7starlake SCH-401 User manual

User’s Manual
Revision Date: June.9.2021
SCH-401
IEC-61850-3, IEEE-1613 Substation 2U Server

SCH-401 User’s Manual
Revision Date: June.9.2021
1
Safety Information
Electrical safety
 To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the
system.
 When adding or removing devices to or from the system, ensure that the power cables for the devices are
unplugged before the signal cables are connected. If possible, disconnect all power cables from the existing
system before you add a device.
 Before connecting or removing signal cables from the motherboard, ensure that all power cables are unplugged.
 Seek professional assistance before using an adapter or extension cord. These devices could interrupt the
grounding circuit.
 Make sure that your power supply is set to the correct voltage in your area.
 If you are not sure about the voltage of the electrical outlet you are using, contact your local power company.
 If the power supply is broken, do not try to fix it by yourself. Contact a qualified service technician or your local
distributor.
Operation safety
 Before installing the motherboard and adding devices on it, carefully read all the manuals that came with the
package.
 Before using the product, make sure all cables are correctly connected and the power cables are not damaged. If
you detect any damage, contact your dealer immediately.
 To avoid short circuits, keep paper clips, screws, and staples away from connectors, slots, sockets and circuitry.
 Avoid dust, humidity, and temperature extremes. Do not place the product in any area where it may become
wet.
 Place the product on a stable surface.
 If you encounter any technical problems with the product, contact your local distributor
Statement
 All rights reserved. No part of this publication may be reproduced in any form or by any means, without prior
written permission from the publisher.
 All trademarks are the properties of the respective owners.
 All product specifications are subject to change without prior notice

SCH-401 User’s Manual
Revision Date: June.9.2021
2
Revision History
Revision Date (yyyy/mm/dd) Changes
V1.0 2021/06/09 First release
Packing List
Item Description Q’ty
1 SCH-401 IEC-61850-3, IEEE-1613 Substation 2U Server 1
2 Driver CD 1
Ordering information
SCH-401
IEC-61850-3, IEEE-1613 Substation 2U Server with Intel 10th Gen Xeon® W-1200 or Core™ i9/i7/i5 Processor, 2 × RJ45
GbE, 1 x IPMI, 67V~143V DC-IN,TPM/FTDI Support, 2 x 200W DC/DC Redundant Power Supply, Operating Temperature
-20~+60°C

SCH-401 User’s Manual
Revision Date: June.9.2021
3
RoHS Compliance
7Starlake RoHS Environmental Policy and Status Update
7Starlake is a global citizen for building the digital infrastructure. We are committed to providing
green products and services, which are compliant with
European Union RoHS (Restriction on Use of Hazardous Substance in Electronic Equipment) directive 2011/65/EU, to be
your trusted green partner and to protect our environment.
In order to meet the RoHS compliant directives, 7Starlake has established an engineering and manufacturing task force
to implement the introduction of green products. The task force will ensure that we follow the standard 7Starlake
development procedure and that all the new RoHS components and new manufacturing processes maintain the highest
industry quality levels for which 7Starlake are renowned.
The model selection criteria will be based on market demand. Vendors and suppliers will ensure that all designed
components will be RoHS compliant

SCH-401 User’s Manual
Revision Date: June.9.2021
4
Chapter 1 : Production Introduction ....................................................................................................... 5
1.1 Specifications ........................................................................................................................... 5
1.2 Front Panel I/O Placement ....................................................................................................... 7
1.3 Rear Panel I/O Placement ........................................................................................................ 8
1.4 Mechanical Dimensions ........................................................................................................... 9
Chapter 2 : Rear I/O Ports ..................................................................................................................... 10
2.1 LAN/IPMI port ........................................................................................................................ 10
2.2 VGA/DVI-D/DP port ................................................................................................................ 10
2.3 USB3.2 port ............................................................................................................................ 10
Chapter 3 : System Setup ..................................................................................................................... 11
3.1 Removing the Top Cover from the Chassis ............................................................................ 11
3.2 Installing PCIe Card................................................................................................................. 11
3.3 Install the screws on the upper cover .................................................................................... 12
3.4 2.5” Easy Swap SSD installation ............................................................................................. 12
Chapter 4: AMI BIOS UTILITY ................................................................................................................. 12
4.1 Starting ................................................................................................................................... 13
4.2 Navigation Keys ...................................................................................................................... 13
4.3 Main Setup ............................................................................................................................. 13
4.4 Advanced Setup Configuations .............................................................................................. 16
4.5 Event Logs .............................................................................................................................. 50
4.6 IPMI ........................................................................................................................................ 52
4.7 Security................................................................................................................................... 55
4.8 Boot ........................................................................................................................................ 62
4.9 Save & Exit .............................................................................................................................. 65

SCH-401 User’s Manual
Revision Date: June.9.2021
5
Chapter 1 : Production Introduction
1.1 Specifications
System
CPU 10th Generation Intel® Xeon® W-1200 Processors
Intel® Xeon® W-1290TE Processor (20M Cache, up to 4.50 GHz)
Intel® Xeon® W-1250TE Processor (12M Cache, up to 3.80 GHz)
10th Generation Intel® Core™ i9/i7/i5 Processors
Intel® Core™ i9-10900TE(20M Cache, up to 4.60 GHz)
Intel® Core™ i7-10700TE(16M Cache, up to 4.50 GHz)
Intel® Core™ i5-10500TE(12M Cache, up to 3.70 GHz)
Memory type 4 x DDR4 up to 128GB
Expansion Slot 1 PCI-E 3.0 x16
2 PCI-E 3.0 x4
Storage Device 4 x 2.5” Easy swap HDD/SSD Tray (Support RAID 0,1,5,10)
Rear I/O
Power Button 1 x w/Indicator LED
USB 2 x USB 2.0
Front I/O
Power Input 2 x 125V DC-IN
LAN 2 x RJ45 GbE LAN ; 1 x IPMI
USB 4 x USB 3.2
DisplayPort 2 x DP
DVI 1 x DVI-D
VGA 1
Power
Power Input 125V DC-IN, 2 x 200W DC/DC Redundant Power Supply(INRUSH CURRENT :
45A/110VDC)
Security
TPM 1
Management

SCH-401 User’s Manual
Revision Date: June.9.2021
6
FTDI 1
OS support list
Windows Windows 10 x64
Linux Ubuntu, Red Hat
Mechanical and Evvironmental
Dimension 430 x 450 x 88 mm ( W x D x H )
Operating Temp. -20°C to 60°C
Storage Temp. -40°C to 85°C
Relative Humidity 5% to 95%, non-condensing
Standards CE, FCC, MIL-STD 810G Compliance
System Design Fanless
Mounting 2U Rackmount
MIL-STD-810G Test
Method 507.5, Procedure II (Temperature & Humidity)
Method 516.6 Shock-Procedure V Non-Operating (Mechanical Shock)
Method 516.6 Shock-Procedure I Operating (Mechanical Shock)
Method 514.6 Vibration Category 24/Non-Operating (Category 20 & 24,
Vibration)
Method 514.6 Vibration Category 20/Operating (Category 20 & 24, Vibration)
Method 501.5, Procedure I (Storage/High Temperature)
Method 501.5, Procedure II (Operation/High Temperature)
Method 502.5, Procedure I (Storage/Low Temperature)
Method 502.5, Procedure II (Operation/Low Temperature)
Method 503.5, Procedure I (Temperature shock)
EMC CE, FCC compliant
Green Product RoHS, WEEE compliance

SCH-401 User’s Manual
Revision Date: June.9.2021
7
1.2 Front Panel I/O Placement
1) 4 x HDD Tray
2) 2 x USB2.0
3) Power Button

SCH-401 User’s Manual
Revision Date: June.9.2021
8
1.3 Rear Panel I/O Placement
1) IPMI
2) 4 x USB3.2
3) 2 x GbE
4) VGA
5) DVI-D
6) 2 x DP
7) 4 x PCIe expansion
8) 2 x DC-IN

SCH-401 User’s Manual
Revision Date: June.9.2021
9
1.4 Mechanical Dimensions

SCH-401 User’s Manual
Revision Date: June.9.2021
10
Chapter 2 : Rear I/O Ports
2.1 LAN/IPMI port
2.2 VGA/DVI-D/DP port
A VGA port and a DVI-D port are located next to DisplayPorts 1/2 on the I/O back panel. Use these
connections for VGA and DVI displays. The VGA connector is on top and the DVI-D is on the
bottom.
There are two DisplayPorts located on the rear I/O back panel. DisplayPort, developed by the VESA
consortium, delivers digital display and fast refresh rate. It can connect to virtually any display
using a DisplayPort adaptor for devices such as VGA, DVI, or HDMI.
2.3 USB3.2 port

SCH-401 User’s Manual
Revision Date: June.9.2021
11
Chapter 3 : System Setup
3.1 Removing the Top Cover from the Chassis
The sixteen screws on the top and side are used to secure the cover to the chassis. Remove these
screws and put them in a safe place for later use
3.2 Installing PCIe Card
First, you need to remove the baffle and screws. There is PCIe x4 / 8/16 slot on the motherboard,
insert the corresponding PCIe Card and lock the screw

SCH-401 User’s Manual
Revision Date: June.9.2021
12
3.3 Install the screws on the upper cover
Attach the screws at sixten locations to complete the installation
3.4 2.5” Easy Swap SSD installation
SCH-401 support four 2.5” Easy Swap SSD
• Use Tri-angle security key to open keylock and pull out the 2.5”SSD tray.
• Put 2.5”SSD on the tray and make sure SSD is fixed and push the tray back.
• Use Tri-angle security key to lock tray door
Chapter 4: AMI BIOS UTILITY
This chapter provides users with detailed descriptions on how to set up a basic system
configuration through the AMI BIOS setup utility.

SCH-401 User’s Manual
Revision Date: June.9.2021
13
4.1 Starting
To enter the setup screens, perform the following steps:
• Turn on the computer and press the <Del> key immediately.
• After the <Del> key is pressed, the main BIOS setup menu displays. Other setup screens can be
accessed from the main BIOS setup menu, such as the Chipset and Power menus.
4.2 Navigation Keys
The BIOS setup/utility uses a key-based navigation system called hot keys. Most of the BIOS setup
utility hot keys can be used at any time during the setup navigation process.
Some of the hot keys are <F1>, <F10>, <Enter>, <ESC>, and <Arrow> keys.
Left/Right The Left and Right <Arrow> keys moves the cursor to select a
menu.
Up/Down The Up and Down <Arrow> keys moves the cursor to select a
setup screen or sub-screen.
+− Plus/Minus The Plus and Minus <Arrow> keys changes the field value of a
particular setup setting.
Tab The <Tab> key selects the setup fields.
F1 The <F1> key displays the General Help screen.
F10 The <F10> key saves any changes made and exits the BIOS setup
utility.
Esc The <Esc> key discards any changes made and exits the BIOS
setup utility.
Enter The <Enter> key displays a sub-screen or changes a selected or
highlighted option in each menu.
4.3 Main Setup
When you first enter the AMI BIOS setup utility, you will enter the Main setup screen. You can
always return to the Main setup screen by selecting the Main tab on the top of the screen. The
Main BIOS setup screen is shown below and the following items will be displayed:

SCH-401 User’s Manual
Revision Date: June.9.2021
14
The Main BIOS setup screen has two main frames. The left frame displays all the options that can be
configured. Grayed-out options cannot be configured; options in blue can. The right frame displays
the key legend. Above the key legend is an area reserved for a text message. When an option is
selected in the left frame, it is highlighted in white. Often a text message will accompany it.
 System Date
Use this function to change the system date.
Select System Date using the Up and Down <Arrow> keys. Enter the new values through the
keyboard. Press the Left and Right <Arrow> keys to move between fields.
The date setting must be entered in MM/DD/YY format.
 System Time
Use this function to change the system time.
Select System Time using the Up and Down <Arrow> keys. Enter the new values through the
keyboard. Press the Left and Right <Arrow> keys to move between fields.
The time setting is entered in HH:MM:SS format.
Note: The time is in 24-hour format. For example, 5:30 A.M. appears as 05:30:00, and 5:30 P.M. as

SCH-401 User’s Manual
Revision Date: June.9.2021
15
17:30:00.
 BIOS Version
This item displays the version of the BIOS ROM used in the system.
 Build Date
This item displays the date when the version of the BIOS ROM used in the system was built.
 Memory Information
Total Memory
This item displays the total size of memory available in the system.

SCH-401 User’s Manual
Revision Date: June.9.2021
16
4.4 Advanced Setup Configuations

SCH-401 User’s Manual
Revision Date: June.9.2021
17

SCH-401 User’s Manual
Revision Date: June.9.2021
18

SCH-401 User’s Manual
Revision Date: June.9.2021
19
