FWT Wifi AP_USB x 4
User’s Guide
Version: 1.0
Date: August 14, 2013
3JTech Co., Ltd.
2F, No. 342, Fu-Shing N. Rd.
Taipei, Taiwan
Tel: [phone]
e-mail: [email protected]

http://www.3jtech.com.tw
http://www.pnpipcameras.com
FWT WIFIAP_USB x 4 User’s Guide
Copyright of 3JTech Co., Ltd. (also doing business asA3J Engineering Inc.)
2
Revision History
Version Date Changes
1.0 08/14/2013 First Release of FWT Wifi AP_USB x 4 User’s Manual

http://www.3jtech.com.tw
http://www.pnpipcameras.com
FWT WIFIAP_USB x 4 User’s Guide
Copyright of 3JTech Co., Ltd. (also doing business asA3J Engineering Inc.)
3
Table of Contents
Revision History .......................................................................................................................... 2
TABLE OF CONTENTS .............................................................................................................. 3
CHAPTER 1. PRODUCT OVERVIEW ......................................................................................... 5
1.1 INTRODUCTION ..................................................................................................................... 5
1.2 FEATURES ............................................................................................................................ 6
1.3 PACKAGE CONTENTS ............................................................................................................ 7
CHAPTER 2. PHYSICAL DESCRIPTION .................................................................................... 8
2.1 PANELS ................................................................................................................................ 8
2.1.1 Front Panel .................................................................................................................. 8
2.1.2 Rear Panel ................................................................................................................... 9
2.2 ILLUSTRATION .................................................................................................................... 10
2.2.1 Front Panel Information ............................................................................................ 11
Phone Connector ............................................................................................................ 11
3G ANT SMA Connector ................................................................................................ 11
SIM Card Slot .................................................................................................................. 11
Power Supply Connector ................................................................................................ 11
WAN Port ........................................................................................................................ 11
LAN Network Connectors .............................................................................................. 11
USB 1~USB 3 Connectors ............................................................................................. 11
RESET Button ................................................................................................................. 11
2.2.2 Rear Panel Information ............................................................................................. 11
LEDs ................................................................................................................................ 11
2.2.3 LED Description on the Rear Panel ......................................................................... 12
CHAPTER 3. WEB-BASED MANAGEMENT ............................................................................ 13
3.1. INTERNET SETTINGS ........................................................................................................... 15
3.1.1 WAN .......................................................................................................................... 15
3.1.1.1 Static(Fixed IP) WAN Mode ............................................................................... 16
3.1.1.2 DHCP(Auto Config) WAN Mode ......................................................................... 16
3.1.1.3 PPPoE (ADSL) WAN Mode ................................................................................ 17
3.1.1.4 3G Settings ......................................................................................................... 18
3.1.2 LAN ............................................................................................................................ 19
3.1.3 DHCP Client .............................................................................................................. 21
3.1.4 VPN (GRE) ................................................................................................................ 22
3.1.5 Advanced Routing Settings ....................................................................................... 23

http://www.3jtech.com.tw
http://www.pnpipcameras.com
FWT WIFIAP_USB x 4 User’s Guide
Copyright of 3JTech Co., Ltd. (also doing business asA3J Engineering Inc.)
4
3.2 WIRELESS SETTINGS ........................................................................................................... 24
3.2.1 Basic Wireless Settings ............................................................................................ 24
3.2.2 Wireless Security/Encryption Settings .................................................................... 29
3.2.2.1 Disable Mode ...................................................................................................... 29
3.2.2.2 WEPAUTO(WEP) Mode ...................................................................................... 30
3.2.2.3 WPA-PSK / WPA2-PSK Mode .......................................................................... 32
3.2.3 Station List ................................................................................................................ 34
3.2.4 Wireless Statistics .................................................................................................... 35
3.3 FIREWALL SETTINGS .......................................................................................................... 36
3.3.1 MAC/IP/Port Filtering Settings ................................................................................ 36
3.3.2 Port Forwarding Settings ......................................................................................... 38
3.3.2.1 Create a Port Forwarding .................................................................................. 38
3.3.3 DMZ Settings ............................................................................................................. 41
3.3.4 System Security Settings ......................................................................................... 42
3.4 MANAGEMENT .................................................................................................................... 44
3.4.1 System Management ................................................................................................. 44
3.4.2 SIM Card Control ...................................................................................................... 46
3.4.3 SMS Sending/Receiving ............................................................................................ 49
3.4.4 TR-069 ...................................................................................................................... 51
3.4.5 Fax Sending/Receiving via FWT .............................................................................. 52
3.4.5.1 Usage of FAX ..................................................................................................... 52
3.4.5.2 Fax Settings ........................................................................................................ 54
3.4.6 Firmware Upgrade .................................................................................................... 55
3.4.7 Configuration Management ....................................................................................... 56
3.4.8 Status ......................................................................................................................... 57
3.4.9 Statistic ...................................................................................................................... 58
CHAPTER 4. GSM SETUP ....................................................................................................... 59

http://www.3jtech.com.tw
http://www.pnpipcameras.com
FWT WIFIAP_USB x 4 User’s Guide
Copyright of 3JTech Co., Ltd. (also doing business asA3J Engineering Inc.)
5
1. Product Overview
1.1 Introduction
FWT Wifi AP_USB x 4, a 3G WiFi Router with a WAN port and multiple cellular modems, is the
perfect option to connect a small group of PCs to a high-speed broadband Internet connection or to
an Ethernet backbone. Configurable as a DHCP server, FWT Wifi AP_USB x 4 acts as the only
externally recognized Internet device on your local area network (LAN). The FWT Wifi AP_USB x 4
also serves as an Internet firewall to protect your network from being accessed by outside users.
In addition, this AP is a Fixed Wireless Terminal (FWT). A simple desk phone can be connected to
the phone jack to make and receive calls. The SIM card inserted in the device is used for GSM calls.

http://www.3jtech.com.tw
http://www.pnpipcameras.com
FWT WIFIAP_USB x 4 User’s Guide
Copyright of 3JTech Co., Ltd. (also doing business asA3J Engineering Inc.)
6
1.2 Features
yRouter Mode
‐ 3G Dial-up
‐ 3 WAN Modes (It includes Static(Fixed IP), DHCP(Auto Config) and PPPoE (ADSL))
‐ DHCP Sever
‐ NAPT (Network Address and Port Translation)
‐ NAT (Network Address Translation)
yInternet
Access
‐ TCP/IP, UDP, ICMP, ARP, PPP, NAT, DHCP (Server), Static IP assignment
ySecurity Features
‐ Password protected configuration access
‐ User authentication (PAP/CHAP) for PPP connection
yWireless Features
‐ Support 802.11b/g, 802.11n draft 3.0 Wireless Access Point
‐ Support 128-Bit and 64-Bit WEP encryption, WPA-PSK, WPA2-PSK
y Security
‐ Support packet inspection and filtering
‐ Intrusion detection and protection
‐ Password protected system management
yEthernet
Interface
‐ Compliant with IEEE 802.3 and 802.3u 10/100 Mbps
yHTTP Web-Based
Management
‐ Firmware upgrade by UI
‐ WAN and LAN side connection statistics
‐ Password protected access
‐ Wireless LAN
ySupport TR-069 management function
y Support the Fax function
y Support the load balance function with multiple 3G

http://www.3jtech.com.tw
http://www.pnpipcameras.com
FWT WIFIAP_USB x 4 User’s Guide
Copyright of 3JTech Co., Ltd. (also doing business asA3J Engineering Inc.)
7
1.3 Package Contents
─ 1 x FWT Wifi AP_USB x 4
─ 1 x RJ45 Ethernet Cable
─ External 3G Antenna with 3M Antenna Cable
─ RJ11 Phone Cable
─ 3G USB Dongle (Optional)
─ 1 x PowerAdapter
─ 1 x CD with this User’s Manual
─ Quick Setup Guide

http://www.3jtech.com.tw
http://www.pnpipcameras.com
FWT WIFIAP_USB x 4 User’s Guide
Copyright of 3JTech Co., Ltd. (also doing business asA3J Engineering Inc.)
8
2. Physical Description
The following information contains the physical description of the FWT Wifi AP_USB x 4. This
includes the functions and the locations of each connector and indicator. This information provides
useful reference when installing the product. Please familiarize yourself with the
FWT WifiAP_USB x 4.
2.1 Panels
2.1.1 Front Panel
For more related description, please refer to the Section 2.2 and Section 2.2.1.
1
2
3
8
5
6
4
7

http://www.3jtech.com.tw
http://www.pnpipcameras.com
FWT WIFIAP_USB x 4 User’s Guide
Copyright of 3JTech Co., Ltd. (also doing business asA3J Engineering Inc.)
9
2.1.2 Rear Panel
For more detailed description, please refer to the Section 2.2 and Section 2.2.2.
9

http://www.3jtech.com.tw
http://www.pnpipcameras.com
FWT WIFIAP_USB x 4 User’s Guide
Copyright of 3JTech Co., Ltd. (also doing business asA3J Engineering Inc.)
10
2.2 Illustration
No. in
Figures Name on FWT Wifi AP_USB x 4 Description Remark
1 Phone Connector
To connect with an analog
phone via a RJ-11 cable
Refer to Section 2.2.1 for front
panel information
2 3G ANT SMA
Connector To externally connect with
the 3G Antenna Refer to Section 2.2.1 for front panel information
3 SIM Card Slot To connect with the internal
modem
Refer to Section 2.2.1 for front
panel information
4 Power Supply
Connector
To connect with the FWT
Wifi AP_USB x 4 and the
power adapter
Refer to Section 2.2.1 for front
panel information
5 WAN Port For the access of Internet Refer to Section 2.2.1 for front
panel information
6 LAN Network
Connectors
To connect to the device and
Ethernet port via RJ45 cable Refer to Section 2.2.1 for front panel information
7 USB 1~USB 3
Connectors
To externally connect with
the 3G dongle(s) Refer to Section 2.2.1 for front panel information
8 Reset Button To reset the FWT Wifi AP_USB x 4 to its factory
defaults
Refer to Section 2.2.1 for front
panel information
9 LEDs
To display the status of FWT
Wifi AP_USB x 4
Refer to Section 2.2.2 for rear
panel information and Section
2.2.3 for LED description on the
rear panel

http://www.3jtech.com.tw
http://www.pnpipcameras.com
FWT WIFIAP_USB x 4 User’s Guide
Copyright of 3JTech Co., Ltd. (also doing business asA3J Engineering Inc.)
11
2.2.1 Front Panel Information
Phone Connector
Offer the Voice FWT function.
3G ANT SMA Connector
Support 3G mode for the access of Internet.
SIM Card Slot
Plug the SIM card chip.
Power Supply Connector
Plug the power adapter. The specifications of FWT Wifi AP_USB x 4’s power adapter are as follows:
Input: 100 ~ 240V AC, 50/60Hz
Output: 12V DC / 1.5A
WAN Port
Offer the access of Internet.
LAN Network Connectors
FWT WifiAP_USB x 4 is designed for 10/100Mbps Ethernet networks. FWT Wifi AP_USB x 4
connects to the network via category 5 cable.
USB 1~USB 3 Connectors
Plug the 3G USB dongle for the load balance.
Note: Please plug the 3G USB dongle when the router is powered off.
RESET Button
Support the hardware reset function. Press this button 2 seconds around, and the settings of the
device will return to the factory defaults.
Note: Please do not power off the router while resetting it to the factory default.
2.2.2 Rear Panel Information
LEDs
Include the LEDs of POWER, SMS, WLAN (Wireless LAN), LAN Link, WAN Link, Pick Up/Hang Up,
3G PPP Status, and Cellular Signal Strength.

http://www.3jtech.com.tw
http://www.pnpipcameras.com
FWT WIFIAP_USB x 4 User’s Guide
Copyright of 3JTech Co., Ltd. (also doing business asA3J Engineering Inc.)
12
2.2.3 LED Description on the Rear Panel
LED Color Status
POWER( )Yellow Lit when +12V DC power is on and working.
SMS( ) Yellow Lit when receiving any new SMS(s).
Off at any status except the incoming of new SMS(s).
WLAN(Wireless LAN )Yellow Lit when the WiFi function is enabled.
Flash when the data is transmitting.
Off when the WiFi function is disabled.
LAN Link( ) Yellow Lit when the cable connection with device exists.
Flash when the data is transmitting.
Off when no cable connection exists.
WAN Link( )Yellow Lit when the cable connection with device exists.
Flash when the data is transmitting.
Off when no cable connection exists.
Pick Up/Hang Up ( )Yellow Lit when picking up the connected analog phone.
Off when hanging up the connected analog phone.
3G PPP Status ( ) Yellow Lit when dialup is connected.
Flash when the data is transmitting.
Off when dialup is disconnected.
3 Cellular Signal Strength LEDs
Low ( )
Yellow
All 3 LEDs lit when the signal strength is good.
(The LEDs lit would decrease progressively upon the
signal strength)
Medium ( )
High ( )

http://www.3jtech.com.tw
http://www.pnpipcameras.com
FWT WIFIAP_USB x 4 User’s Guide
Copyright of 3JTech Co., Ltd. (also doing business asA3J Engineering Inc.)
13
3. Web-Based Management
This chapter instructs you how to configure and manage the FWT Wifi AP_USB x 4 through the web
user interface it supports. With this facility, you can easily access and monitor through the LAN port
of the FWT Wifi AP_USB x 4.
After the FWT Wifi AP_USB x 4 has been connected to your PC via RJ45 network cable, type
http://10.10.10.254 in IE browser, it will show the following screen and ask you to input the user
name and password in order to login and access authentication. The default user name and the
password are both “admin”. For the first time to use, please enter this default user name and the
password, then click the OK button. The root setup page for FWT Wifi AP_USB x 4 will be displayed
once the login process is successful. The user will be able to fully access and configure the system.

http://www.3jtech.com.tw
http://www.pnpipcameras.com
FWT WIFIAP_USB x 4 User’s Guide
Copyright of 3JTech Co., Ltd. (also doing business asA3J Engineering Inc.)
14
In the FWT WifiAP_USB x 4, it supports a simple user management function to configure the system.
As the figure below shows, for example, left section is the whole function tree with web user interface
while each of main functions, including INTERNET SETTINGS, WIRELESS SETTINGS, FIREWALL,
and MANAGEMENT is selected.
By means of the hyperlink of Status, Statistic or Management in this root setup page, you can directly
jump to the related pages if you would like to realize the basic information of the system.

http://www.3jtech.com.tw
http://www.pnpipcameras.com
FWT WIFIAP_USB x 4 User’s Guide
Copyright of 3JTech Co., Ltd. (also doing business asA3J Engineering Inc.)
15
3.1. Internet Settings
3.1.1 WAN
The WAN (Wide Area Network) section is where you configure your Internet connection type.
Besides supporting 3G dialup connection type to access Internet, there are three WAN connection
modes to choose from: Static (Fixed IP), DHCP(Auto Config) and PPPoE(ADSL). If you are unsure
of your connection method, please contact your Internet Service Provider before configuring the
required parameters. Note: If using the PPPoE option, you will need to ensure that any PPPoE
client software on your computers is removed or disabled.
Through the Wan Weight function on this WAN setting webpage, you can set up the transmission
ratio among the Ethernet WAN and each 3Gs (WAN1: WAN2: WAN3: WAN4: WAN5) for the router’s
load balance. Default is 1:1:1:1:1.
Note: If the external dongle is not connected, the wan weight for it must be either 0 or empty.
：
：

http://www.3jtech.com.tw
http://www.pnpipcameras.com
FWT WIFIAP_USB x 4 User’s Guide
Copyright of 3JTech Co., Ltd. (also doing business asA3J Engineering Inc.)
16
3.1.1.1 Static(Fixed IP) WAN Mode
Used when your ISP provides you a set IP address that does not change. The IP information is
manually entered in your IP configuration settings. You must enter the IP address, Subnet Mask,
Default Gateway, Primary DNS Server, and Secondary DNS Server. Your ISP provides you with
all of this information.
3.1.1.2 DHCP(Auto Config) WAN Mode
A method of connection where the ISP assigns your IP address when your router requests one from
the ISP's server. Some ISP's require you to make some settings on your side before your router can
connect to the Internet.
Hostname: Some ISP's may check your computer's hostname. The hostname identifies your
system to the ISP's server. This way they know your computer is eligible to receive an IP
address. In other words, they know that you are paying for their service.

http://www.3jtech.com.tw
http://www.pnpipcameras.com
FWT WIFIAP_USB x 4 User’s Guide
Copyright of 3JTech Co., Ltd. (also doing business asA3J Engineering Inc.)
17
3.1.1.3 PPPoE (ADSL) WAN Mode
Select this option if your ISP requires you to use a PPPoE (Point to Point Protocol over Ethernet)
connection. DSL providers typically use this option. This method of connection requires you
to enter a User Name and Password (provided by your Internet Service Provider) to gain
access to the Internet.
Operation Mode: Typically, connections are not always on. The router allows you to set the
reconnection mode. The setting is:
Keep Alive: A connection to the Internet is always maintained. When this option is
selected, please enter a value in the field of Redial Period which is the time
interval the machine will be redialed before the PPPoE connection is disconnected.

http://www.3jtech.com.tw
http://www.pnpipcameras.com
FWT WIFIAP_USB x 4 User’s Guide
Copyright of 3JTech Co., Ltd. (also doing business asA3J Engineering Inc.)
18
3.1.1.4 3G Settings
This section is where you configure your dialup up connection type. There are 2 modem types to
choose from: Cellular 2G and 3G.
Up to four 2G/3G are allowed to be used at a time through one internal 2G/3G module and three
external USB ports for the connection of 3G dongles. With these multiple 2G/3G, they will balance
the load of WAN transmission for the router. Based on your USB1/USB2/USB3 hardware
configuration on FWT WIFI AP_USB x 4, sequentially set up these cellular modems (See the figure
below).
2G/3G ISP Settings: Your 2G/3G service provider will provide you with the values to fill in for
the required fields of Access Point Name (APN Gateway),PPP User Name, PPP Password
and Dial Number.
Dial Number: The 2G/3G dial command. Default is *99#.
Authentication Mode: The mode for PPP authentication. Default is Auto.
Connection Type: There are four types of operation mode supported: 3G only, 3G+2G(3G
Preferred), 2G only, and 2G+3G(2G Preferred). Default is 3G + 2G (3G Preferred).
For Internal Modem
2G/3G Settings
For External USB Port 1
2G/3G Settings
For External USB Port 2
2G/3G Settings
For External USB Port 3
2G/3G Settings

http://www.3jtech.com.tw
http://www.pnpipcameras.com
FWT WIFIAP_USB x 4 User’s Guide
Copyright of 3JTech Co., Ltd. (also doing business asA3J Engineering Inc.)
19
3.1.2 LAN
These are the settings of the LAN (Local Area Network) interface for the AP. The AP's local
network (LAN) settings are configured based on the IP Address and Subnet Mask assigned in this
section. The IP address is also used to access this web-based management interface. It is
recommended that you use the default settings if you do not have an existing network.
IP Address: The IP address of your router’s LAN port. Default: 10.10.10.254.
Subnet Mask: Subnet Mask of your LAN (default: 255.255.255.0). All devices on the network
must have the same subnet mask to communicate on the network.
DHCP Type: DHCP stands for Dynamic Host Configuration Protocol. The DHCP section is
where you configure the built-in DHCP Server to assign IP addresses to the computers and
other devices on your local area network (LAN). When you select Server item from this
pull-down list to enable this function, the following parameters will be displayed. You must enter
the IP address, Subnet Mask, Primary DNS Server and/or Secondary DNS Server.

http://www.3jtech.com.tw
http://www.pnpipcameras.com
FWT WIFIAP_USB x 4 User’s Guide
Copyright of 3JTech Co., Ltd. (also doing business asA3J Engineering Inc.)
20
Start IP Address: Specify the DHCP Client IP address that will start.
End IP Address: Specify the DHCP Client IP address that will end.
Note: The number of the “End IP” must be greater than “Start IP”, and cannot be the same as the
router’s IP address.
DHCP Lease Time: Designate the amount of the time for the device to recycle and give out
the IP addresses to the devices in your network (default: 86400).
Statically Assigned: You can statically assign the client MAC and IP address. Up to three
IPs and MACs can be assigned.
