ZUM Radio Elite 3.5 LCD ZUMspot User manual
Elite 3.5 LCD ZUMspot kit user guide
Copyright 2019-2022 ZUM R dio, Inc 1 Rev 1.3
Elite 3.5 LCD ZUMspot
The Elite 3.5 LCD ZUMspot kit is low power simplex digit l mode hotspot. It supports Dst r, DMR,
Fusion, NXDN, P25 nd POCSAG.
Elite 3.5 LCD ZUMspot kit user guide
Copyright 2019-2022 ZUM R dio, Inc 2 Rev 1.3
Table of Contents
ZUMspot bo rd specific tions: ..................................................................................................................... 3
Kit includes: ................................................................................................................................................... 3
Setup: ............................................................................................................................................................ 4
Powering up: ......................................................................................................................................... 4
Ethernet: ............................................................................................................................................... 5
Configure displ y type: ......................................................................................................................... 6
Ethernet: ............................................................................................................................................... 6
Wi-Fi: ..................................................................................................................................................... 7
Configur tion: ..................................................................................................................................... 11
Configur tion (ex mple to en ble D-St r): ......................................................................................... 12
Finished: ...................................................................................................................................................... 13
Support: ...................................................................................................................................................... 13
Elite 3.5 LCD ZUMspot kit user guide
Copyright 2019-2022 ZUM R dio, Inc 3 Rev 1.3
ZUMspot board specifications:
•
ZUMspot Bo rd Fully Assembled And Tested
•
High perform nce 32-bit ARM processor
•
Supports DMR, P-25, D-St r, System Fusion, NXDN nd POCSAG
•
Onbo rd LEDs to show st tus (Tx, Rx, PTT, Mode)
•
Up to 10mW RF power
•
SMA ntenn connector, UHF ntenn included
•
The firmw re is pre-lo ded nd is e sily upgr ded vi softw re
Kit includes:
•
ZUMspot RPi UHF Bo rd
•
R spberry Pi 4
•
Custom c se
•
3A power supply
•
3.5" LCD screen
•
UHF Antenn
•
Pre-Im ged 16 GB MicroSD C rd with Pi-St r Softw re
•
1 Ye r W rr nty
Elite 3.5 LCD ZUMspot kit user guide
Copyright 2019-2022 ZUM R dio, Inc 4 Rev 1.3
Setup:
●
M ke sure the SD c rd is inst lled in the R spberry Pi 4
●
Inst ll the ntenn onto the RF connector
Po ering up:
●
Plug in the USB-C power c ble to your Elite 3.5 ZUMspot LCD kit. Then plug the c ble into the
w ll d pter nd insert th t into n AC outlet.
●
If the Elite 3.5 LCD ZUMspot kit doesn’t power up, then press the switch on the c ble nd it
should power up now.
Elite 3.5 LCD ZUMspot kit user guide
Copyright 2019-2022 ZUM R dio, Inc 5 Rev 1.3
Ethernet:
●
If you re going to use Ethernet, plug the c ble into the RJ45 connector on the end of the c se.
Elite 3.5 LCD ZUMspot kit user guide
Copyright 2019-2022 ZUM R dio, Inc 6 Rev 1.3
Setup Pi-Star:
Configure display type:
●
In the “MMDVMHost Configuration” section
●
M ke sure “MMDVM display Type” is set to “Nextion”
●
M ke sure “Port” is set to “Modem”
●
M ke sure “Nextion Layout” is set to “ON7LDS L3”
Ethernet:
●
If you re using Ethernet, the IP ddress should utom tic lly be retrieved by the DHCP system
built into the PiSt r softw re. No other configur tion should be needed.
Elite 3.5 LCD ZUMspot kit user guide
Copyright 2019-2022 ZUM R dio, Inc 7 Rev 1.3
Wi-Fi:
●
Power up the Elite 3.5 LCD ZUMspot kit.
●
After 3 minutes, sc n for Wi-Fi ccess points from your phone or l ptop. One should ppe r with
the n me “Pi-Star-Setup”
●
Connect to it. When sked for the Wi-Fi p ssword type in: r spberry
●
After 3 minutes, go to your web browser (Chrome, Firefox, etc.) nd connect to the website:
http://pi-st r (for Windows, Linux nd Android devices
http://pi-st r.loc l (for OS X nd iOS devices)
●
You should see this p ge:
●
Go to Configuration
○
You will be sked to put in the def ult usern me which is “pi-star” nd the def ult
p ssword which is “raspberry”
Elite 3.5 LCD ZUMspot kit user guide
Copyright 2019-2022 ZUM R dio, Inc 8 Rev 1.3
○
Select “Configure WiFi
Elite 3.5 LCD ZUMspot kit user guide
Copyright 2019-2022 ZUM R dio, Inc 9 Rev 1.3
oClick on “Scan for Net orks (10 secs)”
Elite 3.5 LCD ZUMspot kit user guide
Copyright 2019-2022 ZUM R dio, Inc 10 Rev 1.3
●
Select your Wi-Fi SSID nd enter your p ssword.
●
Click on “Save (and connect)” to s ve the Wi-Fi configur tion
●
Reboot your Elite 3.5 LCD ZUMspot kit
Elite 3.5 LCD ZUMspot kit user guide
Copyright 2019-2022 ZUM R dio, Inc 11 Rev 1.3
Configuration:
●
Ch nge the Node C llsign to your own, set the “Radio Frequency” to m tch your r dio nd
m ke sure the “Radio/Modem Type” is set to “ZUMspot - Raspberry Pi Hat (GPIO)”, set the
“System Time Zone” to your time zone, nd set the “Dashboard Language” to the l ngu ge you
prefer.
●
Click “Apply Changes” when you re done
Elite 3.5 LCD ZUMspot kit user guide
Copyright 2019-2022 ZUM R dio, Inc 12 Rev 1.3
Configuration (example to enable D-Star):
●
Now you c n turn on D-St r by selecting the “D-Star Mode” switch nd clicking “Apply Changes”
Elite 3.5 LCD ZUMspot kit user guide
Copyright 2019-2022 ZUM R dio, Inc 13 Rev 1.3
Finished:
Once you h ve completed the Pi-St r configur tion you c n st rt using the Elite 3.5 LCD ZUMspot kit to
connect to DSTAR, DMR nd other networks.
There is more inform tion on configuring nd using Pi-St r in this document:
https:// m teurr dionotes.com/im ges/1-Pl ying_with_Pi-St r.pdf
Support:
MMDVM groups.io group:
https://groups.io/g/OpenDV
Pi-St r support forum:
https://forum.pist r.uk/
Pi-St r F cebook support group:
https://www.f cebook.com/groups/pist r/
Pi-St r Wiki:
http://wiki.pist r.uk
ZUM R dio F cebook group:
https://www.f cebook.com/groups/249802742395450/
