R1
FCCID：2AGRQR1

 OperationManual

1. Product introduction
Icharming, a combination of technology and fashion and a crossover of tradition
and internet, CharmRing has powerful and practical functions with stylish
appearance.
1、Capable of setting photo-taking function by gesture at yours own will.
Industry’s longest Bluetooth-controlled photo-taking distance, up to 10
meters.
2、Health function could give you professional advice about sport data that
display by APP. CharmRing could be used for step counter without mobile
phone.
3、The ring will flash on call. You may stop worry about missing any
important calls if your cell phone is not handy.
4、 In case of oblivion or anti-loss, CharmRing link with mobile phone by
bluetooth,it could alert their owners to know that the ring or the mobile
phone is far away.
5、In emergency situations, your friends and relatives(preinstall the
emergency contact phone number by APP) will receive warning message and
positional information by special gesture. Warning message contains
preinstall text and instant positional information.
6、 You could share motion data,photos among social circle. Sharing a joy is

第3页
a happiness.
7、 Do not use the Charm Ring in the environment at too high or too low
Temperature, never expose the device under strong sunshine or too wet
environment. The suitable temperature for the phone and accessories is
0-45℃
2. Product list
Charm Ring R1 product list ：
1、 Charm Ring R1
2、 Portable charging case
3、 USB power line
4、 Diamond flat cloth
5、 Operation instruction
6、 Certificate of warranty card
3. diagram of product appearance

第4页
4. Product Features Guide
First use of this product, please read the manual, operate according to the
instructions：
1. Open the product box and check products according to the checklist.
2.

第5页
There is a switch(ON/OFF) on the bottom of charging case. Turn on the switch,
the ring is opening in the charging case. The ring could be linked with
Bluetooth. Turn off the switch, the ring is closed and all functions are
closed. At ordinary times, put the switch in on. Only under the long-term
unused situation, please turn off the switch(off)
3. Please take out of USB that placed in packaging box of lining small cardboard
box. The Fist-time user needs to charge Ring and case before using. This
product does not provide power adapter and other mobile phone’s power
adapter could be used，The USB is Charging only.
4. Tear up the protective film and to make sure that charging sports could be
contacted with charging case.
5.
While it is charging, put ring in the charging case(please aware of the
direction of ring). Please turn charging contacts inward or it would not
be recharged. While it is charging, cover with the lid, state indicator
lamp is on means the ring is charging. When the charging capacity is full,
state indicator lamp will go out. The recharge time is about one hour. Please
note that the ring could be charged only when the lid is closed.
6. The charging case has set-in battery, when the charging case has power it
could charge the ring without any external power source. When the charging
case out of power, the case needs the external power source. The charging
case could be used on a single full charge.

第6页
The state indicator lamp 2 is on, it means the ring is charging(external
power source is be linked). When the top state indicator lamp 1 is on, it
means the charging case is recharged. When remove the USB cable for charging,
state indicator lamp 2 will be off. The recharge time of case is about
1.5hours.
7.
Before using, you need to install APP. The ring need to used with APP and
the related function could be achieved.
（1）
Before using, you need to install APP which supports Android 4.3
version and above. IPHONE needs IOS 7.0 and above. If mobile phone
does not satisfy requirements, the APP will not be installed.
（2） Before using, mobile phone needs to install APP. Scanning QR code
to get the APP. Clicking the web links to get the APP.

第7页
http://www.strawcom.com/android.html
http://www.strawcom.com/ios.html
5. APP instructions
1. User Registration and Bluetooth Link
（1） The first-time user needs to fill out the customer register
correctly, so that we can offer you with better service and exercise
suggestion. We will not divulge the information or use it for any other

第8页
purpose.

第9页
（2） After finishing the registration, entering APP interface to bind
the ring. Clicking top-left icon for entering the setting screen and menu
list. Selecting the first option “Charm Ring not connected” and choosing
the need option in the search listing to link the Bluetooth.

第10 页

第11 页

第12 页

第13 页
When a ring linked with mobile phone, the user menu “Charm Ring
unconnected”will show the ring battery which means you could use the ring
as a result of the successful bind.
（3）
If the searching or binding is failure, please to make sure Bluetooth is
turn on. The ring and mobile phone should in the coverage of communication.
Please keep the ring as close as possible to the mobile phone for
successfully connection.

第14 页
2. personal information setting

第15 页
3. optional switch setting

第16 页
When using, please open all the function switch for using. The light notification
could be changed by the slider of “call notification” and “phone lost
notification”.
4. motion calculation
（1）set the fitness goals, you could set the fitness goals based on individual
requirement.

第17 页
（2） APP will record your motion data for good fitness habit everyday.

第18 页
（3） Ranking

第19 页
5. Emergency setting

第20 页
Contacts in the emergency list will receive warning message and current positional with the
ring wiggled frequently.
