A&D BA-T Series User manual

BA-6TE
BA-6DTE
BA-225TE
BA-225DTE
BA-125DTE
1WMPD4004315

© 2021 A&D Company Ltd. All rights reserved.
No part of this publication may be reproduced, transmitted, transcribed, or translated into
any language in any form by any means without the written permission of A&D Company
Ltd.
The contents of this manual and the specifications of the instrument covered by this
manual are subject to change for improvement without notice.
Windows, Word and Excel are trademarks of the Microsoft Corporation., registered in the
U.S. and other countries and regions.
Mac and macOS are trademarks of Apple Inc., registered in the U.S. and other countries
and regions.
Product names and company names mentioned in this manual are trademarks or
registered trademarks of their respective companies in Japan or other countries and
regions.

3
Contents
1. Introduction.................................................................................................................................... 7
2. Part Names, Installation and Precautions..................................................................................... 9
3. Screens and Operations (Keys and Buttons).............................................................................. 19
4. IR Sensors and Auto Doors ........................................................................................................ 24
5. Application................................................................................................................................... 26

4
6. Quick Performance Check [Repeatability Measurement] Screen ................................................................... 51
7. Communication device................................................................................................................ 52
8. Password Function...................................................................................................................... 54
9. Menu Screen ............................................................................................................................... 61
10. [Sensitivity adjustment] screen.................................................................................................... 62
11. Calibration test/check.................................................................................................................. 69
12. Filter Settings .............................................................................................................................. 96
13. System settings ........................................................................................................................... 97

5
14. Underhook................................................................................................................................. 124
15. Interface Specifications (Standard) ........................................................................................... 125
16. Connection with Peripheral Devices ......................................................................................... 130
17. Printing Weighing Value Data with a Printer ............................................................................. 133
18. Connecting to a Personal Computer......................................................................................... 136

6
19. Data Output ............................................................................................................................... 139
20. Command.................................................................................................................................. 150
21. Error Codes ............................................................................................................................... 155
22. Ionizer (AX-ION-25) .................................................................................................................. 158
23. Maintenance.............................................................................................................................. 160
24. Troubleshooting ........................................................................................................................ 160
25. Specifications ............................................................................................................................ 162
26. Compliance ............................................................................................................................... 169

7
1. Introduction
Thank you for purchasing A&D’s electronic balance.
Please read this instruction manual carefully to understand and make full use of the BA-T series
analytical electronic balance.
Caution
Operations may differ depending on the software version of your balance.
For confirmation of the software version of the balance, refer to “13.23. Software version”.
Features
A 5-inch touch screen is adopted for easy operation.
Intuitive operation is provided through the touch screen.
Equipped with the breeze break auto doors that can be opened and closed without touching them.
The removable breeze break makes it easy to clean the inside of the weighing chamber.
A self check function is included for automatically evaluating repeatability performance without a weight.
The BA-T series can automatically perform sensitivity adjustment with the internal weight. (Automatic
sensitivity adjustment)
(Temperature change, set time, fixed time interval [interval time])
When performing the sensitivity adjustment/calibration test, etc. for the balance, the output
corresponding to GLP/GMP, etc. can be output.
Using a printer (sold separately), it is possible to record the sensitivity adjustment/calibration test
results.
GLP :Good Laboratory Practice. Standards for implementing safety tests for drugs and medicines.
GMP :Good Manufacturing Practice. Rules for manufacturing and quality control.
The clock built into the balance allows you to output the weighing value with the date and time.
(The clock settings can be restricted so that only the Administrator can change them. [Password
function])
The BA-T series comes standard with the underhook for weighing magnetic materials.
Four different applications are available.
Normal weighing, counting mode, percent weighing, minimum weight alert function.
BA-6DTE, BA-225DTE and BA-125DTE have the smart range function as standard. This function allows
for weighing with the precision range after subtracting the tare within the weighing capacity.
The readability of precision range for BA-6DTE is 1 μg.
The readability of precision range for BA-225DTE and BA-125DTE is 10 μg.
With the password function, the sensitivity adjustment of the balance and the operation of changing the
function table can be restricted.
An RS-232C interface, USB interface, Ethernet and Bluetooth for outputting the weighing value and
data of the balance are equipped as standard.
It is possible to communicate with a Windows personal computer that has data communication software
WinCT or WinCT-Plus installed. The software can be downloaded from our website
(https://www.aandd.jp).

8
The BA-T series is equipped with a DC type ionizer (static eliminator) that does not generate wind, and
eliminates static electricity from charged objects before weighing in order to reduce errors due to static
electricity. The discharge electrode unit of the ionizer can be removed and can be cleaned and replaced
by itself.

9
2. Part Names, Installation and Precautions
Caution
This product is a precision instrument, and it should be carefully unpacked.
It is advisable to store the packing materials so that they can be used when transporting the balance for
repair.
The contents of the package vary depending on the product. Refer to the illustration of the packing
contents and make sure that everything is included.
Do not connect the AC adapter to the balance until the balance is assembled and installed.
Do not connect the included AC adapter to other devices.
Use the dedicated AC adapter specified for the balance.
If you use the wrong AC adapter, the balance and other equipment may not work properly.
Make sure that the AC adapter is unplugged before you connect the breeze break unit and the ionizer.
BA-T series analytical balance is composed of the weighing unit and display unit. It is not possible to
replace just one of the units.

10
Weighing unit
Display unit
protection cover Breeze break top door
Breeze break
bottom plate
Quick Start Guide
Tweezers
Display unit
USB cable
(approx. 1.8 m)
Cable A
(approx. 0.2 m)
Cable B
(approx. 1.0 m)
Cable C
(
approx. 0.6 m)
Ionizer AC adapter
Pan A, φ25 Pan support A
Breeze break front glass
Breeze break unit
Breeze break ring A
Dust plate A
Small glass breeze break set
Breeze break doors
Aluminum round pans for analysis (10 pieces each)
Side panes
(3 pieces)
Top pane
Base stand
Large pan,
φ
15, 0.8 mL
Medium pan,
φ
12, 0.3 mL
Small pan,
φ
8, 0.05 mL
Pan B, φ85 Breeze break ring B
Dust plate B
Breeze break
front glass
Breeze break unit
Breeze break doors
Unpacking
Packing contents common to BA-T series
Packing contents for BA-6TE / BA-6DTE
Packing contents for BA-225TE / BA-225DTE / BA-125DTE

11
Assembly and installation
The BA-6TE is used here for the example of assembly. Other models can be assembled in the same
way.
Step 1. Pull out the breeze break
locking handles.
Step 2. Place the breeze break unit on
the weighing unit.
Step 3. Push in the breeze break locking
handles to secure the units to each
other.
Step 4. Assemble the weighing pan.
For BA-6TE / BA-6DTE, assemble
the five parts of the weighing pan in
the correct position by referring to
the cross-sectional view.
For BA-225TE / BA-225DTE /
BA-125DTE, assemble the four
parts of the weighing pan in the
correct position by referring to the
cross-sectional view.
Breeze break unit
Step 1.
Step 3.
Step 2.
Weighing unit
For BA-225TE / BA-225DTE / BA-125DTE
For BA-6TE / BA-6DTE
Pan A
Pan support A Pan B
Breeze break ring A Breeze break ring B
Dust plate A Dust plate B
Breeze break
bottom plate
Cross-sectional view for
BA-6TE / BA-6DTE
Cross-sectional view for
BA-225TE / BA-225DTE / BA-125DTE

12
Step 5. Assemble the glass breeze break.
Assemble the BA-6TE / BA-6DTE
glass breeze break in the weighing
chamber.
Align the side panes with the notch
of the base stand.
Example of the small breeze break
with the right side open.
Step 6. Insert the breeze break top door
from the handle side.
Step 7. Assemble the breeze break
doors on the left and right sides.
7a Insert the breeze break doors on
the left and right sides.
7b Secure the breeze break doors
with the latches.
Step 8. Assemble the breeze break front
glass.
8a Insert the breeze break front
glass.
8b Secure the breeze break front
glass with the latches.
Top pane
Side panes (3 pieces)
Step 5.
Base stand
Side pane
Notch
Base stand
Step 7a.
Step 6.
Step 8b.
Step 7b.
Step 7a.
Step 8a
Step 8b.
Step 7b.

13
Step 9. Using the included cable A and cable B, connect the "weighing unit" and "breeze break unit" (with
the cable A) and the "display unit" and "weighing unit" (with the cable B) respectively, paying
attention to the direction of the arrow on each cable (on the connector).
Caution: Make sure to unplug the AC adapter before connecting.
Step 10. If the display unit is placed in front of the weighing unit, cable B can be stowed in the left or right
groove of the weighing unit. Loosen the leveling foot when stowing the cable in the groove.
Caution: When stowing the cable, do not tilt the weighing unit.
Step 11. Connect the breeze break unit and ionizer with the included cable C.
Caution: The ionizer operates when the AC adapter is connected to the balance.
Step 12. Connect the included AC adapter to the balance.
Step 10.Groove for cable
Loosen the leveling foot when
stowing the cable in the groove
Leveling foot Groove for cable
Bottom of the weighing unit
Display unit
Breeze break unit
Ionizer
Step 9
Step 12
Cable A
Cable B
AC adapter
Weighing unit
Grounding terminal
Serial number
Step 11
Cable C

14
BA-6TE / BA-6DTE
BA-225TE / BA-225DTE / BA-125DTE
Installation considerations, preparation and precautions
Prepare the following installation conditions in order to bring out the full performance of the balance.
Note that the installation environment needs to be taken into consideration for the highly sensitive BA-
6TE / BA-6DTE.
Install the balance in an environment where the temperature and relative humidity are not excessive.
The best operating temperature is about 20°C ±2°C at about 45% to 60% relative humidity.
Install the balance where it is free of dust.
The weighing table should be solid. (An anti-vibration table or stone table is ideal)
We recommend using an anti-vibration table (AD-1671) for BA-6TE.
It is advisable to install the display unit in a location other than on the anti-vibration table so that errors
due to tilt that occurs when operating the switches of the balance on the anti-vibration table can be
avoided.
Place the balance on a horizontal table, and make sure that it is not tilted.
Install the balance in a stable location, avoiding vibration and shock. Corners of rooms on the first floor
are best, as they are less prone to vibration.
Install the balance where it is not affected by heaters or air conditioners. Avoid breezes and drafts in the
room.
You can reduce the influence of breezes and drafts by using an AD-1672/AD-1672A (large size) or AD-
1676 (medium size) tabletop breeze break.
Install the balance where it is not exposed to direct sunlight.
Install the balance away from equipment which produces magnetic fields.
Level the weighing unit with the leveling feet and bubble spirit level. Refer to “2.3.1. How to adjust the
level of the balance”.

15
Bubble
spirit level
The balance is
level (Correct
weighing)
The balance is
tilted (Inaccurate
weighing)
Up
Leveling foot
Down
Down
Leveling foot
Up
Red circle
Bubble
Be sure to warm up the balance before use for at least an hour, or at least four hours for BA-6TE/BA-
6DTE, with the AC adapter connected to the power supply.
Adjust the sensitivity of the balance before using it for the first time or after having moved it to another
location so that accurate weighing can be performed. For how to adjust sensitivity, refer to
“10. [Sensitivity Adjustment] Screen”.
Do not install the balance where flammable or corrosive gas is present.
How to adjust the level of the balance
Level the balance by adjusting the leveling feet
so that the bubble of the bubble spirit level is
centered in the red circle.
Leveling foot
Bubble spirit level
When the bubble is off to the left.
Turn the leveling foot on the front right in the
clockwise direction.
When the bubble is off to the right.
Turn the leveling foot on the front left in the
clockwise direction.
When the bubble is off to the
backward position.
Turn both leveling feet on
the front in the clockwise
direction at the same time.
When the bubble is off to the
forward position.
Turn both leveling feet on the front in the
counterclockwise direction at the same time.

16
Precautions during use for more accurate weighing
For precise and accurate weighing, please take notice of the
following.
Weighing errors may occur due to the influence of static
electricity. Note that if the ambient humidity drops below 45% RH
insulators such as plastics are liable to have static electricity.
Ground the balance and perform the following as needed.
A DC type ionizer that produces no currents of air is available for
the BA-T series balances. Refer to “22. Ionizer (AX-ION-25)” and
remove static electricity from the charged sample directly.
Increase the relative humidity at the place where the
balance is installed.
Weigh the sample in a conductive metal container or the
like.
Wipe off charged materials such as plastic with a damp
cloth to suppress static electricity.
Influence of magnetism may cause weighing errors.
When measuring magnetic materials (iron, etc.), keep the
sample away from the balance main body by means such as
underhook weighing.
Place the sample in the center of the weighing pan.
Weighing errors may occur if there is a difference between the
ambient temperature and temperature of the sample (and the
container). For example, when the room temperature is 20 °C,
convection occurs around a Petri dish or watch glass that is
40 °C and the balance displays a value lighter than the actual
weight. Before weighing the sample and the container, try to
acclimatize them to the ambient temperature.
Perform the weighing operation carefully and quickly. If
measurement takes a long time, error-inducing factors will
increase due to changes in temperature and humidity in the
weighing chamber, air turbulence or reaction/humidity absorption
by the sample.
Do not leave the sample on the weighing pan for an extended
period of time. If a sample is left on the weighing pan for a long
time, the measured value will change due to deviation from the
zero point caused by environmental changes or due to creep
phenomenon.
Metal case
Charged sample
Ground Ionizer
Magnetic material Underhook
weighing
Room
temperature 20 °C
Convection
40 °C
No impact shock
Good Bad
When placing a sample on the weighing pan, do not drop it, or do not place a sample greater than the
balance weighing capacity. In addition, place the sample in the center of the pan.
With the highly sensitive BA-6TE, the weighing value may fluctuate after the stabilization indicator lights
up. It is advisable to set a certain reading time (10 seconds, etc.) after the stabilization indicator lights
up and read the value.

17
For weighing where impurities will be a problem, it is advisable to prepare samples outside the
weighing chamber in order to prevent the substance from scattering inside the weighing chamber.
When pressing the touch screen or keys, do not press with a sharp object such as a pen. Instead,
press the center of the key with your finger.
Be sure to press the RE-ZERO button before weighing in order to eliminate measurement
errors.
Measurement results include error from air buoyancy. The buoyancy of air varies depending on the
sample volume, atmospheric pressure, temperature, and humidity. Correct the buoyancy for the most
precise measurement.
Prevent foreign substances such as powder, liquid, and metal pieces from entering the balance.
Precautions after use
Avoid mechanical shock to the balance.
Do not disassemble the balance.
Do not use any strong organic solvents to clean the balance. Clean the balance with a lint free cloth that
is moistened with a mild detergent.
Prevent foreign substances such as powder, liquid and metal pieces from entering the balance.
Caution on the power supply
Be sure to warm up the balance before use for at least an hour, or at least four hours for BA-6TE/BA-
6DTE, with the AC adapter connected to the power supply.
The balance is constantly provided with power as long as the AC adapter is connected.
The balance is not adversely affected in this state.
It is advisable to always keep the balance in this state for accurate weighing.
Be sure to keep the BA-6TE/BA-6DTE always in a state where power is being supplied.

18
Connection terminals of the display unit
5RS-232C connector
1Wired LAN 6USB mini B connector
2External input switch 1
7 USB Type A connector dedicated for flash drives
3External input switch 2 8Terminal for Cable B
4AC adapter input 9Ground terminal
Name
Description
1
Wired LAN
For configuration details, refer to “13.15.Wired LAN”.
2External input switch 1
A contact input switch.
For configuration details, refer to “13.19. External input switch”.
For usage details, refer to “15.4.External input terminal (external input
switch)”.
3External input switch 2
4AC adapter input For precautions for use, refer to “2. Part Names, Installation and
Precautions”.
5RS-232C connector
For configuration details, refer to “13.13. RS-232C interface”.
For specifications, refer to “15.1. RS-232C specifications”.
For usage details, refer to “16. Connection with Peripheral Devices”.
6USB mini B connector
For configuration details, refer to “13.14. USB interface”.
For specifications, refer to “15.2. USB specifications”.
For usage details, refer to “16. Connection with Peripheral Devices” and
“18. Connecting to a Personal Computer”.
7USB Type A connector
Dedicated for USB flash drives.
For usage details, refer to “15.3. USB flash drive (USB host)”.
8Terminal for Cable B Connected to the weighing unit. Refer to “2.2. Assembly and
installation”.
9Ground terminal For related items, refer to “2.4. Precautions during use for more
accurate weighing”.

19
3. Screens and Operations (Keys and Buttons)
Standby screen
When you touch the ON:OFF key or the touch screen in the standby screen, the weighing screen
is displayed.
When you select a key other than the ON:OFF key, the corresponding screen is displayed.
ON:OFF key
HOME screen (weighing screen)
The HOME screen is displayed when you touch the HOME key .
1Quick performance check button 10 Sensitivity adjustment/calibration test button
2Application button 11 Communication device setting button
3Left IR sensor function change button 12 Right IR sensor function change button
4Stabilization indicator 13 Capacity, readability
5Left IR sensor 14 Right IR sensor
6Weighing display 15 Date/time display
16 Warning display
17 Unit display
7ON:OFF key 18 LOG-IN key
8HOME key 19 MENU key
9PRINT button 20 RE-ZERO button

20
1P-TEST button
The P-TEST button performs a quick performance test.
The quick performance test automatically checks the performance of the
balance by loading and unloading the internal weight. Refer to “6. Quick
Performance Check”.
2APP button
The APP button displays the application setting screen and saves the
settings related to weighing.
Main items: Application selection (Normal weighing, Counting mode,
Percent mode, Minimum weight alert function, Unit of measure, Minimum
display digit, Statistical calculation function, Decimal separator, Warning
display, etc.) Refer to “5. Application”.
3Left IR sensor function
change button
Displays the options for changing the IR sensor operation settings.
You can configure the settings individually for the left and right IR
sensors. At the factory setting, they open/close the breeze break door.
4Stabilization indicator Displayed when the weighing value of the balance is stable.
5Left IR sensor
A touchless sensor. When you bring your hand closer, it reacts and the
assigned breeze break door opens/closes (at the factory setting). Refer
to “4. IR Sensors and Auto Doors”.
6Weighing display Displays the weighing value of the balance.
7ON:OFF key
Turns the screen display on and off. The ON:OFF key is active during
any operation.
When the screen display is turned off, the standby screen appears.
When the screen display is turned on, the weighing screen appears.
8HOME key Displays the weighing screen. The HOME key is active during any
operation.
9PRINT button Outputs data to the device connected to the balance.
Refer to “16. Connection with Peripheral Devices” and “19. Data Output”.
10 CAL button
The CAL button displays the [Sensitivity adjustment/calibration test]
screen. Select and execute the sensitivity adjustment/calibration test with
the internal or external weight. Refer to “10. [Sensitivity Adjustment]
Screen”.
11
Communication device
setting button
Displays the [7. Communication device] screen.
Configure the settings of or remove the connected communication
device.
12
Right IR sensor function
change button
Displays the options for changing the IR sensor operation settings.
You can configure the settings individually for the left and right IR
sensors. At the factory setting, they open/close the breeze break door.
13 Capacity, readability Displays the capacity and readability of the balance.
14 Right IR sensor
A touchless sensor. When you bring your hand closer, it reacts and the
assigned breeze break door opens/closes (at the factory setting). Refer
to “4. IR Sensors and Auto Doors”.
15 Date/time display Displays the current date and time.
16 Warning display Refer to the next page.
17 Unit display Displays the set unit.
