A-MTK AH21K9M User manual

w ww. a -m tk . co m
sales@a -mt k .c om
TE L: +8 8 6- 2 - 8226 9 85 5
FA X : + 88 6 -2- 82269800
A-MTK 2016 new launching the AH21K9M PnP wireless IP camera! The new
PnP cam provides you all the protection functions you need:
1. PIR for human detection
2. Motion detection for moving object
3. Audio detection for abnormal sound
4. Camera tampering for prevent IP camera from broken
5. Built in IR LED and ICR, day and night surveillance

w ww. a -m tk . co m
sales@a -mt k .c om
TE L: +8 8 6- 2 - 8226 9 85 5
FA X : + 88 6 -2- 82269800
Upon the above detections happening, A-MTK smart phone apps will trigger
different actions to warn you:
1. Audio alert
2. Send push notify to smart phone
3. Save event video to mSD card
4. Send event video to your Google drive
Easy, user friendly setup
Step 1: When you firstly get the AH21K9M, only need to plug and power,
download smart phone apps:
Panoview (for Andorid ) i-Panoview (for iOS)
Step 2: Open the APPs and click “First Install”

w ww. a -m tk . co m
sales@a -mt k .c om
TE L: +8 8 6- 2 - 8226 9 85 5
FA X : + 88 6 -2- 82269800
Step 3: Choose “WIFI”
Step 4: Type your Access point Wifi password, and IP camera password.
Then Apps will searching for wireless cameras in same access point

w ww. a -m tk . co m
sales@a -mt k .c om
TE L: +8 8 6- 2 - 8226 9 85 5
FA X : + 88 6 -2- 82269800
Step 4: Apps automatically find the camera
Now, you get the live video!
Everything on mobile phone
Setup motion detection window on A-MTK apps; playback mSD card or
Google drive video on A-MTK apps

w ww. a -m tk . co m
sales@a -mt k .c om
TE L: +8 8 6- 2 - 8226 9 85 5
FA X : + 88 6 -2- 82269800
General Specification
Model AH21K9M
Effective Pixel: 720P HD
Lens: fixed: 2.6mm
IR LED: High-light IR LED * 1pc, ICR for day and night
Video
Video Encoder: H.264
Video Resolution: User can choose HD or VGA resolution for live view and
recording.
Dual streaming
Live View: 4pcs IP cams quad view
Audio
Audio CODEC: AAC
Audio Input / Out: Built-in MIC. Built-in speaker
Network
Ethernet: 10/100M auto negotiation
Wireless: 802.11n
Device ID: Dips ID
Security: HTTPS encryption
Users: 2 simultaneous users ( to one IP cam)
System Integration

w ww. a -m tk . co m
sales@a -mt k .c om
TE L: +8 8 6- 2 - 8226 9 85 5
FA X : + 88 6 -2- 82269800
Alarm Triggers: PIR detector for human detection (far-infrared), Motion
detection, Camera tampering, Audio Detection
Motion Detection: Video motion detection up to 9 windows
Alarm Events: Video file or Snapshot upload to Google drive™, Video file or
Snapshot save to IP cam mSD card, Audio alert to IP camera speaker out,
Push notify to “Panoview” or “i-Panoview”
General
Power Supply: 12V DC external power adapter
Connectors: RJ-45 10BaseT/100Base, TXSMA Antenna, 12V DC power jack,
mSD card, Factory default reset
Indication LED: Green and orange LEDs
Operating Temperature: 0°C ~ 40°C
Operating Humidity: 20% ~ 80% (non-condensing)
Panoview™ supported OS
Android: Android 4.4 or above
iOS: iOS 9.0 or above
