52" DLPTM Integrated HDTV (Z52SZ80)
◗ 52" DLPTM Integrated HDTV
Our DLPTM HDTVs deliver brilliant picture and razor
sharp images
◗ 1500:1 High Contrast Ratio
Brings out subtle color differences and provides rich
detailed imagery.
◗ High Brightness
Renders an incredibly bright picture, even in
light-drenched environments.
◗ 1280 x 720 Resolution
High resolution format produces extremely
detailed imagery
◗ Hi-Res Component, S-Video, A/V and HDMI Inputs
Multiple inputs for DVD players, VCRs, computers
and video game systems
XT

Dimensions and weights are approximate. Design and specifications subject to change without notice.
© 2005 LG USA, Inc. Zenith and the “Z Bolt” are registered trademarks of Zenith Electronics Corporation.
Marketed and Distributed by LG Electronics U.S.A., Inc. 1000 Sylvan Avenue, Englewood Cliffs, NJ 07632
www.zenith.com 1-877-9-zenith
52" DLPTM Integrated HDTV (Z52SZ80)
Rev 06.20.05
VIDEO
Native Display Resolution 1280 x 720p
Contrast Ratio 1500:1
Brightness 450 cd/m2
Lamp Life 8,000 hours
Comb Filter 3D Y/C
Color Temperature Adjustment 3 Modes
Aspect Ratio Adjustment 7 Modes
3:2 Pull-down Cinema Correction 480i
EZ Video/Picture Selection Mode 6 modes
High Contrast Screen w/ Non-glare Coating •
Front Surface Mirror •
Screen Pitch 0.065mm
Decoder Formats MPEG2
CORE FEATURES
Tuner(s) ATSC/NTSC/QAM
AUDIO
Audio Output Power 30W (15W x 2)
Speaker System Details 2 Way 4 Speaker
Bass Reflex System •
Surround System Type SRS TruSurround XT
EZ SoundRite (Volume Leveler) •
EZ Sound/Sound Selection Mode 6 Modes
EZ Mute (sound/caption control) •
CABINET/ACCESSORIES
Cabinet Style Table Top
Cabinet Color Black
Remote Control Type Universal
SPECIAL FEATURES
Custom Input Labels •
Hide Input Function •
Discrete IR Codes •
Favorite Channel Selection/Surf •
Tri-lingual Menus English, Spanish, French
On/Off Timer •
Sleep Timer •
Auto Off (When no video is present) •
Flashback (Previous Channel) •
Parental Control With V-Chip •
EZ Menus (High Performance Interface) •
EZ Scan (Auto Programming) •
AUDIO/VIDEO INPUTS/OUTPUTS
TV Rear
- RF Inputs 2
- S-Video In 1
- Composite Video & Audio L/R In 2
- Composite Video & Audio L/R Out 1
- Component DVD/DTV
(480i, 480p, 720p, 1080i) & Audio L/R In 2
- RGB In (PC/DTV Input) 1
- RS-232c (Software Upgrade & Control) 1
- Variable Audio Out and Type RCA
- Optical Audio In 2
- Optical Audio Out 1
- HDMI 2
TV Side
- S-Video In 1
- Composite Video & Audio L/R In 1
DIMENSIONS
Cabinet Dimensions
- Width x Height x Depth 47.5” x 33.6” x 16.1”
- Weight Out of Package 83.3 lbs.
Dimensions with Packaging
- Width x Height x Depth 52.8” x 37.5” x 19.8”
- Weight In Package 94.0 lbs.
UPC 044642701987
Warranty 1 year parts/labor
Remote Control Functions in TV Mode
123
456
789
0
TV
MODE LIGHTPOWER
TV/VIDEO DVI
RGB
VCR
CABLE
DVD SAT
MUTE
SWAPPIPCH- PIPCH+
PIP
RATIO
RECORD
STOP
PAUSE
REW
PLAY
FF
MENU EXIT
CC FREEZE
PIP INPUT
VOL CH
SURF
SAP VIDEO
COMP2COMP1
SIDE
SKIP
ENTER
FLASHBK
TV Rear
TV Side
AUDIO
DVD / DTV INPUT
(R) (L) Pr Pb Y
AUDIO
(R) (L) Pr Pb Y
COMPONENT
INPUT 2
COMPONENT
INPUT 1
ANTENNA
+75 |
MONITOR
OUT
VIDEO
INPUT 1
VIDEO
INPUT 2
S-VIDEO
INPUT
RS-232c
(480i, 480p, 720p, 1080i)
AUDIO
(R) (L)
VARIABLE
AUDIO
AUDIO
(R) (L)
VIDEO
RGB IN
(PC/DTV INPUT)
AUDIO
(R) (L)
RGB/DVI
INPUT
HDMI 1/DVI
HDMI 2
OPTICAL
OUTPUT
OPTICAL INPUT 1
(COMPONENT2)
OPTICAL INPUT 2
(DVI)
DIGITAL AUDIO
OPTICAL
CABLE
+75 |
(L) - AUDIO - (R)
VIDEO
S-VIDEO
