of your freezer:
• While freezing fresh foods, the maximum amount of fresh food (in kg) that can be frozen
in 24 hours is indicated on the appliance label.
• For optimum appliance performance to reach maximum freezing capacity, activate
Super Freeze (SF) mode 24 hours before placing fresh food into the freezer.
• After placing fresh food into the freezer, 24 hours is generally su󰀩cient for freezing.
”Super Freeze” mode will be deactivated automatically in 2-3 days to save energy.
If you would freeze a small amount (up to 3 kg) in your freezer:
• Place your food without touching already frozen food and activate “Fast Freezing”
mode. You can put your food next to other frozen food after it is completely frozen (after
minimum 24 hours).
• Do not re-freeze frozen food after it has thawed. This may cause health issues, such as
food poisoning.
• Allow hot food to completely cool down before placing it in the freezer.
• When buying frozen food ensure that these have been frozen at suitable temperatures
and that the packing is intact.
NOTE: If you attempt to open the freezer door immediately after closing it, you will nd that
it will not open easily. This is normal. Once equilibrium has been reached, the door will open
easily.
Important note:
• Never refreeze thawed frozen food.
• The taste of some spices found in cooked dishes (anise, basilica, watercress, vinegar,
assorted spices, ginger, garlic, onion, mustard, thyme, marjoram, black pepper, etc.)
changes and they assume a strong taste when they are stored for a long period of time.
Therefore, add small amounts of spices to food to be frozen, or the desired spice should
be added after the food has thawed.
• The storage time of food is dependent on the type of oil used. Suitable oils are margarine,
calf fat, olive oil and butter. Unsuitable oils are peanut oil and pig fat.

EN - 17 -
• Food in liquid form should be frozen in plastic cups and other food should be frozen in
plastic folios or bags.
The table below is a quick guide to show you the most e󰀩cient way to store the major
food groups in your freezer compartment.
Meat and sh Preparation Maximum storage time
(months)
Steak Wrap in foil 6 - 8
Lamb meat Wrap in foil 6 - 8
Veal roast Wrap in foil 6 - 8
Veal cubes In small pieces 6 - 8
Lamb cubes In pieces 4 - 8
Minced meat In packaging without using spices 1 - 3
Giblets (pieces) In pieces 1 - 3
Bologna sausage/salami Should be kept packaged even if it has a membrane
Chicken and turkey Wrap in foil 4 - 6
Goose and duck Wrap in foil 4 - 6
Deer, rabbit, wild boar In 2.5 kg portions or as llets 6 - 8
Freshwater sh
(Salmon, Carp, Crane,
Catsh)
After cleaning the bowels and scales of the sh,
wash and dry it. If necessary, remove the tail and
head.
2
Lean sh (Bass, Turbot,
Flounder) 4
Fatty shes (Tuna,
Mackerel, Bluesh,
Anchovy)
2 - 4
Shellsh Clean and in a bag 4 - 6
Caviar In its packaging, or in an aluminium or plastic
container 2 - 3
Snails In salty water, or in an aluminium or plastic container 3
NOTE: Thawed frozen meat should be cooked as fresh meat. If the meat is not cooked after defrosting, it
must not be re-frozen.
Vegetables and Fruits Preparation Maximum storage time
(months)
String beans and beans Wash, cut into small pieces and boil in water 10 - 13
Beans Hull, wash and boil in water 12
Cabbage Clean and boil in water 6 - 8
Carrot Clean, cut into slices and boil in water 12
Pepper Cut the stem, cut into two pieces, remove the core
and boil in water 8 - 10
Spinach Wash and boil in water 6 - 9
Cauliower Remove the leaves, cut the heart into pieces and
leave it in water with a little lemon juice for a while 10 - 12
Eggplant Cut into pieces of 2cm after washing 10 - 12

EN - 18 -
Vegetables and Fruits Preparation Maximum storage time
(months)
Corn Clean and pack with its stem or as sweet corn 12
Apple and pear Peel and slice 8 - 10
Apricot and Peach Cut into two pieces and remove the stone 4 - 6
Strawberry and
Blackberry Wash and hull 8 - 12
Cooked fruits Add 10 % of sugar to the container 12
Plum, cherry, sourberry Wash and hull the stems 8 - 12
Maximum storage time
(months)
Thawing time at room
temperature (hours)
Thawing time in oven
(minutes)
Bread 4 - 6 2 - 3 4-5 (220-225 °C)
Biscuits 3 - 6 1 - 1,5 5-8 (190-200 °C)
Pastry 1 - 3 2 - 3 5-10 (200-225 °C)
Pie 1 - 1,5 3 - 4 5-8 (190-200 °C)
Phyllo dough 2 - 3 1 - 1,5 5-8 (190-200 °C)
Pizza 2 - 3 2 - 4 15-20 (200 °C)
Dairy products Preparation Maximum storage time
(months) Storage conditions
Packet (Homogenized)
Milk In its own packet 2 - 3 Pure Milk – in its own packet
Cheese - excluding
white cheese In slices 6 - 8
Original packaging may be
used for short-term storage.
Keep wrapped in foil for
longer periods.
Butter, margarine In its packaging 6

EN - 19 -
CLEANING AND MAINTENANCE
Disconnect the unit from the power supply before cleaning.
Do not wash your appliance by pouring water on it.
Do not use abrasive products, detergents or soaps for cleaning the
appliance. After washing, rinse with clean water and dry carefully. When
you have nished cleaning, reconnect the plug to the mains supply with dry
hands.
• Make sure that no water enters the lamp housing and other electrical components.
• The appliance should be cleaned regularly using a solution of bicarbonate
of soda and lukewarm water.
• Clean the accessories separately by hand with soap and water.
Do not wash accessories in a dish washer.
• Clean the condenser with a brush at least twice a year.
This will help you to save on energy costs and increase
productivity.
The power supply must be disconnected during cleaning.
PART - 4.
Defrosting
• Your appliance performs automatic
defrosting. The water formed as a result
of defrosting passes through the water
collection spout, ows into the vaporisation
container behind your appliance and
evaporates there.
• Make sure you have disconnected the
plug of your appliance before cleaning the
vaporisation container.

EN - 20 -
• Remove the vaporisation container from its position by removing the screws as indicated.
Clean it with soapy water at specic time intervals. This will prevent odours from forming.
Replacing LED Lighting
Depending on the model, one LED strip in the
freezer is used to illuminate the interior of your
appliance.
To replace any of the LEDs, please contact the
nearest Authorised Service Centre.
Some versions may not include freezer
illumination.
LED strip
TRANSPORTATION AND CHANGING OF
INSTALLATION POSITION
PART - 5.
Transportation and Changing Positioning
• The original packaging and foam may be kept for re-transportation (optional).
• Fasten your appliance with thick packaging, bands or strong cords and follow the
instructions for transportation on the packaging.
• Remove all movable parts (drawers, Ice trays and so on) or
x them into the appliance against shocks using bands when
re-positioning or transporting.
Always carry your appliance in the upright position.
Repositioning the Door
• It is not possible to change the opening direction of your appliance door if door handles
are installed on the front surface of the appliance door.
• It is possible to change the opening direction of the door on models without handles.
• If the door-opening direction of your appliance can be changed, contact the nearest
Authorised Service Centre to change the opening direction.
