ABL METERS Operator's manual

EN
Article No.: 0301676_EN_a
Installation and Configuration Guide
METERS
METERL

| Contact
ii
Contact
ABL GmbH
Albert-Büttner-Straße 11
91207 Lauf an der Pegnitz
Germany
[phone]
[phone]
[email protected]
www.ablmobility.de
Customer Service
[phone]
[email protected]
www.ablmobility.de/en/service/support/
Revision: 0301676_EN_a, Version: 23.05.22
T
h
i
n
k
b
e
f
o
r
e
y
o
u
p
r
i
n
t

Contents | iii
Contents
Contact ii
Additional technical information 4
Intended use 4
Information in this document 4
Important information 5
General 5
Safety instructions 5
User information 6
Dimensional drawings and dimensions 7
Energy meter EM210 7
Cable type current transformers up to 300A 7
Cable type current transformers up to 600A 7
Introduction to the METERS and METERL load
management systems 8
Identification 8
Items supplied 8
Compatible products 8
The energy meter at a glance 10
The display at a glance 11
The cable type current transformer at a glance 11
Mechanical and electrical installation 13
Selecting the connection mode 14
Installation guidelines 14
Installation of the energy meter and the
cable type current transformers 15
Data connection with the controller of a
group installation 18
Setting up the energy meter 19
Setup via the ABL User Interface application 23
Appendix 29
Technical specifications 29
IP rating 30
Data cable recommendations 30
Allocation schematic from spring terminal
to Easy2Install interface 31
Trademarks 31
Copyright and disclaimer 32
Disposal advice 32

| Additional technical information
4
Additional technical information
Additional technical information is required to install the controller/extender charging stations and the control unit
from ABL, as well as to set up a group installation. It is contained in separate documents.
In addition, the technical data for the METERS|METERL load management systems and the compatible products are
collated in product-specific data sheets. You can download these documents from the ABL website using the follow-
ing link:
https://www.ablmobility.de/en/service/downloads.php
NOTE
Displaying the additional information on a computer, tablet or smartphone
Additional technical information is made available in the Portable Document Format (PDF).
To display PDF files, you need the free Adobe Acrobat Reader or comparable software.
You can find further information about our product range, as well as about separately available accessory compo-
nents on our website at www.ablmobility.de. Please visit:
https://www.ablmobility.de
Intended use
METERS|METERL is an external load management system for a single controller charging station or a group in-
stallation controlled via an eMH2 or eMH3 controller wallbox, an eMC2 or eMC3 controller charging pole or via the
1V0001/1V0002 external control unit. METERS|METERL allows dynamically controlled, efficient distribution of the
available charging current to up to 16 charge points by measuring the energy flow via the three cable type current
transformers supplied and feeding the values back to the controller. METERS measures currents up to 300A, METERL
up to 600A, ensuring that electric vehicles can charge at the maximum available charging current.
Information in this document
This document describes how to install the three cable type current transformers and the energy meter as well as
how to subsequently configure them on the energy meter and via the ABL User Interface software. It is recommended
that all working steps described in this document are carried out by qualified specialist electrical contractors only.
User Specialist electrical
contractor
Installation and Configuration Guide
(this document)
Additional technical information
Data sheets
Installation instructions for charging stations
(eMH2/eMH3/eMC2/eMC3) and control unit
(1V0001/1V0002)

Important information | 5
Important information
General
This manual describes all working steps required to install and/or operate the product it concerns.
Certain sections of this manual are specially formatted for quick and easy reference.
Descriptions listing equally valid options are indicated by bullet points.
1 Descriptions listing operating steps are numbered in chronological order.
DANGER!
Indicates life-threatening electrical voltages
Sections marked with this symbol indicate electrical voltages that present a danger of loss of life or grievous
bodily injury.
Actions marked with this symbol must not be carried out under any circumstances.
WARNING!
Indicates important actions and further hazards
Sections marked with this symbol indicate further hazards that may result in damage to the product or to other
connected components.
Actions marked with this symbol must be carried out with special care.
NOTE
Indicates important information for operation or installation
Sections marked with this symbol indicate further important information and features necessary for successful
operation.
Actions marked with this symbol should be carried out as required.
Passages marked with this symbol contain valuable additional information.
Safety instructions
The safety notices serve to ensure the proper and safe installation, as well as subsequent safe operation of the
device.
DANGER!
Violation of the safety information
Disregard of or actions contrary to the safety information and instructions contained in this manual may lead to
electric shock, fire, severe injury and/or death.
Please pay attention to the following points:
Please read this manual carefully.
Heed all warnings and follow all instructions.
Only use components intended and sold for the product by ABL.
Do not install this device in close vicinity to running water, water jets or areas subject to flooding.
The product must not be installed in explosive atmosphere areas (EX areas).
Mechanical installation should be carried out by qualified specialist personnel.

| Important information
6
Electrical installation and testing must be carried out with reference to local rules by a qualified specialist
electrical contractor, who, on the basis of their specialist training and experience, as well as their knowledge of
the relevant standards, is able to assess and carry out the working steps described in this manual and recognise
potential hazards.
In case of installation faults, or malfunctions that can be traced back to faulty installation, always contact the
contractor who carried out the installation first.
The product must not be covered with other objects or materials.
No liquids or receptacles containing liquids must be placed on the product.
Do not under any circumstances make alterations to the product. Any disregard of this instruction represents a
safety risk, fundamentally breaches the guarantee provisions and may void the warranty with immediate effect.
Malfunctions affecting the safety of persons, connected electric devices or the device itself must be resolved by a
qualified specialist electrical contractor.
Should one of the following malfunctions occur, please contact the specialist electrical contractor who has carried
out the installation of your charging station and accessories:
yThe product housing has been damaged mechanically, or the housing cover has been removed or can no longer
be closed.
ySufficient protection against splashing water and/or foreign objects is no longer provided.
yThe product does not function properly or has been otherwise damaged.
WARNING!
Observation of further safety instructions
Please always observe all further safety instructions in the manuals for the optionally available charging stations
and control units.
User information
Ensure that rated voltage and rated current of the supply cable at the installation location comply with the param-
eters of your local electricity grid and that the rated output of the product and the connected charging stations is
not exceeded during operation.
Local safety regulations regarding the operation of electrical devices for the country in which you operate the
product and the connected charging stations always apply.
No user-maintainable parts are located inside the device.
Only have the product repaired by a qualified specialist electrical company.
NOTE
Changes to functions and design features
Please note that all technical details, specifications and design characteristics of the product may be changed
without prior notice.

Dimensional drawings and dimensions | 7
Dimensional drawings and dimensions
The following dimensional drawings show the dimensions of all components of the METERS and METERL load man-
agement systems.
Energy meter EM210
Energy meter (included in METERS and METERL), front and side view
(all dimensions in mm)
Cable type current transformers up to 300A
Current transformer for attachment to a single power line (included in METERS), front and side view.
(all dimensions in mm)
Cable type current transformers up to 600A
Current transformer for attachment to a single power line (included in METERL), front and side view.
(all dimensions in mm)
*

| Introduction to the METERS and METERL load management systems
8
Introduction to the METERS and METERL load management systems
Thank you very much for choosing a METERS/METERL dynamic load management system from ABL!
The METERS|METERL load management systems combine an external energy meter with three cable type cur-
rent transformers for measuring the three-phase total current (charging stations and domestic consumption) or
section current (domestic consumption only). The energy meter communicates with the controller charging station
(eMH2|eMH3|eMC2|eMC3) or control unit (1V0001|1V0002) in a group or individual installation and allows dy-
namic and efficient distribution of the available electricity to all charge points based on this measurement. METERS
can measure currents up to 300A, while METERL is designed for larger installations with up to 600A.
Further information on technical data is available in the appendix from page29.
Identification
There is a label on the packaging to identify the type of load management
system. Check the label to make sure that the model you have is the system
suitable for your application.
METERL 1 Stück
Externes Lastmanagement(L)
ABL GmbH
Albert-Büttner-Straße 11
D-91207 Lauf
www.abl.de
Items supplied
METERS|METERL are supplied with the following components:
Energy meter, 1pc Cable type current transformer
(300 or 600 A), 3pcs
Download note (multilingual), 1pc
Zubehör
Download-Hinweis, Stand 10/2019
Produktnummer: 0301431_b
Die ausführlichen Installations- und
Bedienungsanleitungen stehen als
Download unter www.ablmobility.de
bereit.
The detailed installation and operating
manuals are available for download at
www.ablmobility.de.
DE
EN
ABL_Downloadhinweis-Anleitung_01.indd 1 21.10.19 17:03
NOTE
Checking the components included
Check immediately after unpacking whether all components are included: should any components be missing,
please contact the dealer from whom you purchased the load management system.
Compatible products
The METERS and METERL load management systems are offered as separate accessories for the following ABL
products.
Wallbox eMH2 Controller (2W2240| 2W2241)
Charging station from ABL with one charge point for use as a controller in a
group installation, either with a permanently integrated charging cable or with
a charging socket
h = 437mm, w = 328mm, d = 170mm
(Housing without protrusions)

Compatible products | 9
Wallbox eMH3 Controller (3W2260| 3W2261| 3W2263| 3W2264|
3W2283| 3W2284)
(Calibration law compliant) charging station from ABL with one or two charge
points for use as a controller in a group installation, either with a permanently
integrated charging cable or with a charging socket
h = 492mm, w = 394mm, d = 192mm
(Housing without protrusions)
Charging pole eMC2 Controller (2P4445)
Charging pole from ABL for use as a controller in a group installation with two
charging sockets
h = 1,460mm, w = 440mm, d = 200mm
(Housing without protrusions)
Charging pole eMC3 Controller (3P4412|3P4435)
Calibration law compliant charging pole from ABL with two charge points,
either with permanently integrated spiral charging cables or with charging
sockets
h = 1,661mm, w = 590mm, d = 220mm
(Housing without protrusions)
External control unit (1V0001|1V0002)
Controller unit from ABL without its own charge points, either mounted in a
sturdy wall-mounted housing or as a top-hat rail module for installation in a
control cabinet
h = 320mm, w = 205mm, d = 146mm
(1V0001 housing)
You can find further information on ABL charging stations and accessories at
www.ablmobility.de.

| Introduction to the METERS and METERL load management systems
10
The energy meter at a glance
The energy meter is designed as a top-hat rail model for installation in a control cabinet or distribution box. For
details on installation, see section “Installation of the energy meter and the cable type current transformers” on
page15.
The energy meter itself offers the following connections, buttons and displays:
ATerminal blocks
Screw terminals 1to 6are used to connect the supplied cable type current transformers, screw terminals
7to !are used to supply power to the meter.
BToggle key
This key is used to navigate within the system/parameter menus and to increase/decrease the currently se-
lected parameter value. To switch between the modes (Up/Increase or Down/Decrease) press the enter
keyD.
You can find further information on key operation in section “Setting up the energy meter” on page19.
CRed LED
This LED flashes red proportionally to the measured energy.
DEnter key
This button is used to open a parameter menu, to switch between the modes of the toggle key Band to con-
firm/exit a parameter menu.
You can find further information on key operation in section “Setting up the energy meter” on page19.
EOutput and RS485 terminals
The static outputs "to %are not used with METERS|METERL. The screw terminals &to )serve as
RS485 interfaces for communication with the controller charging station/control unit. The screw terminal ~is
required for terminating the RS485 bus.
FDisplay
The LCD display shows all system/parameter menus and measured values.
You can find further information on the display in the next section and in section “Setting up the energy meter”
on page19.
GGreen LED
The LED lights up green when the energy meter is properly supplied with voltage. When the LED flashes
green, the energy meter is also communicating with the charging station/control unit via the serial RS485
interface.
B
C
A
E
G
D
F

The display at a glance | 11
The display at a glance
In measuring mode, the energy meter display shows the current measured values as well as system and warning
information.
H
I
HMeasuring range
Depending on the selected connection mode, the measured current values for
one or all three phases are displayed here.
ISignal ranges
Symbols relating to operation are shown here:
– Symbol for wrong phase sequence
– Symbol for system values
– Symbol for phase-to-phase voltage L1-2, L2-3, L3-1
During setup of the energy meter, the display shows the system and parameter menus and provides visual feedback
for the items in the menus.
J
LK
JMenu item
The currently selected menu in the energy meter software is displayed here.
Use the toggle key Bto switch between the menus, and the enter key Dto
activate editing in this menu.
KValue range
The current value for the selected menu is shown here.
LIncrease/decrease symbol
– The selected menu/current value is increased.
– The selected menu/current value is decreased.
You can switch between and by pressing the enter key D.
The cable type current transformer at a glance
METERS|METERL are supplied with three cable type current transformers each, which are designed for measuring
currents up to 300A (METERS) or 600A (METERL), but are otherwise identical in construction.
Each cable type current transformer is built as follows:
1Clamp-on core
Thanks to the clamp-on mechanism, the current transformer can be mounted on already laid cables with a ca-
ble diameter of up to 24mm (METERS) or 36mm (METERL) and locked via the latch.
1
2
4
3

| Introduction to the METERS and METERL load management systems
12
2Energy flow arrows
These arrows on the housing specify the energy flow and thus the installation direction.
3Connection cables
The two cables are used to connect to the screw terminals 1to 6of the energy meter. The red wire K
should be screwed into an odd-numbered terminal on the meter (1, 3and 5), while the black wire Lis as-
signed to the even-numbered terminals (2, 4and 6).
NOTE
Assignment according to connection mode
Please note that depending on the selected connection mode (see “Selecting the connection mode” on
page14), not all cable type current transformers may be required: In connection mode 1P, only one cur-
rent transformer is connected to terminals 1and 2of the energy meter; terminals 3to 6are not used
in this mode.
4Cable tie tab
To secure the current transformer, it can be protected against slipping etc. via an optional cable tie and this
tab on the cable.

Mechanical and electrical installation | 13
Mechanical and electrical installation
The METERS and METERL load management systems can be used flexibly for the total current measurement of a sys-
tem or for section current measurement within a system.
Total current measurement
For total current measurement, the cable type current transformers are installed on the individual phases of the house
supply line and the energy meter on the house connection.
This measurement takes into account both the building load and the consumption of the charging stations.
WARNING!
Approval requirement by the grid operator
Please note that the position of the energy meter for total current measurement may have to be approved by your
local grid operator.
Contact your local grid operator for further information!
Section current measurement
In contrast, with section current measurement, the cable type current transformers are installed behind the tap for
the charging stations, and the energy meter can be installed nearby in a distributor in the building.
This measurement only takes into account the building load, and not the consumption of the charging stations.
WARNING!
Correct specification of the measurement situation
In order to correctly identify the meter values, the meter position must be specified correctly when setting up the
load management system via the ABL User Interface software (see page26).
non-variable load
variable load
BuildingSub-distributionMains connection
variable load
non-variable load
BuildingSub-distributionMains connection

| Mechanical and electrical installation
14
Selecting the connection mode
To ensure correct current measurement, a connection mode must also be selected and entered in the SYS menu
when setting up the energy meter (see “Setting up the energy meter” on page19).
The following connection modes are supported by METERS|METERL.
Connection mode Description
Name of the option in the SYS menu: 3P.n
3 phases, 4 wires
Connection of three current transformers via terminals 1, 2,3,
4, 5and 6 on the energy meter
Power supply via screw terminals 7, 8, 9and ! on the ener-
gy meter, fuse protection F=315mA
Name of the option in the SYS menu: 3P
3 phases, 3 wires
Connection of three current transformers on the energy meter via
terminals 1, 2, 3, 4, 5and 6 on the energy meter
Power supply via screw terminals 8, 9and ! on the energy
meter, fuse protection F=315mA
L
Name of the option in the SYS menu: 1P
Single phase, 2 wires
Connection of one current transformer via terminals 1and 2on
the energy meter
Power supply via screw terminals 9and ! on the energy meter,
fuse protection F=315mA
WARNING!
Support for non-compatible connection modes
The energy meter supplied with METERS|METERL supports other connection types in principle, although these
are not required in practical use as a load management system. Therefore, always make sure that the energy me-
ter is set to the appropriate connection option in the SYS menu.
“Setting up the energy meter” on page20
Installation guidelines
Depending on the type of current measurement (total or section current) and the connection mode selected, the fol-
lowing guidelines should be observed when installing the current transformers and the energy meter:
Be sure to observe all local regulations for electrical installations, fire prevention and accident prevention.
All guidelines for the installation of low-voltage systems in accordance with IEC 60364-1 and IEC 60364-5-52
apply.
Depending on the type of current measurement, the cable type current transformers are attached to the individual
wires of the house supply line (total current measurement) or the sub-distribution unit for the building (section
current measurement).
The cables for connecting the current transformers determine the maximum distance to the energy meter and thus
the position in the distribution box.
Fused taps (F = 315mA) must also be provided in the distribution box to supply power to the energy meter.

Installation of the energy meter and the cable type current transformers | 15
Installation of the energy meter and the cable type current transformers
The energy meter and the current transformers must be installed in a distribution box. Depending on the position of
the current measurement, you will need to use the distributor for the house supply line (total current measurement) or
the sub-distributor for the building (section current measurement).
The energy meter is a standard top-hat rail module that can be placed on any DIN rail. The distance between the en-
ergy meter and the current transformers is determined by the length of the connection cables that are permanently
connected to the current transformers.
You will need the following tools and components for the installation:
Phillips screwdriver Optional: Cable tie
(1 per transformer)
DANGER!
Dangerous electrical currents
Always observe the 5 safety rules:
1Cut power source
2Secure all cut-off devices
3Verify absence of voltage
4Ground and short-circuit
5Cover or bar access to adjacent components under voltage
WARNING!
Electrical installation guidelines
The entire installation must be carried out by a qualified specialist electrical contractor!
The electrical supply cable must be disconnected from the power supply during the entire installation.
The connection to the electricity grid must only be established after the installation has been completed in
order to subsequently set up the energy meter (see “Setting up the energy meter” on page19).
Proceed as follows:
1 Switch off the power supply to the house before
the distributor.

| Mechanical and electrical installation
16
2 Install the energy meter on a DIN rail in the
distributor.
yThe distance to the current transformers is
determined by the connection cables of the
transformers.
3 Locate the cables for current measurement in the
distributor.
4 Connect the energy meter to the mains via specially
fused cable taps (F = 315mA).
yAssign the screw terminals 7, 8, 9and
!on the energy meter in accordance with the
connection mode selected ( page14).
F
5 Connect the fixed connection cables of the current
transformers to the energy meter.
yAssign the connection terminals 1, 2, 3,
4,5 and 6on the energy meter in accord-
ance with the connection mode (see table next
page).
K L K L K L

Installation of the energy meter and the cable type current transformers | 17
Connection mode 3P.n 3P 1P
Cable type current transformer 1 K1K1K1
L 2L 2L 2
Cable type current transformer 2 K 3K 3–
L 4L 4–
Cable type current transformer 3 K 5K 5–
L 6L 6–
6 Open a cable type current transformer, place it
around one of the cables and close the catch, which
must audibly click into place.
yThe energy flow direction and thus the installa-
tion direction is specified by the arrows shown
on the housing:
Mains Consumer
yRepeat the process for all cables that are rele-
vant for the selected connection mode.
K
5A
L
WARNING!
Adhering to the electrical energy flow direction
Always observe the energy flow direction and thus the installation direction for the power cable indicated by
the arrow on the current transformer. Otherwise, the energy meter connected to the current transformer cannot
measure reliable current values.
WARNING!
Pre-condition for the installation of a cable type current transformer
Please note that a cable type current transformer may only be installed on a power line if its connection cables
are either connected together (short-circuited) or connected to the connection terminals of the energy meter.
Otherwise, the cable type current transformer may be damaged!
This completes the installation of the cable type current transformer and the energy meter.

| Mechanical and electrical installation
18
Data connection with the controller of a group installation
The energy meter must communicate with the controller charging station/control unit via its RS485 interface for the
system’s load management. The Modbus interface depends on the year of manufacture – on older ABL charging sta-
tions it is designed with spring terminals and on newer models it is equipped with RJ45 sockets. METERS|METERL
are compatible with both systems.
Cat 5e or Cat 6 data cables with a cross-section of at least 0.14mm² are recommended for the wiring. The internal
twisting must be maintained until connection to the respective terminal.
NOTE
Communication via the free interface
In the controller of a group installation, one of the two Modbus interfaces remains unassigned, while the other is
used for communication with the extender charging stations.
Wire the free interface in the controller to the RS485 interface of the energy meter.
Connect the interfaces as follows:
Charging station with spring terminals
Connect the contacts as follows:
Meter contact Charging station spring
terminal
&METER – B
(METER – A
)METER – M
To terminate the RS485 bus, a wire jumper must also be
inserted between the contacts (and ~on the energy
meter!
A M B
CONTROL
A M B
METER
Charging station with RJ45 interface
Connect the contacts as follows:
Meter
contact
Bus
assignment
Wire colour
T-568B
PIN
assignment
RJ45
&BBrown 8
(ABrown-white 7
)M Blue 4
M Blue-white 5
To terminate the RS485 bus, a wire jumper must also be
inserted between the contacts (and ~on the energy
meter!
1 2 3 4 5 6 7 8
MODBUS EN1 MODBUS
METER
M
E
T
E
R
C
N
T
R
L
CONTROL
CONTROL
METER

Setting up the energy meter | 19
NOTE
Adhering to the colour scheme when wiring via the E2I interface
In contrast to the wiring for charging stations with spring terminals, you must always adhere to the colour as-
signment shown above for charging stations with an E2I interface!
Use a network cable that corresponds to the T-568B pinout.
If you use a cable with a different pinout, you must always ensure that the assignment between the pins
of the RJ45 plug (4, 5, 7 and 8) and the contacts of the energy meter (15, 16 and 17) – as shown above, but
regardless of the wire colour specified – is adhered to.
WARNING!
Termination of the bus connection
In addition to the wire jumper used for termination between the contacts (and ~on the energy meter, the
RS485 bus must also be terminated at the last extender charging station. You can find further information on this
in the corresponding installation manual for the charging station.
Setting up the energy meter
To ensure accurate measurement, the energy meter must be set up via its system and parameter menus. This can be
done using the toggle and enter keys as well as the visual feedback on the display:
Toggle key Navigation within the menus
Select next/previous option
Edit a parameter value
Increase/decrease value
Enter key – press briefly Navigation within the menus
Open selected menu for editing
Edit a parameter value
Switch toggle key between “ Increase value” and
“ Decrease value”
Enter key – hold for approx. 3 seconds
3 Sek.
Edit a parameter value
Open configuration mode
Confirm input/finish editing the menu item
The following guidelines apply when setting up the energy meter as described below:
The energy meter must be supplied with power.
The energy meter must be connected to the current transformers.
The value must be entered within 120 seconds, otherwise the energy meter will switch back to measuring mode.

| Mechanical and electrical installation
20
Proceed as follows to set up the energy meter:
1 Press and hold the enter key for about 3 seconds.
yThe password entry menu will be displayed.
≥3S
NOTE
Enter the factory default password
A password is required in order to set up the energy meter. This is set as 0by default.
2 If a value other than 0is displayed, press the toggle
key until 0appears on the display and hold the
enter key for about 3 seconds to confirm.
yThe CnGPASS menu will be displayed.
≥
3S
WARNING!
Changing the factory default password
If required, you can set a new password between 000 and 999 via the CnGPASS menu to protect the energy me-
ter against unauthorised access.
To change the password, briefly press the enter key , select a new password with the toggle key , then
confirm the new password by holding the enter key for about 3 seconds.
If you change the password, you must keep it in a safe place for reference.
NOTE
Skipping unnecessary menus
To give a better overview, only menus relevant to the setup are described below. Unnecessary menus (such as
APPliC., SEnSOr, etc.) are not mentioned and can be skipped when selecting menu options.
3 Use the toggle key to select the SYS menu and
briefly press the enter key .
≤1S
≤
1S
