zSpace 300 User manual

zspace.com zSpace 300 User’s Guide
770-00014-01 Rev B
zSpace for
Education
Model 300 User’s Guide

zSpace is a registered trademark of zSpace, Inc. All other trademarks are the property of their respective
owners.
© zSpace, Inc. 2015

visit us online at zpace.com
Contents
The zSpace System 1
Contents of the zSpace Box 1
Parts of Your zSpace 2
Side Panel 4
Rear Panel 5
Power 5
How zSpace Works 7
Head-Tracked Stereoscopic Display 7
Stylus Interaction 7
Using 3D in zSpace 8
Adjustable Angle 8
Setting Up your zSpace 9
Hardware 9
System Software 10
Firmware 11
Customizing your zSpace 12
Applications for your zSpace 13
Installing and Updating Applications 13
Launching Applications 14
Using zSpace STEM Applications 14
Safety Instructions 15
Usage 15
Basic Operation 16
Environment 16
Physiological Effects 16
Caring for zSpace 16
Replacing the Battery 17
Troubleshooting 18
Recycling (WEEE) and RoHS 19
Appendix A: Specifications 20
Appendix B: Certifications 21
Appendix C: Limited Warranty 23

zspace.com
The zSpace System
Congratulations on your purchase of the zSpace, which is an all-in-one system including the monitor and
computer in a single unit. This guide reviews the features, setup process, and basic usage information.
Contents of the zSpace Box
zSpace model 300
Stylus
Mouse and keyboard
1 Pair 3D glasses
1 Pair 3D clip-ons
1 Pair 2D glasses (for observers)
1 Power supply for zSpace display
1 Quickstart guide

zspace.com
Parts of Your zSpace
zSpace System Components
Eyewear
In order to use your zSpace in stereoscopic mode (3D), you need to wear the 3D eyewear. This eyewear includes
small reflectors, which the tracking cameras use to identify your head position.
3D Glasses with Reflectors

zspace.com
Your zSpace also includes a pair of 2D glasses without the tracking reflectors. A secondary observer can wear
these and share your experience in 2D without interfering with the tracking.
Stylus
You can use the stylus to interact with 3D applications using six degrees of freedom of motion. Six degrees of
freedom refers to the stylus’s full range of motion in three-dimensional space. A mouse is limited to two
coordinates on a flat plane.
You use the stylus buttons to select UI controls and interact with objects in the scene.
Stylus
Tracking Cameras
The tracking cameras help 3D applications provide a realistic, immersive experience. The application adjusts the
viewpoint as you move your head, just as the view changes “in real life.”
These cameras are necessary for the stylus and head tracking to work. When they are active, you can see red
lights. Please do not block the cameras.
Touchscreen
You can use one or two fingers to control any 2D or 3D application, wherever you can use a mouse. You can also
use the stylus for touchscreen input in 2D applications.
Mouse and Keyboard
The system includes a wired USB 1.1 mouse and keyboard. You can use the mouse and keyboard with both
traditional 2D applications and with 3D applications that support mouse and keyboard input.

zspace.com
Webcam
The webcam is part of the zSpace. You can use this for chatting or video conferencing.
Note: This webcam will not capture images on the display for zView because it is facing you, not the screen.
Integrated Stand
To adjust the angle, hold the easel leg with one hand and the top handle with the other. Adjust the easel leg
carefully to the desired angle. For best results, we suggest an angle between 30 and 65 degrees.
Warning: Be careful to set the angle so the zSpace is stable and does not fall over. This could damage the
zSpace or cause injury.
Side Panel
The side of the zSpace has two upper USB 2.0 ports, two lower USB 3.0 ports, and an audio input/output port.
We recommend you use the USB 2.0 ports for the mouse and keyboard. You can use the audio port with 3.5 mm
input devices for mono headphones, stereo headphones, or mono/stereo headphones with microphone.
The Side of the zSpace

zspace.com
Rear Panel
The rear panel has a port for the stylus, the power supply, an HDMI port, a USB 2.0 port, and an Ethernet
connection.
The Back of the zSpace
Power
The power button is on the top of the zSpace.
Power Button

zspace.com
The zSpace uses Windows Power Management Tools. By default, the display will turn off after 15 minutes and
the computer will enter sleep mode after 30 minutes. To resume from sleep mode, press the Enter key or the
power button.
To adjust the power settings, use the Windows Control Panel’s Power Options menu.
Note: The default power settings have been selected for compliance with ENERGY STAR.

zspace.com
How zSpace Works
zSpace has many features to enable a compelling user experience.
Head-Tracked Stereoscopic Display
The head-tracked display enables the zSpace to display the left and right images for a stereoscopic display. The
images adjust as your eyes move within the tracking zone. This capability ensures a comfortable virtual
experience.
Stylus Interaction
The tracking cameras enable the stylus to interact with virtual items anywhere within the tracking zone.
zSpace Tracking Zone

zspace.com
Using 3D in zSpace
To use zSpace with 3D applications, put on the 3D glasses and pick up the stylus.
Use the center button on the stylus to select icons and menu options and interact with objects in the scene.
Tip: Move the stylus over the objects in the application. Depending on the application, some objects may
highlight or the stylus might buzz when the stylus beam touches the object. These are objects you can select and
move.
Adjustable Angle
You can adjust the zSpace angle to increase your viewing comfort. By adjusting the stand, you can change the
angle. We recommend angles between 30 and 60 degrees.
Adjustable Angle
With the stand closed, the zSpace is 25” (64 cm) wide, 18” (45 cm) tall, and 3” (8 cm) deep, at its widest, tallest,
and deepest.
The following table gives the zSpace’s “footprint,” or space on the desktop, at 30, 45, and 60 degrees.
Angle
Width
Depth
30 degrees
25” (64 cm)
17” ( 43 cm)
45 degrees
25” (64 cm)
15” (38 cm)
60 degrees
25” (64 cm)
12” (31 cm)

zspace.com
Setting Up your zSpace
Hardware
1. Confirm that you have all the hardware components. For each zSpace, your system includes the
following components:
ozSpace model 300
ozSpace 3D eyewear with markers (regular glasses and clip-ons)
ozSpace 2D eyewear without the markers
ozSpace stylus with cable
oKeyboard and mouse
oPower supply for the zSpace display with corresponding cable
2. Plug in all the cables:
oPlug the mouse and keyboard into the USB 2.0 ports on the side panel.
oPlug in the power cord and the stylus into the ports on the back panel.
oPress the power button on the top of the zSpace.
Refer to the illustrated Quickstart Guide that comes in the box with your zSpace. You can also download
a copy from http://zspace.com/setup.
3. When you finish connecting the zSpace hardware, make sure you have the latest version of the zSpace
system software and firmware. Refer to the following sections for more information.
Important: Do not download new video drivers except from the zSpace Support site,
https://support.zspace.com/hc/en-us, and only if recommended. AMD drivers from Windows updates, the AMD
support site, and other third-party sites are not guaranteed to work properly with zSpace.

zspace.com
System Software
The zSpace for Education is preinstalled with zSpace System Software version 5. To check for updates to the
System Software, you will need an Internet connection. Follow these steps:
1. In the Windows Start menu, select the zSpace folder, then choose zSpace Control Panel.
2. Check the version number in the upper right corner of the zSpace Control Panel.
Checking the Version Number
3. In a browser window, go to http://zspace.com/downloads and click on the zSpace 300 System Software
link.
4. If the latest version is newer than the one on your zSpace Control Panel, click on the download link.
5. Before you install the new version, uninstall the current version of the System Software.
a. Open the Windows Control Panel and select Programs and Features, then select Uninstall
Program.
b. Scroll down the list to select the zSpace System.
c. Right click on zSpace System and select Uninstall.
6. Next, run the downloaded installer and follow the on-screen prompts.

zspace.com
Firmware
If you install a newer version of the System Software, you will automatically get the latest firmware. Otherwise,
please make sure you have the correct firmware version. To do so:
1. On the zSpace Control Panel, click on the Firmware Updater button.
2. Click on the green check mark to begin. If necessary, a new version will download.
Start Firmware Check
3. Wait for the System Check to complete. It will restart the zSpace and show a checkmark when the check
is complete.
Firmware Check Complete
Congratulations! You are ready to begin using your zSpace. To start exploring immediately, go the Windows
Start menu and select one of the installed applications. Remember to put on the 3D glasses with trackers when
using the 3D applications.
If you experience any problems, refer to the Troubleshooting section on page 18.

zspace.com
Customizing your zSpace
The stylus is a key means of interacting with 3D applications. By default, the stylus buttons are set as follows:
Center button: Selects UI controls and objects in the application.
Right button: A secondary button that may bring up a pop-up menu.
If you prefer, you can switch the use of the center, right, and left buttons. To do so, open the zSpace Control
Panel and click on Stylus Configuration.
You can also turn off the LED lights and the vibration if you find those distracting.
Stylus Configuration Option

zspace.com
Applications for your zSpace
The zSpace includes the Windows 8.1 operating system, zSpace System Software, and drivers for all the built-in
components, including the touch screen, cameras, and FirePro W5170M graphics card.
Important: Do not download new video drivers except from the zSpace Support site,
https://support.zspace.com/hc/en-us, and only if recommended. AMD drivers from Windows updates, the AMD
support site, and other third-party sites are not guaranteed to work properly with zSpace.
The System Software is available for download from https://zspace.com/downloads. Use the App Manager to
download Zone, zSpace STEM applications, and demo applications.
Note that the zSpace STEM applications require a license purchased from zSpace to activate the applications.
Other third-party STEM applications are available for purchase from zSpace.
Installing and Updating Applications
To open the zSpace App Manager, click on its icon on the desktop or in the Windows Start menu.
Desktop Icon
The App Manager displays applications and content that you can install. It also shows updates for installed
applications, if any are available. You will need an Internet connection to check for updates.
Note: The App Manager will not include updates to the zSpace System Software.
Please visit https://zspace.com/downloads to find additional software titles for use with the zSpace.

zspace.com
Launching Applications
zSpace Zone provides a 3D interface for launching both 3D and 2D applications. It is already set up to launch the
zSpace applications pre-installed on your zSpace.
Tip: In a multi-user environment, we recommend you lock Zone to prevent users from adding and deleting
applications. Ctrl + L locks and unlocks Zone.
Starting Zone: Click on its icon on the desktop or in the Windows Start menu.
Desktop Icon
Launching an application: Click on its icon in Zone.
Adding an application:
1. If Zone is locked, you cannot see the menu at the top. To unlock Zone, press Ctrl + L.
2. Move the cursor to the top of the screen to see the menu.
3. Select File -> Add or press Ctrl + A.
4. Locate the file’s executable or its shortcut and double-click on it.
Note: For the zSpace STEM applications, add a link to the shortcut, not the .exe file. The shortcut
contains important parameters. To locate the shortcuts, open the zSpace folder in the Windows
Start Menu.
5. Press Ctrl +L to lock Zone.
Exiting Zone: Press Alt + F4.
Using zSpace STEM Applications
The zSpace Education website, http://edu.zspace.com, provides short videos on using the zSpace STEM
applications. To see these videos, click on the Resources link.
zSpace Studio, Newton’s Park, Franklin’s Lab, CyberScience 3D, and Corinth include curated educational
activities and models. To learn about individual activities, click on the Activities link on the zSpace Education
website. You can read activity plans for instructors and view videos.

zspace.com
Safety Instructions
Please carefully review the safety instructions described in the following section. This information is provided to
help you experience the best features of your zSpace and prevent problems that may decrease performance.
Failure to follow the instructions might void the limited warranty agreement, in which case zSpace will not be
responsible for replacing or repairing the product. Disregarding specific safety instructions may also cause injury
and serious damage to health.
Usage
Only use the power adapter provided with the zSpace. Using a different type of power adapter may
cause damage with the risk of fire. Be sure to use a grounded power source.
When moving or adjusting the zSpace, be careful when grasping the upper plastic enclosure. Excessive
pressure could misalign or damage the sensors.
Mishandling or dropping the zSpace may cause alignment problems with the tracking device.
Do not open or disassemble the zSpace or any hardware components associated with zSpace. In some
cases, there is risk of electrical shock. Opening the system or damaging components will void the
warranty.
Avoid placing sharp or heavy objects on the zSpace to prevent scratching the display surface or causing
breakage.
Avoid dropping the stylus or catching the cable on immovable objects.
When using zSpace eyewear, be careful not to remove or damage the markers, which are critical to head
tracking.
If the zSpace screen is damaged for any reason, do not touch any liquid emanating from the unit. In case
of contact with skin, rinse or flush any affected surfaces immediately with running water. Please consult
a physician in all cases.

zspace.com
Basic Operation
The zSpace display works best in moderate lighting conditions. Moving lights within the view of the
sensors can affect overall performance of the tracking mechanisms. Avoid bright lights for best results.
The power button is on the top of the zSpace. It controls the power to the system. You cannot turn off
the display separately.
Environment
Temperature : 10 - 35 degrees C (50 - 95 degrees F)
Humidity : 10 - 80 %, non-condensing (dry location)
Do not operate or store zSpace hardware in any location where temperature changes are severe.
Physiological Effects
Avoid long hours of prolonged use of 3D applications which may cause eyestrain, mild fatigue, and in
extreme cases, illness and seizures. Do not engage in operating vehicles or machinery when feeling any
of the described effects as a result of using the system.
zSpace disclaims any and all liability to users for any dizziness, nausea, headaches and/or other
sensations of physical discomfort or illness that a user may experience as a result of use of the zSpace.
In some cases, viewing objects in 3D stereo may cause disorientation and the objects may appear blurry.
Note: The FirePro graphics card handles the synchronization of left and right frames. You do not need
to force synchronization.
Caring for zSpace
Keep the zSpace’s display surface and tracking cameras clean and free from scratches or damage. Use an
anti-static or slightly damp cloth with light pressure. Regular cleaning will help prolong the life of the
screen surface.
Avoid cleaning products that contain alcohol, as they will leave a residue on the screen.
Use a lint-free cloth to remove any dirt or residue from the zSpace eyewear.
Keep the zSpace in a clean, dry place, and avoid extremes in temperature.
Avoid contact with liquids.

zspace.com
When cleaning, disconnect the zSpace from the power source.
Replacing the Battery
The zSpace includes a 3-volt lithium coin cell battery, which provides power to the real-time clock. When you
replace the battery, use an equivalent battery designated for this product.
Warning: There is a risk of fire and burns if the battery is not handled properly. To reduce the risk of injury:
Do not try to recharge the battery.
Do not expose the battery to temperatures higher than 60°C (140° F).
Do not disassemble, crush, puncture, short external contacts, or dispose of the battery in fire or water.
Static electricity can damage the electronic components of the zSpace or optional equipment. Before beginning,
ensure that you discharge static electricity by briefly touching a grounded metal object.
Caution: Removing or replacing a battery will clear the CMOS settings. Make sure you back up the CMOS
settings before you begin.
