3Jtech netFox Wifi/GPS Camera User manual

Ver 1.0.0.1
Since 1988
1
Quick Installation Guide for netFox Wifi/GPS Camera
1. netFox Packing List :
Before you start installing netFox, please verify that the package contains the following items:
1x netFox
1x External GPS Antenna (Optional)
1x 12V/1A Adapter with Micro USB Connector
1x Mini USB Interface AV Cable with the Headset and Camera
1x 2G SD Card
1x CD with Demo Application Program and netFox User’s Guide
This Quick Installation Guide
NOTE: Please notify your sales representative immediately if any items listed above is missing or damaged.
2. Hardware Connection Settings for netFox
1) Use an AV cable to connect to the mini USB connector of netFox.
2) Make sure the SD card has inserted to the SD card slot of netFox (For its correct position,
please refer to the figure 2), and your wifi-router is ready as well.
3) Connect the power cable to the micro USB power connector of your netFox.
4) Press the “Push to Link” button (see the red arrow of the figure 2) to power on your netFox.
5) Insert CD to your PC to install the netFox AP. (Refer to Section 4.)
NOTE 1 : The procedures of powering on netFox will take 1 minute around. And also make sure that netFox
has been charged for 4 hrs in your first use.
NOTE 2 : netFox will allow the image and voice on the spot to be remotely transmitted to PC/server running
netFox AP by pressing the “Push to Link” button while netFox is powering on. And keep pressing
the “Push to Link” button over 3 seconds, netFox will be powered off.

Ver 1.0.0.1
Since 1988
2
3. LED Description on netFox
LED Color Status
3G Modem LED Green N/A
2G Modem LED Red N/A
GPS LED Green Flash when GPS location is detected.
Lit when no GPS location is detected.
SD Card Status
LED Red Lit when no space of the SD card is left.
Off when the space of the SD card still remains.
Recording
Status LED Red Lit when the device is doing recording.
Off when the device stops recording.
Cellular Signal
Strength LED Green Lit when the signal strength is good.
Flash when the signal strength is moderate.
Off when the signal strength is weak.
Flash per second when the device is turned on whether the power adapter
exists or not.
Lit when the device is being charged in case the power adapter exists.
System
Operation
Status LED
Green Off when the device is fully charged in case the power adapter exists.
Off when the device is turned off in case no power adapter exists.
Fig. 1 LEDs on netFox

Ver 1.0.0.1
Since 1988
3
4. Install the netFox AP Software
1) To install netFox AP to your PC for
netFox Wifi/GPS Cameras, please
insert CD and double click the
NetFoxSetup.msi file. Follow the
wizard and it can be found on Start
Menu if the installation succeeds.
Viewing Image from Cameras/ Making VoIP Phone Calls/ Doing MAP Searching via GPS
1) Please start the netFox AP software you installed, and netFox will automatically show up on
Camera List if your netFox’s basic settings and WIFI connection settings are completed.
(For more details about these settings, please refer to Section 3.1.1 and 3.1.2 of netFox’s
user’s manual.)
2) To view the camera, click on the checkbox in front of the ID belonging to your desired netFox,
and the image window will pop up at the section below the camera list.
3) To make a VoIP phone call, just right click on the desired entry of netFox on the camera list
and select the Dial function from the pop-up menu.
4) To search for your netFox’s position, please install the GPS AP we offer in advance. Execute
the Setup MAP function under the MAP… file menu of netFox AP to locate the
GpsSystem.exe file of the GPS AP you had installed. Then, enable the Run MAP function
for the initiation the GPS MAP function.
NOTE 3: The built-in GPS function works only when netFox is placed in the outdoors. When you power on netFox,
this function will begin to be initiated as well and it will take 15 minutes at least for netFox to locate its
position successfully.
Fig. 2 The Connection of netFox
