A1TECH RPOSTAR Gold User manual

65K Color OLED
3D effect animation
Long RF range
Full-down menu
Li-Polymer battery
Touch unlock
￭ 65K Color OLED Rechargeable Li-Polymer Battery ￭
￭ 3D Motion Video Long RF Range ￭
￭ Touch Unlock Pull-down Menu ￭
Gold
Full Color 2-way Remote Car Starter & Alarm System
A1Tech Inc.
Note : This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
zReorient or relocate the receiving antenna.
zIncrease the separation between the equipment and receiver.
zConnect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
zConsult the dealer or an experienced radio/TV technician for help.
The device complies with Part 15 of FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) This device must accept any
interference received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for Compliance
could void the user's authority to operate the equipment.
Connecting of peripherals requires the use of grounded shielded signal cables.

3
Adopted 65,000 colour Organic Light Emitting Diode (OLED). OLED is self-emissive and
has the following advantages: great brightness, fast response time for full motion
video, full viewing angles, light weight, great durability, power efficiency, broad
operating temperature ranges. Be noted that this 3-button remote with a built-in
buzzer is not waterproof.
4
￭ This product is for DC 12V vehicles only.
￭ The quality of this product is guaranteed only when installed by a technician of our
dealer according to installation instruction.
￭ This alarm system is not able to protect the vehicle completely from the burglary.
We hold no liability for an accident caused by wrong installation.
￭ Keep the remote control dry. Do not drop or disassemble it.
￭ In case of missing remote control contact the dealer near you to delete the old code
and input the code of new remote control.
￭ Pull on the hand brake of a manual transmission vehicle on a steep hill to prevent car
accident and do not start your car remotely. (See page 9 to cancel the reservation.
)
￭ Shock sensor may make a false alarm when a strong inducted current happens like
thunder or lightning. Adjust the sensitivity of the sensors properly to prevent a
false alarm.
￭ Make it sure not to use in the closed area to prevent air-pollution.
Do not exceed the legally permitted engine runtime.
￭ This system uses low-powered radio wave. Hence, the operating range may be
shortened due to jamming or weather.
￭ This product is designed for installation in practically all cars. However, in case of
improper installation, unfit electrical system or aged cars the system features may
operate irregularly and malfunction.
￭ Please note the phone number of the authorized dealer or installer for emergency.
Remote Control
Remote
∙Lock/Unlock
∙Panic Siren
∙Previous Menu
∙Status Check
∙Select/Setup Menu
∙Remote Start
∙Move/Save
Time∙
Door Lock∙
Temperature∙
Mute∙
Valet∙
Proximity∙
∙Battery Level
∙Timer Start
∙Turbo
∙Silent Alarm
■ The images of the remote control are subjected to change.
Before Usage
■ Power ON/OFF
Press button II + III for 5 sec. to turn on/off the power. We recommend
to turn off the power if you don't use the remote control for long time.

In case of button lock-out, errors or freeze of the display it is recommended to re-set
your remote control.
Your lovely picture can be saved and displayed.
Send your own image (jpg format) and the remote
to near dealer.
Powered by a built-in 3.7V Lithium Polymer battery.
If the battery level shows one bar, charge your remote.
The LED of the charger lights GREEN when the battery is full
(after ca. 15￣30 min.). Refrain from unnecessary pressing of the
buttons to prevent rapid current consumption.
Plug-in Car Charger
5
Attach the touch sensor on the front windshield. You can lock and
unlock the doors without a key or remote by fingering of the saved
4-digit PIN on the touch sensor. ☞ See page 15 how to use.
The LED in the middle indicates current status of the system.
6
Communication Module & Touch Sensor
Attach the antenna (so-called Transceiver) on the front windshield or frame.
When attached on the place where the window is tinted, the operating range can be
apparently shortened due to RF interception.
￭ LED Indicator
R/B flash continuously: system armed
Red flashes: the vehicle is attacked
Blue On: valet mode
Blue flashes: auto-arming
LED Off: system disarmed
󰏉 We recommended to remove stuff (like snow and mud) and to dry the part
around the sensor on the front windshield.
Don't use the touch sensor with the gloved finger.
￭ Adjustment of the Proximity
Adjust the sensitivity of the proximity
(
key-
less entry) by turning of the screw in the
middle. Turn it clockwise to diminish, and
counter-clockwise to increase the distance.
Touch Sensor
Communication Module
Reset
Remote Control
Image Box (Optional)
Charging the Battery
✔ To reset prick a pin into the small hole in the middle of the left side.
✔ To view the image (2 sec. long) press button II.
TOUCH
󰏉 Use the supplied plug-in car charger ONLY. Otherwise, the
battery could explode or the remote's circuit can go wrong.
Plug in the charger when the engine is running.

Door Lock/Unlock Remote Start Long
Panic Siren 3 sec. Trunk Open
Status Check Valet Mode
To check the communication between the remote and the system press button II.
The interior temperature and the current status (arming mode, disarmed or out of range)
of your vehicle will be displayed.
➠
There are 2 kinds of system operating using the remote.
The one is pressing the buttons directly and the other is
to use the pull-down menu.
5 sec.
※ You can easily operate the features like Panic Siren, Remote Start, Trunk Open and Valet
by using pull-down menu. Refer to page 8.
7
5 sec.
■ Operation
Operating by the remote. Move and select a function, and press II to operate.
➠
■ Watch
Set current time. Be noted that there could be a time tolerance.
➠
■ System Setting
You can setup the system features.
➠
8
Communication
Operating using Remote
Operating and Setting by Pull-down Menu
Pull-down Menu
RF Range Check
Press button II for 5 sec. to enter the pull-down menu.
Choose one of 3 menus (Operation/Watch/System Setting) and
select a feature you want to operate or setup.
Button I for previous menu, button II for select/operate/save and
button III for move through the (sub-)menus.
12:25P
Power ON/OFF

I or 3 sec.
I
9
I + III
When your vehicle is being valet parked, washed or serviced, you can temporarily
suspend alarm features and remote engine starting except lock/unlock and trunk open.
I + II
3 sec.
10
Features
Features
Arming / Door Lock
• Doors locked • 1 chirp
• System armed • 1 flash
• Blue and red LED blinking
• If your remote beeps 5 sec. after door lock, you have left a door ajar. No siren.
The door icon is displayed with beeps.
• The alarm system is fully armed 15 sec. after door lock.
• For ordinary operation make sure that the dome-light switch is set to illuminate
when a door is opened.
• When attacked, the red LED blinks.
Disarming / Door Unlock
• Doors unlocked • 2 chirps
• System disarmed • 2 flashes
• If the system makes 4 chirps and 4 flashes, the door, hood or trunk was opened
in your absence. 3 chirps and 3 flashes mean your car was bumped or hit.
• If you unlock (disarm) the doors and don't get into the carr within 30 sec., the
doors will be automatically re-locked (re-armed).
Power Trunk Open
✔ When you open the trunk remotely, the sensors don't work for 30 sec.
Remote Valet
• 1 chirp • 1 flash
• Key ON- Blue LED 10 sec.
Panic Siren
• Continuous siren and flash
♻ To exit valet mode repeat the procedure above. (2 chirps)
✗ To stop the siren press button II.

➠
To prevent unforseen accident the gear should be in neutral position.
For your safety the system must be reserved as follows:
①. Set neutral gear and remove the key. The engine will run up to 1 min.
②. Exit the vehicle and lock the doors. The engine turns off and the system is armed.
11
With chirps and flashes you can easily find your car in the night/crowded area.
➠
The engine starts at the preset time. This feature is active only while arming mode.
When the time is pre-set, the icon appears on the display.
➠ ▶
The chirp sound is muted when the remote activates your vehicle.
The icon is displayed when set on.
➠
12
Features Features
Remote Engine Starting
• The engine runs for programmed time (see page 19) and stops automatically if left
unattended. Heater (or air-conditioner) is activated 1 min. after the engine start.
• For climate control, you must preset the heater (or air-conditioner) to the desired
position before exiting the vehicle.
• If failed in the first attempt, it tries to start the engine 2 more attempts.
• While running the system is fully armed except shock sensing.
• 1 chirp ➟ 3 chirps
• 1 flash ➟ continuous
✗ To shut off the engine: press button III again, or unlock and lock the doors.
Reservation for Manual Transmission
✗ Cancellation
• If you OPEN a door without starting, the remote engine starting is cancelled.
New reservation above mentioned is necessary.
• If you open the door before you remove the key, the engine turns off immediately
and the remote engine starting is NOT reserved.
• If you unlock and lock the doors (none of the doors is opened) while engine is
running, the remote engine starting is still reserved.
Car Finder
Mute
✗ To cancel the time: repeat the procedure above. disappears.
Programmable Timer Start
✗ Repeat the procedure above to return to normal mode. disappears.
6:20A

In case of door-, hood-, trunk- or shock-sensing while arming, the siren howls, the
parking lights flash and the warning red LED blinks rapidly.
13
Sometimes it is useful to keep your car running if you drop by at a convenience store,
remove the key and lock the doors. All security functions operate normally except
shock sensing while the engine is running.
➠ ➠
Press III Remove the key Close the door Lock
The starter kill will protect your vehicle from missing by disabling the engine starter
while the system is armed. An optional SPDT relay should be installed.
If someone tries to start your car, the starter is interrupted and the siren sounds.
An additional shock sensor, ultrasonic sensor or pin switch can be installed to reinforce
your car security. Ask near dealer.
Extra one-way remote control (Watchcon) can be coded and used together with the
main remote control. To input the code see page 16.
14
Convenient Features
Security
Alarm Trigger
• Continuous Siren
• Continuous Flash
• Warning red LED
• External shock sensor: It chirps and flashes for 10 sec.
• Optional shock sensor or ultrasonic sensor: Siren works for 30 sec.
• Door, hood or trunk opened: Siren sounds for 30 sec. When sensing continuously,
it goes on with the siren (30 sec.) at an interval of 5 sec.
• For hood- and trunk-sensing you may install an optional pin switch.
✗ To turn off the siren: Press button II or unlock the door (button I).
Starter Kill (optional)
Quick Service
Sensor Extension (optional)
Spare Remote Control

If you are the unfortunate victim of a car hijacking, be sure that the thief will not get
away with your car! The engine will run only if you press III after unlocking the doors.
➠ ➠
Press I Press III Engine start
■ How to set
To use this feature you need an optional relay.
Set as described below after the installation of the relay.
➠ ➠ ➠
Open the door Key ON Press and hold 5 sec. Beep
When set on (follow the description below), the dual unlock pulse will be generated when
you press button I (unlock the doors).
➠ ➠ ➠
Open the door Key ON Press and hold 10 sec. Beep
When it comes to the crunch (or in emergency)
you can open the door without a key or remote
control by touching on the touch sensor.
1. Touch the LED 10 times.
2. The red LED turns on. (within 5 sec.)
3. Touch the first digit.
(The blue LED flashes once for every touch.)
4. The red LED flashes. (within 5 sec.)
5. Repeat the steps 3 and 4 for the next 3 digits.
6. Is PIN accepted, the doors are unlocked.
➠ ➠ ➠
10 times LED on Input 4-digit PIN Unlock
16
Convenient Features
PIN Unlock
󰏉 For the touch sensor responds to the weak electric current of the finger it is
strongly recommended to remove stuff (like snow and mud) and to dry the part
around the sensor on the front windshield.
Do not use the touch sensor with the gloved finger.
(Ex.: PIN is 1578)
☞ ☀ Touch 10 times
☀ LED On
☞ ☀ Touch 1 time
☀ LED On
☞ ☀ Touch 5 times
☀ LED On
☞ ☀ Touch 7 times
☀ LED On
☞ ☀ Touch 8 times
☀ LED On
• If 5 consecutive attempts went failed within 30 min., this feature doesn't work for
the next 24 hours. (When unlocked remotely, you can use this feature again.)
• In case of wrong number or interruption the driver is paged.
Dual Unlock Pulse
Anti-hijack
✗ To cancel dual unlock pulse : repeat the procedure above. (2 chirps)
Convenient Features
✗ To exit Anti-hijack : repeat the procedure above. (2 chirps)
In not use, you don't need to press button III for starting the engine.

■ How to input my PIN
1. Open the door and turn the key On and Off 5 times.
2. Red and blue LED blinking. (within 30 sec.)
3. Input the first digit. (a blue flash for every single touch)
4. Red flashes for the number of the digit after 1.5 sec.
5. Repeat steps 2nd, 3rd and 4th digits.
6. When finished, the blue and red LED verify the PIN. (red -> first digit: blue -> red
-> second digit: blue -> red -> third digit: blue -> red -> fourth digit)
Open the door Key ON Red/Blue Input PIN
17
The user can set up the system features according to the car type.
It is recommended NOT to change the system setting once selected.
Menu ➪ System Setting ➪ Move to Sub-menu ➪ Select
Press button II to save the feature.
After engine starting by the key the doors
will be locked after 5 sec. and unlocked
automatically when the engine is shutoff.
[Menu ➪ System ➪ Ignition Lock ➪ On] ▶
For the turbo vehicles: the engine will run
for 2 min. after the engine shutoff.
When selected, will appear. ▶
[Menu ➪ System ➪ Turbo ➪ On]
The doors will be automatically unlocked
when you approach, and locked when you
go away from your car. ▶
When selected, will appear.
[Menu ➪ System ➪ Proximity ➪ On]
18
System Setting
Ignition-controlled Door Lock
Turbo
Proximity (Key-less Entry)
󰏉 Be noted that the proximity could operate irregularly or malfunction due to
radio jamming etc.
Convenient Features
✔ If you don't input the new PIN within 30 seconds, the old PIN is deleted
and the function "Touch Unlock" doesn't operate.

When set on ( is displayed), siren and flash
won't be activated in case of being attacked.
The remote notices you the attach with beeps
and icon. This is useful in anti-noise area or ▶
when seeking for an offender.
[Menu ➪ System ➪ Siren ➪ Off]
You can select the arming mode.
Active Arming: After getting off the system will
be automatically armed when all doors are closed.
Passive Arming: After getting off the system will ▶
be armed only if you lock the doors remotely.
[Menu ➪ System ➪ Arming Mode ➪ Active]
You can select the (remote start) engine runtime
among 3 min., 15 min. and 25 min.
[Menu ➪ System ➪ Engine Run ➪ 15/25/3 min.]
▶
In case of malfunction or mishandling of the
remote control, you can initialize it.
Be noted that the time will be re-set and
the current time should be set newly. ▶
[Menu ➪ System ➪ Factory Setup ➪ Default]
19
The remote control is not taught to the system. So, you must input the code after the
installation. This system will learn up to 3 remote controls.
Open the door 7 times Beep Press II Beep
1. Open the door and turn the key to 'OFF'.
2. Turn the key to "ON and OFF" 7 times. (1 chirp)
3. Press button II within 5 sec. The code is saved with chirps.
If you have lost a remote or the system malfunctions without particular reason, it is
strongly recommended to erase the current code to prevent your car from being
stolen. In this case the system is initialized so that new remote should be coded again.
Open the door 10 times Beep Beep
1. Open the door and turn the key to 'ON'.
2. Turn the key to "OFF and ON" 10 times. The system is initialized with 2 chirps.
20
System Setting
Silent Alarm
Active/Passive Arming
Engine Runtime
Factory Setup
Learn Routine
System Initialization
✔ To input 2~3 remote controls press button II one after another.
✔ Turn the key 10 times through even if you hear chirps in between.
Technical Support
