ZoneAlarm Z100G User manual

©2006 Check Point Software Technologies Ltd. All rights reserved. Check Point, the Check Point logo, ZoneAlarm, ZoneAlarm Internet Security Suite, Zone Labs, and the Zone
Labs logo are trademarks or registered trademarks of Check Point Software Technologies Ltd. or its affiliates. SofaWare is a registered trademark of SofaWare Technologies Ltd.
All other product names mentioned herein are trademarks or registered trademarks of their respective owners.
120-4840-6.0
Secure Wireless Router
Z1 00 G
Helpful Information on
Installation and Set-Up
Getting Started
Guide

2
Thank you for purchasing ZoneAlarm®Secure
Wireless Router Z100G, the first complete
security solution for home networks.
This Getting Started Guide will help you understand and effectively use ZoneAlarm®Secure Wireless Router
Z100G. We’ve made the product simple to set up and provide you with step-by-step instructions.
Table of Contents
Overview ............................................................................................................................. 3
What do you need in order to begin the installation?....................................................... 3
Section One: Getting Started............................................................................................. 3
Part 1: Connecting the Antennas ................................................................................... 3
Part 2: Power Up Your ZoneAlarm Secure Wireless Router Z100G ............................. 3
Part 3: Connect Your Network........................................................................................4
Part 4: Configure Your PCs............................................................................................. 5
Section Two: Setup Wizard ................................................................................................ 6
Part 1: Starting the Wizard ............................................................................................. 6
Part 2: Connect to the Internet....................................................................................... 7
Part 3: Setting Time and Date ...................................................................................... 13
Part 4: Configuring Your Secure Wireless Network..................................................... 14
Part 5: Changing the Product Key ............................................................................... 16
Section Three: Subscription Security Services............................................................... 18
Part 1: Activate Your ZoneAlarm®Secure Wireless Router Z100G.............................18
Part 2: Connecting to a Service Center ....................................................................... 19
Section Four: Additional Feature Configuration ............................................................. 22
Part 1: Setting Up Network Antivirus Protection......................................................... 22
Part 2: Configuring Your Network Security Level ........................................................ 24
Part 3: Configuring SmartDefense™Security Settings ................................................ 25
Part 4: Printer Sharing Setup........................................................................................ 27
Section Five: Configure a Computer to Connect to the Wireless Network ................... 34
Section Six: Software Updates and Technical Support.................................................. 35

3
Overview
ZoneAlarm®Secure Wireless Router Z100G is the first comprehensive security solution for home networks.
Developed and supported by SofaWare Technologies, an affiliate of Check Point Software Technologies, the
worldwide leader in securing the Internet, ZoneAlarm®Secure Wireless Router Z100G incorporates the same
powerful Check Point®security technology chosen by 98% of the Fortune 500 companies. It features a fire-
wall, a customizable antivirus gateway, an integrated print server, intrusion prevention, Super G 108 Mbps
speed, extended wireless range, and a high-performance, remote wireless access point.
Package Contents
The ZoneAlarm®Secure Wireless Router Z100G package includes the following:
•Black ZoneAlarm®Secure
Wireless Router Z100G
• Two black antennas
• Power adapter
• Orange Ethernet cable
• Gray USB extension cable
•Wall-mounting kit, including two plastic
conical anchors and two crosshead screws
•Getting Started Guide
• Additional documentation CD-ROM
(e.g., User Guide) with 15-day trial version
of ZoneAlarm Internet Security Suite
•End-User License Agreement
What do you need in order to begin the installation?
•A cable or DSL modem and Internet
connection.
•A computer with a wired NIC (Network
Interface Card) to be used for initial
configuration.
•A Web browser. Internet Explorer®5.0
or higher or Mozilla FireFox®1.0 or
higher are recommended.
•Wired or wireless NIC installed on each
computer you want to connect to the
network.
Section One: Getting Started
Part 1: Connecting the Antennas
•Carefully screw the two supplied antennas onto the antenna connectors marked ANT1 and ANT2 on the
ZoneAlarm®Secure Wireless Router Z100G rear panel.
•Bend the antennas at the hinges, so that they point upwards.
Part 2: Power Up Your ZoneAlarm Secure Wireless Router Z100G
• Connect the power adapter to the PWR port on the ZoneAlarm®Secure Wireless Router Z100G appliance
rear panel, and then plug the adapter into a power outlet.
• The PWR/SEC LED on the front panel will start flashing, indicating that your ZoneAlarm®Secure Wireless
Router Z100G is now on.

4
Part 3: Connect Your Network
•Connect one end of the network cable provided with your ZoneAlarm®Secure Wireless Router Z100G to
the WAN port on the appliance rear panel, and connect the other end to your cable or DSL modem, as
shown in the figure below.
•Make sure your DSL or cable modem is powered on.
•The WAN LED will light up, indicating proper connection to your modem.
•Connect one end of your network cable to one of the four LAN ports, and connect the other end to your
PC. If you have additional PCs or other network devices you wish to connect with a cable, you can con-
nect them to the LAN ports.
•A corresponding LAN LED will light up, indicating each connected computer.

5
Part 4: Configure Your PCs
Before continuing, make sure all your PCs are configured correctly.
For Windows®XP Operating Systems:
•Open the Control Panel window by clicking , choosing Settings, and then
choosing Control Panel.
•Select Network and Internet Connections, double click to open.
•Select Local Area Connection, double click to open.
•Select Properties.
Select Obtain an IP address
automatically.
Select Obtain DNS Server address
automatically.
Select OK and then close.
If prompted to restart your PC, click Yes. Restart your DSL or Cable Modem.
Note: The configuration process varies between operating systems. If you are using a Macintosh or another
operating system, please consult the ZoneAlarm Secure Wireless Router Z100G User Guide provided on the
enclosed CD-ROM.
Select Internet Protocol (TCP/IP).
Select Properties.

6
Section Two: Setup Wizard
Part 1: Starting the Wizard
•Go to http://my.firewall
• Choose an administrator password. It is important to select a hard to guess password that includes both
letters and numerical characters.
• Choose an administrator password. Type in both password fields.
• Click OK.
The setup wizard will appear automatically the first time you access the http://my.firewall interface, after
choosing an administrator password. It will guide you through the basic configuration procedures. You can run
the setup wizard again any time by choosing Setup from the menu in the my.firewall interface, and clicking the
ZoneAlarm®Secure Wireless Router Z100G Setup Wizard button.
• Click Next.

7
Part 2: Connect to the Internet
The first part of the setup wizard guides you through the configuration of your Internet connection. Before
proceeding, make sure no computers are currently using your Internet connection and that the ZoneAlarm®
Secure Wireless Router Z100G is the only device connected to your modem.
Step 1: Select your Internet connection method.
Note: If you are not certain what type of connection to choose, contact your Internet Service Provider.
Option 1: PPPoE Connection
• Select PPPoE.
• Click Next.
• Fill out the form with the login information provided to you by your Internet Service Provider (ISP).

8
Type in your username
(as provided by your ISP)
Type in your password
(as provided by your ISP)
Retype your password
If you do not have all the information required to fill out this form, please contact
your Internet Service Provider (ISP).
• Click Next.
• Proceed to Step 2 (Page 12).
Option 2: PPTP Connection
• Select PPTP.
• Click Next.

9
If you do not have all the information required to fill out this form, please contact your
Internet Service Provider (ISP).
• Click Next.
• Proceed to Step 2 (Page 12).
Option 3: Cable Modem Connection
• Select Cable Modem.
• Click Next.
•Proceed to Step 2 (Page 12).
Type in your username
(as provided by your ISP)
Type in your password
(as provided by your ISP)
Retype your password
Type your Service Name
(as provided by your ISP)
Type the IP address of the
PPTP modem
Type the local IP address
required for accessing
The subnet mask of the
PPTP modem
Fill out the form with the login information provided to you by your Internet Service Provider (ISP).

10
Option 4: Static IP Connection
• Select Static IP.
• Click Next.
Fill out the form with the login information provided to you by your Internet Service Provider (ISP).
The static IP address pro-
vided to you by your ISP.
Select the subnet mask
that applies to the static IP
address provided to you by
your ISP.
The IP address of the
Default Gateway as pro-
vided to you by your ISP.
The Primary DNS Server IP
address.
The Secondary DNS server
IP address (this field is
optional)
The WINS server IP address
(this field is optional)
If you do not have all the information required to fill out this form, please contact
your Internet Service Provider (ISP).
• Click Next.
• Proceed to Step 2 (Page 12).

11
Option 5: DHCP (Dynamic IP) connection
•No further settings are required.
• Select DCHP.
• Click Next.
• Proceed to Step 2 (Page 12).

12
Step 2: Connection Settings Confirmation
Review the connection settings and click Next. If the settings appear incorrect, click Back
and correct the configuration.
Step 3: Establishing Connection
ZoneAlarm®Secure Wireless Router Z100G will now attempt to connect to the Internet with
the selected connectivity method and login information.
Upon a successful connection, a finish screen appears.
• Click Next.
Your ZoneAlarm®Secure Wireless Router Z100G gateway is now connected to the Internet.

13
Part 3: Setting Time and Date
Setting the correct time and date on your ZoneAlarm®Secure Wireless Router Z100G will ensure the event log
provides you with the correct event time and remote access VPN connections function properly.
Make sure the date and time on your computer are set correctly and then select Your Computer’s Clock.
• Click Next.
• Click Next.

14
Part 4: Configuring Your Secure Wireless Network
The setup wizard allows you to configure all the required settings for your wireless connection, including secu-
rity parameters. For more information on the options available, please see page 97 in the ZoneAlarm®Secure
Wireless Router Z100G User Guide provided on the enclosed CD-ROM.
Step 1: Wireless Network Configuration
• Click Next.
Step 2: Wireless Security Configuration
Choose Enable Wireless
networking to activate your
wireless network
Type a name for your net-
work, up to 32 characters.
You may use letters and
numeric characters.
For example: “SmithFamily”
Choose your country
Choose 802.11g Super
(11/54/108)
Choose Automatic
• Choose WPA-Personal.
Note: WPA-Personal is the recommended method of encryption for home and home office wireless networks.
To learn about other wireless encryption methods, please refer to page 98 in the ZoneAlarm Secure Wireless
Router Z100G User Guide provided on the enclosed CD-ROM.
• Click Next.

15
Select a hard to guess phrase 8-63 characters long. It is recommended you use both letters and digits. For
example: “Live Long and Prosper 1701”. Note: You can use blanks and the pass-phrase is case-sensitive.
• Click Next.
Step 3: Wireless Connection Settings Confirmation
Review the wireless security settings and click Next. If the settings appear incorrect, click Back
and correct the configuration
• Click Next.
Your secure wireless network is now active. To learn how to connect your PCs and other network devices
to the wireless network, please see Section Five in this guide.
Enter your pass-phrase here.
Click here to create a random-
ized pass-phrase automatically.

16
Part 5: Changing the Product Key
Unless otherwise instructed when purchasing your ZoneAlarm®Secure Wireless Router Z100G, there is no
need to change the product key of your appliance, and you may skip this part of the wizard.
Choose Keep these Settings.
• Click Next.
• Click Next.

17
Connecting to a service center allows you to receive software and security updates as well as value-added
security services. If the service center login information was already supplied to you by your Internet Service
Provider or Network Security Service Provider, please proceed to Connecting to a Service Center, Section
Three, Part 2 in this guide. Otherwise, deselect Connect to a Service Center.
• Click Next.
• Click Finish.
Congratulations!
You have completed the basic installation and configuration process of your ZoneAlarm®Secure Wireless
Router Z100G. It is now ready to securely connect your PCs to the Internet.

18
Section Three: Subscription Security Services
In order to receive comprehensive security services for your ZoneAlarm®Secure Wireless Router Z100G such
as antivirus and security updates, you need to activate your subscription and connect to a service center.
Part 1: Activate Your ZoneAlarm®Secure Wireless Router Z100G
In case the value-added services are provided to you by your Internet Service Provider or Network Security
Service Provider, proceed to Step 2 (page 19).
• Go to http://my.firewall and log in with the administrator username and password.
• In the welcome screen, locate your MAC address and your purchase code. These are required in order to
activate your free subscription.
To activate your subscription:
Make sure you are connected to the Internet and click on Activate Your Free Subscription.
• Fill out the form.
• Click Send.
A confirmation screen appears to approve the form has been sent.
Type your email.
Choose your country from the list.
Choose your state from the list.
Enter your MAC address.
Type your full name.
Type your phone number.
Enter your purchase code.
An e-mail will be sent to the e-mail
address you filled in the form, with
your login information.

19
Part 2: Connecting to a Service Center
Upon receiving your service center login information, proceed with your service center connection.
Step 1: Opening the Service Center Connection Wizard
Go to http://my.firewall and log in with the administrator username and password and click on Services in the
left hand menu.
• Click Connect.
Step 2: Choosing a Service Center
• Choose Connect to a Service Center.
Choose Connect to a Service Center

20
Type your gateway ID and registration key, and click Next.
If this form appears and you do not have all the information required to fill out it, please contact your Internet
Service Provider (ISP) or your Network Security Service Provider.
• Proceed to Step 3.
In case you followed the instructions in Step 1, choose zone.sofaware.com.
• Click Next.
• Proceed to Step 3.
In case the value-added services are provided to you by your Internet Service Provider or Network Security
Service Provider, choose Specified IP and type the IP as provided by the Service Provider.
• Click Next.
