Zanussi ZWH6100 P User manual

ZWH6140 P
ZWH6120 P
ZWH6121 P
ZWH6100 P
ZWH6101 P
147214411
User manual ............................................... 2
Manual do Utilizador ................................... 24
Manual de instrucciones.............................. 46
!"#$%&'$()"%*+,-) .......................................... 68
Washing machine
Máquina de lavar
Lavadora
./012*%$()%(3"41
EL
EN
PT
ES

2
Contents
Safety information
In the interest of your safety and to
ensure the correct use, before installing
and first using the appliance, read this
user manual carefully, including its hints
and warnings.
Important!
To avoid unnecessary mistakes and
accidents, it is important to ensure that
all people using the appliance are
thoroughly familiar with its operation and
safety features.
Save these instructions and make sure
that they remain with the appliance if it is
moved or sold, so that everyone using it
through its life will be properly informed
on appliance use and safety.
General safety
It is dangerous to alter the specifications or
attempt to modify this product in anyway.
Wash small items such as socks, laces,
washable belts etc in a washing bag or
pillow case as it is possible for such items
to slip down between the tub and the inner
drum.
Do not use your washing machine to wash
articles with whalebones, material without
hems or torn material.
Always unplug the appliance and turn off
the water supply after use and before
cleaning or maintenance.
Under no circumstances should you attempt
to repair the machine yourself. Repairs
carried out by inexperienced persons may
cause injury or serious malfunctioning.
Contact your local Service Centre. Always
insist on genuine spare parts.
During high temperature wash program the
door glass may get hot. Do not touch it!
Make sure that small pets do not climb into
the drum. To avoid this, please check into
the drum before using the appliance.
Any objects such as coins, safety pins,
nails, screws, stones or any other hard,
sharp material can cause extensive damage
and must not be placed into the machine.
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless
they have been given supervision or
instruction concerning use of the appliance
by a person responsible for their safety.
Only use the advised quantities of fabric
softener and detergent. Damage to the
fabric can ensue if you overfill. Refer to the
manufacturer’s recommendations of
quantities.
Safety information .....................................
Environment concerns...............................
Product description...................................
Technical data...........................................
Installation.................................................
First use....................................................
Daily use...................................................
2
4
5
5
6
8
8
Control panel.............................................
Set your washing program.........................
International wash code symbols................
Programs informations...............................
Washing programs....................................
Care and cleaning.....................................
Something not working..............................
11
12
15
16
17
18
21
EN

3
Installation
This appliance is heavy. Care should be
taken when moving it.
When unpacking the appliance, check that
it is not damaged. If in doubt, do not use it
and contact the Service Centre.
All packing and transit bolts must be
removed before use. Serious damage can
occur to the product and to property if this
is not adhered to. See relevant section in
the user manual.
After having installed the appliance, check
that it is not standing on the inlet and drain
hose and the worktop is not pressing the
electrical supply cable.
If the machine is situated on a carpeted
floor, please adjust the feet in order to allow
air to circulate freely.
Always be sure, that there is no water
leakage from hoses and their connections
after the installation.
Any plumbing work required to install this
appliance should be carried out by a
qualified plumber.
Any electrical work required to install this
appliance should be carried out by a
qualified electrician.
This appliance is designed for domestic
use. It must not be used for purposes other
than those for which it was designed.
Only wash fabrics which are designed to be
machine washed. Follow the instructions on
each garment label.
Do not overload the appliance. See the
relevant section in the user manual.
Before washing, ensure that all pockets are
empty and buttons and zips are fastened.
Avoid washing frayed or torn articles and
treat stains such as paint, ink, rust, and
grass before washing. Underwired bras
must NOT be machine washed.
Garments which have been in contact with
volatile petroleum products should not be
machine washed. If volatile cleaning fluids
are used, care should be taken to ensure
that the fluid is removed from the garment
before placing in the machine.
Use
Never use the washing machine if the power
supply cable, the control panel, the working
surface or the base are damaged so that the
inside of the washing machine is accessible.
Never pull the power supply cable to remove
the plug from the socket; always take hold of
the plug itself.
This washing machine is not intended for
use by young children or infirm persons
without supervision.
Young children should be supervised to
ensure that they do not play with the
appliance.
The packaging components (e.g. plastic film,
polystyrene) can be dangerous to children -
danger of suffocation! Keep them out of
children’s reach
Make sure that children or pets do not climb
into the drum. To avoid this the machine
incorporates special feature.
To disable this device and restore the
possibility of closing the door, rotate the
button anti-clockwise until the groove is
vertical.
To activate this
device, rotate the
button (without
pressing it) inside
the door clockwise
until the groove is
horizontal. If
necessary use a
coin.
Keep all detergents in a safe place out of
children’s reach.
Child safety

Packaging materials
The materials marked with the symbol are
recyclable.
>PE<=polyethylene
>PS<=polystyrene
>PP<=polypropylene
Old machine
Ecological hints
This means that they can be recycled by
disposing of them properly in appropriate
collection containers.
Use authorised disposal sites for your old
appliance. Help to keep your country tidy!
To save water, energy and to help protect the
environment, we recommend that you follow
these tips:
Normally soiled laundry may be washed
without prewashing in order to save
detergent, water and time (the environment
is protected too!).
The machine works more economically if it is
fully loaded.
The symbol on the product or on its
packaging indicates that this product may not
be treated as household waste. Instead it shall
be handed over to the applicable collection
point for the recycling of electrical and
electronic equipment.
By ensuring this product is disposed of
correctly, you will help prevent potential
negative consequences for the environment
and human health, which could otherwise be
caused by inappropriate waste handling of this
product.
For more detailed information about recycling
of this product, please contact your local city
office, your household waste disposal service
or the shop where you purchased the product.
4
Environment concerns
With adequate pre-treatment, stains and
limited soiling can be removed; the laundry
can then be washed at a lower temperature.
Measure out detergent according to the
water hardness, the degree of soiling and the
quantity of laundry being washed.

4
3
2
1
Water Drain Hose
11
Door Opening Handle
4
Control Panel
3
Worktop
2
Detergent Dispenser Drawer
1
Drain Filter
5
8
6
12 Hose Holders
13 Back Feet
Water Inlet Hose
8
Front Feet
7
Rating Plate
6
Mains Cable
10
Drain Hose Support
9
12
11
10
9
713
5
5
Product description
Technical data
85 cm
60 cm
54 cm
Height
Width
Depth
0,8 MPa
0,05 MPa
Maximum
Minimum
Cottons
Synthetics
Delicates
Hand Wash
Maximum Load
Water supply pressure
Maximum
Spin Speed
ZWH 6101P
Dimensions
220-240 V/50 Hz
2000 W
10A
7.0 kg
2.5 kg
2.5 kg
2.0 kg
ZWH 6121P
1000 rpm1200 rpm
ZWH 6100PZWH 6120P
ZWH 6140P
1400 rpm
Power supply voltage/frequency
Total power absorbed
Minimum fuse protection

6
Installation
Unpacking
All transit bolts and packing must be
removed before using the appliance.
You are advised to keep all transit devices so
that they can be refitted if the machine ever has
to be transported again.
Important!
Very carefully
remove the front
polystyrene block
(B) by gently pulling
the polyethylene
bag (1) downwards
then (2) out,
ensuring not to tear
the bag (If fitted).
Using a spanner
unscrew and
remove the two rear
bottom screws.
Lay the machine
on its back
ensuring that the
hoses are not
crushed. Place
one of the
polystyrene angle
packings under
the machine.
Some models are provided with a bottom
cover that will be found inside the washing
machine drum. After ensuring the polyethylene
bags have been removed, follow below
instruction:
Remove the
polystyrene base,
set the machine
upright and unscrew
the remaining rear
screw. Slide out the
relevant pin.
Slide out the two
plastic pins.
Remove the
polystyrene block
(A) protecting the
motor (If fitted).
Locate the
bottom cover as
shown in
position (C).
(1).
Then push the
top end to lock to
the bottom of
washing machine.
(2).
Cover all the open
holes with the plugs
which you can find in
the bag containing
the instruction
booklet.
A
C
1
2
2
Positioning
Install the machine on a flat hard floor.
Make sure that air circulation around the
machine is not impeded by carpets, rugs etc.
Check that the machine does not touch the
wall or cupboard units.
1
2
B

This could be done by tying it to the tap with a
piece of string or attaching it to the wall.
In a sink drain pipe branch. This branch
must be above the trap so that the bend is
at least 60 cm above the ground.
Directly into a drain pipe at a height of not
less than 60 cm and not more than 90 cm.
The end of the drain hose must always be
ventilated, i.e. the inside diameter of the drain
pipe must be larger than the outside diameter of
the drain hose.
The drain hose must not be kinked. Run it along
the floor; only the part near the drainage point
must be raised.
In this case, make
sure the end cannot
come unhooked when
the machine is
emptying.
7
Connect the water inlet hose to a tap with
3/4” BSP thread.
Use the hose supplied with the washing
machine. DO NOT USE OLD HOSES.
The other end of the inlet hose which
connects to the machine can be turned in
any direction.
Simply loosen the fitting, rotate the hose and
retighten the fitting, making sure there are no
water leaks.
Water inlet
Never place cardboard, wood or similar
materials under the machine to compensate
for any unevenness in the floor.
Carefully level by
screwing the
adjustable feet
in or out.
The inlet hose must not be lengthened. If it is
too short and you do not wish to move the
tap, you will have to purchase a new, longer
hose specially designed for this type of use.
The end of the drain hose can be positioned in
three ways:
Hooked over the edge of a sink using the
plastic hose guide supplied with the
machine.
Water drainage
For the correct functioning of the machine
the drain hose must remain hooked on the
proper support piece situated on the top
part of back side of the appliance.
Electrical Connection
This machine is designed to operate on a
220-240 V, single-phase, 50 Hz supply.
“An incorrect power supply may void your
warranty.”
90 cm 60 cm

8
Check that your domestic electrical installation
can take the maximum load required (2.0 kW),
also taking into account any other appliances
in use. The manufacturer declines any responsibility
for damage or injury through failure to comply
with the above safety precaution. Should the
appliance power supply cable need to be
replaced, this should be carried out by our
Service Centre.
Connect the machine to an earthed socket.
Important!
Ensure that the electrical and water
connections comply with the installation
instructions.
Run a cotton cycle at 90 °C, without any
laundry in the machine, to remove any
manufacturing residue from the drum and
tub. Pour 1/2 a measure of detergent into
the dispenser drawer and start the machine.
First Use
Daily Use
Follow the wash code symbols on each
garment label and the manufacturer’s washing
instructions. Sort the laundry as follows: whites,
coloureds, synthetics, delicates, woollens.
Sorting the laundry
Button up pillowcases, close zip fasteners,
hooks and poppers. Tie any belts or long
tapes.
Rub particularly soiled areas with a special
detergent or detergent paste. Treat curtains
with special care. Remove hooks or tie them
up in a bag or net.
Never wash whites and coloureds together.
Whites may lose their “whiteness” in the
wash.
New coloured items may run in the first
wash; they should therefore be washed
separately the first time.
Remove persistent stains before washing.
Make sure that no metal objects are left
in the laundry (e.g. coins, hair clips,
safety pins, pins).
Before loading the laundry
Blood: treat fresh stains with cold water. For
dried stains, soak overnight in water with a
special detergent then rub in the soap and
water.
Oil based paint: moisten with benzine stain
remover, lay the garment on a soft cloth and
dab the stain; treat several times.
Dried grease stains: moisten with turpentine,
lay the garment on a soft surface and dab the
stain with the fingertips and a cotton cloth.
Stubborn stains may not be removed by just
water and detergent. It is therefore advisable to
treat them prior to washing.
Removing stains

Load the laundry
Place the laundry in
the drum, one item at
a time, shaking them
out as much as
possible. Close the
door.
Open the door by carefully pulling the door
handle outwards.
Recommended loads are indicated in the
program charts. General rules:
Washing a maximum load makes the most
efficient use of water and energy.For heavily
soiled laundry, reduce the load size.
Cotton, linen: drum full but not too tightly
packed;
Synthetics: drum no more than half full;
Delicate fabrics and woollens: drum no
more than one third full.
Maximum loads
Mould stains: treat with bleach, rinse well
(whites and fast coloureds only).
Grass: soap lightly and treat with bleach
(whites and fast coloureds only).
Ball point pen and glue: moisten with
acetone (*), lay the garment on a soft cloth and
dab the stain.
Lipstick: moisten with acetone (*) as above,
then treat stains with methylated spirits.
Remove any residual marks from white fabrics
with bleach.
The detergent and any additives must be
placed in the appropriate compartments of the
dispenser drawer before starting the wash
program.
If using concentrated powder or liquid
detergents, a program without prewash must
be selected.
Any fabric softener or starching additives must
be poured into the compartment marked “ ”
before starting the wash program.
Red wine: soak in water and detergent, rinse
and treat with acetic or citric acid, then rinse.
Treat any residual marks with bleach.
Ink: depending on the type of ink, moisten the
fabric first with acetone (*), then with acetic
acid; treat any residual marks on white fabrics
with bleach and then rinse thoroughly.
Good washing results also depend on the
choice of detergent and use of the correct
quantities to avoid waste and protect the
environment. Although biodegradable,
detergents contain substances which, in large
quantities, can upset the delicate balance of
nature.
The choice of detergent will depend on the type
of fabric (delicates, woollens, cottons, etc.), the
colour, washing temperature and degree of
soiling.
Only low suds Front load washer detergents
should be used in this appliance:
Detergents and additives
powder detergents for all types of fabric.
powder detergents for delicate fabrics (60
°C max) and woollens,
liquid detergents, preferably for low
temperature wash program (60 °C max) for
all types of fabric, or special for woollens
only.
Rust: oxalic acid dissolved in hot water or a
rust removing product used cold. Be careful
with rust stains which are not recent since the
cellulose structure will already have been
damaged and the fabric tends to hole.
Tar stains: first treat with stain remover,
methylated spirits or benzine, then rub with
detergent paste.
(*) do not use acetone on artificial silk.
9

Some models have Flexi Dose option
( ) which allow to use liquid or
powder detergent.
Follow the product manufacturer’s
recommendations on quantities to use and do
not exceed the MAX mark in the detergent
dispenser drawer.
The type and quantity of detergent will depend
on the type of fabric, load size, degree of soiling
and hardness of the water used.
Do not spray stain pre-treatment products
(e.g. Vanish) on or near the machine, as it
can attack plastic materials reducing its life.
Information on hardness of the water in your
area can be obtained from the relevant water
supply company, or from your local authority.
Follow the product manufacturers’ instructions
on quantities to use.
Water hardness is classified in so-called
“degrees” of hardness.
Quantity of detergent to be used
Not enough washing powder causes:
the washload to turn grey,
greasy clothes.
Too much washing powder causes:
sudsing,
reduced agitation and washing effect,
inadequate rinsing.
Use less detergent if:
you are washing a small load,
the laundry is lightly soiled,
large amounts of foam form during washing.
10
Compartment : this compartment is
only used for washing powder when a
program has Prewash or Stain.
Compartment : this compartment is used
for fabric conditioner and starching agent.
Compartment : this compartment is
used for washing powder or liquid.
Open the detergent dispenser drawer
The detergent
dispenser is
divided into three
compartments.
Aways add laundry detergents before switching
the machine on and keep the dispenser clean
and dry, so that the detergent can be efficiently
dispensed from the unit.
When using the washing machine for the first
time, check that the dispenser is set for the
type of detergent you will use.
Pull the dispenser drawer forward until it
stops.
Remove the drawer. Push the drawer edge
outwards where indicated by the arrow
(PUSH) to facilitate drawer removal.
Check the position of the flap at the “ ”
detergent compartment in the dispenser
drawer. (Factory setting is flap up for
powder.)
To do this, proceed as follows:
UP- Flap position if
using POWDER
detergent.
pressing the catch
downwards and by
pulling it out.
DOWN - Flap position
if using LIQUID
detergent.
Add the detergent
PUSH
REMOVE
TO CLEAN
PUSH
REMOVE
TO CLEAN

Clip the flap down if you are going to use
liquid detergent.
Refit the dispenser back into its runners.
11
Measure out the amount of detergent required,
pour it into the “main wash” compartment
“ ”.
Measure out the detergent and the
fabric softener
If required, pour fabric softener into the
compartment marked (the amount used
must not exceed the “MAX” mark in the
drawer).
If you wish to carry out the “prewash” phase,
pour it into the compartment marked “ ”.
for mainwash
for prewash
You are now ready to add detergent.
Close the drawer gently.
Remember:
If you change the type of detergent you use,
the position of the flap will need changing.
for softener
Program selector dial
Temperature button
Spin button
Quick wash button
Delay start button
Start/Pause button
Program progress display
1 2 3 4 65 7
Control panel
4
3
2
1
7
6
5

12
Set your washing program
Attention!
The selector dial is divided into following sections:
The selector dial can be turned either clockwise or
anticlockwise. Position “O” to Reset program/Switching
OFF the machine.
If you turn the program selector dial to another program
when the machine is working, the red Start/Pause ( ) pilot
light will flash 3 times to indicate a wrong selection. The
machine will not perform the new selected program.
At the end of the program the selector dial must be
turned to position “O”, to switch the machine off.
(Cottons)
(Cottons Prewash)
(Cottons Economy)
(Synthetics)
(Mixed Fabric)
(Delicates)
(Rinse)
(Drain)
(Spin)
(Easy Iron)
(Blanket)
(Mini 30)
(Jeans)
(Wool/Handwash)
(Cancelling/Off)
Program selector dial Turn the program selector dial to the required program. The
green Start/Pause ( ) light starts to flash.
Temperature Button ( ) Press this button repeatedly to increase or decrease the
temperature, if you want your laundry to be washed at a
temperature different from the one proposed by the
washing machine.
If a temperature is chosen that is not allowed with the
selected program, the red pilot light of the Start/pause
( ) button will flash 3 times.
* for more programs information see page 16.
Turn the selector dial to “O” to cancel a program which is
running. Now you can select a new program.
Cancelling a program
By selecting position (Cold) the machine will wash with
cold water. To be used for extremely delicate items,
such as curtains.

turn the program selector dial to “O”.
This option can be used for lightly soiled in order to obtain
a good washing result in a short time.
Quick Wash Buttons ( )
Rinse Hold ( ): by selecting this option the water of the
last rinse is not emptied out to prevent the fabrics from
creasing.
When the program has finished the pilot lights “End Cycle
( )” is on, the Start/Pause ( ) and the “Washing
( )” pilot light are off and the door is locked to indicate
that the water must be emptied out.
Auto Spin Reduction ( ): by selecting a programme,
reduce the spin speed if needed, by means of the
relevant button.
depress Start/Pause ( ) button.
at the end of program, only the pilot light End Cycle
( ) comes on.
select the Drain ( ) or Spin ( ) program.
To empty out the water:
The washing time will be reduced according to type of
fabric and the selected temperature.
13
Spin Buttons ( )
If an option is chosen that is not allowed with the selected
program, the red pilot light of the Start/Pause ( ) button
will flash 3 times.
set the washing machine to PAUSE by pressing the
Start/Pause ( ) button;
Before you start the program, if you wish to delay the
start, press the Delay Start button repeatedly, to select the
desired delay. The relevant light illuminates.
This option makes it possible to delay the starting of the
washing program by 3, 6, and 9 hours.
You must select this option after you have set the program
and before you press the Start/Pause button. You can
cancel the delay time at any moment, before you press the
Start/Pause button.
If you have already pressed the Start/Pause button, and you
wish to cancel the delay time, proceed as follows:
Select the Delay Start ( )
press the Delay Start ( ) button once, the light
relevant to the selected delay goes off.
press the Start/Pause ( ) button again to start the
programme.
the appliance proposes automatically the maximum spin
speed provided for that programme. By selecting Automatic
Spin reduction the spin speed is reduced to a half, but not
less than 400 rpm. The relevant light illuminates.

14
To select this option PRESS and HOLD the Spin ( )
and Quick Wash ( ) button together (This must be
selected after choosing the desired program
and before depressing the Start/Pause ( )
button) untill the pilot light is turn on.
Extra Rinse Option ( ) This option is recommended for people who are allergic to
detergents, and in areas where the water is very soft.
The machine performs some additional rinses.
The selected delay can be changed only after selecting
the washing program again.
The door will be locked throughout the delay time. If you
need to open the door, you must first set the washing
machine to PAUSE by pressing the Start/Pause ( )
button and then wait about 3 minutes.
Important!
After you have closed the door, press the Start/Pause
button again.
To start the selected program, press the “Start/Pause
( )” button; the corresponding green pilot light stops
flashing.
To interrupt a program which is running, depress the
“Start/Pause ( )” button: the corresponding green pilot
light starts to flash.
To restart the program from the point at which it was
interrupted, press the “Start/Pause ( )” button again.
If you have chosen a delayed start ( ), the machine will
begin the countdown.
The “Washing ( )” light is on to indicate that the appliance
starts operating and the door is locked.
Start/Pause button ( )
To turn the Extra Rinse option off press and hold the same
buttons until the pilot light goes off.
When the program has finished, the “ ” pilot light
comes on.
When the pilot light “ ” comes on this means that the
machine is performing the washing cycle.
Program progress display
When the pilot light “ ” comes on this means that the
The machine performs some additional rinses.
(Washing)
(Extra Rinse)
(End Cycle)

International wash code symbols
These symbols appear on fabric labels, in order to help you choose the best way to treat your laundry.
15
If you need to open the door, you must first set
the washing machine to PAUSE by pressing
the Start/Pause ( ) button, after that you
need to wait about 2-3 minutes to release
door lock.
It is possible to change any option before the
program carries it out. The option “Quick Wash
( )”cannot be modified after the Start/Pause
has been pressed.
Changing a running program is possible only
by resetting it. Turn the program selector dial
to “O” and then to the new program position.
The washing water in the tub not be emptied
out. Start the new program by depressing the
“Start/Pause ( )” button again.
Depress the “Start/Pause ( )” button to
interrupt a program which is running, the
corresponding light starts to flash. Depress the
button again to restart the program.
If the machine is already heating or the water
level is above the bottom edge of the door or
that the drum is turning. In this case the door
can not be opened.
If you can not open the door but you need to
open it you have to switch the machine off by
turning the selector dial to “O”. After about 3
minutes the door can be opened (pay attention
to the water level and temperature!).
Altering an option or a running program
Interrupting a program
Opening the door after the program
has started
Energetic wash
Delicate wash
95 °C 60 °C 40 °C 30 °C
Max.wash
temperature
Max.wash
temperature
Max.wash
temperature
Max.wash
temperature
Hand wash
at all
Bleaching hcaelbtonoDretawdlocnihcaelB
Ironing Hot iron max 200°C Warm iron max 150°C Lukewarm iron max 110°C Do not iron
Dry cleaning Dry cleaning
in all solvents
Dry cleaning in perchlorethylene,
petrol, pure alcohol, R 111 & R 113
Dry cleaning in petrol,
pure alcohol and R 113
Do not
dry clean
Drying Tumble dry
high
temperature
low
temperature
Do not
tumble dry
Do not wash

16
Programs informations
Washing programme for white and coloured cottons fabrics.
select this program if you wish your laundry to be prewashed at 30° C
before the main wash.
To reset a programme and to switch off the machine turn the selector dial
to “O”. Now, a new programme can be selected.
Washing programme for synthetic or mixed fabrics.
Washing programme for delicate fabrics.
select this program if you wish your laundry to be washed is slightly/
normally soiled cottons. This program will obtain good washing results
whilst saving energy.
Highly energy efficient cold wash programme for lightly soiled laundry.
This programme requires a detergent which is active in cold water.
Washing programme for machine washable wool as well as for hand
washable woollens and delicate fabrics with the “hand washing ” care
symbol.
With this programme it is possible to rinse and spin cotton garments which
have been washed by hand. The machine performs 3 rinses, followed by a
final spin at maximum speed. The spin speed can be reduced by pressing
Spin button.
For emptying out the water of the last rinse in programmes with the Rinse
Hold ( ) option. Turn first the programme selector dial to “O”, then select
programme Drain and press the Start/Pause button.
Separate spin for hand washed garments and after programmes with
Rinse Hold ( ) option. Before selecting this programme the selector dial
must be turned to “O”. You can choose the speed by means of the
relevant button to adapt it to the fabrics to be spun.
Selecting this programme the laundry is gently washed and spun to avoid
any creasing. In this way ironing is easier. Furthermore the machine will
perform some additional rinses. This programme can be used only for
cotton and synthetic fabrics.
Separate programme for lightly soiled synthetics, mixed fabrics and
delicates.
A gentle program designed for mixed fabrics found in delicate clothes.
Trousers, shirts or jackets in denim and jersey realized with hi-tech
materials. The Extra Rinse option is activated automatically.
(Cottons)
(Cottons
Prewash)
(Synthetics)
(Mixed Fabric)
(Delicates)
(Rinse)
(Drain)
(Spin)
(Easy Iron)
(Blanket)
(Mini 30)
(Wool/
Handwash)
(Cancelling/Off)
(Cottons
Economy)
(Jeans)

17
Washing programs
7.0
kg
7.0
kg
7.0
kg
7.0
kg
2.5
kg
2.5
kg
2.0
kg
Max.
Load
Cottons
COTTONS
Prewash
Economy
Synthetics
Mixed
Fabric
Delicates
Wool/
Handwash
White, coloured cotton
and linen (Normally
soiled items).: e.g. shirts,
underwear, towels.
White, coloured cotton
and linen (Heavy soiled
items).: e.g. sheets,
tablecloths, household
linen.
White, coloured cotton
and linen (slightly or
normally soiled cotton
items).: e.g. shirts,
blouses, underwear,
towels.
Synthetic or mixed fabrics
(Normally soiled items).:
e.g. underwear, coloured
garments, non-shrink
shirts, blouses.
Mixed fabrics (lightly
soiled laundry).
Delicate fabrics
(Normally soiled items).:
e.g. curtains, acrylics,
viscose, polyester.
Woollens and hand
washing fabrics.
Separate rinse cycle for
hand washed items of
cottons.
Main wash at
- 90° C
(1400 rpm for ZWH 6140P ;
1200 rpm for ZWH 6120P, 6121P ;
1000 rpm for ZWH 6100P, 6101P).
(Cold) -
90° C
Main wash at
- 90° C
(Cold) -
90° C
(Cold) - 60° C
(Cold) - 40° C
(Cold) - 40° C
(Cold)
40° - 60° C
Rinses
Long spin
Main wash at
- 60° C
Rinses
Long spin
Main wash at
40° - 60° C
Rinses
Long spin
Rinses
Long spin
Main wash at
- 40° C
Main wash at
- 40° C
Rinses
Short spin
Main wash at
(Cold)
Rinses
Long spin
Rinses
Long spin
Rinses
Long spin
Program/
Temperature
Description
of program
Options
Type of laundry
(1400 rpm for ZWH 6140P ;
1200 rpm for ZWH 6120P, 6121P ;
1000 rpm for ZWH 6100P, 6101P).
(1400 rpm for ZWH 6140P ;
1200 rpm for ZWH 6120P, 6121P ;
1000 rpm for ZWH 6100P, 6101P).
(1400 rpm for ZWH 6140P ;
1200 rpm for ZWH 6120P, 6121P ;
1000 rpm for ZWH 6100P, 6101P).
(1200 rpm for ZWH 6140P ;
1200 rpm for ZWH 6120P, 6121P ;
1000 rpm for ZWH 6100P, 6101P).
(1200 rpm for ZWH 6140P ;
1200 rpm for ZWH 6120P, 6121P ;
1000 rpm for ZWH 6100P, 6101P).
(700 rpm for ZWH 6140P ;
700 rpm for ZWH 6120P, 6121P ;
700 rpm for ZWH 6100P, 6101P).
(1200 rpm for ZWH 6140P ;
1200 rpm for ZWH 6120P, 6121P ;
1000 rpm for ZWH 6100P, 6101P).
Rinse
2.5
kg

You must DISCONNECT the appliance from the
electricity supply, before you can carry out any
cleaning or maintenance work.
The water we use normally contains lime. It is a
good idea to periodically use a water softening
powder in the machine. Do this separately from
any laundry washing, and according to the
softening powder manufacturer's instructions.
This will help to prevent the formation of lime
deposits.
Leave the door open for a while. This helps to
prevent mould and stagnant smells forming
inside the appliance. Keeping the door open
after a wash will also help to preserve the door
seal.
With the use of low temperature washes it is
possible to get a build up of residues inside
the drum. We recommend that a maintenance
wash be performed on a regular basis.
Descaling
After each wash
Maintenance Wash
18
* Cottons Economy at 60 °C is recommended for a full load of normally soiled cottons, and is
the water and energy rating label program (in accordance with CEE 92/75 standards).
Max.
Load
Program/
Temperature
Description
of program
Options
Type of laundry
Drain
For emptying out the
water left in the drum.
Not availableDrain of
water
7.0
kg
7.0
kg
7.0
kg
Spin
Blanket
Mini 30
Jeans
Separate spin program
for spin out the water
from clothes.
Cottons and synthetic
or mixed fabrics.
A gentle program
designed for mixed
fabrics found in delicate
clothes.
Synthetics and delicates
(lightly soiled items) or
which only needs
freshening up.
Trousers, shirts or
jackets in denim and
jersey realized with
hi-tech materials.
Drain
Long spin
2.5
kg
2.5
kg
2.5
kg
SPECIALS
Easy Iron
Rinses
Short spin
Main wash at
30° - 40° C
Rinses
Short spin
Main wash at
30° C
Rinses
Short spin
(Cold) -
60° C
(Cold) -
40° C
30° - 40° C
30° C
Main wash at
- 60° C
Main wash at
- 40° C
Rinses
Long spin
Care and cleaning
Important!
(1400 rpm for ZWH 6140P ;
1200 rpm for ZWH 6120P, 6121P ;
1000 rpm for ZWH 6100P, 6101P).
(900 rpm for ZWH 6140P ;
900 rpm for ZWH 6120P, 6121P ;
900 rpm for ZWH 6100P, 6101P).
(700 rpm for ZWH 6140P ;
700 rpm for ZWH 6120P, 6121P ;
700 rpm for ZWH 6100P, 6101P).
(700 rpm for ZWH 6140P ;
700 rpm for ZWH 6120P, 6121P ;
700 rpm for ZWH 6100P, 6101P).
(1200 rpm for ZWH 6140P ;
1200 rpm for ZWH 6120P, 6121P ;
1000 rpm for ZWH 6100P, 6101P).

19
The washing powder and additive dispenser
drawer should be cleaned regularly.
Flush it out under a tap, to remove any traces
of accumulated powder.
Remove the drawer
by pressing the
catch downwards
and by pulling it out.
To aid cleaning,
the top part of
the additive
compartment
should be
removed.
Having removed the drawer, use a small brush
to clean the recess, ensuring that all washing
powder residue is removed from the upper and
lower part of the recess.
Clean the exterior cabinet of the appliance with
soap and water only, and then dry thoroughly.
To run a maintenance wash:
External cleaning
Cleaning the dispenser drawer
Cleaning the drawer recess
The drum should be empty of laundry.
Select the hottest cotton wash program.
Use a normal measure of detergent, must be
a powder with biological properties.
use a small brush
to clean the recess.
Replace the drawer and run the rinse programme
without any clothes in the drum.
Drain filter collects lint and other items left in the
dirty laundry to prevent pump blockage
The pump must be cleaned regularly. To clean
the filter, proceed as follows:
Cleaning the drain filter
Turn programme selector dial to position Off
(O).
Unplug the appliance.
Open the door.
Turn the drum and align the filter cover
(FILTER) with the arrow on the door seal.
Open the filter cover by pressing the special
hook and by rotating the cover upwards.
Press here

20
Hold filter securly
and pull upwards to
remove it from its
position.
Remove eliminate the
eventual fluff or small
objects around the
filter.
Clean the filter under
the water tap.
Important!
The filter is inserted correctly when the
indicator on this top is visible and you
will hear “Click” sound.
After cleaning the
filter, open the filter
cover and insert the
filter back to its
position.
It is therefore a good idea to clean it from time
to time.
Cleaning the water inlet filter
If your water is very hard or contains traces of
lime deposit, the water inlet filter may become
clogged.
close the filter
cover.
insert the mains
plug again.
Do not start washing clothes without the
filter in its place.
Unscrew the water
inlet hose.
Turn off the water
tap.
Clean the filter
using a hard bristle
brush.
Tighten up the inlet
hose.
Important!
