Built-in loudspeaker
8222 EB-500
Busch-AudioWorld®
=== Ende der Liste für Textmarke Co ver ===

Operating Instructions
Busch-AudioWorld®
Operating Instructions | 1473-1-8321
— 2 —
Pos: 4 /#Neustruktur#/ Online-Dokumentatio n (+KNX)/Inhaltsver zeichnis (--> Für alle Dokume nte <--)/Inhaltsverzeic hnis @ 19\mod_1320649044386_ 15.docx @ 109653 @ @ 1
1Safety.......................................................................................................................................................................3
2Intended use............................................................................................................................................................3
2.1 Environment............................................................................................................................................3
3User Manual.............................................................................................................................................................3
4Technical data..........................................................................................................................................................4
5Setup and function...................................................................................................................................................5
5.1 Features of function and equipment........................................................................................................5
5.2 Possible combinations ............................................................................................................................5
5.3 Device diagram.......................................................................................................................................6
6Installation and electrical connection .......................................................................................................................7
6.1 Requirements for the electrician .............................................................................................................7
6.2 General installation instructions ..............................................................................................................8
6.3 Mounting methods ..................................................................................................................................8
6.4 Area of application ..................................................................................................................................8
6.4.1 Mounting of the built-in loudspeaker .......................................................................................................9
6.5 Installation ring......................................................................................................................................10
6.6 Disassembly of the built-in loudspeaker................................................................................................10
6.7 Electrical connection.............................................................................................................................11
6.7.1 Installation / connection possibilities .....................................................................................................11
=== Ende der Liste für Textmarke TOC ===

Operating Instructions
Busch-AudioWorld®
Safety
Operating Instructions | 1473-1-8321
— 3 —
Pos: 6 /#Neustruktur#/ Online-Dokumentatio n (+KNX)/Überschr iften (--> Für alle Doku mente <--)/1. Ebene/S - T/Sic herheit @ 18\mod_130261279179 0_15.docx @ 103357 @ 1 @ 1
1 Safety
Pos: 7 /#Neustruktur#/ Online-Dokumentatio n (+KNX)/Sicher heitshinweise und Hinweise ( --> Für alle Dokumente <--)/W arnhinweise/Sicherheit - 230 V @ 18\mod_13026068 16750_15.doc x @ 103308 @ @ 1
Warning
Electric voltage!
Risk of death and fire due to electrical voltage of 230 V.
– Work on the 230V supply system may only be performed by authorised electricians!
– Disconnect the mains power supply prior to installation and/or disassembly!
Pos: 8 /#Neustruktur#/ Online-Dokumentatio n (+KNX)/Überschr iften (--> Für alle Doku mente <--)/1. Ebene/A - F/Besti mmungsgemäßer Gebrauch @ 18\mod_1 302763321316_15.doc x@ 1034 83 @ 1 @ 1
2 Intended use
Pos: 9 /#Neustruktur#/ Online-Dokumentation (+K NX)/Bestimmungsgemäßer Gebrauc h/AudioVideo/Besti mmungsgemaesser Gebr auch -Audio allgemein @ 23\mod _1335942854884_15.doc x @ 208893 @ @ 1
The device is part of the Busch-AudioWorld® system and is to be used exclusively with the components that are
supplied and licensed as described in the "Structure and Function" chapter. The device must only be installed in
dry indoor rooms.
Pos: 10.1 /#Neustrukt ur#/Online-Dokumen tation (+KNX)/Übersc hriften (--> Für alle Dokumente <--) /2. Ebene/U - Z/ Umwel t @ 25\mod_13406919 35719_15.docx @ 220064 @ 2 @ 1
2.1 Environment
Pos: 10.2 /#Neustrukt ur#/Online-Dokumen tation (+KNX)/Sic herheitshinweise und Hin weise (--> Für alle Dokumente <--)/ Hinweise - Umwelt/Hinweis - Umwel t - Hinweis Elektrogerä te@ 18\mod_13027 63973434_15.doc x@ 103500 @ 2 @ 1
Consider the protection of the environment!
Used electric and electronic devices must not be disposed of with domestic waste.
– The device contains valuable raw materials which can be recycled. Therefore, dispose of the
device at the appropriate collecting depot.
Pos: 10.3 /#Neustrukt ur#/Online-Dokumen tation (+KNX)/Sic herheitshinweise und Hin weise (--> Für alle Dokumente <--)/ Hinweise - Umwelt/Hinweis - Umwel t - Entsorgung Elektrogerä te @ 20\mod_1325760695972 _15.docx @ 136583 @ @1
All packaging materials and devices bear the markings and test seals for proper disposal. Always dispose of the
packaging material and electric devices and their components via the authorized collecting depots and disposal
companies.
The products meet the legal requirements, in particular the laws governing electronic and electrical devices and
the REACH ordinance.
(EU Directive 2002/96/EC WEEE and 2002/95/EC RoHS)
(EU REACH ordinance and law for the implementation of the ordinance (EC) No.1907/2006)
Pos: 11 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Überschr iften (--> Für alle Dokumente <--)/ 1. Ebene/A - F/Anwenderhandbuc h @ 19\mod_1309347227593_ 15.docx @ 107473 @ 11 @ 1
3 User Manual
Pos: 12 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Sonstige/V erweis auf Systemhandb uch/Anwenderhandb uch - Variabel @ 23\mod_133475098 9818_15.docx @ 208623 @ 1 @ 1
Detailed information for planning Busch-AudioWorld®systems is contained in the user manual. Download at
www.Busch-Jaeger.com.
Pos: 13 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Steuermodu le - Online -Dokumentation (--> Für alle Dokument e <--)/++++++++++++Seitenumbruch++++++++++++@ 9\mod_12688 98668093_0.doc x@ 52149 @ @ 1

Operating Instructions
Busch-AudioWorld®
Technical data
Operating Instructions | 1473-1-8321
— 4 —
Pos: 14 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Überschr iften (--> Für alle Dokumente <--)/ 1. Ebene/S - T/Technische Date n @ 11\mod_1279185386320_15. docx @ 83019 @ 1 @ 1
4 Technical data
Pos: 15 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Technisc he Daten/AudioVideo/ Technische Daten - 8222 @ 22\mod_1332501 976590_15.docx @ 206101 @ 1 @ 1
General
Basket diameter 5“ (13 cm)
Impedance 16 ohm
Sound pressure 92 dB
Radiation angle 100°
Protection type IP 20
Device-specific
Nominal power 8222 EB-500 6 W RMS
8224 EB-500 7 W RMS
Frequency response 8222 EB-500 50 … 11000 Hz
8224 EB-500 84 … 16500 Hz
Temperature range 8222 EB-500 0 … 35 °C
8224 EB-500 -25 … 55 °C
Pos: 16 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Steuermodu le - Online -Dokumentation (--> Für alle Dokument e <--)/++++++++++++Seitenumbruch++++++++++++@ 9\mod_12688 98668093_0.doc x@ 52149 @ @ 1

Operating Instructions
Busch-AudioWorld®
Setup and function
Operating Instructions | 1473-1-8321
— 5 —
Pos: 17 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Überschr iften (--> Für alle Dokumente <--)/ 1. Ebene/A - F/Aufbau und Funktion @ 11\mod_1279185 435352_15.doc x@ 83027 @ 21 @ 1
5 Setup and function
Pos: 18 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Überschr iften (--> Für alle Dokumente <--)/ 2. Ebene/A - F/Funktions- und Auss tattungsmerkmale @ 23\mod_1 336557630140_15.d ocx @ 209136 @ 22 @ 1
5.1 Features of function and equipment
Pos: 19 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Aufbau und Funk tion/Audio/Funk tionen - 8222 @ 33\mod_1360757467712_1 5.docx @ 277450 @ 2 @ 1
The built-in loudspeaker 8222 EB-500 is used to play back the audio signals of Busch-Jaeger amplifier inserts,
radios, MDRC amplifiers, and microphone consoles.
Pos: 20 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Überschr iften (--> Für alle Dokumente <--)/ 2. Ebene/G - L/Kombina tionsmöglichkeiten @ 19\mod_1320312 769153_15.doc x@ 109520 @ 22 @ 1
5.2 Possible combinations
Pos: 21 /#Neustruktur #/Online-Dokumentation (+K NX)/Kombinationsmögli chkeiten/Audio/Ko mbinationsmöglic hkeiten - 8222 @ 23\mod_1334565314 657_15.docx @ 208238 @ 2 @ 1
8222 EB-500 8222 EB-500
8205
X
8227
X
8208
X
8228
X
8211 U
X
8229/1
X
8214 U
X
8229/2
X
8215 U
X
