AAXA Technologies P4X User manual

aaxa
TECHNOLOGIES
User Guide
P4X Pico Projector

Caution!
WARNING: Please use this product as instructed. Misuse may cause
injury or death.
DO NOT use while driving
DO NOT expose to water or wet
surfaces. Electric shock may occur
DO NOT expose the LED to your
eyes or the eyes of others
DO NOT block or restrict airow
from ventilation holes as this may
cause the projector to overheat
Keep the projector, battery, or
charger away from any heat sources
Caution for Battery Use
• Do not pierce or puncture the battery
with sharp objects
• Do not heat the product or expose it to
high temperature.
• Do not wet it or place it in any liquid
Caution for Earphone (Earplug) Use
• Prolonged use at high volume may
impair your hearing.
• High volume during walking or driving
may cause distractions and result in
injury or death

Table of Contents
Chapter 1: P4X at a glance
Main Unit Front/Back
Remote & Keypad
Accessories
Chapter 2: Getting Started
Powering On / OFF
Focus Adjustment / Throw
Distance
External Inputs /Input Sources
Connecting to a Computer VGA
Connecting to a Computer HDMI
Connecting to Composite Video
Connecting to HDMI Video
Connecting to Speaker or Head-
phones
2
2
3
4
5
5
6
7
8
10
12
14
16
17
19
21
21
22
24
26
28
29
30
30
32
Connecting a Micro SD Card
Connecting to a USB Host
Chapter 3: Menu Screens
Main menu
Video Player Menu
Photo Viewer Menu
Music Player Menu
Ebook Viwer Menu
Setup Menu
Chapter 4: Technical Details
Troubleshooting
Specications
1

P4X at a Glance
2
Power Button
VGA Input
Power Input
A/V Input
Projection Lens
Headphone
Conrm Selection
Directional Pad
Mini USB Port
Mini HDMI
Chapter 1
Main Unit Front/Back/Side
Charge Indicator
Micro SD Card Port
Back Button
Focus Adjustment
Reset Hole
Power On/Off
Main Menu Navigation

Remote & Keypad
3
NOTICE: Pressing power on the remote will only put the projector in STANDBY
mode. Please press the power button on the projector if you want to turn it off.
Power On/Off
Main Menu Navigation
Select Source
Media Player Menu
Navigation
Power Exit/BackDirection Pad
Both the keypad and remote can be used to navigate through the menus. The Main Menu
Navigation on the remote functions exactly the same as the directional pad on the P4X unit.

Accessories
4
*Under various circumstances, the actual accessories may be different from
those shown in the pictures above.
Tripod Remote
Power Adapter
VGA Cable
A/V Cable
Mini USB to
USB Adapter

Getting Started
1. Connect the power cord to the P4X.
2. Connect the wall plug into the wall power source.
3. Press POWER button and hold for 2-3 seconds to switch on or switch off
the power
• The LED turns red while charging.
• The LED turns green when charging is nished.
• 4 hours of charge time is required to reach a full charge.
5
Powering ON the projector
Chapter 2
Powering OFF the projector
1. Press and hold the power button for 3 seconds.
2. The optical engine should power off and the fan should stop spinning.
• Note. Pressing the power button on the remote puts the projector in
standby mode. It will NOT turn off the projector.
Note: The P4X Projector battery does not charge when it is in operation.

Focus Adjusment / Throw Distance
Focus Adjustment
1. Spin the focus wheel left of right until the image becomes
clear.
2. The recommended focus distance for this projector is 12” to
innity.
6
DIAGONAL SCREEN SIZE
16:9 Aspect Ratio
Throw Distance Chart
Distance inch (“)
12
18
24
30
36
74
84
96
Diagonal Inch (“)
6.3
9.5
12.6
15.8
18.9
38.9
44.2
50.5
Throw Ratio 1.9
*minimum throw distance: 10 inches

External Inputs/Outputs
7
Laptop Desktop USB Stick
Headphone/speaker
Micro SD Card
Composite Cable HDMI Cable

Connecting to a Computer via VGA
Connect the large end of the
8
VGA Cord
to your computer’s
VGA Adapter
Connect the small end of the
VGA Cord
to your P4X’s
VGA Adapter
Step 1:
Step 2:
Step 3:
In the Main Menu
Select “VGA” icon

Connecting to a Computer Cont.
Step 4:
Enabling VGA or HDMI output on your Computer – To enable VGA or HDMI output on your com-
puter most computers require “turning on” the video output feature. Each computer is different.
Please consult your owner’s manual for instructions to enable VGA or HDMI output. Below are
standard instructions for a Windows XP computer – not all systems are the same.
Press function & “F5” to instruct
the computer to enable multiple
displays.
You can also press Windows+P to
toggle through display settings.
*NOTE: different operating sys-
tems may differ
Step 5:
1. Right click on computer desk-
top and select “Properties”
2. Display Properties window
will pop up
3. Click on the “Settings” Tab
4. If a secondary monitor is
grayed out, click on it and
check “Extend my Windows
Desktop onto this monitor”
5. If the image is blurry or the
text is not legible, adjust
the screen resolution. We
recommend 800x600 or
1024x768.
Step 6:
9

Connecting to a Computer via HDMI
Connect the large end of the
10
HDMI Cord
to your computer’s
HDMI Adapter
Connect the small end of the
HDMI Cord
to your P4X’s
HDMI Adapter
Step 1:
Step 2:
Step 3:
Select “HDMI” icon
In the Main Menu

Connecting to a Computer Cont.
Step 4:
Enabling VGA or HDMI output on your Computer – To enable VGA or HDMI output on your com-
puter most computers require “turning on” the video output feature. Each computer is different.
Please consult your owner’s manual for instructions to enable VGA or HDMI output. Below are
standard instructions for a Windows XP computer – not all systems are the same.
Press function & “F5” to instruct
the computer to enable multiple
displays.
You can also press Windows+P to
toggle through display settings.
*NOTE: different operating sys-
tems may differ
Step 5:
1. Right click on computer desk-
top and select “Properties”
2. Display Properties window
will pop up
3. Click on the “Settings” Tab
4. If a secondary monitor is
grayed out, click on it and
check “Extend my Windows
Desktop onto this monitor”
5. If the image is blurry or the
text is not legible, adjust
the screen resolution. We
recommend 800x600 or
1024x768.
Step 6:
11

Connecting to Composite Video
Connect one end of the
Composite Cord
to your P4X’s
A/V Adapter
Connect opposite end of to your devices
Step 1:
Step 2:
Composite Cord Composite Cord
12

Connecting to Composite Video Cont.
Connectivity with multimedia devices
The P4X can connect to many media devices including: iPod, iPhone, iPad, VHS
players, DVD players, smart phones, cameras, video game consoles and other
peripherals with ease.
*Apps on smart phones require video out capabilities to be displayed with the P4X. 13
Step 3:
Select “AV” icon
In the Main Menu
Turn on your multimedia device.
Step 4:
Composite Cord

Connecting to HDMI Video
Connect one end of the
Mini-HDMI
to your P4X’s
HDMI Adapter
Connect opposite end of to your devices
Step 1:
Step 2:
HDMI Adapter
14

Connecting to HDMI Video Cont.
Connectivity with multimedia devices
The P4X can connect to many media devices including: iPod, iPhone, iPad, VHS
players, DVD players, smart phones, cameras, video game consoles and other
peripherals with ease.
*Apps on smart phones require video out capabilities to be displayed with the P4X. 15
Step 3:
Select “HDMI” icon
In the Main Menu
Turn on your multimedia device.
Step 4:
HDMI Adapter

Connecting Speakers/Headphones
Connect your speaker
or headphones
16
3.5 mm cord
to your P4X’s
Speaker Adapter
Step 1:
Step 2:
Caution for Earphone (Earplug) Use
• Prolonged use at high volume may impair
your hearing.
Ensure the power and volume on your
speaker or headphones is turned on
Step 3:
Place headphones/earphones in/over ears

Micro SD Card
17
How to insert your Micro SD Card
• Slide in your SD card into the SD card
slot on the front of the P4X. (as shown
in picture)
• Gently slide the SD card until it *clicks*
into place.
*Review the Specication
section of this manual to read
about the supported le
formats.
How to access your Micro SD Card
• Once your SD card has been inserted,
you can navigate to the SD card icon in
the main menu.
• After selecting SD card mode you
should now be able to access the data
on the SD device through the onboard
media player.
Speaker Adapter

Micro SD Card Cont.
18
Media Player menu
• In the Media Player selection you can
choose from Videos, Pictures, Audio,
and Ebooks.
• Select the appropriate menu for the type
of le you wish to view.
Return: Brings you
back to the main
menu
Up Folder: Brings
you back to the
previous folder
File Menu System
• The P4X will show all folders and les
you have on your SD Card.
• Use the directional buttons to navigate
to different folders or les.
Videos Audio Pictures Ebooks
P4X
