1 Introduction

1.1 Document Scope

This document describes the SPA-PABXR-V2 PABX Recall Voice Recorder.

Item No.

Item Name

Product Description

3005010169

SPA-PABXR-V2

PABX Recall Voice Recorder

1.2 Publication Log

Revision

Date

Author

Status

1.0

28.10.2014

ETRONIC CSU-6 CO

documentation

1.1

5.10.2021

HKL

Published in Zenitel template

4SPA-PABXR-V2 PABX Recall Voice Recorder

2 SPA-PABXR-V2 PABX Recall Voice Recorder

The SPA-PABXR-V2 is a recall unit which can be connected to either the telephone network or a

trunk interface. Both connection possibilities have 3 program settings:

1. Let the Low Frequency (LF) signal pass directly through.

2. Play the message instantly when the line is on hook.

3. Play the message for 5 seconds after the line is on hook.

There is also the option of selecting 6 zones.

2.1 Application

Calling the applied number, the unit will automatically go off-hook. With trunk interface the unit will

go off-hook with a switch signal. The unit has a maximum recording time of 30 seconds. Recording

time is independent of the settings described below.

2.2 Audio Passes Directly Through

After the dial tone, the zone selection will be performed. Zone selection is done by sending a

DTMF tone that will be detected by the unit. When ‘0’ is pressed, all zones will be selected

automatically. Zone selection is terminated by pressing ‘#’. Hereafter the LF signal goes directly to

the speaker. If the unit is set for automatic zone selection, all zones will be activated, and the zone

selection procedure is ignored.

2.3 Audio Playback without Delay

After the dial tone the desired message can be recorded. The message length is limited to 30

seconds. After recording the message, ‘#’ is pressed for the selection of zones. When ‘0’ is

pressed, all zones will be selected automatically. The message will be played instantly when the

line is on-hook. If zone selection is not performed within 15 seconds, the unit will automatically set

the line to go on-hook. If the message is longer than 30 seconds, the unit will indicate with two

short tones and switch automatically over to zone selection.

If the unit is set to automatic zone selection, all zones will be activated after the line is on-hook.

2.4 Audio Playback with Delay

After the dial tone the desired message can be recorded. The message length is limited to 30

seconds. After recording the message, ‘#’ is pressed for the selection of zones. When ‘0’ is

pressed, all zones will be selected automatically. The message will be played 5 seconds after the

line is imposed. If zone selection is not performed within 15 seconds, the unit will automatically set

the line to go on-hook. If the message is longer than 30 seconds, the unit will indicate with two

short tones and switch automatically over to zone selection.

If the unit is set to automatic zone selection, all zones will be activated after the line is on-hook.

2.5 Detection of on Hook Line When Connected to Phone Line

After LF-signal ends, one from the central will detect incoming hook flash, recording tones or

pressed ‘*’ that equals on-hook. See electrical specifications for data.

SPA-PABXR-V2 PABX Recall Voice Recorder 5

3 Function Settings

3.1 DIP Switch ‘PROG’ Settings

Position

Function

ON: Calibration not necessary

OFF: The unit must be calibrated

Calibration is performed as follows:

Call the unit

Press # 9798

Hook on

Calibration takes approximately 10 seconds

ON: Automatic choice of all zones

OFF: Zones are chosen manually

ON: The message is played directly without recording

OFF: The message is recorded

ON: The message is played without delay

OFF: The message is played with a 5-second delay

Change of DIP switch settings requires a power off / power on of the unit.

3.2 Jumper ‘J1’ settings

Connecting to PSTN jumper ‘J1’ is moved to position ‘PSTN’.

Connecting to TRUNK ‘J1’ is moved to position ‘TRUNK’.

In trunk mode the unit can operate without an exchange. Connect an audio input and a potential

free switch (dry contact) for activation to X151. There is no individual zone selection in this mode.

3.3 Volume P1

With Potentiometer P1 it is possible to adjust audio output level.

6SPA-PABXR-V2 PABX Recall Voice Recorder

4 Electrical Specification

Supply Voltage: 24 VDC / 100mA +40% - 25%

Load of NO/NC contacts: max 250 VRMS / 170mA

Calling Voltage: 30-120 VEFF / 25 Hz ±2.5 Hz, 50 Hz ±5 Hz

Recorded Tone: 425 Hz ±25 Hz / –22 dBm – 0 dBm

DC Loop Current: 8 mA – IMAX (according to TBR 21, section 4.7.1: IMAX = 60mA)

4.1 Environment

Working Temperature: -15 °C to +55 °C

Humidity: 93% RH

SPA-PABXR-V2 PABX Recall Voice Recorder 7

5 SPA-PABXR-V2 Connections

5.1 Layout

5.2 X150 (Input/Output)

1 (Output)

Audio output

2 (Output)

Audio output

3 (Output)

Message playback indicator. Connected to unit Ground.

Ground

Power supply

Ground

7 (Output)

Zone 1. Activation signal.

8 (Output)

Zone 2. Activation signal.

9 (Output)

Zone 3. Activation signal.

10 (Output)

Zone 4. Activation signal.

11(Output)

Zone 5. Activation signal.

12 (Output)

Zone 6. Activation signal.

13 (Input)

Activation signal zone selection. It is possible to have your own activation

signal. Signal here will be outputted to zone selection 1-6 on X150 (position 7-

12). Load max. 250VAC/170mA.

EARTH

5.3 X151 (Bidirectional/Input)

Line a / Audio input

Line b / Audio input

3 (Input)

TI Switch. When in “TRUNK” mode use X151 (position 3+4) with a potential

free contact for activation. When released it will automatically play back the

message with delayed playback setting.

4 (Input)

TI Switch

8SPA-PABXR-V2 PABX Recall Voice Recorder

5.4 X152 (Output)

1, 2

Playback switch potential free contact. Load max. 250VAC/170mA.

5.5 X153 (Output)

1, 2

Zone 1 potential free contact. Load max. 250VAC/170mA.

3, 4

Zone 2 potential free contact. Load max. 250VAC/170mA.

5, 6

Zone 3 potential free contact. Load max. 250VAC/170mA.

7, 8

Zone 4 potential free contact. Load max. 250VAC/170mA.

9, 10

Zone 5 potential free contact. Load max. 250VAC/170mA.

11, 12

Zone 6 potential free contact. Load max. 250VAC/170mA.

5.6 X154 (Input)

1, 2

PAUSE input switch (potential free)

5.7 LEDs

REC

Indicates a recording is active

PLAY

Indicates a playback is active

Indicates current zone is active at playback. Zone 1.

Indicates current zone is active at playback. Zone 2.

Indicates current zone is active at playback. Zone 3.

Indicates current zone is active at playback. Zone 4.

Indicates current zone is active at playback. Zone 5.

Indicates current zone is active at playback. Zone 6.

SPA-PABXR-V2 PABX Recall Voice Recorder 9

6 Timing Specification for Off-Hook

6.1 Calling and Off-Hook

Afløftning

Indkobling af

øvrigt kredsløb

Indkobling af LF

output

Tlf. linie

OUTPUT

DETECT

= 40ms +/- 10ms (50Hz)

80ms +/- 20ms (25Hz)

=1 s

OUTPUT

= 150 ms

KLARTONE

Off-hook

Phone line

Engaging of

circuit

Engaging of

LF output

10 SPA-PABXR-V2 PABX Recall Voice Recorder

6.2 Detection of Recording Tone

busy tone

Tlf. linie

Afløftning

Indkobling af

øvrigt kredsløb

Indkobling af LF

output

tBUSY

tBUSY = 45 ms +/- 5 ms

6.3 Detection of Missing Loop Current

Afløftning

Indkobling af

øvrigt kredsløb

Indkobling af LF

output

Sløjfestrøm

NO_LOOP_CURRENT

= 0.4 ms +/- 0.1 ms

Off-hook

Phone line

Engaging of

circuit

Engaging of

LF output

Hook flash

Hook off

Engaging of

circuit

Engaging of

LF output
