ABD ABD-LS10 User manual

Safety instruction
This device has left our premises in absolutely perfect condition. In
order to maintain this condition and to ensure a safe operation, it is
absolutely necessary for the user to follow the safety instructions and
warning notes written in this manual.
User Manual
10W GOBO mini moving head
Professional Entertainment Equipment
CAUTION!
Be careful with your operations. With a dangerous voltage you can suffer a
dangerous electric shock when touching the wires！
Electric shock when touching the wires!

Features
Voltage: AC110-240V 50/60Hz
Power: 110W
Light source: 1*10W LUMIAN WHITE LED
DMX Channel: 7/12 CH
4 operation modes: Automatic running, DMX, Sound Active, Master/Slave
Weight: 3.9 kg
Control
LED Display Control Instruction
Display
Function
ADDR
A001-A512
CHND
7CH/12CH
SLND
NAST(Master)，SL 1 (Slave 1)，SL 2 (Slave 2)
SHND
SOUD, AUTO
SOUN
ON/OFF
SENS
0-100(set up the sensitivity of sound control)
BLND
NO/YES Ready model
LED
ON/OFF(background light )
DISP
Set up positive and negative direction
PAN
NO/YES (Set up positive and negative moving for Motor X)
TILT
NO/YES (Set up positive and negative moving for Motor Y)
MANU
PAN, TILT, COLOR,GOBO,DIMM, STROB
TEST
Self-checking function
HOUR
Work time
VER
Program NO.V101
RSET
Self-checking reset
The motor minute adjustment operate
First push the “MEUN” button into the meun,next push the ;ENTER button
At lease 3 seconds,now the display will be show “pan”.you can use
“UP”or “DOWN” to choose the ‘Tilt” to adjustment,please make sure the
number between -127—127 to adjustment motor.at last you can push the
Enter button to keeping you site number.

Channel
Effect
Value
Control
10 Channe
Funtion
0--69
No effect
70--89
X/Y motor moving can close the lighting
90--109
X/Y motor moving t can not close the lighting
110--129
color plate moving can close the lighting
130--149
Color plate moving can not close the lighting
150--169
Gobo plate moving can close the lighting
170--189
Gobo plate moving can close the lighting
190--199
No effect
200--209
Light reset
210---249
No effect
250--255
Stochastic sound effect
11 Channel
Dimmer
0--255
Dimmer from dark to bright
12 Channel
strobe
0--7
Lighting Close
8--15
Lighting open
16--131
Strobe from slow to fast
132--139
Lighting open
140--181
Lighting Close fast -open slow
182--189
Lighting open
190--231
Lighting Slow close-fast open
232--239
Lighting open
240--247
Stochastic sound effect
DMX channel display.7/12CH Can choose
7 Channel:
Channel
Effect
Value
Control
1 Channel
x motor
0--255
Adjustment for Motor X moving (0-----630°)
2 Channel
Y motor
0--255
Adjustment for Motor Y moving (0-----182°)
3 Channel
Dimmer
0--255
Lighting dimmer from dark to bright
4 Channel
Strobe
0--7
Lighting Close
8--15
Lighting open
16--131
Strobe from slow to fast
132--139
Lighting open
140--181
Lighting Close fast -open slow
182--189
Lighting open
190--231
Lighting Slow close-fast open
232--239
Lighting open
240--247
Stochastic sound effect
248--255
Lighting Open
5 Channel
Color
0--31
Light open
32--63
Color 1
64--95
Color 2
96--127
Color 3
128--159
Color 4
160--191
Color 5
192--223
Color 6
224--255
Color 7
6 Channel
Gobo
0--15
Light open
16--31
Gobo 1
32--47
Gobo 2
48--63
Gobo 3
64--79
Gobo 4
80--95
Gobo 5
96--111
Gobo 6
112--127
Gobo 7

128--146
Gobo 7 Shake
147--164
Gobo 6 Shake
165--182
Gobo 5 Shake
183--201
Gobo 4 Shake
202-219
Gobo 3 Shake
220-237
Gobo 2 Shake
238-255
Gobo 1 Shake
7Channel
-
Funtion
0--69
No effect
70--89
X/Y motor moving can close the lighting
90--109
X/Y motor moving t can not close the lighting
110--129
color plate moving can close the lighting
130--149
Color plate moving can not close the lighting
150--169
Gobo plate moving can close the lighting
170--189
Gobo plate moving can close the lighting
190--199
No effect
200--209
Light reset
210--249
No effect
250--255
Stochastic sound effect
12 Channel:
Channel
Effect
Value
Control
1 Channel
x motor
0--255
(0-----630°)
2 Channel
x motor
0--255
Adjustment for Motor X moving
3Channel
Y motor
0--255
(0-----182°)
4 Channel
Y motor
0--255
Adjustment for Motor Y moving
5Channel
X/Y motor
0--255
X/Y motor moving speed from fast to slow
6 Channel
X/Ymotor
effect
0--15
No effect
16--35
Effect 1
36--55
Effect 2
56--75
Effect 3
76--95
Effect 4
96--115
Effect 5
116--15
Effect 6
136--15
Effect 7
156-175
Effect 8
176--195
Effect 9
196--215
Effect 10
216--235
Effect 11
236--255
Effect 12
7 Channel
X/Y motor
0--255
X/Y motor moving speed from fast to slow
8Channel
Color plate
0--31
open
32--63
Color 1
64--95
Color 2
96--127
Color 3
128--159
Color 4
160--191
Color 5
192--223
Color 6
224--255
Color 7
9Channel
Gobo plate
0--15
open
16--31
Gobo 1
32--47
Gobo 2
48--63
Gobo 3
64--79
Gobo 4
80--95
Gobo 5
96--111
Gobo 6
112--127
Gobo7
128--146
Gobo 7 Shake
147--164
Gobo 6 Shake
165--182
Gobo 5 Shake
183--201
Gobo 4 Shake
202--219
Gobo 3 Shake
220--237
Gobo 2 Shake
238--255
Gobo 1 Shake
