ZhongWang Electronic ZT-830T User manual
MODEL
ZT-830T
PAGE:
1OF4
PRODUCT
INSTRUCTION DESCRIPTION
Wireless Camera
ZT-830T
WIRELESS CAMERAUSER SMANUAL
REVISIONS DESCRIPTION DATE DESIGN
SHENZHENZHONGWANG ELECTRONCO., LTD
APPROVAL
PAGES
TOTAL
FILE
NUMBER ISSUEDATE CHECK
4 DESIGN
FILENUMBER
MODEL ZT-830T PAGES:2OF4
Operation instruction
1.Connectingthe receiverantenna. (Figure1)
2.Connectingthe 9V/12Vdirect current stabilizer(Figure2), pilot lamplighting(Figure3).
3.Connectingthe audioandvideo (figure4)outputwiththe inputtothe monitor,the television
shouldbeset on A/Vmodel.
4.Connectingthe audioand video output withthe input ofthe transmitter.
5.Plugpowerjack ofDC powersupply(8V ，300mA)intothe powersocketofthe CMOS
camera(figure6).(Batteryofthe samevoltageisacceptable.)
6.Turningthemicro-adjustmentknob(figure5)on the receivertill receivingthe pictureofthe
wireless camera.
7.Fine tune tothe desireposition till the imageofCMOScameraisreceived.
8.Adjust the lensofthe CMOScamera(figure7)tobest position.
Notice
1.Themachine issupplied withmanydifferenttypes,pleaseprovide withelectricpoweraccording
the value on the label.
2.Obstructsbythe buildingand soon will causeattenuation.
3.Normallythat the machine will slightlywarmupduringoperation.
4.Shouldanyothermalfunctionsoccur, pleasecontact localdistributor.
5.Undernormaloperationalconditions,oneyear swarrantyisgranted.iftherearequalityproblems
within3months, thiscompanywill unconditionallyreplacewithanewcamera.
6.Pleasepowerdownwhen charge.
Waning
Thisproductisforthe solepurposeofsecurityand applicableformonitoringin
residentialhouses,shopsand companies.Theusershall observelocalrules,regulationsandlaws,
and shall besolelyliableinthisregard.Thiscompanyshall not beliableforanyillegalitiestherein
SHENZHENZHONGWANG ELECTRONCO., LTD TEL +86-755-8336 1499
FAX +86-755-8336 1433
http://www.ztv.cc
FCC Information
Thisdevicecomplieswithpart15oftheFCCRules,Operation
issubjecttothefollowingtwoconditions:(1)Thisdevice
maynotcauseharmfulinterference,and (2)Thisdevice mustacceptanyinterference
received,includinginterference that
maycauseundesiredoperation.
CAUTION: Changesormodificationsnot expre
sslyapprovedbySummerinfant mayvoidtheusersauthoritytooperatethis
equipment.
NOTE:Thisequipmenthasbeentestedand foundtocomplywiththelimitsforaClassBdigitaldevice,pursuanttopart15of
theFCC Rules.
Theselimitsaredesignedtoprovidereasonableprotectionagainst
harmfulinterference inaresidentialinstallation.This
equipmentgenerates,usesand canradiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththe
instructions,maycauseharmfulinterferencetoradiocommunications,However,thereisnoguaranteethatinterference
will
notoccurinaparticularinstallation.Ifthisequipmentdoescauseharmfulinterference toradioortelevisionreception,which
canbedeterminedbyturningtheequipment
offand on,theuserisencouragedtotrytocorrecttheinterferencebyoneor
moreofthefollowingmeasures:
l Reorient orrelocatethereceivingantenna
l Increasetheseparationbetweentheequipment and thereceiver
l Consult thedealeroranexperiencedradio/ TVtechnicianforhelp.
FILENUMBER MODEL ZT-830T PAGES:3OF4
TechnicalData
ITEM TYPE
Transmission
Frequency 2.414~2.468GHz4cH
Electricpower:DC 5V
Output power <10mW
Video input: 1.0VP-P(MAX)
Powerconsumption current80mA
Audioinput: 2VP-P(Max.)
Effectiverange (no obstacles) 30m
CMOS
IMAGESENSOR 1/3-inchCMOSImageSensor
CMOSTOTALPIXELS 628*582
SYNC SYSTEM INTEMAL
MINIMUMILLUMINATION 1LμxF1.25600°K
RESOLUTION 330TVLine
Mode:AWB(Zerocolorrolling)
WHITEBALANCE
Range:3200~10000°K
GAINCONTROL AGC
S/NRATIO 48dB(Min)/60dB(TYP)(AGCOFF)
ELECTRONICSHUTTER 1/60~1/15,000sec
CAMMACORRECTION 0.45
OPERATIONTEMPERATURE -20℃~60℃
OPERATIONHUMIDITY 85%RH
SHENZHENZHONGWANG ELECTRONCO.,LTD TEL +86-755-8336 1499
FAX +86-755-8336 1433
http://www.ztv.cc
