IBM 306m - eServer xSeries - 8849 User manual

IBM xSeries 306m Ty pes 8849 and 8491
User’s Guide


IBM xSeries 306m Ty pes 8849 and 8491
User’s Guide


Note:
Before using this information and the product it supports, be sure to read the general information in “Notices,” on page 51.
Third Edition (March 2006)
©Copyright International Business Machines Corporation 2006. All rights reserved.
US Government Users Restricted Rights –Use, duplication or disclosure restricted by GSA ADP Schedule Contract
with IBM Corp.

Contents
Safety ............................v
Chapter 1. The xSeries 306m Types 8849 and 8491 server ........1
Related documentation ......................1
Notices and statements in this document ................2
Features and specifications .....................3
What your server offers ......................4
Reliability, availability, and serviceability features .............5
IBM Director ..........................5
The UpdateXpress program ....................6
Server controls, LEDs, and power ..................7
Front view ..........................7
Rear view ..........................8
Server power features......................8
Chapter 2. Installing options ...................11
Server components .......................11
System-board internal connectors .................12
System-board switches and jumpers ................13
System-board external connectors .................14
System-board LEDs ......................15
System-board option connectors .................16
Installation guidelines ......................17
System reliability guidelines ...................17
Handling static-sensitive devices .................18
Removing the cover .......................18
Installing an adapter .......................19
Installing ahard disk drive.....................22
Installing asimple-swap Serial ATA hard disk drive...........22
Installing ahot-swap hard disk drive ................23
Replacing aCD or DVD drive ...................24
Installing amemory module ....................25
Replacing afan.........................27
Replacing the riser-card assembly ..................29
Completing the installation.....................30
Installing the cover ......................30
Connecting the cables .....................30
Updating the server configuration .................31
Chapter 3. Configuring the server .................33
Using the ServerGuide Setup and Installation CD ............33
ServerGuide features .....................34
Setup and configuration overview .................34
Typical operating-system installation ................35
Installing your operating system without ServerGuide ..........35
Using the Configuration/Setup Utility program .............35
Starting the Configuration/Setup Utility program ............36
Configuration/Setup Utility menu choices ..............36
Passwords .........................39
Using the SAS/SATA Configuration Utility program (hot-swap SAS/SATA models
only) ............................41
Starting the SAS/SATA Configuration Utility program ..........41
SAS/SATA Configuration Utility menu choices ............41
©Copyright IBM Corp. 2006 iii

Using the Adaptec HostRAID configuration programs ...........42
Using the Adaptec RAID Configuration Utility programs (for Serial ATA
HostRAID).........................42
Using the SAS/SATA Configuration Utility program (for SAS/SATA HostRAID) 44
Using the baseboard management controller ..............45
Installing the OSA SMBridge management utility program ........45
Using the baseboard management controller utility programs .......47
Configuring the Gigabit Ethernet controllers ..............48
Updating IBM Director ......................48
Appendix. Notices .......................51
Edition notice .........................51
Trademarks ..........................52
Important notes.........................52
Product recycling and disposal ...................53
Battery return program ......................54
Electronic emission notices ....................55
Federal Communications Commission (FCC) statement .........55
Industry Canada Class Aemission compliance statement ........55
Australia and New Zealand Class Astatement ............55
United Kingdom telecommunications safety requirement.........55
European Union EMC Directive conformance statement .........55
Taiwanese Class Awarning statement ...............56
Chinese Class Awarning statement ................56
Japanese Voluntary Control Council for Interference (VCCI) statement ...56
Index ............................57
iv IBM xSeries 306m Types 8849 and 8491: User’s Guide

Safety
Before installing this product, read the Safety Information.
Antes de instalar este produto, leia as Informações de Segurança.
Pred instalací tohoto produktu si prectete prírucku bezpecnostních instrukcí.
Læs sikkerhedsforskrifterne, før du installerer dette produkt.
Lees voordat udit product installeert eerst de veiligheidsvoorschriften.
Ennen kuin asennat tämän tuotteen, lue turvaohjeet kohdasta Safety Information.
Avant d’installer ce produit, lisez les consignes de sécurité.
Vor der Installation dieses Produkts die Sicherheitshinweise lesen.
Prima di installare questo prodotto, leggere le Informazioni sulla Sicurezza.
Les sikkerhetsinformasjonen (Safety Information) før du installerer dette produktet.
Antes de instalar este produto, leia as Informações sobre Segurança.
©Copyright IBM Corp. 2006 v

Antes de instalar este producto, lea la información de seguridad.
Läs säkerhetsinformationen innan du installerar den här produkten.
vi IBM xSeries 306m Types 8849 and 8491: User’s Guide

Important:
All caution and danger statements in this documentation begin with anumber. This
number is used to cross reference an English caution or danger statement with
translated versions of the caution or danger statement in the IBM Safety Information
book.
For example, if acaution statement begins with anumber 1, translations for that
caution statement appear in the IBM Safety Information book under statement 1.
Be sure to read all caution and danger statements in this documentation before
performing the instructions. Read any additional safety information that comes with
the server or optional device before you install the device.
Statement 1:
DANGER
Electrical current from power, telephone, and communication cables is
hazardous.
To avoid ashock hazard:
vDo not connect or disconnect any cables or perform installation,
maintenance, or reconfiguration of this product during an electrical
storm.
vConnect all power cords to aproperly wired and grounded electrical
outlet.
vConnect to properly wired outlets any equipment that will be attached to
this product.
vWhen possible, use one hand only to connect or disconnect signal
cables.
vNever turn on any equipment when there is evidence of fire, water, or
structural damage.
vDisconnect the attached power cords, telecommunications systems,
networks, and modems before you open the device covers, unless
instructed otherwise in the installation and configuration procedures.
vConnect and disconnect cables as described in the following table when
installing, moving, or opening covers on this product or attached
devices.
To Connect: To Disconnect:
1. Turn everything OFF.
2. First, attach all cables to devices.
3. Attach signal cables to connectors.
4. Attach power cords to outlet.
5. Turn device ON.
1. Turn everything OFF.
2. First, remove power cords from outlet.
3. Remove signal cables from connectors.
4. Remove all cables from devices.
Safety vii

Statement 2:
CAUTION:
When replacing the lithium battery, use only IBM Part Number 33F8354 or an
equivalent type battery recommended by the manufacturer. If your system has
amodule containing alithium battery, replace it only with the same module
type made by the same manufacturer. The battery contains lithium and can
explode if not properly used, handled, or disposed of.
Do not:
vThrow or immerse into water
vHeat to more than 100°C (212°F)
vRepair or disassemble
Dispose of the battery as required by local ordinances or regulations.
Statement 3:
CAUTION:
When laser products (such as CD-ROMs, DVD drives, fiber optic devices, or
transmitters) are installed, note the following:
vDo not remove the covers. Removing the covers of the laser product could
result in exposure to hazardous laser radiation. There are no serviceable
parts inside the device.
vUse of controls or adjustments or performance of procedures other than
those specified herein might result in hazardous radiation exposure.
DANGER
Some laser products contain an embedded Class 3A or Class 3B laser
diode. Note the following.
Laser radiation when open. Do not stare into the beam, do not view directly
with optical instruments, and avoid direct exposure to the beam.
viii IBM xSeries 306m Types 8849 and 8491: User’s Guide

Statement 4:
≥18 kg (39.7 lb) ≥32 kg (70.5 lb) ≥55 kg (121.2 lb)
CAUTION:
Use safe practices when lifting.
Statement 5:
CAUTION:
The power control button on the device and the power switch on the power
supply do not turn off the electrical current supplied to the device. The device
also might have more than one power cord. To remove all electrical current
from the device, ensure that all power cords are disconnected from the power
source.
1
2
Safety ix

Statement 8:
CAUTION:
Never remove the cover on apower supply or any part that has the following
label attached.
Hazardous voltage, current, and energy levels are present inside any
component that has this label attached. There are no serviceable parts inside
these components. If you suspect aproblem with one of these parts, contact
aservice technician.
Statement 10:
CAUTION:
Do not place any object weighing more than 82 kg (180 lb) on top of
rack-mounted devices.
>82 kg (180 lb)
Attention: This server is suitable for use on an IT power distribution system,
whose maximum phase to phase voltage is 240 Vunder any distribution fault
condition.
xIBM xSeries 306m Types 8849 and 8491: User’s Guide

Chapter 1. The xSeries 306m Types 8849 and 8491 server
The IBM
® xSeries ® 306m Type 8849 and Type 8491 server is ideally suited for
networking environments that require superior microprocessor performance, efficient
memory management, and flexibility.
Performance, ease of use, and reliability were key considerations in the design of
the server. These design features make it possible for you to customize the system
hardware to meet your business needs.
The server comes with alimited warranty. For information about the terms of the
warranty and getting service and assistance, see the Warranty and Support
Information document.
The server contains IBM Enterprise X-Architecture
™ technologies, which help
increase performance and reliability. For more information, see “What your server
offers” on page 4and “Reliability, availability, and serviceability features” on page 5.
You can obtain up-to-date information about the server and other IBM server
products at http://www.ibm.com/eserver/xseries/.
Related documentation
This User’s Guide contains general information about the server, including how to
install supported options and how to configure the server. The following
documentation also comes with the server:
vInstallation Guide
This printed document contains instructions for setting up the server and basic
instructions for installing some options.
vWarranty and Support Information
This document is in Portable Document Format (PDF) on the xSeries
Documentation CD. It contains information about the terms of the warranty and
getting service and assistance.
vSafety Information
This document is in PDF on the IBM xSeries Documentation CD. It contains
translated caution and danger statements. Each caution and danger statement
that appears in the documentation has anumber that you can use to locate the
corresponding statement in your language in the Safety Information document.
vRack Installation Instructions
This printed document contains instructions for installing the server in arack.
vProblem Determination and Service Guide
This document is in PDF on the IBM xSeries Documentation CD. It contains
information to help you solve problems yourself, and it contains information for
service technicians.
Depending on the server model, additional documentation might be included on the
IBM xSeries Documentation CD.
The server might have features that are not described in the documentation that
comes with the server. The documentation might be updated occasionally to include
information about those features, or technical updates might be available to provide
additional information that is not included in the server documentation. These
©Copyright IBM Corp. 2006 1

updates are available from the IBM Web site. To check for updated documentation
and technical updates, complete the following steps.
Note: Changes are made periodically to the IBM Web site. The actual procedure
might vary slightly from what is described in this document.
1. Go to http://www.ibm.com/support/.
2. Under Search technical support,type xSeries 306m and click Search.
Notices and statements in this document
The caution and danger statements that appear in this document are also in the
multilingual Safety Information document, which is on the IBM xSeries
Documentation CD. Each statement is numbered for reference to the corresponding
statement in the Safety Information document.
The following notices and statements are used in this document:
vNote: These notices provide important tips, guidance, or advice.
vImportant: These notices provide information or advice that might help you avoid
inconvenient or problem situations.
vAttention: These notices indicate potential damage to programs, devices, or
data. An attention notice is placed just before the instruction or situation in which
damage could occur.
vCaution: These statements indicate situations that can be potentially hazardous
to you. Acaution statement is placed just before the description of apotentially
hazardous procedure step or situation.
vDanger: These statements indicate situations that can be potentially lethal or
extremely hazardous to you. Adanger statement is placed just before the
description of apotentially lethal or extremely hazardous procedure step or
situation.
2IBM xSeries 306m Types 8849 and 8491: User’s Guide

Features and specifications
The following information is asummary of the features and specifications of the
server. Depending on the server model, some features might not be available, or
some specifications might not apply.
Racks are marked in vertical increments of 4.45 cm (1.75 inches). Each increment
is referred to as aunit, or “U.” A1-U-high device is 1.75 inches tall.
Table 1. Features and specifications
Microprocessor:
One Intel
® LGA 775 Pentium ® IV w/
1024 KB (minimum) Level-2 cache
Note: Use the Configuration/Setup
Utility program to determine the type
and speed of the microprocessor.
Memory:
vMinimum: 512 MB
vMaximum: 8GB
vType: PC4200, 533 MHz, ECC,
DDR II unbuffered SDRAM DIMMs
only
vSlots: Four dual inline
vSupports 512 MB, 1GB, and 2GB
DIMMs
Drives:
CD/DVD: Ultrabay Enhanced
Expansion bays:
Two 3.5-inch slim-high bays for hard
disk drives.
vHot-swap models: Supports
maximum of two serial-attached
SCSI (SAS) drives or two serial
ATA (SATA) drives
vSimple-swap models: Supports
maximum of two SATA drives
Expansion slots:
vTwo 66/100 MHz/64-bit PCI-X slots
vUpgradable to one PCI Express x8
slot and one 66/100 MHz/64-bit
PCI-X slot
Video controller:
vATI RN50B video on system board
vCompatible with SVGA and VGA
v16 MB DDR video memory
Power supply:
350 watt (110 or 220 Vac
auto-sensing)
Size:
vHeight: 43 mm (1.70 inches)
vDepth: 559 mm (22 inches)
vWidth: 440 mm (17.32 inches)
vMaximum weight: 12.7 kg (28 lb)
depending on your configuration
Integrated functions:
vTwo Broadcom NetXtreme
™ GB
Ethernet controllers on the system
board with Wake on LAN
® support
vSerial port
vFour USB ports (two on front and
two on rear of server)
vKeyboard port
vMouse port
Hard disk controllers:
vSerial ATA (SATA) controller with
integrated RAID (simple-swap
SATA models)
vSerial-attached SCSI (SAS)
controller with integrated RAID
(hot-swap SAS/SATA models)
Acoustical noise emissions:
vSound power, idling: 65 decibel
maximum
vSound power, operating: 65
decibel maximum
Environment:
vAir temperature:
–Server on: 10° to 35°C (50.0°
to 95.0°F); altitude: 0to 914 m
(2998.7 ft)
–Server off: -40° to 60°C
(-104° to 140°F); maximum
altitude: 2133 m(6998.0 ft)
v
Humidity:
–Server on: 8% to 80%
–Server off: 8% to 80%
Heat output:
Approximate heat output in British
thermal units (Btu) per hour:
vMinimum configuration: 341 Btu (100
watts) per hour
vMaximum configuration: 1024 Btu
(300 watts) per hour
Electrical input:
vSine-wave input (47-63 Hz) required
vInput voltage low range:
–Minimum: 100 Vac
–Maximum: 127 Vac
v
Input voltage high range:
–Minimum: 200 Vac
–Maximum: 240 Vac
v
Input kilovolt-amperes (kVA),
approximately:
–Minimum: 0.102 kVA
–Maximum: 0.55 kVA
Notes:
1. Power consumption and heat
output vary depending on the
number and type of optional
features installed and the
power-management optional
features in use.
2. These levels were measured in
controlled acoustical environments
according to the procedures
specified by the American National
Standards Institute (ANSI) S12.10
and ISO 7779 and are reported in
accordance with ISO 9296. Actual
sound-pressure levels in agiven
location might exceed the average
values stated because of room
reflections and other nearby noise
sources. The declared sound-power
levels indicate an upper limit, below
which alarge number of computers
will operate.
Chapter 1. The xSeries 306m Types 8849 and 8491 server 3

What your server offers
The server uses the following features and technologies:
vBaseboard management controller
The baseboard management controller provides basic service-processor
environmental monitoring functions. If an environmental condition exceeds a
threshold or if asystem component fails, the baseboard management controller
lights LEDs to help you diagnose the problem. Critical errors are also included in
the error log.
vIBM Director
IBM Director is aworkgroup-hardware-management tool that you can use to
centrally manage xSeries servers. For more information, see the IBM Director
documentation on the IBM Director CD.
vIBM Enterprise X-Architecture technology
IBM X-Architecture technology combines proven, innovative IBM designs to make
your Intel-processor-based server powerful, scalable, and reliable. For more
information, see http://www.ibm.com/servers/eserver/xseries/xarchitecture/
enterprise/index.html.
vLarge system-memory capacity
The memory bus supports up to 8GB of system memory. The memory controller
supports error correcting code (ECC) for up to four industry-standard PC4200,
533 MHz, ECC, double-data-rate (DDR) II unbuffered synchronous dynamic
random access memory (SDRAM) dual inline memory modules (DIMMs).
vIBM ServerGuide
™ Setup and Installation CD
The ServerGuide Setup and Installation CD that comes with the server provides
programs to help you set up the server and install a32-bit Windows
® operating
system. The ServerGuide program detects installed hardware options and
provides the correct configuration programs and device drivers. For more
information about the ServerGuide Setup and Installation CD, see “Using the
ServerGuide Setup and Installation CD” on page 33.
vIntegrated network support
The server comes with an integrated Intel Gigabit controller, which supports
connection to a10-Mbps, 100-Mbps, or 1000-Mbps network. For more
information, see “Configuring the Gigabit Ethernet controllers” on page 48.
vLarge data-storage capacity
The server supports up to two 25.4-mm (1-inch) slim-high, 3.5-inch hard disk
drives (Serial Advanced Technology Attachment (SATA) or serial-attached SCSI
(SAS), depending on server model).
vServeRAID
™ support
The server supports ServeRAID adapters to create redundant array of
independent disks (RAID) configurations.
vSystems-management capabilities
The server supports an optional IBM Remote Supervisor Adapter II. When this
adapter is used with the integrated baseboard management controller that comes
with the server, you can manage the functions of the server locally and remotely.
The Remote Supervisor Adapter II also provides system monitoring, event
recording, and dial-out alert capability.
4IBM xSeries 306m Types 8849 and 8491: User’s Guide

Reliability, availability, and serviceability features
Three important computer design features are reliability, availability, and
serviceability (RAS). The RAS features help to ensure the integrity of the data that
is stored in the server, the availability of the server when you need it, and the ease
with which you can diagnose and repair problems.
The server has the following RAS features:
vAdvanced Configuration and Power Interface (ACPI)
vAdvanced Desktop Management Interface (DMI) features
vIntelligent Platform Management Interface (IPMI) 1.5 support providing secure
remote power on/power off and seven standard alerts for components such as
fans, voltage, and thermals
vAutomatic restart after power failure
vAuto-restart initial program load (IPL)
vBoot-block recovery
vBuilt-in, menu-driven configuration and setup programs
vCooling fans with speed-sensing capability
vCustomer-upgradeable basic input/output system (BIOS) code
vECC memory
vError codes and messages
vMenu-driven diagnostic programs on CD
vMonitoring support for temperature, voltage, and fan speed
vParity checking on the SAS bus and PCI bus
vPower-on self-test (POST)
vRead-only memory (ROM) checksums
vSDRAM with serial presence detect (SPD)
vServer management
vStandby voltage for system management features and monitoring
vSystem error log (with an optional Remote Supervisor Adapter II installed)
vVital product data (VPD); includes information stored in nonvolatile memory for
easier remote viewing
vWake on LAN
IBM Director
With IBM Director, anetwork administrator can perform the following tasks:
vView the hardware configuration of remote systems, in detail
vMonitor the usage and performance of critical components, such as
microprocessors, disks, and memory
vCentrally manage individual or large groups of IBM and non-IBM Intel-based
servers, desktop computers, workstations, and mobile computers on avariety of
platforms
IBM Director provides acomprehensive entry-level workgroup hardware manager.
Key features include:
vAdvanced self-management capabilities for maximum system availability
vMultiple operating-system platform support, including Microsoft
® Windows 2000
Server, Windows XP Professional, Red Hat Linux, SUSE LINUX, and Novell
Chapter 1. The xSeries 306m Types 8849 and 8491 server 5

NetWare. For acomplete list of operating systems that support IBM Director, see
the IBM Director Compatibility Document. This document is in Portable Document
Format (PDF) at http://www.ibm.com/servers/eserver/xseries/
systems_management/sys_migration/ibmdiragent.html. It is updated every 6to 8
weeks.
vSupport for IBM and non-IBM servers, desktop computers, workstations, and
mobile computers
vSupport for systems-management industry standards
vIntegration into leading workgroup and enterprise systems-management
environments
vEase of use, training, and setup
IBM Director also provides an extensible platform that supports advanced server
tools that are designed to reduce the total cost of managing and supporting
networked systems. By deploying IBM Director, you can achieve reductions in
ownership costs through the following benefits:
vReduced downtime
vIncreased productivity of IT personnel and users
vReduced service and support costs
For more information about IBM Director, see the IBM Director CD that comes with
the server, the IBM Director documentation on the CD, and the IBM xSeries
Systems Management Web page at http://www.ibm.com/servers/eserver/xseries/
systems_
management/xseries_sm.html, which presents an overview of IBM Systems
Management and IBM Director.
The UpdateXpress program
The UpdateXpress program is available for most xSeries servers and server
options. It detects supported and installed device drivers and firmware in the server
and installs available updates. You can download the UpdateXpress program from
the Web at no additional cost, or you can purchase it on aCD. To download the
program or purchase the CD, go to http://www.ibm.com/servers/eserver/xseries/
systems_management
/sys_migration/xpress.html.
6IBM xSeries 306m Types 8849 and 8491: User’s Guide

Server controls, LEDs, and power
This section describes the controls and light-emitting diodes (LEDs) and how to turn
the server on and off.
Front view
The following illustration shows the controls, light-emitting diodes (LEDs), and
connectors on the front of the server.
Power-on LED
Power-control button
Reset button
Hard disk drive activity LED
Locator LED
System-error LED
USB 1 connector
USB 2 connector
CD-eject button
CD drive activity LED
Power-on LED: When this LED is lit, it indicates that the server is turned on. When
this LED is off, it indicates that ac power is not present, or the power supply or the
LED itself has failed.
Note: If this LED is off, it does not mean that there is no electrical power in the
server. The LED might be burned out. To remove all electrical power from the
server, you must disconnect the power cord from the electrical outlet.
Power-control button: Press this button to turn the server on and off manually. A
power-control-button shield comes installed around the button to prevent the server
from being turned off accidentally. You can remove this disk-shaped shield if you
prefer.
Reset button: Press this button to reset the server and run the power-on self-test
(POST). You might have to use apen or the end of astraightened paper clip to
press the button.
Hard disk drive activity LED: When this LED is flashing, it indicates that ahard
disk drive is in use.
Locator LED: When this LED is lit, it has been lit remotely by the system
administrator to aid in visually locating the server.
System-error LED: When this LED is lit, it indicates that asystem error has
occurred.
USB connectors: Connect aUSB device to either of these connectors.
CD-eject button: Press this button to release aCD from the CD drive.
CD drive activity LED: When this LED is lit, it indicates that the CD drive is in use.
Chapter 1. The xSeries 306m Types 8849 and 8491 server 7

Rear view
The following illustration shows the LEDs on the rear of the server.
Ethernet 1 transmit / receive
activity LED
Ethernet 2 transmit / receive
activity LED
Ethernet 1 speed LED
Ethernet 2 speed LED
Ethernet transmit/receive activity LED: This LED is on each Ethernet connector.
When this LED is lit, it indicates that there is activity between the server and the
network.
Ethernet speed LED: This LED is on each Ethernet connector. When this LED is
lit, it indicates that the Ethernet network speed is 1Gbps. When this LED is off, it
indicates that the Ethernet network speed is 10 Mbps or 100 Mbps.
The following illustration shows the connectors on the rear of the server.
Power-cord connector
Mouse connector
Keyboard connector
Serial connector
Video connector
Ethernet 2 connector
Ethernet 1 connector
USB 1 connector
USB 2 connector
Power-cord connector: Connect the power cord to this connector.
Keyboard connector: Connect aPS/2 keyboard to this connector.
Mouse connector: Connect amouse or other PS/2 device to this connector.
Serial connector: Connect a9-pin serial device to this connector.
Video connector: Connect amonitor to this connector.
Ethernet connector: Use either of these connectors to connect the server to a
network.
USB connector: Connect aUSB device to either of these connectors.
Server power features
When the server is connected to an ac power source but is not turned on, the
operating system does not run, and all core logic except for the service processor
(the mini-baseboard management controller or optional Remote Supervisor Adapter
II) is shut down; however, the server can respond to requests from the service
processor, such as aremote request to turn on the server.
8IBM xSeries 306m Types 8849 and 8491: User’s Guide
